ISD-SMG318LT-F
Temperature Measurement Walk-Through Detector
Description
ISD-SMG318LT-F walk-through metal detector, adopting the thermal imagery technology, realizes non- contact temperature measurement. Face detection function of the camera makes an accurate positioning of the measurement. The detector also supports metal detection.
It is suitable for safety inspection of dangerous goods and is widely used in public occasions and important places, etc. It is recommended to be used indoor with a windless environment.
Functions
Non-contact temperature measurement: face temperature
measurement with accurately personnel matching. Temperature accuracy:±0.5 , detection distance: 0.5 to 1.5 m, target height: 1.45 m to 1.85 m
Temperature filtering: adjustable temperature threshold. An
over-threshold temperature will trigger the audible strobe light
Counting display: displays the walk-through people number,
metal alarm times, real time temperature, number of people in abnormal temperature
Metal detection: metal likes a clip Multi-Area alarm: Indicates the metal position on the body.
Max. 18 areas
Modularized component: easy transmission and installation
Thermal Imaging Features
Smart Functions:
Temperature exception detection Linkage for audible alarm Linkage of white strobe light alarm
Thermal Imaging Functions:
Uncooled sensor, resolution: 160 x 120 Supports AGC4.0, DDE, and 3DNR Supports dual-light fusion image Supports visible light and thermal imaging frame over lay
System Functions:
Dual-channel, single IP Dual-streaming PoE power supply IP66 protective level Operation temperature: 5 to 40, 95% RH
Interfaces:
10M/100M self-adapting network interface Micro SD/Micro SDHC/Micro SDXC card (128G/256G) slot 1-ch alarm input/output
15 pseudo colors: white, black , red, etc.
Visible Light Functions:
4 MP, 1/2.7 “ CMOS, Max. resolution: 2688×1520@25fps Supports low bit rate, low latency and ROI Independent settings for day or night condition
1-ch audio input/output 1-ch 12 VDC power input
Security: Security verification, such as HTTPS, supports license
creating
Three level of users, IP address filtering, user and password
authentication
Metal Detection Features
Detection accuracy: metal in the size like a clip (or 1/2 clip)
is detectable on the middle of the detector. Goods like Belt buckle can be excluded. Copper, aluminum, and zinc (over 150 g) , controlled knife, and gun are detectable
Anti-interference: multiple detector can work abreast at the
same time
Multi-area alarm: Indicates the metal position on the body.
Max. 18 areas
Frequency settings: 100 frequencies can be set, and
different ring tone for different frequency
Sensitivity Settings: 255 level of sensitivity can be set People counting: display the number of walk-through
people and people in alarm
Positioning LED: LEDs on the sides of the detector for
indicating the position of the prohibited goods.
LCD screen Storing sensitivity parameters for different scenes for
shortcut settings.
Material: PVC shell
Specifications
Thermal Imaging
Sensor
Vanadium oxide uncooled sensor
Max. Resolution
160× 120
Pixel Interval
17μm
Response Waveband
8 to 14μm
NETD
40mk(@25°C,F#=1.0)
Lens (Focal Length)
3mm
MRAD
9.44
Field of View
50°×37.2°
Min. Focusing Distance
0.5m
Aperture
1.1
Pseudo Color
15, white heat, black heat,fusion1, rainbow, fusion2, iron oxide red1, iron oxide red2, puce, color1, color2, ice & fire, rain, red heat, green heat, and dark blue
Visible Light
Sensor
4 MP 1/2.7" Progressive Scan CMOS
Resolution
2688×1520@25fps
Min. illuminance
0.0018Lux @(F1.6,AGC ON) ,0 Lux with IR
Shutter speed
1/3s to 1/100,000s
Focal length
4mm
Field angle
84.0°×44.8°
Day/Night switch
ICR
WDR range
120dB
IR distance
Max. 15 m
Image frame
Thermal imaging and visible light
Thermal imaging integrated with visible light frame
Picture in picture
Supports visible light and thermal imaging frame over lay
Smart information overlay
Supports (only temperature measurement rule and temperature are supported)
Smart function
Linkage alarm
Linkage of strobe light and audible alarm
Temperature measurement
Temperature exception detection
Expert mode: 10 pints, 10 frame, 21 rules on each line
Body temperature measurement
AI face detection, multi-target detection
Measurement range
30 to 45
Temperature Alarm
Alarm triggered when the temperature is over the threshold
Measurement accuracy
No black body:±0.5 With black body: ±0.3
Compression
Video compression
H.265/H.264/MJPEG
H265:
Main Profile
H264:
Baseline Profile / Main Profile / High Profile
Video bit rate
32 Kbps to 8Mbps
Video standard
G.711/G.722.1/G.726/MP2L2/PCM
Audio bit rate
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2)
Storage
SD card storage
Micro SD/Micro SDHC/Micro SDXC card (128GB or 256GB)
NVR storage
96/86/77/76I series NVR Supports live view/playback, rule display, alarm report, and remote configuration
Network
Main stream
Visible light: 50Hz: 25fps (1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) Visible light: 60Hz: 30fps (1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) Thermal Imaging: 25fps (160 × 120 (output320 × 240))
Sub stream
Visible light: 50Hz: 25fps (704 × 576), 25fps (640 × 480) Visible light: 60Hz: 30fps (704 × 480), 30fps (640 × 480) Thermal Imaging: 25fps (160 × 120 (output 320 × 240))
Network protocol
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NT P,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour
Interface protocol
ONVIF(PROFILE S,PROFILE G),ISAPI,SDK,Ehome,GB28181
Max. live view channel number
20
User
Three level: administrator, operator, general user
Safety strategy
User and password authentication, HTTPS encryption, IEEE 802.1x control, IP address filtering
Interface
Alarm input
1, 0 to 5 V alarm input
Alarm output
1, NO relay output, alarm type configurable
Audio input
1, 3.5mm Mic in/Line in interface. Line input: 2-2.4V[p-p]
Audio output
1, 600Ω
Reset button
1
Network interface
1,RJ45 10/100M self-adaption
RS-485 interface
1
SD card slot
1 Client
iVMS-4200/HIK-CONNCET
Browser
IE7+, Chrome18+, Firefox5.0+, Safari5.02+
General
Power supply
110~240VAC50-60Hz
Consumption
<72W
Operation temperature and humidity
Speed dome: 5 to 40, 95% RH Walk-through detector: -20 to 85, 99%, RH
Protective level
Dome camera: IP66 Walk-through detector: IP53
Dimension Detector dimension(without dome
camera)
2200 x 850 x 480mm (H x W x D) Dome camera dimension
138.3 mm × 138.3 mm × 123.1 mm(H x W x D)
Package dimension
2270 x 700 x230mm(H x W x D)
Weight
Net weight
About 50Kg
Available Model
ISD-SMG318LT-F
