HIKVISION DS-9008HFI-ST, DS-9108HFI-ST, DS-9016HFI-ST, DS-8104HFI-ST, DS-8108HFI-ST Quick Operation Manual
...
DS-9100/9000/8100/8000HFI-ST Series DVR
Quick Operation Guide
Version 2.1.0
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to DS-9104HFI-ST, DS-9108HFI-ST, DS-9116HFI-ST; DS-9004HFI-ST,
DS-9008HFI-ST, DS-9016HFI-ST; DS-8104HFI-ST, DS-8108HFI-ST, DS-8116HFI-ST; DS-8004HFI-ST,
DS-8008HFI-ST, and DS-8016HFI-ST series DVR.
Verify Contents
Verify that the package contents are correct by checking the items against the packing list.
Note: Please contact your dealer for damaged or missing items.
DVR Pre-Installation
The DS-9100/9000/8100/8000HFI-ST Series DVR is highly advanced surveillance equipment that should be
installed with care. Please take into consideration the following precautionary steps before installation of the DVR.
1. Keep all liquids away from the DVR.
2. Install the DVR in a well-ventilated and dust-free area.
3. Ensure environmental conditions meet factory specifications.
4. Install a manufacturer recommended HDD.
DVR Installation
During the installation of the DVR:
1. Use brackets for rack mounting.
2. Ensure there is ample room for audio and video cables.
3. When installing cables, ensure that the bend radius of the cables are no less than five times than its diameter.
4. Connect both the alarm and RS-485 cable.
5. Allow at least 2cm (~0.75-inch) of space between racks mounted devices.
6. Ensure the DVR is grounded.
7. Environmental temperature should be within the range of -10 ºC ~ 55 ºC , 14ºF ~ 131ºF.
8. Environmental humidity should be within the range of 10% ~ 90%.
Hard Disk Installation
Before you start:
Before installing a hard disk drive (HDD), please make sure the power is disconnected from the DVR. A factory
recommended HDD should be used for this installation.
Up to 8 SATA hard disks can be installed on your DVR.
Tools Required: Screwdriver.
Steps (for DS-9100/9000HFI-ST):
1. Fasten the hard disk mounting handle to the hard disk with screws.
2. Insert the key and turn in clockwise direction to open the panel lock.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
2
3. Press the buttons on the panel of two sides and open the front panel.
4. Insert the hard disk along the slot until it is placed into position.
5. Repeat the above steps to install other hard disks onto the DVR. After having finished
the installation of all hard disks, replace the front panel and lock it with the key
again.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
3
Steps (for DS-8100/8000HFI-ST):
1. Remove the cover from the DVR by unfastening the screws on the back and side.
2. Install the HDD in the HDD rack using the provided screws. Fasten the screws on the
button to fix the HDD.
3. Connect one end of the data cable to the motherboard of DVR and the other end to the
HDD.
4. Connect the power cable to the HDD.
5. Re-install the cover of the DVR and fasten screws.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
4
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
5
Front Panel
DS-9100/9000HFI-ST
DS-8100/8000HFI-ST
No.
Name
Function Description
1
ALARM
Alarm indicator turns red when a sensor alarm is detected.
READY
Ready indicator is normally blue, indicating that the DVR is functioning
properly.
STATUS
Status indicator turns blue when DVR is controlled by an IR remote.
Indicator turns red when controlled by a keyboard and purple when IR
remote and keyboard is used at the same time.
HDD
HDD indicator blinks red when data is being read from or written to HDD.
MODEM
Reserved for future usage.
TX/RX
TX/RX indictor blinks blue when network connection is functioning
properly.
GUARD
Guard indicator turns blue when the device is in armed status; at this
time, an alarm is enabled when an event is detected.
The indicator turns off when the device is unarmed. The arm/disarm
status can be changed by pressing and holding on the ESC button for
more than 3 seconds in live view mode.
2
IR Receiver
Receiver for IR remote
3
Front Panel Lock
(for
DS-9100/9000HFI-ST)
You can lock or unlock the panel by the key.
4
DVD-ROM
Slot for DVD-ROM. (Optional)
5
Alphanumeric Buttons
Switch to the corresponding channel in Live view or PTZ Control
mode.
Input numbers and characters in Edit mode.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
6
Switch between different channels in All-day Playback mode.
The light of the button is blue when the corresponding channel is
recording; it is red when the channel is in network transmission status;
it is pink when the channel is recording and transmitting.
6
USB Interfaces
Universal Serial Bus (USB) ports for additional devices such as USB mouse
and USB Hard Disk Drive (HDD).
7
ESC
Back to the previous menu.
Press for Arming/disarming the DVR in Live View mode.
REC/SHOT
Enter the Manual Record setting menu.
In PTZ control settings, press the button and then you can call a PTZ
preset by pressing Numeric button.
It is also used to turn audio on/off in the Playback menu.
PLAY/AUTO
The button is used to enter the All-day Playback mode.
It is also used to auto scan in the PTZ Control menu.
ZOOM+
Zoom in the PTZ camera in the PTZ Control setting.
A/FOCUS+
Adjust focus in the PTZ Control menu.
It is also used to switch between input methods (upper and lowercase
alphabet, symbols and numeric input).
EDIT/IRIS+
Edit text fields. When editing text fields, it will also function as a
Backspace button to delete the character in front of the cursor.
On checkbox fields, pressing the button will tick the checkbox.
In PTZ Control mode, the button adjusts the iris of the camera.
In Playback mode, it can be used to generate video clips for backup.
MAIN/SPOT/ZOOM-
Switch between main and spot output.
In PTZ Control mode, it can be used to zoom out the image.
F1/ LIGHT
Select all items on the list when used in a list field.
In PTZ Control mode, it will turn on/off PTZ light (if applicable).
F2/ AUX
Cycle through tab pages.
MENU/WIPER
Press the button will help you return to the Main menu (after successful
login).
Press and hold the button for 5 seconds will turn off audible key beep.
In PTZ Control mode, the MENU/WIPER button will start wiper (if
applicable).
PREV/FOCUS-
Switch between single screen and multi-screen mode.
In PTZ Control mode, it is used to adjust the focus in conjunction with
the A/FOCUS+ button.
PTZ/IRIS-
Enter the PTZ Control mode.
In the PTZ Control mode, it is used to adjust the iris of the PTZ camera.
8
DIRECTION
The DIRECTION buttons are used to navigate between different fields
and items in menus.
In the Playback mode, the Up and Down button is used to speed up and
slow down recorded video. The Left and Right button will select the
next and previous day of recordings.
In Live View mode, these buttons can be used to cycle through
channels.
In PTZ control mode, it can control the movement of the PTZ camera.
ENTER
The ENTER button is used to confirm selection in any of the menu
modes.
It can also be used to tick checkbox fields.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
7
In Playback mode, it can be used to play or pause the video.
In single-frame Playback mode, pressing the button will advance the
video by a single frame.
In Auto-switch mode, it can be used to stop /start auto switch.
9
JOG SHUTTLE Control
Move the active selection in a menu. It will move the selection up and
down.
In Live View mode, it can be used to cycle through different channels.
In the Playback mode: For DS-9100/9000HFI-ST, the ring is used to
jump 30s forward/backward in video files. For DS-8100/8000HFI-ST,
the outer ring is used to set the speed to Single frame and the inner ring
is used to jump 30s forward/backward in video files.
In PTZ control mode, it can control the movement of the PTZ camera.
10
POWER ON/OFF
Power on/off switch.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
8
Rear Panel
DS-9100/9000HFI-ST
DS-8100/8000HFI-ST
No.
Item
Description
1
VIDEO IN
BNC connector for analog video input.
2
LOOP OUT
(for DS-9100/9000HFI-ST)
BNC connector for video loop output.
3
VIDEO SPOT OUT
BNC connector for video output.
4
VIDEO OUT
BNC connector for video output.
1. When both HDMI and VGA are connected, it is used for live view
only;
2. When either HDMI or VGA is connected, it is used as the spot video
output for live view, playback, recording and PTZ controls;
3. When neither HDMI nor VGA is connected, it is used as the main
video output for live view and menu operations.
5
AUDIO OUT
RCA (for DS-9100/9000HFI-ST) / BNC (for DS-8100/8000) connector
for audio output. This connector is synchronized with VIDEO OUT.
6
LINE IN
RCA (for DS-9100/9000HFI-ST) / BNC (for DS-8100/8000) connector
for audio input.
7
AUDIO IN
RCA (for DS-9100/9000HFI-ST) / BNC (for DS-8100/8000) connector
for audio input.
8
AUDIO IN
(for DS-9100/9000HFI-ST)
DB26 connector for audio input.
9
RS-232 Interface
Connector for RS-232 devices.
10
VGA
DB9 connector for VGA output. Display local video output and menu.
11
HDMI
HDMI video output connector.
12
eSATA (Optional)
Connects external SATA HDD, CD/DVD-RM.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
9
13
LAN Interface
Connector for LAN (Local Area Network).
14
Termination Switch
RS-485 termination switch.
Up position is not terminated.
Down position is terminated with 120Ω resistance.
15
RS-485 Interface
Connector for RS-485 devices. T+ and T- pin connects to R+ and Rpin of PTZ receiver respectively.
Controller Port
D+, D- pin connects to Ta, Tb pin of controller. For cascading devices,
the first DVR’s D+, D- pin should be connected with the D+, D- pin of
the next DVR.
ALARM IN
Connector for alarm input.
ALARM OUT
Connector for alarm output.
16
GROUND
Ground (needs to be connected when DVR starts up).
17
AC 100V ~ 240V
AC 100V ~ 240V power supply.
18
POWER
Switch for turning on/off the device.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
10
Peripheral Connections
Connecting to Alarm Input / Output Device
The alarm input/output interface of the DVR is shown as below:
The alarm input is an open/closed relay. If the input is not an open/closed relay, follow the connection diagram
below:
To connect to an AC/DC load, use the following diagram:
For DC load, JP4 can be used within the limit of 12V/1A safely. If the interface is connected to an AC load, JP4
should be left open. Use an external relay for safety (as shown in the figure above).
There are 4 jumpers (JP4, JP5, JP6, and JP7) on the motherboard, each corresponding with one alarm output. By
default, jumpers are connected. To connect an AC load, jumpers should be removed.
Note: An external relay is needed to prevent electric shock when connecting to an AC load.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
11
Alarm Connection
To connect alarm devices to the DVR:
1. Disconnect pluggable block from the ALARM IN /ALARM OUT terminal block.
2. Unfasten stop screws from the pluggable block, insert signal cables into slots and fasten stop screws. Ensure
signal cables are in tight.
3. Connect pluggable block back into terminal block.
RS-485 Connection
To connect RS-485 devices to the DVR:
1. Disconnect pluggable block from the RS-485 terminal block.
2. Unfasten stop screws from the pluggable block, insert signal cables into slots and fasten stop screws. Ensure
signal cables are in tight.
3. Connect pluggable block back into terminal block.
Note: Make sure the pan/tilt receiver unit is connected to the T+ and T- of the DVR.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
12
Controller Connection
To connect a controller to the DVR:
1. Disconnect pluggable block from the KB terminal block.
2. Unfasten stop screws from the KB D+, D- pluggable block, insert signal cables into slots and fasten stop
screws. Ensure signal cables are in tight.
3. Connect Ta on controller to D+ on terminal block and Tb on controller to D- on terminal block. Fasten stop
screws.
4. Connect pluggable block back into terminal block.
Note: Make sure both the controller and DVR are grounded.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
13
Specifications
Table 1 Specifications for DS-9100HFI-ST
Model
DS-9104HFI-ST
DS-9108HFI-ST
DS-9116HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch,
BNC
(1.0 Vp-p, 75 Ω)
PAL /NTSC
self-adaptive
8-ch,
BNC
(1.0 Vp-p, 75 Ω)
PAL /NTSC
self-adaptive
16-ch,
BNC
(1.0 Vp-p,75 Ω)
PAL /NTSC
self-adaptive
Audio
compression
OggVorbis
Audio input
4-ch,
RCA (2.0 Vp-p, 1 kΩ)
8-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1 kΩ)
Audio 5-8: DB26
connector
16-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1 kΩ)
Audio 5-16: DB26
connector
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI output
1-ch, resolution:
1920 × 1080P /60 Hz, 1920 × 1080P /50 Hz, 1600 × 1200 /60 Hz,
1280 × 1024 /60 Hz, 1280 × 720 /60 Hz, 1024 × 768 /60 Hz
VGA output
1-ch, resolution:
1920 × 1080P /60 Hz ,1600 × 1200 /60 Hz,1280 × 1024 /60 Hz,
1280 × 720 /60 Hz, 1024 × 768 /60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot
output
1-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
Video loop out
4-ch,
BNC (1.0 Vp-p, 75 Ω)
8-ch,
BNC (1.0 Vp-p, 75 Ω)
16-ch,
BNC (1.0 Vp-p, 75 Ω)
Encoding
resolution
4CIF /2CIF /CIF /QCIF
Frame rate
25 fps (P) /30 fps (N)
Video bit rate
32 Kbps-8192 Kbps, or user defined (Max. 8192 Kbps)
Audio output
2-ch, RCA (2.0 Vp-p, 1 kΩ)
Audio bit rate
16 Kbps
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
14
Dual-stream
Support | (Sub-stream at CIF/QCIF: 25 fps (P) /30 fps (N))
Stream type
Video, Video & Audio
Playback
resolution
4CIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
8 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External
interface
Network
interface
2, RJ45 10M /100M /1000M self-adaptive Ethernet
Serial interface
1 RS-232 interface (for parameters configuration, maintenance,
transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
USB interface
2, USB2.0
Alarm in
4
16
16
Alarm out
2 4 4
General
Power supply
100~240 VAC, 6.3 A, 50~60 Hz
Consumption
≤ 70 W (without hard disk or DVD-R/W)
Working
temperature
-10 ºC ~+55 ºC
Working
humidity
10%~90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 90 mm
Weight
≤ 8 Kg (without hard disk or DVD-R/W)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
15
Table 2 Specifications for DS-9000HFI-ST
Model
DS-9004HFI-ST
DS-9008HFI-ST
DS-9016HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
8-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
16-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
IP video input
8-ch
16-ch
32-ch
Composite
video input
Up to 8-ch (Analog
video + IP video)
Up to 16-ch (Analog
video + IP video )
Up to 32-ch (Analog
video + IP video )
Audio
compression
OggVorbis
Audio input
4-ch,
RCA (2.0 Vp-p, 1 kΩ)
8-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1 kΩ)
Audio 5-8: DB26
connector
16-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1 kΩ)
Audio 5-16: DB26
connector
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI output
1-ch, resolution:
1920 × 1080P /60 Hz , 1920 × 1080P /50 Hz, 1600 × 1200 /60 Hz,
1280 × 1024 /60 Hz, 1280 × 720 /60 Hz, 1024 × 768 /60 Hz
VGA output
1-ch, resolution:
1920 × 1080P /60 Hz , 1600 × 1200 /60 Hz,1280 × 1024 /60 Hz,
1280 × 720 /60 Hz, 1024 × 768 /60 Hz
Playback
resolution
5Megapixels /3Megapixels
/1080P /UXGA /720P /4CIF /VGA /DCIF /2CIF /CIF /QCIF
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot
output
1-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576,
NTSC: 704 × 480
Video loop out
4-ch,
BNC (1.0 Vp-p, 75 Ω)
8-ch,
BNC (1.0 Vp-p, 75 Ω)
16-ch,
BNC (1.0 Vp-p, 75 Ω)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
16
Encoding
resolution
4CIF /2CIF /CIF /QCIF
Frame rate
25 fps (P) /30 fps (N)
Video bit rate
32 Kbps-8192 Kbps, or user defined (Max. 8192 Kbps)
Audio output
2-ch, RCA (2.0 Vp-p, 1 kΩ)
Audio bit rate
16 Kbps
Dual-stream
Support | (Sub-stream at CIF /QCIF: 25 fps (P)/30 fps (N))
Stream type
Video, Video & Audio
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
8 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External
interface
Network
interface
2, RJ45 10M /100M /1000M self-adaptive Ethernet
Serial interface
1 RS-232 interface (for parameters configuration, maintenance,
transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
USB interface
2, USB2.0
Alarm in
4
16
16
Alarm out
2 4 4
General
Power supply
100~240 VAC, 6.3 A, 50~60 Hz
Consumption
≤ 70 W (without hard disk or DVD-R/W)
Working
temperature
-10 ºC ~+55 ºC
Working
humidity
10%~90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 90 mm
Weight
≤ 8 Kg (without hard disk or DVD-R/W)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
17
Table 3 Specifications for DS-8100HFI-ST
Model
DS-8104HFI-ST
DS-8108HFI-ST
DS-8116HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
8-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
16-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
Audio
compression
OggVorbis
Audio input
4-ch,
BNC
(2.0 Vp-p, 1 kΩ)
8-ch,
BNC
(2.0 Vp-p, 1 kΩ)
16-ch,
BNC
(2.0 Vp-p, 1 kΩ)
Voice talk input
1-ch, BNC (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI output
1-ch, resolution:
1920 × 1080P /60 Hz, 1920 × 1080P /50 Hz,1600 × 1200 /60 Hz,
1280 × 1024 /60 Hz, 1280 × 720 /60 Hz, 1024 × 768 /60 Hz
VGA output
1-ch, resolution:
1920 × 1080P /60 Hz, 1600 × 1200 /60 Hz, 1280 × 1024 /60 Hz,
1280 × 720 /60 Hz, 1024 × 768 /60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot
output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
Optional
Encoding
resolution
4CIF /2CIF /CIF /QCIF
Frame rate
25 fps (P) /30 fps (N)
Video bit rate
32 Kbps ~ 8192 Kbps, or user defined (Max. 8192 Kbps)
Audio output
2-ch, BNC (Linear, 600 Ω)
Audio bit rate
16 Kbps
Dual-stream
Support | (Sub-stream at CIF/QCIF: 25 fps (P)/30 fps (N))
Stream type
Video, Video & Audio
Playback
resolution
4CIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
8 SATA interfaces
eSATA
1 eSATA interface
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
18
Capacity
Up to 4TB capacity for each disk
External
interface
Network
interface
1 RJ45 10M /100M /1000M self-adaptive Ethernet
Serial interface
1 RS-232 interface (for parameters configuration, maintenance,
transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
USB interface
2, USB2.0
Alarm in
4
16
16
Alarm out
2 4 4
General
Power supply
100~240 VAC, 6.3 A, 50~60 Hz
Consumption
≤ 70 W (without hard disk or DVD-R/W)
Working
temperature
-10 ºC ~ +55 ºC
Working
humidity
10% ~ 90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 90 mm
Weight
≤ 8 Kg (without hard disk or DVD-R/W)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
19
Table 4 Specifications for DS-8000HFI-ST
Model
DS-8004HFI-ST
DS-8008HFI-ST
DS-8016HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
8-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
16-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC
self-adaptive
IP video input
8-ch
16-ch
32-ch
Composite
video input
Up to 8-ch (Analog
video + IP video)
Up to 16-ch (Analog
video + IP video)
Up to 32-ch (Analog
video + IP video)
Audio
compression
OggVorbis
Audio input
4-ch,
BNC
(2.0 Vp-p, 1 kΩ)
8-ch,
BNC
(2.0 Vp-p, 1 kΩ)
16-ch,
BNC
(2.0 Vp-p, 1 kΩ)
Voice talk input
1-ch, BNC (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI output
1-ch, resolution:
1920 × 1080P /60 Hz ,1920 × 1080P /50 Hz,1600 × 1200 /60 Hz,
1280 × 1024 /60 Hz, 1280 × 720 /60 Hz, 1024 × 768 /60 Hz
VGA output
1-ch, resolution:
1920 × 1080P /60 Hz ,1600 × 1200 /60 Hz, 1280 × 1024 /60 Hz,
1280 × 720 /60 Hz, 1024 × 768 /60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot
output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
Optional
Encoding
resolution
4CIF /2CIF /CIF /QCIF
Frame rate
25 fps (P) /30 fps (N)
Video bit rate
32 Kbps ~ 8192 Kbps, or user defined (Max. 8192 Kbps)
Audio output
2-ch, BNC (Linear, 600 Ω)
Audio bit rate
16 Kbps
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
20
Dual-stream
Support | (Sub-stream at CIF/QCIF: 25fps (P)/30fps (N))
Stream type
Video, Video & Audio
Playback
resolution
5Megapixels /3Megapixels
/1080P /UXGA /720P /4CIF /VGA /DCIF /2CIF /CIF /QCIF
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
8 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External
interface
Network
interface
1 RJ45 10M /100M /1000M self-adaptive Ethernet
Serial interface
1 RS-232 interface (for parameters configuration, maintenance,
transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
USB interface
2, USB2.0
Alarm in
4
16
16
Alarm out
2 4 4
General
Power supply
100~240 VAC, 6.3 A, 50~60 Hz
Consumption
≤ 70 W (without hard disk or DVD-R/W)
Working
temperature
-10 ºC ~ +55 ºC
Working
humidity
10% ~ 90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 90 mm
Weight
≤ 8 Kg (without hard disk or DVD-R/W)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
21
HDD Storage Calculation Chart
The following chart shows an estimation of storage space used based on recording at one channel for an hour at a
fixed bit rate.
Bit Rate
Storage Used
96K
42M
128K
56M
160K
70M
192K
84M
224K
98M
256K
112M
320K
140M
384K
168M
448K
196M
512K
225M
640K
281M
768K
337M
896K
393M
1024K
450M
1280K
562M
1536K
675M
1792K
787M
2048K
900M
Note: Please note that supplied values for storage space used is just for reference. Storage space used is estimated
by formulas and may have some deviation from actual value.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
22
Menu Operation
Menu Structure
The menu structure of the DVR is shown as below:
DS-9100/8100HFI-ST
DS-9000/8000HFI-ST
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
23
Startup and Shutdown
Proper startup and shutdown procedures are crucial to expanding the life of the DVR.
To start your DVR:
1. Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an
Uninterruptible Power Supply (UPS) be used in conjunction with the device. The Power indicator LED on
the front panel should be red, indicating the device gets the power supply.
2. Press the POWER button on the front panel. The Power indicator LED should turn blue. The unit will begin
to start.
To shut down the DVR:
1. Enter the Shutdown menu.
Menu > Shutdown
2. Select the Shutdown button.
3. Click the Yes button.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
24
Using the Setup Wizard
By default, the Setup Wizard will start once the DVR has loaded.
Operating the Setup Wizard:
1. The Setup Wizard will walk you through some important settings of your DVR. If you don’t want to use the
Setup Wizard at this time, click the Cancel button. You can also choose to use the Setup Wizard next time by
leaving the “Start Wizard when DVR starts?” checkbox checked.
2. Click Next button on the Wizard window to enter the Login window.
3. Enter the admin password. By default, the password is 12345.
4. To change the admin password, check the New Admin Password checkbox. Enter the new password and
confirm the password in the given fields.
5. Click the Next button to enter the date/time settings window.
6. After the time settings, click Next button which to go to the Network Setup Wizard window.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
25
DS-9100/9000HFI-ST
DS-8100/8000HFI-ST
Note: Dual NIC is supported by DS-9100/9000HFI-ST only.
7. Click Next button after you configure the network parameters to enter the HDD Management window.
8. To initialize the HDD, click the Init button. Initialization will remove all the data saved in the HDD.
9. Click Next button to enter the Network Camera Management window (Not supported by
DS-8100/9100HFI-ST DVR).
DS-9000/8000HFI-ST
10. Click Search to search network cameras. Click Add to add network camera(s). Tick Synchronize IP
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
26
Camera checkbox to synchronize the default parameters configured in DVR to all the network cameras (Not
supported by DS-8100/9100HFI-ST DVR).
11. After finishing network camera(s) settings, click Next button. This will take you to the Record Settings
window.
12. Click Copy, to copy the settings to other cameras.
DS-9100/8100HFI-ST
DS-9000/8000HFI-ST
Note: IP Camera is supported by DS-9000/8000HFI-ST only.
13. Click OK to complete the startup Setup Wizard.
Live View
Some icons are provided on screen in Live View mode to indicate different camera status. These icons include:
Live View Icons
In the live view mode, there are icons at the right top of the screen for each channel, showing the status of the
record and alarm in the channel, so that you can find problems as soon as possible.
Alarm (video loss, tampering, motion detection or sensor alarm).
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
27
Alarm & Record
PTZ Control
Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before
you set the PTZ camera.
Before you start, please check that the PTZ and the DVR are connected properly through RS-485 interface.
PTZ Settings
To configure PTZ settings:
1. Enter the PTZ Settings interface.
Menu >Camera> PTZ
DS-9100/8100HFI-ST
DS-9000/8000HFI-ST
2. Choose the camera for PTZ setting next to Camera label.
3. Enter the parameters of the PTZ camera.
Note: All the parameters should be exactly the same as the PTZ camera parameters.
4. Click Copy if you want to configure same settings to other PTZ cameras.
5. Click the Apply button to save and exit the interface.
Record (manual record, schedule record, motion detection or alarm triggered record)
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
28
PTZ Control
In the Live View mode, you can press the PTZ Control button on the front panel or on the remote, or choose the
PTZ Control icon to enter the PTZ toolbar.
Description of the PTZ toolbar icons
Icon
Description
Icon
Description
Icon
Description
Direction button and
the auto-cycle button
Zoom+, Focus+,
Iris+
Zoom-, Focus-, Iris-
The speed of the
PTZ movement
Light on/off
Wiper on/off
Zoom
Middle Preset
Patrol
Pattern Menu
Previous item
Next item
Start pattern/patrol
Stop the patrol or
pattern movement
Minimize
windows
Exit
Playback
Play back the record files of a specific channel in the live view menu.
Instant playback by channel
Choose a channel under live view using the mouse and click the button in the shortcut operation menu.
Note: Only record files recorded during the past five minutes on this channel will be played back.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
29
All-day Playback by channel
1. Enter the All-day Playback menu.
Mouse: right click a channel in live view mode and select All-day Playback from the menu.
Front Panel: press PLAY button to play back record files of the channel under single-screen live view.
Under multi-screen live view, record files of the top left channel (not masked) will be played back.
Note: pressing numerical buttons will switch playback to related channels during playback process.
2. Playback management.
The toolbar in the bottom part of Playback interface can be used to control playing process.
The channel and time selection menu will display by moving the mouse to the right of the playback interface.
Just tick the channel or channels if you want to switch playback to another channel or execute simultaneous
playback of multiple channels.
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
30
DS-9100/8100HFI-ST
DS-9000/8000HFI-ST
Note: Playback of IP Camera is supported by DS-9000/8000HFI-ST only.
Backup
Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer.
To export recorded files:
1. Enter Video Export interface.
Choose the channel(s) you want to back up and press Quick Export button.
DS-9100/8100HFI-ST
Quick Operation Guide of DS-9100/9000/8100/8000HFI-ST Series DVR
31
DS-9000/8000HFI-ST
Note: Backing up recorded files of IP Camera is supported by DS-9000/8000HFI-ST only.
2. Enter Export interface, choose backup device and press Export button to start exporting.
3. Check backup result.
Choose the record file in Export interface and press button to check it.
Loading...
