DS-2CD6365G0E-I(V)(S) (B)is a fisheye network camera
capable of providing a 360-degree panoramic image of its
surveillance scene.
The progressive scan CMOS sensor provides high-resolution
images of up to 3072 × 2048.
Up to 18 live view display modes, designed for 3 mount types,
meet various user preference.
Three independently controlled IR lights offer a range of 15 m
and provide good vision in low or even zero-light environment.
DS-2CD6365G0E-I(V)(S) (B)
6 MP IR Network Fisheye Camera
1/1.8” Progressive Scan CMOS
Max. 3072 × 2048 @30fps
Up to 18 live view display modes
120 dB WDR
Up to 15m IR range
Built-in microphone and speaker
Smart features
6 behavior analyses, and 3 exception
detections
With –V Model
Without –V Model
Page 2
Specifications
Camera
Image Sensor
1/1.8'' Progressive Scan CMOS
Min. Illumination
Color: 0.047 Lux @ (F2.6, AGC ON),
B/W: 0.0047 Lux @ (F2.6, AGC ON), 0 Lux with IR
Shutter Speed
1 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120 dB
Lens Focal Length
1.27 mm
Aperture
F2.6
FOV
Horizontal FOV 180° (wall mount), 360°(ceiling mount), 360°(table mount)
Lens Mount
M12
IR IR Range
Up to 15 m IR range, 3 LEDs. Each LED is independently controlled.
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type
Baseline Profile/ Main Profile /High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
SVC
H.265 and H.264 support
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection, region entrance detection, region exiting detection,
unattended baggage detection, object removal detection
Exception Detection
Audio exception detection
Region of Interest
4 fixed regions for main stream and sub-stream
Max. Resolution
3072 × 2048
Main Stream
Max. Frame Rate
50Hz: 25fps (3072 × 2048, 2048 × 2048, 1280 × 1280)
60Hz: 30fps (3072 × 2048, 2048 × 2048, 1280 × 1280)
Sub Stream
Max. Frame Rate
50Hz: 25fps (720 × 720, 720 × 480)
60Hz: 30fps (720 × 720, 720 × 480)
Image Enhancement
BLC, HLC, defog, 3D DNR
Image Setting
Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software
or web browser
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In (-S)
Picture Overlay
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Live View Display
Mount Type
Support table, wall, and ceiling mounting
Page 3
Decoding Mode
Support hardware decoding and software decoding
Display Mode
18 display modes in total
Software decoding:
Ceiling mount: fisheye view, 180 panorama view, 360 panorama view, 360 panorama + PTZ, 360
panorama + 3PTZ, 360 panorama + 6PTZ, 360 panorama + 8PTZ, 2PTZ, 4PTZ, fisheye + 3PTZ, fisheye
+8 PTZ, half sphere, cylinder
Wall mount: fisheye view, panorama view, panorama + 3PTZ, panorama + 8PTZ, 4PTZ, fisheye +
3PTZ, fisheye +8 PTZ
Table mount: fisheye view, 180 panorama view, 360 panorama view, 360 panorama + PTZ, 360
panorama + 3PTZ, 360 panorama + 6PTZ, 360 panorama + 8PTZ, 4PTZ, fisheye + 3PTZ, fisheye +8
PTZ, cylinder
Hardware decoding:
Ceiling mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion
Wall mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion
Table mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion
Audio (-S)
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Network
Network Storage
Support microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login,
HDD full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Security Measure
Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address
filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP
address filter
Firmware Version
5.5.73
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users. 3 user levels, administrator, operator and user
Client
iVMS-4200, iVMS-4500, Hik-Connect, iVMS-5200
Web Browser
IE8+, Chrome31.0-44, Firefox 30.0-51, Safari8.0+
Interface
Communication Interface
1 RJ45 10M/100M/1000M self-adaptive Ethernet port
Audio (-S)
1 Audio input (line in, 3.5 mm), 1 audio output (line out, 3.5 mm);
2 built-in microphone, 1 built-in speaker, mono sound
Alarm (-S)
1-ch alarm input, max. 12 V; 1-ch alarm output, max 24 VDC, 1 A
On-board storage
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Reset Button
Yes
General
Operating Conditions
-40 °C to +60 °C (-40 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC±20%, PoE (802.3af, class 0),
-S model: two-core terminal block
Without –S model: Φ 5.5 × 2.1 mm coaxial power plug
Power Consumption
12 VDC, 0.9 A, max. 11 W
PoE (802.3af, 36 to 57 V), 0.3 A to 0.2 A, max. 12 W
Protection Level (-V)
IP67, IK8
Page 4
Available Model
DS-2CD6365G0E-I (1.27 mm) (B); DS-2CD6365G0E-IS (1.27 mm) (B), DS-2CD6365G0E-IV (1.27 mm) (B), DS-
2CD6365G0E-IVS (1.27 mm) (B)
Dimensions
152.8(6")
50.1(2")
152.8(6")
55(2.2")
Unit: mm (inch)
Without -V Mod el
With -V Model
Material
Metal
Dimensions
Without –V model: 167.4 × 152.8 × 50.1 mm (6. 6" × 6" × 2")
With –V model: 167.4 × 152.8 × 55 mm (6. 6" × 6" × 2.2")
Weight
Approx. 1400 g (3.09 lbs)
Accessories
Page 5
DS-1280ZJ-DM25
Junction Box
DS-1281ZJ-DM25
Inclined Ceiling Mount
DS-1273ZJ-DM25
Wall Mount
DS-1271ZJ-DM25
Pendant Mount
DS-1283ZJ
Wall Mount (3-axis Adjustment)
