Hikvision DS-2CD2523G0-IS-2-8mm, DS-2CD2523G0-IS-4mm Specsheet

DS-2CD2523G0-I(W)(S)
2 MP IR Fixed Mini Dome Network Camera

 1920 × 1080@30fps
 IR: Up to 10 m
 H.265+. H.265
 120dB WDR
 Built-in Micro SD/SDHC/SDXC slot, up to 128G
 PoE
 BLC/3D DNR/HLC/ROI
 Wi-Fi (Optional)

Key Features

Specifications

Camera

Image Sensor

1/2.7" Progressive Scan CMOS

Min. Illumination

Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Day & Night

IR Cut Filter

Digital Noise Reduction

3D DNR

WDR

120dB

3-Axis Adjustment

Pan: -30° to +30°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

Focal length

2.8, 4, 6 mm

Aperture

F2.0

FOV

2.8 mm, Horizontal field of view: 114°, Vertical field of view: 62°, Diagonal field of view: 135°
4 mm, Horizontal field of view: 86°, Vertical field of view: 46°, Diagonal field of view: 102°
6 mm, Horizontal field of view: 54°, Vertical field of view: 30°, Diagonal field of view: 62°

Lens Mount

M12

IR

IR Range

Up to 10 m

Wavelength

850nm

Compression Standard

Video Compression

Main stream: H.265/H.264
Sub-stream: H.265/H.264 /MJPEG
Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 16 Mbps

Audio Compression

G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM

Audio Bit Rate

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)

Smart Feature-set

Behavior Analysis

Line crossing detection, intrusion detection

Face Detection

Yes

Region of Interest

Support 1 fixed region for main stream and sub-stream separately


Max. Resolution

1920 × 1080

Main Stream

50Hz:25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream

50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client
software or web browser

Image Enhancement

BLC/3D DNR/HLC
