Hikvision DS-2CC51A1N-VF User Manual

Day/Night High-definition Dome Camera·User Manual

Day/Night High-definition

Dome Camera

User Manual

UD.6L0201D0070A01

Day/Night High-definition Dome Camera·User Manual

Models

DS-2CC 5181P(N)-VF

DS-2CC 5185P(N)-VF

DS-2CC 5191P(N)-VF

DS-2CC 5195P(N)-VF

DS-2CC 51A1P(N)-VF

DS-2CC 51A5P(N)-VF

DS-2CC 5183P(N)-VF

DS-2CC 5187P(N)-VF

DS-2CC 5193P(N)-VF

DS-2CC 5197P(N)-VF

DS-2CC 51A3P(N)-VF

DS-2CC 51A7P(N)-VF

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

This manual applies to following cameras:

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

Day/Night High-definition Dome Camera·User Manual

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.”

0100001021113

Day/Night High-definition Dome Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a comm ercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio com munications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmo nized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

Day/Night High-definition Dome Camera·User Manual

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispos e of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Day/Night High-definition Dome Camera·User Manual

Safety Warnings and Cautions

Please pay attention to the following warnings and cautions:

Hazardous Voltage may be present: Special

measures and precautions must be taken when

using this device. Some potentials (voltages) on the

device may present a hazard to the user. This device

should only be used by Employees from our company with

knowledge and training in working with these types of devices that

contain live circuits.

Power Supply Hazardous Voltage: AC mains voltages

are present within the power supply assembly. This device must be

connected to a UL approved, completely enclosed power supply, of

the proper rated voltage and current. No user serviceable parts

inside the power supply.

System Grounding (Earthing): To avoid shock, ensure

that all AC wiring is not exposed and that the earth grounding is

Day/Night High-definition Dome Camera·User Manual

maintained. Ensure that any equipment to which this device will be

attached is also connected to properly wired grounded receptacles

and are approved medical devices.

Power Connect and Disconnect: The AC

power supply cord is the main disconnect device to

mains (AC power).The socket outlet shall be

installed near the equipment and shall be readily

accessible.

Installation and Maintenance: Do not connect/disconnect

any cables to or perform installation/maintenance on this device

during an electrical storm.

Power Cord Requirements: The connector

that plugs into the wall outlet must be a

grounding-type male plug designed for use in your

region. It must have certification marks showing certification by an

agency in your region. The connector that plugs into the AC

receptacle on the power supply must be an IEC 320, sheet C13,

female connector. See the following website for more information

http://kropla.com/electric2.htm.

Lithium Battery: This device contains a Lith ium Battery. There

is a risk of explosion if the battery is replaced by a n incorrect type.

Day/Night High-definition Dome Camera·User Manual

Dispose of used batteries according to the vendor’s instructions

and in accordance with local environmental regulations.

Perchlorate Material: Special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is

required by California Code of Regulations, Title 22, Division 4.5,

Chapter 33: Best Management Practices for Perchlorate Materials.

This device includes a battery which co ntains perchlorate material.

Ta iwan battery recycling:

Please recycle batteries.

Thermal and Mechanical Injury: Some

components such as heat sinks, power regulators,

and processors may be hot; care should be taken

to avoid contact with these components.

Electro Magnetic Interference: This e quipment has not

been tested for compliance with emissions limits of FCC and similar

international regulations. This device is not, and may not be,

offered for sale or lease, or sold, or leased until a uthorization from

the United States FCC or its equivalent in o ther countries has been

obtained. Use of this equipment in a residential location is

prohibited. This equipment generates, uses and can radiate radio

frequency energy whic h may result in ha rmful interference to radio

communications. If this equipment does cause harmful

interference to radio or television reception, which can be

Day/Night High-definition Dome Camera·User Manual

determined by turning the equipment on and off, the user is

required to take measures to eliminate the interference or

discontinue the use of this equipment.

Lead Content:

Please recycle this device in a responsible

manner. Refer to local environmental

regulations for proper recycling; do not dispose

of device in unsorted municipal waste.

Day/Night High-definition Dome Camera·User Manual

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the

warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

 Please adopt the power adapter which can meet the safety

extra lo w voltage (SELV) request. And so urce with DC 12V or

AC 24V (depending on models) according to the IEC60950-1

and Limited Power Source standard.

 If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to

Day/Night High-definition Dome Camera·User Manual

disassemble the camera yourself. (We shall not assume any

responsibility for problems caused by unauthorized repair o r

maintenance.)

 To reduce the risk of fire or electrical shock, do not expose

this product to rain or moisture.

 This installation should be made by a qualified service

person and should conform to all local codes.

 Please install blackouts equipment into the power supply

circuit for convenient supply interruption.

 Please make sure that the ceiling can support more than

50(N) Newton gravities if the camera is fixed to the ceiling.

Cautions

 Make sure the power supply voltage is correct before using

the camera.

 Do not drop the camera or subject it to physical shock.  Do not touch sensor modules with fingers. If cleaning is

necessary, use a c lean cloth with a bit o f ethanol and wipe it

gently. If the camera will not be used for an extended period

of time, put on the lens cap to protect the sensor from dirt.

 Do not aim the camera at the sun or extra bright places. A

blooming or smear may occur otherwise (which is not a

malfunction however), and affecting the endurance of

sensor at the same time.

Day/Night High-definition Dome Camera·User Manual

 The sensor may be burned out by a laser beam, so when any

laser e quipment is being used, m ake sure that the surface of

the sensor will not be exposed to the laser beam.

 Do not place the camera in extremely hot o r cold

temperatures (the operating temperature should be

between -10°C ~ 60°C , dusty or damp locations, and do not

expose it to high electromagnetic radiation.

 To avoid heat accumulation, goo d ventilat ion is required for

a proper operating environment.

 Do not let water and any liquid flow into the camera.  While shipping, the camera should be packed in its original

packing, or packing of the same texture.

 Improper use or replacement of the battery may result in

hazard of explosion. Replace with the same or equivalent

type only. Dispose of used batteries according to the

instructions provided by the battery manufacturer.

Day/Night High-definition Dome Camera·User Manual

Table of Contents

1 Introduction ......................................................................14

1.1 Product Features .................................................... 14

1.2 Overview ............................................................... 16

2 Installation........................................................................18

2.1 Ceiling Mounting .................................................... 18

2.2 In-ceiling Mounting Without Gang Box .................... 22

2.3 Wiring .................................................................... 27

3 Menu Operations...............................................................28

3.1 Menu Description (A).............................................. 28

3.1.1 Menu Overview ............................................. 28

3.1.2 Lens Settings ................................................ 29

3.1.3 Shutter/AGC Setting ..................................... 30

3.1.4 White Balance Setting ................................... 33

3.1.5 Backlight Setting ........................................... 36

3.1.6 Picture Adjust Setting.................................... 36

3.1.7 ATR Setting ................................................... 37

3.1.8 Motion Detection Setting ............................... 38

3.1.9 Privacy Mask Setting ..................................... 40

3.1.10 Day/Night Setting ....................................... 42

3.1.11 NR Setting .................................................. 44

3.1.12 Camera ID Setting ...................................... 44

3.1.13 SYNC Setting .............................................. 46

3.1.14 Language Setting ........................................ 47

3.1.15 Camera Reset Setting.................................. 47

3.1.16 Defective Pixel Correct Setting..................... 47

3.1.17 Save All/Exit ............................................... 47

Day/Night High-definition Dome Camera·User Manual

3.2 Menu Description (B).............................................. 48

3.2.1 Menu Overview ............................................. 48

3.2.2 Scene ........................................................... 50

3.2.3 Exposure....................................................... 50

3.2.4 Funtion ......................................................... 59

3.2.5 System ......................................................... 67

3.2.6 Language ...................................................... 70

3.2.7 Exit ............................................................... 70

1 Glossary ................................................................... 71

2 Troubleshooting......................................................... 75

3 Technical Maintenance ............................................... 77

Day/Night High-definition Dome Camera·User Manual

1 Introduction

1.1 Product Features

This series of camera adopts high-sensitivity sensor and advanced

circuit board design technology. It possesses o f hig h resolution,

low distortion, and low noise features, etc. It is extremely suitable

for surveillance system and image process system.

The main features of DS-2CC 5181/5191/51A1P （N）-VF are as

follows:  Adopt high-performance SONY CCD, providing high-quality


 Color: minimum 0.001Lux@F1.2, B/W: minimum

0.0001Lux@F1.2

 ICR filter auto switch  Support OSD menu, which enables user to configure the

detailed parameters

 Back Light Compensation (BLC) with programmable BLC area  Auto-white balance with high color rendition  High Signal Noise Ratio (SNR), which br ings clear and

high-quality image

 Auto electronic shutter control to adapt to the different

surveillance environments

Day/Night High-definition Dome Camera·User Manual

 Auto gain control, adaptive brightness  Privacy mask with 8 optional colors and 8 configurable areas  Advanced 3-axis design makes this series of dome camera is

applicable to the different installation environment

The main features of DS-2CC 5183/5193/51A3P (N)-VF,

DS-2CC 5185/5195/51A5P (N)-VF, and

DS-2CC 5187/5197/51A7P (N)-VF are as follows:

 High-performance SONY CCD, providing high-quality image  Color: minimum 0.001Lux@F1.2, B/W: minimum

0.0001Lux@F1.2

 ICR filter auto switch  Support Wide Dynamic Range (WDR) for backlighting

surveillance (supported by DS-2CC5187/5197/51A7P (N)-VF)

 OSD menu, which enables user to configure the detail

parameters

 Back Light Compensation (BLC) with programmable BLC area  Auto white balance with high color rendition  High SNR, which brings clear and high-quality image  3D digital noise reduce to get clear and fine image  Support SMART IR  Electronic image stabilization (EIS) function to get steady and

clear image

 Auto electronic shutter control to adapt to the different

surveillance environments

Day/Night High-definition Dome Camera·User Manual

 Auto gain control, adaptive brightness  Support auto iris  Privacy mask with 8 optional co lors and 12 configurable areas  Advanced design technology with high reliability  Advanced 3-axis design allows the dome camera to meet the

different mounting requirements

1.2 Overview

Figure 1-1 Overview

Day/Night High-definition Dome Camera·User Manual

1 Lo wer Dome

6 Menu Button

2 B lack Liner

7 AUX Interface

3 Lens Co ver

8 Len Adjust Lever

4 C amera

9 T ilt Lock Screw

5 Base P late

Day/Night High-definition Dome Camera·User Manual

2 Installation

Before you start:

Please make sure that the device in the package is in goo d

condition and all the assembly parts are included.

This series of camera support several mounting methods like

ceiling mounting, in-ceiling mounting with a gang box, in-ceiling

mounting without a gang box and wall mounting. We will take

ceiling mounting and in-ceiling mounting without a gang box as

the examples in this chapter.

2.1 Ceiling Mounting

Note:

Please make sure that the ceiling is strong enough to withstand

three times the weight of the camera.

Steps:

1. Attach the drill template (supplied) to the place where you

want to fix the camera.

2. Drill four screws holes according to the number 2 circles on the

drill template as shown in Figure 2-1.

Day/Night High-definition Dome Camera·User Manual

Anticlockwise

Black Liner

White Base

Figure 2-1 The Drill Temp late

3. Drill a hole in the ceiling according to the circle in the center of

the template if you want to route the cables through the ceiling.

Skip this step if you want to route the cables on the surface of

the ceiling.

4. Rotate the lower dome of the camera anticlockwise to take it

down from the camera and remove the black liner.

Figure 2-2 Black Liner Disassembling

Day/Night High-definition Dome Camera·User Manual

Camera

Base Plate

Screws

Ceiling

5. Attach the base plate to the ceiling and secure it with the

supplied 4 self-tapping screws as shown in Figure 2-3.

Note:

Please use expansion screws if the dome camera is mounted to

cement wall.

Figure 2-3 Mounting the Base Plate

6. Route the cables through the cable hole.

7. Align the camera with the base plate. Rotate the camera

clockwise into the base plate.

8. Tighten the lock screw to secure the camera with the base

plate as shown in Figure 2-4.

Figure 2-4 Securing the Camera

Day/Night High-definition Dome Camera·User Manual

Panning Tab le

Tilting Lock

Screw

9. Connect the video output connector to the monitor. Connect

the power connector to the power supply.

10. Three-axis adjustment

1). View the camera image via the monitor.

2). Rotate the panning table to adjust the panning position of

the camera. The adjusting range is from 0 degree to 355

degrees.

3). Loosen the tilting lock screw.

4). Rotate the tilting table to adjust the tilting position of the

camera. The adjusting range is from 0 degree to 180

degrees.

5). Tighten the tilting lock screw.

6). Rotate the lens to adjust the azimuth angle of the image.

The adjusting range is from 0 degree to 355 degrees.

Figure 2-5 Lens Adjustment

Day/Night High-definition Dome Camera·User Manual

Ceiling

Lower Dome Clockwise

11. Attach the black liner to the camera.

12. Rotate the lower dome clockwise to the camera.

13. Remove the protection film softly to complete the installation.

Figure 2-6 Lower Dome Installation

Note:

Remove the protection layer after the installation is completed in

case of the image problem caused by the scrape o f the lower

dome.

2.2 In-ceiling Mounting Without Gang Box

Notes:

1. Please make sure that the ceiling is strong enough to withstand

three times the weight of the camera.

2. In-ceiling mount is not supplied.

Steps:

Day/Night High-definition Dome Camera·User Manual

Set Screw

1. Rotate the lower dome anticlockwise to remove it.

2. Remove the black liner.

3. Loosen the two screws as shown in Figure 2-7.

4. Remove the white base together with the base plate.

Figure 2-7 Disassembling

5. Attach the drill template (supplied) to the place where you

want to fix the camera.

6. Drill two screw holes according to the two circles on the drill

template as shown in Figure 2-8.

7. Drill a hole in the ceiling according to the circle in the center of

the template. It is for in-ceiling mounting.
