DS-2CC176P-A Analog Camera
Technical Manual
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this d oc umentat ion is subje ct to c hange without no tice and doe s not re present an y
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this do cume ntation. T he product(s ) de scr ibed in this do cume ntation ar e furnished
subject to a license a nd may only be used in accordance w ith the terms and condit ions of such lice nse.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplie d. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an indi vidual, firm, o r company or any em ployee thereof wi thout the p rior written con sent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without n otice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusiness@hikvision.com
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1. Key Features
1/2"SONY EX-View HAD CCD
High Light Compensation
Min. Illumination: 0.003 Lux@F1.2 (Color), 0.0003Lux@F1.2 (B/W)
ICR filter auto switch
Digital Noise Reduction (DNR)
OSD menu
Auto iris with DC / video driver
Auto white balance, auto gain control, electronic shutter control and backlight
compensation
CS mount lens (provide adapter for C mount lens)
Internal or Pow er Synchronization
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
2. Specifications
Model
Parameter DS-2CC176P-A
Image Sensor 1/2"SONY EX-View HAD CCD
Signal System PAL
Effective Pixels 752(H)×582(V)
Min. Illumination
Color: 0.003Lux @ F1.2, 0.00002Lux @ (F1.2, sensitivity×256)
B/W: 0.0003Lux @ F1.2, 0.000002Lux @ (F1.2, sensitivity×256)
Electronic Shutter 1/50s to 1/100,000s
Lens Mount C/CS Mount
Auto Iris Lens DC/Video Drive
Day / Night IR Cut Filter Auto Switch
Horizontal Resolution (TVL) 540 (Color), 600 (B/W)
Synchronization Internal / Power synchronization
Video Output 1Vp-p Composite Output (75Ω/BNC)
S/N Ratio More than 52dB
Menu
Camera ID On / Off (15 letters, adjusted position)
Auto Gain Low / Middle / High / Off
D / N Mode Auto1 / Auto2 / Day / Night
Auto White
Balance Auto trace WB1/ Auto trace WB2 / Manual / Auto Control
Privacy On / Off, Maximum 8 Zones
Motion Detection Mode 1 / Mode 2 / Off
BLC / HLS
BLC：Area / Intensity / Off
HLS：Intensity Setting
RS-485 Address / Protocol / Baud Rate
Flicker Proof On/Off
Language Chinese/English
Video Setting
Gamma Amendment, Digital Zoom, Digital Noise Reduction,
POS/NEG ,Mirror, Resolution, Aperture, Y, C, Blemish
Detection
Working Temperature
-10℃~60℃
Power Supply AC24V±10% / DC12V±10%
Power Consumption 5W MAX (10 W MAX with ICR working)
Dimension (mm) 68×57×144.8
Weight
500g
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
3. Dimension
