Hikvision DS-2AE5168N-A Specsheet

DS-2AE5168 series

E Series Analog 5 inch Speed Dome

Key feature

System function:

 1/4’’ high performance Sony CCD
 ±0.1° Preset Accuracy
 Self-adaptive to HIKVISION, Pelco-P/D protocol
 3D intelligent positioning function
 Power-off memory function: restore PTZ & Lens status after reboot
 Built-in temperature sensor, display internal temperature
 IP66 standard (outdoor dome)
 Scheduled PTZ movement

Camera function:

 Auto focus, auto white balance, and auto/manual day & night switch

 Privacy masks programmable

 Support 3D DNR, DWDR and digital zoom

PTZ function:

 360° endless pan range and -5°-90° tilt range
 300°/s Pan Preset Speed and 200°/s Tilt Preset Speed
 0.1°-250°/s Manual Pan Speed and 0.1°-150°/s Manual Tilt Speed
 256 presets programmable; preset image freezing capability
 8 patrols, up to 32 presets per patrol
 4 patterns, with the total recording time not less than 10 minutes
 Proportional zoom function
 Park action: auto call up of PTZ movement, after a defined time of inactivity

Application Scenarios

It can be widely applied to places with no lights or weak lights requiring wide-area and

high-speed monitoring, such as rivers, forests, highways, railways, airports, ports, sentries,

squares, parks, scenic sites, streets, stations, large venues, outside of residential areas, etc.

Model

Parameter

DS-2AE5168-A:PAL,24VAC,Outdoor

DS-2AE5168-A3:PAL,24VAC,Indoor

DS-2AE5168N-A:NTSC,24VAC,Outdoor

DS-2AE5168N-A3:NTSC,24VAC,Indoor

E Series High Speed Dome

Camera

Image Sensor

1/4" Sony CCD

Effective Pixel

PAL: 976(H)×582(V)

Horizontal Resolution

Color: 700 TVL

B/W: 750 TVL

Signal System

PAL/NTSC

Min. Illumination

0.02Lux/(F1.6, AGC ON), 0.0008Lux /(F1.6, AGC ON, sensitivity×256) (color)

0.002Lux/(F1.6, AGC ON), 0.00008Lux /(F1.6, AGC ON, sensitivity×256)(B/W)

White Balance

Auto / Manual / ATW / Indoor / Outdoor

AGC

Auto / Manual

S / N Ratio

≥ 50dB

DNR

High/Medium/Low/off

WDR

128x(On/Off/Auto)

Shutter Time

PAL: 1-1/10,000s

NTSC: 1-1/10,000s

Day & Night

IR Cut Filter

Digital Zoom

16x

Privacy Mask

8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the

same video screen

Focus Model

Auto / Semiautomatic / Manual

Lens

Focal Length

3.3-119mm, 36X

Zoom Speed

Approx.6 s(Optical Wide-Tele)

Angle of View

57.1-1.7 degree(Wide-Tele)

Min. Working Distance

10-1000mm (Wide-Tele)

Aperture Range

F1.4-F3.7

Pan and

Tilt

Pan Range

360°endless

Pan Speed

Pan Manual Speed: 0.1°-250°/s,

Pan Preset Speed: 300°/s

Tilt Range

-5°-90° (Auto Flip )

Tilt Speed

Tilt Manual Speed: 0.1°-150°/s,

Tilt Preset Speed: 200°/s

Proportional Zoom

Rotation speed can be adjusted automatically according to zoom multiples

Number of Preset

256

Patrol

8 patrols, up to 32 presets per patrol

Specifications
