Hikvision DS-2AE4215T-D(C) Turbo 4-Inch Speed Dome is
able to capture high quality images in poor light
environment. The embedded CMOS chip makes WDR,
and real-time 1920 × 1080 resolution possible. With the
help of the 15× optical zoom, and IR cut filter, the camera
offers more details over an expansive area.

 1/2.8" HD progressive scan CMOS
 1920 × 1080
 15× optical zoom, 16× digital zoom
 120 dB true WDR (Wide Dynamic Range)
 3D intelligent positioning
 Switchable TVI/AHD/CVI/CVBS video outputs

DS-2AE4215T-D(C)
2 MP Turbo 4-Inch Speed Dome

Specification

Camera

Model

DS-2AE4215T-D(C)

Image Sensor

1/2.8" progressive scan CMOS

Max. Image Resolution

1920 × 1080

Frame Rate

50Hz: 25fps @(1920 × 1080)
60Hz: 30fps @(1920 × 1080)

Min. Illumination

Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)

White Balance

AUTO/MANUAL/HAUTO/ATW/INDOOR/OUTDOOR

AGC

AUTO/MANUAL

DNR

3D DNR

WDR

≥ 120 dB

Shutter Time

PAL: 1/1 s to 1/10,000 s
NTSC: 1/1 s to 1/10,000 s

Day & Night

IR cut filter

Digital Zoom

16×

Privacy Mask

8 programmable privacy masks

BLC (Backlight Compensation)

Yes

HLC (highlight Compensation)

Yes

EIS (Electric Image Stabilization)

Yes

Reginal Focus

Yes

Lens

Focus Mode

Auto/Semiauto/Manual

Focal Length

5 mm to 75 mm, 15× Optical

Aperture Range

F 1.6 to F 3.5

Field of View

Horizontal field of view: 53.8° to 4.0° (wide to tele)
Vertical field of view: 31.9° to 2.3° (wide to tele)
Diagonal field of view: 60.4° to 4.6°(wide to tele)

Min. Working Distance

10 mm to 1500 mm (wide to tele)

Zoom Speed

Approx. 2.4 s (optical, wide to tele)

Pan and Tilt

Pan Range

360° endless

Pan Speed

Pan manual speed: 0.1° to 100°/s
Pan preset speed: 100°/s

Tilt Range

5° to 90° (auto flip)

Tilt Speed

Tilt manual speed: 0.1° to 80°/s
Tilt preset speed: 80°/s

Proportional Zoom

Rotation speed can be adjusted automatically according to zoom multiples

Presets

256

Patrol

10 patrols, up to 32 presets per patrol

Pattern

5 patterns, with the total recording time no less than 10 minutes

Power-off Memory

Yes

Park Action

Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night
Mode/None

PTZ Position Display

ON/OFF
