HikDashcam AE-DC8322-G2PRO
User Manual
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
2
A Legal Statement
© 2022 Hangzhou HikAuto Technology Co., Ltd. All rights reserved. Specifications subject to change without notice.
HikAuto Technology Co., Ltd. is a division of Hikvision Digital Technology, Ltd., No.555 Qianmo Road, Binjiang District, Hangzhou 310051, China Tel: +86-571-8807-5998
North America Offices: Hikvision USA Inc., 18639 Railroad St., City of Industry, CA 91748, USA • Hikvision Canada, 4848 rue Levy, St-Laurent, Quebec, Canada, H4R 2P1
Tel: +1-909-895-0400 • Toll Free in USA: +1-866-200-6690 • E-Mail: sales.usa@hikvision.com • www.hikvision.com
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images, and all
other information hereinafter are for description and explanation only. The information contained in the
Manual is subject to change, without notice, due to firmware updates or other reasons.
Trademarks
•
jurisdictions.
•
Other trademarks and logos mentioned are the properties of their respective owners.
and other Hikvision trademarks and logos are the properties of Hikvision in various
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT DESCRIBED, WITH
ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS.”
HIKAUTO MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR
OWN RISK. IN NO EVENT WILL HIKAUTO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH
THE USE OF THE PRODUCT, EVEN IF HIKAUTO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKAUTO
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES
RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKAUTO WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. YOU AGREE TO USE THIS PRODUCT
IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE
CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT
USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF WEAPONS
OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
3
B Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Compliance: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
The equipment should be installed and operated with a minimum distance of 7.9 in (20 cm) between the
radiator and your body.
EU Conformity Statement
This product and, if applicable, the supplied accessories too are marked with “CE” and comply
therefore with the applicable harmonized European standards listed under the RE Directive
2014/53/EU, the EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, and the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection
points. For more information, please see: www.recyclethis.info.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
4
B Regulatory Information (continued)
2006/66/EC (Battery Directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling,
return the battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions:
1. This device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes
1. l'appareil ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may operate only using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio
interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec
une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut
choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne
dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
This equipment should be installed and operated with a minimum distance of 20 cm between the radiator
and your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre
corps.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
5
Table of Contents
A Legal Statement ................................................................................................................................................ 2
About this Manual .......................................................................................................................................... 2
Trademarks ..................................................................................................................................................... 2
Disclaimer ....................................................................................................................................................... 2
B Regulatory Information ..................................................................................................................................... 3
FCC Information .............................................................................................................................................. 3
FCC Conditions................................................................................................................................................ 3
EU Conformity Statement
Industry Canada ICES-003 Compliance ......................................................................................................... 4
C Packing List ....................................................................................................................................................... 6
D Parts Introduction ............................................................................................................................................. 7
E Install Dashcam ................................................................................................................................................. 8
F Install Rear Camera ........................................................................................................................................... 9
OPTION 1: Exterior Mounting ........................................................................................................................... 9
OPTION 2: Interior Mounting ......................................................................................................................... 10
G Mobile Phone Connection ............................................................................................................................... 11
H Basic Operations ............................................................................................................................................. 12
Start Up/Shut Down Manually ..................................................................................................................... 12
Recording ..................................................................................................................................................... 12
Voice Control ................................................................................................................................................ 12
Firmware Upgrade ........................................................................................................................................ 12
Specifications .............................................................................................................................................. 13
I Cautions ............................................................................................................................................................ 14
Safety Instructions ...................................................................................................................................... 14
Cautions ........................................................................................................................................................ 14
J Troubleshooting .............................................................................................................................................. 15
................................................................................................................................ 3
6
Dashcam x 1
Electrostatic Sticker x 1
C Packing List
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
Rear
Accessory Package x 1
Camera x 1 and Connector
Cable x 1
3-Lead Hardware Kit Power Cable x 1
User Manual x 1
7
Figure 1, AE-DC8322-G2PRO Front View
Figure 2, AE-DC8322-G2PRO Rear View
D Parts Introduction
3M Adhesive Pad
Parking Mode Indicator
Lens
Mini-USB Port for Connection to
Computer for Data Transfer and 4G
Module Connection
Micro-USB Power Cable Port for 3-Lead
Buck Line Connection
Rear Camera Port
Microphone
MicroSD (TF) Port
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
Speaker
LED Indicator
• Solid Red: Power on
• Solid Blue: Working Properly
Reset Button
8
Clean the windshield and paste the electrostatic
Paste the device onto the electrostatic sticker
Connect the power cord as per the above figure.
Adjust the angle to the target direction.
4
E Install Dashcam
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
Figure 3, Apply Electrostatic Sticker
sticker onto the windshield.
NOTE: The electrostatic sticker prevents residual marks and allows
window cleaning and dashcam repositioning.
Avoid introducing air bubbles. DO NOT reapply the
film repeatedly.
Figure 4, Route Cable to Fuse Box
and route cable to the fuse box for power.
Figure 5, Connect Power Cord
Figure 6, Adjust Dashcam Angle
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
9
F Install Rear Camera
OPTION 1: Exterior Mounting
Peel off the adhesive release paper on the camera bracket. Install the camera centered directly above
the license plate so that it points at the road.
Connect the rear camera to the front dashcam by routing the cable as per the following diagram:
Figure 7, Rear Camera Exterior Cable Run
Figure 8, Rear Camera Exterior Placement
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
10
F Install Rear Camera (continued)
OPTION 2: Interior Mounting
Peel off the adhesive release paper on the camera bracket. Install the camera onto the top center of
the rear window (interior side) so that it points directly at the road.
Connect the camera to the front dashcam by routing the cable as per the following diagram:
Figure 9, Rear Camera Interior Cable Run
Figure 10, Rear Camera Interior Placement on Rear Windshield
11
Scan the QR code to download and install the
Dashcam Wi-Fi default parameters:
G Mobile Phone Connection
HikDashcam app to your mobile phone.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
Add the dashcam to the app.
a. Run the HikDashcam app.
b. Tap Wi-Fi Connection.
Figure 11, Scan QR Code for HikDashcam
• Wi-Fi SSID: HIKVISION-xxxx (xxxx refers to
the last four verification code
characters).
• Wi-Fi password by default is
1234567890
c. In the Wi-Fi list, select the target
dashcam’s Wi-Fi SSID and enter the Wi-Fi
password to establish a connection.
• You can set the dashcam parameters.
• For iOS, go your phone’s Wi-Fi settings
and connect to the dashcam Wi-Fi.
Edit the dashcam password to activate to avoid
abnormal recording after connecting the Wi-Fi.
• Create a new password after first login.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
12
H Basic Operations
Start Up/Shut Down Manually
Press and hold the power button for three seconds to shut down the dashcam. Press the power button to
start the dashcam.
Recording
Recordings are divided into regular videos and emergency videos. You can set the video voice on/off
through the system settings or the HikDashcam app.
Voice Control
The dashcam automatically activates voice control upon startup. Perform any of the following commands
just by saying the phrase out loud:
•
“Snapshot”
•
“Recording On”
•
“Recording Off”
Parking Mode
The AE-DC8322-G2PRO DashCam automatically goes into parking mode when the automobile engine is
shut off (only if using a three lead buck line cable connected directly to the fuse box) and the dashcam
continues to record at 1 fps.
Firmware Upgrade
Step 1: Run the HikDashcam app.
Step 2: Connect to the dashcam you would like to upgrade.
Step 3: Tap the Upgrade button to upgrade the firmware.
13
AE-DC8322-G2PRO
Camera
Image Sensor
CMOS
Resolution
2160p @ 30 fps + 1080p @ 25 fps, 1080p @ 60 fps + 1080p @ 25 fps
Maximum
Front Camera
135° (D), 124° (H)
Rear Camera
125° (D), 110° (H)
Aperture
ƒ/1.75
Video Compression
H.265
Display
Built-in 3" 854 x 480 IPS (In-Plane Switching) color touchscreen
OSD
Display time, date, etc.
Image Format
JPEG
eMMC (built in): 64 GB
MicroSD card: 32 GB to 256 GB
Communication Module
Wi-Fi, Bluetooth
Sensor
G-sensor, GPS
Interfaces
Power Supply
USB 2.0
Audio Input
Mic
Audio Output
Built-in loudspeaker
General
Working Temperature
-20° to 65° C (-4° to 158° F)
Working Humidity
0% to 95%
Power Supply
5 VDC, 2 A
Power Consumption
Maximum 6 W
Dimension (L x W x H)
(w/o Bracket)
Weight (Approximate)
150 g (0.33 lb)
I Specifications
Lens Angle
Storage
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
100 mm × 85 mm × 38 mm (3.6" × 3.5" × 2.8")
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
14
J Cautions
Safety Instructions
These instructions are intended to ensure that users can use the product correctly to avoid danger or
property loss.
Cautions
Injury or equipment damage may occur if any of the cautions are neglected.
•
In the use of the dashcam, you must be in strict compliance with the local laws and regulations.
•
You are recommended to install the dashcam near the rear mirror to ensure the dashcam can record
with the best road view. DO NOT install the dashcam in a location that will block the driver’s sight. Keep
the user manual for future reference. See initial connection of dashcam in the user manual.
•
Purchase the microSD (TF) card from a legal channel. To ensure safe and stable data transmission, it is
recommended to use a microSD (TF) card of V30 or above.
•
Format the new microSD (TF) card before using the card.
•
To protect the microSD (TF) card from damage, shut down the dashcam before inserting and pulling out
the microSD (TF) card.
•
Operating temperature is from -20° to 70° C (-4° to 158° F).
•
To protect the dashcam, DO NOT use it in high temperature, low temperature, or high-humidity
environments. Protect the dashcam from rain and dust.
•
This Manual is subject to updates. The dashcam functions may vary by model.
•
The device’s driving assistance function only sends alarm or warning to the driver and cannot replace
the driver’s judgment. DO NOT rely only on the driving assistance function.
15
Trouble
Solution
K Troubleshooting
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
•
Clean the windshield before installation.
The dashcam falls off easily
Starting the dashcam failed
The dashcam
powers off easily
Recording is abnormal
and indicator is unlit
Recording is blurred
•
Check that the 3M adhesive pad is tightly adhered to the electrostatic
film before installation.
•
Check whether the vehicle is started and the power supply is normal.
•
Check whether the car charger is tightly connected.
•
Restore to defaults: Hold the RESET button until the startup music is
heard.
•
Make sure the power cord is in good condition.
•
Make sure the power cord is tightly connected to the appropriate
interfaces.
•
Make sure that the dashcam started up successfully. Check that the
microSD (TF) card is inserted. Check the microSD (TF) card status, e.g.,
its format and its lifespan. Change the microSD (TF) card if there are
problems.
•
Make sure the protective film has been removed.
•
Check that the windshield and the dashcam lens are clean.
Recording is muted
Dashcam reboots itself
Mobile phone cannot
connect to the dashcam
The mobile phone cannot
display recordings
The microSD (TF) card is
not detected when
connecting the dashcam
to a computer with the
supplied power cord
•
Set audio settings on the device or turn on sound recording in the
HikDashcam app.
•
Turn on sound through the dashcam’s audio control function.
•
Check that the car charger is tightly connected. Check whether the
car charger is equipped with a 5 VDC, ≥2 A power supply interface.
•
Make sure the HikDashcam app is installed. Re-pair the dashcam to
the app.
Check the player or your phone system. Connect the microSD (TF) card to
your computer and display the recordings.
The dashcam does not support data transmission, and the supplied power
cord is only for charging.
If you need to transfer data, connect the microSD (TF) card to your
computer.
16
K Troubleshooting (continued)
Check interference from surrounding Wi-Fi signals. Use the dashcam in an
Connecting to Wi-Fi
takes a long time
Dashcam Wi-Fi
password is forgotten
environment where there is less interference.
Shut down unnecessary programs and apps on your phone to release
some resources for the HikDashcam app, then reconnect the Wi-Fi.
The default password is 1234567890. If you have revised the password,
reset the password by doing the following:
Hold the RESET button on the dashcam until the startup music is heard,
the dashcam will be restored to the defaults.
Go to the HikDashcam app’s Wi-Fi connection interface.
Select the Wi-Fi SSID, and log in with the default password
1234567890.
HikDashcam AE-DC8322-G2PRO User Manual UM AE-DC8322-G2PRO 032922NA
•
Check whether the GPS function is enabled. Normally, the GPS function
is enabled by default. Make sure the device is not in a location with a
weak signal or no signal, such as underground garage.
No GPS signal
•
Make sure there is no metal around the device because metal can
interfere with the GPS signal.
•
Make sure the location where the device is installed has good GPS
reception.
Loading...
