Page 1
Set up
QUICK START GUIDE
Page 2
What’s in the box
CUSTOMER SUPPORT success.highfive.com
Highfive Device
Ethernet Cable HDMI Cable Power adaptor Optional wall mount
Page 3
Device overview
HD Camera
4 Noise cancelling microphones
Foldable hinge and stand
Page 4
Device overview
Power HDMI Audio line out
Reset
Ethernet
Page 5
Installation
1. 2.
3. 4. 5.
3.2.1.
Decide where to position Highfive device.Recommended
positioning is as close to eye level as possible
Set on top of TV
Adjust hinge so that it holds the device
securely to back of TV
Plug the power adaptor into (1) and
connect to the Internet with the Ethernet
cable plugged into (2). Finally, connect a
TV to Roombox using the HDMI cable
plugged into (3).
If positioning on top of TV, open hinge
On your TV
On the wall
(optional wall mount)
FRONT
Page 6
Getting started
1.
2.
4. 6.
Device will turn on automatically
3.
Follow instructions on the screen
When asked to set up device, enter
code that appears on TV screen
You are now ready to Highfive!
5.
Name your device
Using a laptop or mobile device,
navigate to setup.highfive.com
Page 7
Additional Information
WARNING
To avoid risk of overheating and burns:
Use indoors only, between 32-95°F (0-35°C)
Keep out of direct sunlight
Do not set anything on top of or cover device
Do not block airflow to device
Device may become hot to the touch, especially during calls
If your TV is warm to the touch, it’s recommended that you
place device below TV or use included bracket
To avoid risk of fire and shock:
Use only the provided power adapter
Do not get device or power adapter wet
Do not place on or near flammable items
To avoid damage or injury:
Make sure device is securely mounted
Do not tamper with or open device
If you have any questions about these guidelines,
visit http://success.highfive.com
Highfive device is not rated for Ingress Protection (IP) so
should only be used indoors
Highfive Limited Warranty
Highfive Technologies, Inc. (“Highfive”) warrants this
Highfive-branded hardware product against manufacturing
defects one (1) year from the original date of purchase
(“Warranty Period”). In the event that a valid claim is
received within the Warranty Period, Highfive will, at its sole
discretion, either (1) repair the defect free of charge, (2)
replace the product with a new or refurbished product
which is at least functionally equivalent to the original
product, or (3) refund the purchase price of the product.
Damage resulting from use, accident, or normal wear and
tear is not covered
by this or any warranty.
