HID Global OFR100 User Manual

FlexPass OFR100

OPERATING AND

INSTALLATION MANUAL

FlexPass OFR100

Open Format Reader

K02000-000 - 1 - 06/29/01

FlexPass OFR100

1. Important Safety Instructions 3

Table of Contents

2. Product Description 3

3. Features 4

4. Identifying Supplied Parts 4

5. Specification 4

6. Installation 5

7. Wire Color Coded & Wiring 6

8. Wire Connection to A Host/Controller 6

9. Wire Connection to SDC1000 7

10. Operation 7

11. FCC Registration Information 8

12. Warranty and Service 8

K02000-000 - 2 - 06/29/01

FlexPass OFR100

1. Important Safety Instructions

When using your FlexPass OFR100, basic safety precautions should always be followed to reduce
the risk of fire, electrical shock, and injury to persons. In addition, the following should also be
followed:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. If necessary, use
mild soap.

4. Do not use this product near water, such as bath-tub, wash bowl, kitchen sink, laundry tub, in
a wet basement, or swimming pool.

5. This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your installation site, consult your
dealer or local power company.

6. Never push objects of any kind into this product or through the cabinet slots as they may touch
voltage points or short out parts that could result in fire or electric shock. Never spill liquid of
any kind on the product.

7. To reduce the risk of electric shock, do not disassemble this product by yourself, but take it to
qualified service whenever service or repair is required.

8. Unplug this product from the Direct Current (DC) power source and refer to qualified service
personnel under these conditions:

a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled on the product.
c. If the product does not operate normally after following the operating instructions in this

manual.

d. If the product exhibits a distinct change in performance.

2. Product Description

The FlexPass OFR100 is an elegant looking reader which can be mounted to metal door frame

(mullion) or any flat wall surface. The FlexPass OFR100 uses an electronic module in epoxy

potting that ensures successful operation even in harsh environments. Two-color LED (green and

red) and built-in beeper sound provide accurate and reliable system operations.

K02000-000 - 3 - 06/29/01
