HID Global IDENTICLASSA User Manual

15370 Barranca Parkway Irvine, CA 92618

identiCLASS®

Developer Tool Kit

USER GUIDE

October 2010

Document ID: 3034-902, Rev A.0

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement,

please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106

.

identiCLASS Developer Tool Kit User Guide

Copyright / Trademarks

of HID Global Corporation in the U.S. and other countries.

Version History

Date Author Description

October 12, 2010 SH Initial version Rev A.0

Document Version

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

1 Overview

1.1 Introduction

identiCLASS is a universal e-Government reader platform designed for integration into OEM equipment, providing contact or contactless reading of electronic documents. For example: Electronic Passports, Electronic National ID Cards and Electronic Driver’s Licences.

The identiCLASS Developer Tool Kit contains everything a customer needs to integrate identiCLASS into their systems. Included are two types of Reader boards: a small footprint board for space-restricted or mobile devices using an external antenna, and a larger board with built-in antenna for terminals. In addition, included are all the accessories such as cables, drivers and software needed to complete the task.

1.2 About this Guide

This user guide describes:

 The components supplied in your identiCLASS Developer Tool Kit.  How to choose the components you need for your application and example

configurations.

 How to connect the components which you will be using.  How to integrate the identiCLASS reader with your equipment, including tips on

installation.

 Board dimensions and mounting dimensions.  Using the Software Configuration Tool to configure parameters within the

identiCLASS reader.

1.3 Related Documents

Source Description

HID identiCLASS Quick Start Guide HID identiCLASS Product Data Sheet HID identiCLASS Software Configuration Tool User Guide HID identiCLASS Software Developer Guide

1.4 Ordering

See the identiCLASS How to Order Guide.

1.5 RFID Standards Supported

identiCLASS supports ISO 14443A, ISO 14443B, ISO15693 RFID standards.

October 2010 Page 3 of 24

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

2 What’s in the Box

The box is divided into four layers. Described are the components of each layer.

Layer 1

 sample e-passport (A)  one sample dual-interface card (ID card) (B)  one USB Flash Drive containing drivers, software, documentation

and release notes C)

Layer 2

 identiCLASS 3300 Reader Core (A)  identiCLASS smart card adapter – ID1 full card size (B)  identiCLASS smart card adapter – ID0 SIM card size (C)  15cm smartcard adapter cable (D)

Layer 3

 identiCLASS 3500 Reader Board (A)  identiCLASS ID1 antenna (B)  identiCLASS ID3 antenna (C)  10cm antenna cable (D)

Layer 4

 USB cable

Page 4 of 24 October 2010

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

3 Choose the Components

3.1 3500 Reader Board (DG 3500A00)

The identiCLASS 3500 Reader Board has:

 One internal antenna  Connections for one or two external antennas  Internal SAM socket  USB connection  FCC modular approval is planned for release in late 2010. See identiCLASS

microsite at www.hidglobal.com/main/identiclass

for the latest information.

The 3500 Reader Board reads contactless cards/passports using its built-in antenna. Connect the 3500 Reader Board to one or two external antennas, either large (ID3) or small (ID1), see Example Configurations. The 3500 Reader Board is capable of reading ID0 credentials through

il

the bu

October 2010 Page 5 of 24

t-in SAM socket.

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

3.2 3300 Reader Core (DG 3300A00)

The identiCLASS 3300 reader core has:

 One connection to an external antenna  One connection to a smart card adapter  USB connection  small size for use in mobile / hand-held devices

The 3300 Reader Core reads contactless cards/passports using an external antenna, either large (ID3) or small (ID1). Connect the 3300 Reader Core to an external smart card adapter which enables it to read either full-size contact cards or SIM-size contact cards, see Example Configuration

s. Use

card adapter at the

the 3300 Reader Core with both a contactless antenna and a contact smart

same time.

3.3 ID1 Small Antenna (4090A01)

The identiCLASS ID1 Small Antenna provides reading of contactless passports/credentials. It can be connected to the identiCLASS 3500 Reader Board or to the identiCLASS 3300 Reader Core. Use the ID1 Small Antenna on its own, or mounted next to another antenna to enable reading of contactless cards/passports in whichever orientation they are presented, see Example Configurations.

Page 6 of 24 October 2010

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

3.4 ID3 Large Antenna (4090A02)

The identiCLASS ID3 Large Antenna provides reading of contactless passports/credentials. Connect the ID3 Large Antenna to the identiCLASS 3500 Reader Board or to the identiCLASS 3300 Reader Core. Its large window enables an optical reader to be mounted in the center. Use the ID3 Large Antenna on its own, or mounted next to another antenna to enable reading of contactless passports/credentials in whichever orientation they are presented, see Example Configuration

s.

October 2010 Page 7 of 24

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..

identiCLASS Developer Tool Kit User Guide

3.5 ID1 Full-Size Smart Card Adapter (4093A01)

The identiCLASS Full-Size Smart Card Adapter reads contact cards using an ISO 7816 compliant interface. Connect the ID1 Full-Size Smart Card Adapter to the identiCLASS 3300 Reader Core, see Example Configurations.

3.6 ID0 SIM Card Adapter (4093A02)

The identiCLASS SIM-size smart card adapter reads ID0 credentials through the built-in SAM socket. Connect the ID0 SIM Card Adapter to the identiCLASS 3300 Reader Core, see Example Configurations.

Page 8 of 24 October 2010

HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 15370 Barranca Pkwy, Irvine, CA 92618-3106..
