INTEGRATED FINANCIAL INSTANT ISSUANCE (Fii) SOLUTIONS

HID FARGO®
DTCii Plus

DIRECT-TO-CARD FINANCIAL PRINTER / ENCODER BENEFITS:

 Instantly issue cards and boost activation and customer loyalty. The DTCii Plus helps elevate

activation to 100% and shift first transaction to a mere day or two af ter issuance.

 Safeguard from cyber attacks. With no dedicated PC required, the DTCii Plus is more secure and

protected from common networked PC vulnerabilities such as malware installation and sning
attacks.

 Enhance productivity with multiple input hoppers and built-in exception feed . Multiple card input

hoppers streamline production, enabling uninterrupted productivit y while the exception feed allows
for manual introduction of a single card into the printer for unique print jobs.

 Enjoy ease of use. Ecient set-up, loading and printing with all-in-one, pre-loaded print ribbon and

card cleaning cartridge (EZ), and SmartScreen™ graphical display.

SECURITY FEATURES:

 Hardware locks for input hoppers,

card reject bin and consumable
doors

 Kensington® Combination Lock

and Security Cable slot for
physically securing the printer to a
countertop

 TLS 1.2 encryption

 Output hopper card concealment

The HID® FARGO® DTCii Plus Financial Card
Printer/ Encoder makes instant issuance practical
and aordable for a wide range of financial cards,
helping you deliver an outstanding customer
experience with speed, convenience and security.

With the DTCii Plus, branch personnel can hand a
new financial card to a customer in minutes. There
are no worries about cards being lost or stolen in
the mail. Instant issuance with the desktop -based
DTCii Plus means that your customers can start
using their cards immediately — a plus for your
institution.

Creating high-quality, visually rich, and durable
financial cards on demand has never been easier
or more aordable. The DTCii Plus prints financial
cards on both sides and writes card data with its
standard magnetic, contact and contactless smart
card encoders — producing the new generation of
financial cards with no embossed text on the front
and increasingly, a contact or contactless smart
chip inside.

As a driverless printer, the DTCii Plus is truly
unique in that it does not require the use of a
dedicated PC, making it invincible to would-be

cyber criminals. Only the DTCii Plus is entirely
invulnerable to PC-based hacker attacks and
security breaches such as malware installation or
the sning of sensitive cardholder information.
The printer also supports the secure global
Europay MasterCard Visa (EMV) standard,
ensuring that cards are interoperable with the
global payment infrastructure and provide greater
protection from fraud.

Financial institutions are embracing the
convenience and flexibility of the DTCii Plus to
cost-eectively produce secure and durable
financial cards. Eliminating delays and security
concerns, the DTCii Plus puts financial card
issuance where the customer is, instantly — raising
customer service and loyalty to a new level. By
eliminating the traditional problems of cost,
logistics and security, HID Global continues to
make instant financial card issuance practical,
aordable and profitable — with the HID FARGO
DTCii Plus Financial Card Printer/Encoder.

hidglobal.com

KEY FEATU R ES:

 Driverless printer for increased security
 SmartScreen™ graphical status display with easy-to-follow

prompts

 Convenient exception feed for manual introduction of a

single card for unique print jobs

ENCODING OPTIONS

(Supported smart card and magnetic stripe technologies):

 Contactless 13.56 MHz 14443 A/B, ISO 15693) read/write

encoder

 Contact smart card encoder reads from and writes to all

ISO7816 1/2/3/4 memory and microprocessor smart cards
(T=0, T=1) as well as synchronous cards

 ISO format magnetic stripe encoding, dual high- and low-

coercivity, tracks 1, 2, and 3

 Supported magnetic encoding modes: ISO format mag

encoding, custom encoding, raw binary encoding

SPECIFICATIONS

Print Method Dye Sublimation / Resin thermal transfer

Resolution 300 dpi (11.8 dots/mm) continuous tone

Colors Up to 16.7 million / 256 shades per pixel

Easy-to-use pre-loaded ribbons within disposable ribbon cartridges:

Print Ribbon Options

Print Speed** 8 seconds per card (KO*); 24 seconds per card (YMCKOK*)

Accepted Standard Card Sizes CR-80 (3.375˝ L x 2.125˝ W / 85.6 mm L x 54 mm W)

Print Area CR-80 edge-to-edge (3.36˝ L x 2.11˝ W / 85.3 mm L x 53.7 mm W)

Accepted Card Thickness .027" (30 mil) - .043" (40 mil)

Accepted Card Types Press polished PVC, Composite (PET/PVC with PVC as an outer layer), Laminated PVC (credit card construction)

Input Hopper Card Capacity Dual-input card hopper (200 cards 100/ea)

Output Hopper Card Capacity Up to 20 cards (.030˝ / .762 mm)

Reject Hopper Card Capacity Up to 100 cards (.030" / .762mm)

Card Cleaning Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon change

Memory 32 MB RAM

Software Drivers Driverless printer, SDK development required

Interface Ethernet with internal print server

Operating Temperature 65° to 80° F / 18° to 27° C

Humidity 20% to 80% non-condensing

Dimensions 10.05˝ H x 22.94˝ W x 10.27˝ D / 255.3 mm H x 582.7 mm W x 260.9 mm D

Weight 11lbs / 5Kg

Agency Listings

Supply Voltage 120-240Vac, 50-60Hz, 1.6 Amps max.

Supply Frequency 50 Hz / 60 Hz

Warranty Printer – three years; Printhead – three years

Connectivity and Encoding

Display User friendly, SmartScreen™ graphical display

Printer Security

U

I

N

N

E

E

G

 EZ YMCKOK* Cartridge: Full-color with two resin black panels and overlay panel, 200
 EZ KO* Cartridge: Premium black and clear overlay panel, 500 images
 EZ SOK Cartridge: Metallic Silver with clear overlay panel and black resin panel, 250 images

Safety: UL 60950-2, CSA C22.2 (60950-07), and CE; EMC: FCC Class A, CE
(EN 55022 Class A, EN 55024)

Single wire Ethernet for inline printing and encoding. Supported smart card and magnetic stripe technologies:
Contact smart card encoding ISO7816 1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as well as
synchronous cards, Contactless 13.56 MHz ISO 14443 A/B, ISO 15693 read/write encoder, ISO format magnetic stripe
encoding, dual high- and low-coercivity, tracks 1, 2, and 3, Supported magnetic encoding modes: ISO format mag
encoding, custom encoding, raw binary encoding.

Hardware locks for input hoppers, card reject bin and consumable doors, Kensington® Combination Lock and Security
Cable slot, TLS 1.2 encryption, Concealed output hopper.

* Indic ates the ribbon type and th e number of ribbon pane ls printe d where Y=yellow, M=magent a, C=cyan, K= resin black, O=overl ay,
S= resin s ilver
** Print speed indica tes an app roximate p rint spe ed and is measured from th e time a card drops into the outp ut hopper to the tim e the
next ca rd drops into the output hopper. Print speeds do not incl ude encoding time.

p

s

r

t

o

c

d

u
