40-Gigabit Ethernet transceiver modules compatibility matrix ··················· 12
40-Gigabit Ethernet transceiver modules ······················································································· 12 Switching minimum software release requirements ········································································· 13
HPE FlexFabric 12900E switch series minimum software version requirements ······························ 13 HPE FlexFabric 12900 switch series minimum software version requirements ································ 20 HPE FlexFabric 7900 switch series minimum software version requirements ································· 24 HPE 6125XLG Blade switch series minimum software version requirements ·································· 26 HPE FlexFabric 5980 switch series minimum software version requirements ································· 27 HPE FlexFabric 5950 switch series minimum software version requirements ································· 27 HPE FlexFabric 5945 switch series minimum software version requirements ································· 32 HPE FlexFabric 5940 switch series minimum software version requirements ································· 34 HPE FlexFabric 5930 switch series minimum software version requirements ································· 39 HPE FlexFabric 5900 switch series minimum software version requirements ································· 46 HPE FlexFabric 5710 switch series minimum software version requirements ································· 51 HPE FlexFabric 5700 switch series minimum software version requirements ································· 53
Document conventions and icons ······················································ 57
Conventions ··························································································································· 57 Network topology icons ············································································································· 58
Support and other resources ···························································· 59
Accessing Hewlett Packard Enterprise Support ·············································································· 59 Accessing updates ··················································································································· 59
Websites ························································································································· 60 Customer self repair ··········································································································· 60 Remote support ················································································································ 60 Documentation feedback ···································································································· 60
Index ··························································································· 62
i

Overview

Transceiver module type
Connector type
QSFP+ transceiver modules
NOTE:
transceiver modules and cables, contact HP E technical support or
transceiver modules and cables vary by HPE device s. For the transceiver modules
compatibility matrix".
This document describes 40-Gigabit transceiver modules and cables available for HPE Comware-based devices.

List of 40-Gigabit transceiver modules and network cables

QSFP+ optical transceiver modul e MPO/LC QSFP+ copper cable (for interconnecting QSFP+ ports) N/A QSFP+ to SFP+ copper cable (for connect i ng one 40-Gigabit QSFP+
port to four 10-Gigabit SFP+ ports) QSFP+ active optical cable
CFP transceiver modules
40-Gigabit CFP optical transceiver module LC
N/A
HPE 40-Gigabit transceiver modules and cables a re subject to change over time. For the most
recent list of HPE 40-Gigabit marketing staff.
The available
and cables available for a device, see the install ation guide for the device. For the 40-Gigabit transceiver modules and cables for a switch, see "40-Gigabit Ethernet transceiver modules

About optical transceiver modules

Optical transceiver modules (also called fiber transceiver modules) transmit signals over optical fibers and are suitable for long distance transmission.
The following information explains the major specifications of a fiber transceiver module.

Data rate

Data rate is the number of bits transmitted per second. Data rate is typically measured in Gigabits per second (Gbps).

Transmission distance

The transmission distance of optical t ran sceiver modules is divided into short a nd long -range ty pes. Typically, a distance of 2 km (1.24 miles) or below is short-range ty pe and a dist ance of 10 km (6.21 miles) is long-range type.
1
Transmission distances supported by optical transceiver modules are mainly limited by signal
Fiber grade
Fiber diameter (μm)
Modal bandwidth at 850 nm (MHz*km)
attenuation and dispersion suffered during the transmission of fiber signals over fibers.
Signal attenuation occurs because of absorption, dispersion, and leakage over the media as light travels through optical fibers. This attenuation increases in direct ratio to transmission distance.
Dispersion occurs because a fiber transmits light with dif ferent wavelengths at different speeds. Light with different wavelengths r eaches the receiving end at different t ime. This results in spread and blurred pulses.

Central wavelength

Central wavelength represents the wave band used for optical signal transmission. The following central wavelengths (wave bands) are available for common optical transceiver modules: 850 nm, 1310 nm, and 1550 nm.
The 850 nm wave band is used for short-reach transmission.
The 1310 nm and 1550 nm wave bands are used for middle-reach an d long-haul transmissions.

Fiber

Fiber types
Fibers are classified into multimode fibers and single-mode fibers.
Multimode fibers Multimode fibers (MMFs) have thicker fiber cor es than single-mode fibers and can transport
light in multiple modes. However, the intermo dal dispersion is greater and worsens as the transmission distance increases.
Multimode fibers can be classified into mult i ple grades according to their diameters and modal bandwidth, as shown in Table 1. The modal bandwidth is a comprehensive index that reflects the optical characteristics of a multim ode fiber. The modal bandwidth of a multimode fiber is equal to the modulation freque ncy of the maximum modulation f requency pulse that can pass a fiber × the fiber length.
International Telecommunication Union (IT U) defines multimode fiber types in its G series standards. The m ost commonly used multimode fiber is defined in the ITU G.651 standard. The G.651-compliant fiber transmits light in th e wav el ength ran ge of 8 00 nm t o 90 0 nm or 1 200 nm to 1350 nm.
Table 1 Multimode fiber grades
OM3 50/125 2000 OM4 50/125 4700
Single-mode fibers Single-mode fibers (SMFs) have a small core size (typically 9 μm or 10 μm) and can transmit
light in only one mode. Single-mode fibers suff er little intermodal di spersion and are suitabl e for long-haul communication. Single-mode fibers transmit light at the central wavelength of 1310 nm or 1550 nm.
Telecommunication Industries Alliance (TIA)/Electronic Industries Alliance (EIA) defines that single-mode fibers use yellow outer jackets wit h an " SM" mark.
ITU defines single-mode fiber types in its G series standards. The most commonly used single-mode fibers are defined in ITU G.652 and G.655 standards. Table 2 describes features of the G.652 and G.655-compliant fibers.
2
Table 2 Features of G.652 and G.655-compliant fibers
Single-mode fiber type
Wavelength (nm)
Features
Applications
CAUTION:
Cover the connector with a dust cap when it is not connected to optical fibers.
G.652-compliant fiber (standard single-mode fiber)
G.655-compliant fiber (non-zero dispersion shifted fiber)
Fiber diameter
Fiber diameter is expressed as core diameter/cladding diameter, in μm. For example, 9/125 μm represents a fiber core diameter of 9 μm and a fiber cladding diameter of 125 μm.
As a best practice, use the following fiber diamet ers for the HPE Comware-based devices:
G.652 standard single-mode fiber9/125 μm.
G.655 single-mode fiber9/125 μm.
G.651 standard multimode fiber50/125 μm.

Connector

Connectors connect transceiver modules to the transmission media. The following information describes the connectors used by the transceiver m odules for the HPE Comware-based devices.
1260 to 1360
1530 to 1565
1530 to 1565
Zero dispersion at 1310 nm.
Near-zero dispersion around 1550 nm.
Connecting transceiver modules with a central wavelength of 1310 nm or 1550 nm.
1550-nm wavelength-division multiplexing (WDM) transmissions.
Lucent connector or local connector (LC)
Figure 1 LC connector
Multi-fiber Push On connector (MPO)
Figure 2 MPO connector
HPE transceiver modules use only female M PO connectors, whic h have guide holes in the e nd face.
3
MPO connectors are classified into the followin g types based on the polish type:
Fiber 1 Fiber 12Key
Guide hole
Fiber 1 Fiber 12Key
Guide hole
Fiber 13 Fiber 24
Physical contact (PC)—End face polished flat.
Angle-polished contact (APC)—End face polished with an angle, typically 8°.
MPO connectors are available with 12 fibers (see Figure 3) or 24 fibers (see Figure 4).
Figure 3 End face of a 12-fiber connector
Figure 4 End face of a 24-fiber connector

Optical parameters

The following are the major optical parameters:
Transmit power —Transmit power is the power at which the transmitter of an optical transceiver module transmits optical signals, in dBm.
Receive power—Receive power is the power at whic h the re ceiver of a optical transceiver module receives optical signals, in dBm.
The transceiver module specifications in this guide provide the average transmit and receive power ranges.
4

QSFP+ transceiver modules

(nm)
(µm)
(MHz*km)
Optical parameters (dBm)
Transmit power
Receive power

QSFP+ optical transcei ver modules that use MPO connectors

Figure 5 QSFP+ optical transceiver module that uses MPO connectors

Models and specifications

QSFP+ optical transceiver modules provide a transmission rate of 40 Gbps and use MPO connectors.
Table 3 Specifications for QSFP+ optical transceiver modules that use MPO connectors (1)
Product code
JG325B
JG709A
HPE description
HPE X140 40G QSFP+ MPO SR4 Transceiver
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
Central wavelength
850 MMF 50/125
850 MMF 50/125
Fiber mode
Fiber diameter
Modal bandwidth
2000
4700
2000
4700
Transmission distance
100 m (328.08 ft)
150 m (492.12 ft)
300 m (984.25 ft)
400 m (1312.33 ft)
Table 4 Specifications for QSFP+ optical transceiver modules that use MPO connectors (2)
Product code
JG325B
JG709A
HPE description Connector
HPE X140 40G QSFP+ MPO SR4 Transceiver
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
MPO (PC polished, 12-fiber)
MPO (PC polished, 12-fiber)
–7.6 to 0 –9.5 to +2.4
–7.6 to 0 –9.9 to +2.4
5
NOTE:
The 40G QSFP+ ports of the JG325B and JG709A optical transceiver modules can be split into
optical
module and SFP+ optical transceiver modules to be co nne cted mu st be the same in
installation guide that comes with the device.
(nm)
(µm)
(MHz*km)
Optical parameters (dBm)
Transmit power
Receive power
HPE X140 40G QSFP+ LC LR4L 2km
four channels. You can connect a 40G QSFP+ port to four 10G SFP+ ports. The QSFP+ transceiver specifications, including central wavelength and fiber type.
Support for QSFP+ port splitting depends on the device model. For more information, see the

QSFP+ optical transceiver modules that use LC connectors

Figure 6 QSFP+ optical transceiver module that uses LC connectors

Models and specifications

QSFP+ optical transceiver modules pro vide a tra nsmissi on rate of 40 Gb ps and use LC connectors.
Table 5 Specifications for QSFP+ transceiver modules that use LC connectors (1)
Product code
JL286A
JG661A
JL306A
HPE description
HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver Module
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
Central wavelength
Four lanes:
1271
1291
1311
1331
Four lanes:
1271
1291
1311
1331
Four lanes:
1271
1291
1311
1331
Fiber mode
SMF 9/125 N/A
SMF 9/125 N/A
SMF 9/125 N/A
Fiber diameter
Modal bandwidth
Transmission distance
2 km (1.24 miles)
10 km (6.21 miles)
40 km (24.85 miles)
Table 6 Specifications for QSFP+ transceiver modules that use LC connectors (2)
Product code HPE description
JL286A
–10 to +2.3 per lane –11.5 to +2.3 per lane
6
Product code HPE description
Optical parameters (dBm)
Transmit power
Receive power
SM Transceiver
(nm)
(µm)
(MHz*km)
Optical parameters (dBm)
Transmit power
Receive power
JG661A
JL306A
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver Module
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
–7 to +2.3 per lane –13.7 to +2.3 per lane
–2.7 to +4.5 per lane –21.2 to –4.5 per lane

QSFP+ BIDI optical transceiver modules

Figure 7 QSFP+ BIDI optical transceiver module

Models and specifications

QSFP+ BIDI transceiver modules provide a transmission rat e of 40 Gbps and use LC connectors.
Table 7 Specifications for QSFP+ BIDI transceiver modules (1)
Product code
JL251A
JH375A (end of sale)
HPE description
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
HPE X140 40G QSFP+ LC SWDM4 300m MM Transceiver
Central wavelength
Two lanes:
850
900
Four lanes:
850
880
910
940
Fiber mode
MMF 50/125
MMF 50/125
Fiber diameter
Modal bandwidth
2000
4700
2000 240m (787.40 ft)
4700
Transmission distance
100 m (328.08 ft)
150 m (492.12 ft)
350m (1148.29 ft)
Table 8 Specifications for QSFP+ BIDI transceiver modules (2)
Product code HPE description
JL251A
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
–4 to +5 –6 to +5
7
Product code HPE description
Optical parameters (dBm)
Transmit power
Receive power
NOTE:
The operating case temperature of
JL251A is in the range of 10°C to 70° C (50°F to 158°F ). The performance, signal transmitting and receiving capability, and link status of the transceiver module deteriorate when the case temperature is out of this range.
code
JH375A
HPE X140 40G QSFP+ LC SWDM4 300m MM Transceiver
the

QSFP+ copper cables

Figure 8 QSFP+ copper cable
–7.6 to +3 per lane –9 to +3 per lane

Models and specifications

Table 9 Specifications for QSFP+ copper cables
Product
JG326A
JG327A
JG328A
HPE description Cable length Data rate Remarks
HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
1 m (3.28 ft)
3 m (9.84 ft)
5 m (16.40 ft)

QSFP+ to SFP+ copper cables

One end of a QSFP+ to SFP+ copper cable provides a 40-Gigabit QSFP + module, and the other end provides four 10-Gigabit SFP+ modules.
40 Gbps
Used for interconnecting 40-Gigabit QSFP+ ports.
8
Figure 9 QSFP+ to SFP+ copper cable
code

Models and specifications

Table 10 Specifications for QSFP+ to SFP+ copper cables
Product
JG329A
JG330A
JG331A
HPE description Cable length Data rate Remarks
HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cabl e
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cabl e
HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cabl e

QSFP+ active optical cables

Figure 10 QSFP+ active optical cable
1 m (3.28 ft)
3 m (9.84 ft)
5 m (16.40 ft)
40 Gbps
Used for connecting a 40-Gigabit QSFP+ port to four 10-Gigabit SFP+ ports.
9

Models and specifications

code
Table 11 Specifications for QSFP+ active optical cables
Product
JL287A HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable 7 m (22.97 ft)
JL289A HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable 20 m (65.62 ft)
HPE description Cable length Data rate
40 Gbps JL288A HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable 10 m (32.81 ft)
10

CFP transceiver modules

(nm)
(µm)
Optical parameters (dBm)
Transmit power
Receive power
Figure 11 CFP transceiver module

Models and specifications

CFP transceiver modules provide a t ransmission rate of 40 Gbps and use LC connectors.
Table 12 Specifications for CFP transceiver modules (1)
Product code
JC857A
HPE description
HPE X140 40G CFP LC LR4 10km SM Transceiver
Central wavelength
Four lanes:
1271
1291
1311
1331
Table 13 Specifications for CFP transceiver modules (2)
Product code
JC857A
HPE description
HPE X140 40G CFP LC LR4 10km SM Transceiver
Fiber mode
SMF 9/125
–4 to +3 per lane –11.5 to +3 per lane
Fiber diameter
Transmission distance
10 km (6.21 miles)
11

40-Gigabit Ethernet transceiver modules

Product code
Transceiver module
Description
HPE X2A0 40G QSFP+ to QSFP+
LSWM2QSFPPF,40G QSFP+ to 40G QSFP+
compatibility matrix
40-Gigabit Ethernet transceiver modules
Before you install, configure, or upgrade a device with HPE 40-Gigabit Ethernet transceiver modules, always see the device's release notes for latest informat ion. This comp atibility matri x does not replace or supersede the release notes.
Table 14 40 Gigabit Ethernet transceiver modules
QSFP+
40G QSFP+
JG661A
JG709A
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
Transceiver,LSTM2QSFP0,40GBASE QSFP+ Optical Transceiver Module,(40GBASE-LR4,10km,LC)
40G QSFP+ Transceiver,LSWM2QSFPP,40GBASE QSFP+ Optical Transceiver Module,(40GBASE-CSR4,300m,MPO)
JG325B
JL251A
JL286A
JL306A
JG326A
JG327A
JG328A
JG329A
JG330A
JG331A
HPE X140 40G QSFP+ MPO SR4 Transceiver
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
LSWM4QSFPP,QSFP+ 40G Optical Transceiver Module,(850nm,100m,SR4)
LSWM1QSFPPJ,40G QSFP+ BiDi Transceiver,(850nm,100m,SR)
LSXM2QSFPPD,40G QSFP+ Optical Transceiver Module,(1310nm, 2km,LR4L,LC)
LSVM2QSFPPJ,40G QSFP+ Optical Transceiver Module,(1310nm,40km,ER4,WDM,LC)
LSWM2QSTK0,40G QSFP+ Cable,1m
LSWM2QSTK1,40G QSFP+ Cable,3m
LSWM2QSTK2,40G QSFP+ Cable,5m
LSWM2QSTK3,40G QSFP+ to 4x10G SFP+ Cable,1m
LSWM2QSTK4,40G QSFP+ to 4x10G SFP+ Cable,3m
LSWM2QSTK5,40G QSFP+ to 4x10G SFP+ Cable,5m
JL287A
JL288A
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable
12
LSWM2QSFPPE,40G QSFP+ to 40G QSFP+ Active Optical Cable,7m
Product code
Transceiver module
Description
10m Active Optical Cable
Active Optical Cable,10m
JL289A
release
support
version
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable
LSWM2QSFPPG,40G QSFP+ to 40G QSFP+ Active Optical Cable,20m

Switching minimum software release requirements

HPE FlexFabric 12900E switch series minimum software version requirements

Minimum software
Switch or module Transceiver module (Product code)
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr (JG661A)
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Xcvr (JG709A)
HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2606 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A) HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2606
HPE FlexFabric 12900E 48-port 1/10GbE SFP+ 2-port 100GbE QSFP28 HB Module (JH360A)
HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2606 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical
Cable (JL287A) HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical
Cable (JL288A)
DDM
YES R2606
YES
NO
NO
NO
NO
NO
NO
Release
R2606
R2606
R2606
R2606
R2606
R2606
R2606
HPE FlexFabric 12900E 48-port 40GbE QSFP+ HB Module (JH359A)
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable (JL289A)
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr (JG661A)
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Xcvr (JG709A)
HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2609 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A)
13
NO
YES
YES
NO R2609
R2606
R2606
R2606
Minimum software
release
support
version
Switch or module Transceiver module (Product code)
HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2606 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach
Copper Splitter Cable (JG329A) HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach
Copper Splitter Cable (JG330A) HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach
Copper Splitter Cable (JG331A) HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical
Cable (JL287A) HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical
Cable (JL288A)
DDM
NO R2606
NO
NO
NO
NO
NO
NO
NO
Release
R2606
R2606
R2606
R2606
R2606
R2606
R2606
HPE FlexFabric 12900E 36-port 100GbE QSFP28 HB Module (JH357A)
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable (JL289A)
HPE QSFP/SFP+ Adaptor Kit (655874-B21) NO R2609 HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr
(JG661A) HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m
Xcvr (JG709A) HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2606 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A) HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2606 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2606 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach
Copper Splitter Cable (JG329A)
NO
YES
YES
NO
NO
NO
NO
NO
R2606
R2606
R2606
R2606
R2606
R2606
R2606
R2606
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable (JG330A)
HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable (JG331A)
14
NO
NO
R2606
R2606
Minimum software
release
support
version
Switch or module Transceiver module (Product code)
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable (JL287A)
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable (JL288A)
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable (JL289A)
HPE QSFP/SFP+ Adaptor Kit (655874-B21) NO R2609 HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr
(JG661A) HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m
Xcvr (JG709A) HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2606 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A) HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2609 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A)
DDM
NO
NO
NO
YES
YES
NO
NO
Release
R2606
R2606
R2606
R2606
R2606
R2609
R2606
HPE FlexFabric 12900E 18-port 100G QSFP28/18-port 40G QSFP+ HB Module (JH422A)
HPE FlexFabric 12900E 36-port 40G QSFP+ HB Module (JH437A)
HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable (JG327A)
HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable (JG328A)
HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable (JG329A)
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable (JG330A)
HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable (JG331A)
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable (JL287A)
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable (JL288A)
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable (JL289A)
HPE QSFP/SFP+ Adaptor Kit (655874-B21) NO R2609 HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr
(JG661A) HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m
Xcvr (JG709A) HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2606 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A)
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES
NO
R2606
R2606
R2606
R2606
R2606
R2606
R2609
R2609
R2606
R2606
R2606
15
Minimum software
release
support
version
Switch or module Transceiver module (Product code)
HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2606 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical
Cable (JL287A) HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical
Cable (JL288A) HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical
Cable (JL289A) HPE QSFP/SFP+ Adaptor Kit (655874-B21) NO R2609 HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr
(JG661A) HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m
Xcvr (JG709A)
DDM
NO
NO
NO
NO
NO
NO
YES
YES
Release
R2606
R2606
R2606
R2606
R2606
R2606
R2606
R2606
HPE FlexFabric 12900E 6-port 100G QSFP28/6-port 40G QSFP+ HB Module (JH436A)
HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2606 HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2606 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES E2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach
Copper Splitter Cable (JG329A) HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach
Copper Splitter Cable (JG330A) HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach
Copper Splitter Cable (JG331A) HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical
Cable (JL287A) HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical
Cable (JL288A) HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical
Cable (JL289A)
NO
NO
NO
NO
NO
NO
NO
NO
NO
R2606
R2606
R2606
R2606
R2606
R2606
R2606
R2606
R2606
HPE QSFP/SFP+ Adaptor Kit (655874-B21) NO R2609
16
Minimum software
release
support
version
Switch or module Transceiver module (Product code)
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr (JG661A)
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Xcvr (JG709A)
HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2609 HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2609 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
HPE FlexFabric 12900E 48-port 100GbE QSFP28 HB Module(JH667A)
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A) HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach
Copper Splitter Cable (JG329A) HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach
Copper Splitter Cable (JG330A) HPE X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach
Copper Splitter Cable (JG331A)
DDM
YES R2609
YES R2609
NO R2609
NO R2609
NO R2609
NO R2609
NO R2609
NO R2609
Release
HPE FlexFabric 12900E 18-port 100G QSFP28/18-port 40G QSFP+ HF Module (JH425A)
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable (JL287A)
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable (JL288A)
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable (JL289A)
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Xcvr (JG661A)
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Xcvr (JG709A)
HPE X140 40G QSFP+ MPO SR4 Xcvr (JG325B) YES R2609 HPE X140 40G QSFP+ LC BiDi 100m MM Xcvr
(JL251A) HPE X140 40G QSFP+ LC LR4L 2km SM Xcvr (JL286A) YES R2609 HPE X140 40G QSFP+ LC ER4 40km SM Xcvr (JL306A) YES R2609 HPE X240 40G QSFP+ QSFP+ 1m Direct Attach Copper
Cable (JG326A) HPE X240 40G QSFP+ QSFP+ 3m Direct Attach Copper
Cable (JG327A) HPE X240 40G QSFP+ QSFP+ 5m Direct Attach Copper
Cable (JG328A)
NO R2609
NO R2609
NO R2609
YES
YES
NO
NO
NO
NO
R2609
R2609
R2609
R2609
R2609
R2609
HPE X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable (JG329A)
17
NO R2609
Loading...
+ 45 hidden pages
