DATA SHEET
ARUBA CX 6300 SWITCH
SERIES
PRODUCT OVERVIEW
The Aruba CX 6300 Switch Series is a modern, exible and
intelligent family of stackable switches ideal for enterprise
network access, aggregation, core and data center top of rack
(ToR) deployments. Created for game-changing operational
eciency with built-in security and resiliency, the 6300
switches provide the foundation for high-performance
networks supporting IoT, mobile and cloud applications.
Built from the ground up with a combination of cutting-edge
hardware, software and analy tics and automation tools, the
stackable 6300 switches are part of the Aruba CX switching
portfolio, designed for today’s enterprise campus, branch
and data center networks. By combining a modern, fully
programmable OS with the Aruba Network Analytics Engine,
the 6300 switches provide industr y leading monitoring and
troubleshooting capabilities for the access layer.
A powerful Aruba Gen7 ASIC architecture delivers
performance and robust feature support with exible
programmability for tomorrow’s applications. The Aruba
Virtual Stacking Framework (VSF) allows for stacking of up
to 10 switches, providing scale and simplied management.
This exible series has built-in wirespeed 1/10/25/50GbE
uplinks1 and supports high density IEEE 802.3bt high power
PoE. HPE Smart Rate multi-gigabit Ethernet paves the way
for high speed access points and IoT devices by delivering
fast connectivity and high power PoE using existing cabling.
Modular models oer redundancy and PoE customization
with hot-swappable power supplies and fans. Back-to-front
airow available in switch bundle for hot-cold aisle top-
of-rack (TOR) and out-of-band-management (OOBM) data
center deployments.
Aruba Dynamic Segmentation extends Aruba’s foundational
wireless role-based policy capability to Aruba wired switches.
What this means is that the same security, user experience
and simplied IT management can be enjoyed throughout
the network. Regardless of how users and IoT devices
connect, consistent policies are enforced across wired and
wireless networks, keeping trac secure and separate.
KEY BENEFITS
• Stackable Layer 3 switches with BGP, EVPN,
VXLAN, VRF, and OSPF with robust security and
QoS
• High performance 880 Gbps system switching
capacity, 660 MPPS of system throughput and up
to 200 Gbps stacking bandwidth
• Compact 1U switches with full density HPE Smart
Rate (1/2.5/5GbE) multi-gigabit, 60W PoE and SFP+
models
• Power-to-port switch bundle with back-to-front
airow ideal for data center 1GbE ToR and OOBM
deployments
• Built-in high speed 10GbE/25GbE/50GbE uplinks
• Intelligent monitoring, visibility, and remediation
with Aruba Network Analytics Engine
• One touch deployment with the Aruba CX Mobile
App
• Aruba NetEdit support for automated
conguration and verication
• Aruba Dynamic Segmentation enables secure and
simple access for users and IoT
1
PRODUCT DIFFERENTIATORS
AOS-CX - a modern operating system
The Aruba CX 6300 Switch Series is based on AOS-CX, a
modern, database-driven operating system that automates
and simplies many critical and complex network tasks.
A built-in time series database enables customers and
developers to utilize software scripts for historical
troubleshooting, as well as analysis of past trends. This helps
predict and avoid future problems due to scale, security, and
performance bottlenecks.
Page 2
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Our AOS-CX software also includes Aruba Network Analytics
Engine (NAE) and support for Aruba NetEdit. Because AOS-
CX is built on a modular Linux architecture with a stateful
database, our operating system provides the following
unique capabilities:
• Easy access to all network state information allows unique
visibility and analytics
• REST APIs and Python scripting for ne-grained
programmability of network tasks
• A micro-services architecture that enables full integration
with other workow systems and services
• Continuous telemetry data with WebSocket subscriptions
for event driven automation
• Continual state synchronization that provides superior
fault tolerance and high availability
• All software processes communicate with the database
rather than each other, ensuring near real-time state and
resiliency and allowing individual software modules to be
independently upgraded for higher availability
Aruba Central - unied single pane of glass management
Flexible cloud-based or on-premises management for unied
network operations of wired, WLAN, SD-WAN, and public
cloud infrastructure. Designed to simplify day zero through
day two operations with streamlined workows. Switch
management capabilities include conguration, onboarding,
monitoring, troubleshooting, and reporting.
Aruba Network Analytics Engine - advanced monitoring
and diagnostics
For enhanced visibility and troubleshooting, Aruba’s
NetworkAnalytics Engine (NAE) automatically monitors and
analyzes events that can impact network health. Advanced
telemetr y and automation provide the ability to easily identify
and troubleshoot network, system, application and security
related issues easily, through the use of python agents and
REST APIs.
The Time Series Database (TSDB) stores conguration and
operational state data, making it available to quickly resolve
network issues. The data may also be used to analyze trends,
identify anomalies and predict future capacity requirements.
Aruba NetEdit – automated switch conguration and
management
The entire Aruba CX portfolio empowers IT teams to
orchestrate multiple switch conguration changes for smooth
end-to-end service rollouts. Aruba NetEdit introduces
automation that allows for rapid network-wide changes,
and ensures policy conformance post network updates.
Intelligent capabilities include search, edit, validation (including
conformance checking), deployment and audit features.
Capabilities include:
• Centralized conguration with validation for consistency
and compliance
• Time savings via simultaneous viewing and editing of
multiple congurations
• Customized validation tests for corporate compliance and
network change analysis
• Automated large-scale conguration deployment without
programming
• Network health and topology visibility via Aruba NAE
integration
Note: A separate software license is required to use Aruba
NetEdit.
Aruba CX Mobile App – true deployment convenience
An easy to use mobile app simplies connecting and
managing Aruba CX 6300 switches for any size project.
Switch information can also be imported into Aruba NetEdit
for simplied conguration management and to continuously
validate the conformance of congurations anywhere in the
network. The Aruba CX Mobile App is available for download.
Aruba ASICs - programmable innovation
Based on over 30 years of continuous investment, Aruba’s
ASICs create the basis for innovative and agile software
feature advancements, unparalleled performance and deep
visibility. These programmable ASICs are purpose-built
to allow for a tighter integration of switch hardware and
software within campus and data center architectures to
optimize performance and capacity. Virtual Output Queuing
(VOQ) isolates congestion, prevents Head of Line Blocking
(HOLB) and allows full line rate on outgoing (egress) ports.
Flexible ASIC resources enable Aruba’s NAE solution to
inspect all data, which allows for industry-leading analytics
capabilities. The Aruba CX 6300 is based on the Aruba Gen7
ASIC architecture.
Aruba Dynamic Segmentation – campus and branch
fabric
The Aruba Dynamic Segmentation solution enables seamless
mobility, consistent policy enforcement, and automated
congurations for wired and wireless clients across networks
of all sizes. And it extends these benets to applications
hosted on the data center and the public cloud.
2
Page 3
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
This innovation begins with colorless ports and role-
based micro-segmentation technologies. Colorless ports
allows wired clients to connect to any switch port, with the
conguration automated using Radius-Based Access Control.
This eliminates the need for manual on-boarding of clients,
including IoT devices, onto the network.
Role-based micro-segmentation delivers benets of reduced
subnet and VLAN sprawl, simplied policy denition, and
scales policy enforcement by introducing the concept of
client User Roles. These roles are independent of network
constructs such as VLANs and VRFs, and allows clients to be
grouped into a User Role based on their identity. This allows
the colorless ports technology to be extended to the overlay
fabric, as clients are on-boarded with automatic tunnel
creation based on the associated User Role policy.
Dynamic Segmentation provides much needed scale and
exibility in network design by allowing the stretching
of VLANs and subnets across the entire network. Fabric
overlays oer VXL AN on the data plane and provide the
option of a Multi-Protocol BGP eVPN control plane for large
deployments, or a static Layer 2 control plane for simplied
deployments.
Dynamic Segmentation also eliminates the complexity
of service-chaining and redirection of trac to 3rd party
rewalls. User Role Policy can steer client’s trac on overlay
tunnels (User Based Tunnels) to Aruba’s Policy Enforcement
Firewall for deep-packet inspection and application aware
Layer 7 stateful rewall ltering. After performing this
stateful inspection for any security threats, the trac is
automatically put back on the VXL AN fabric to be delivered to
its destination.
Mobility and IoT performance
The Aruba CX 6300 Switch Series uses a fully distributed
architecture that utilizes the Aruba Gen7 ASICs. This ensures
that our switches oer ver y low latency, increased packet
buering, and adaptive power consumption. All switching
and routing are wire-speed to meet the demands of
bandwidth-intensive applications today and in the future.
Each switch includes the following:
• Up to 880 Gbps in non-blocking bandwidth and up to 660
Mpps for forwarding
• 50GbE uplinks1 and large TCAM sizes ideal for mobility
and IoT deployments in large campuses with several
thousand clients
• Selectable queue congurations that allow for increased
performance by dening a number of queues and
associated memory buering to best meet the
requirements of network applications
VSF Stacking - scale and simplicity
The Aruba Virtual Switching Framework (VSF) allows you to
quickly grow your network using high performance front
plane stacking. Four built-in 50G SFP ports support speeds
of 1GbE, 10GbE, 25GbE and 50GbE1 for a total of up to
200Gbps of stacking throughput per switch. Additional
features include:
• Support for up to 10 switches (or members) in a stack via
chain or ring topology
• Flexibility to create stacks that span longer distances such
as hundreds of meters across campuses to kilometres
between sites using long-range 10/25/50GbE1 transceivers
• Flexibility to mix both modular and xed Aruba 6300
models within a single stack to meet your deployment
requirements
• Simplied conguration and management as the switches
act as a single chassis when stacked
• The Aruba CX Mobile app provides support for a validated
stack deployment that ensure that all stack links and
uplinks are connected properly
An Aruba CX 6300 switch for any enterprise environment
Whether in the branch oce or a small to large enterprise
environment, you can choose from 24 and 48 port 1U
models. Each switch includes four high-speed built-in uplinks
that auto-negotiate from 1GbE, 10GbE to 25GbE to 50GbE1 to
deliver non-blocking performance. Fixed format (F) models
include built-in power supplies. The modular (M) models have
rear slots for hot swappable power supplies that allow you
to customize your PoE requirements, and its fans are eld
replaceable. Additional highlights:
• Compact 1U models support:
- 24 and 48 ports of HPE Smart Rate Multi-gigabit Ethernet
IEEE 802.3bz (100M/1GbE/2.5GbE/5GbE) supporting
high power IEEE 802.3bt Class 6 (60W)
- High density 24 port SFP+ model which is ideal for
aggregation
- 10GbE/25GbE/50GbE uplink1 port connectivity
• HPE Smart Rate multi-gigabit (IEEE 802.3bz) Ethernet
supports high speed wireless access points
• For deployments that need higher port and PoE density,
the 6300 supports 60W of PoE in every port of a 48-port
switch for a total of 2880W of PoE
3
Page 4
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• Industry standard IEEE 802.3bt High Power PoE support
(class 6) provides up to 60W per port for support of the
latest IoT devices and APs. PoE support for IEEE 802.3at
Power over Ethernet (PoE+) provides up to 30W per port
as well as any IEEE 802.3af-compliant end device
• Support for pre-standard PoE detection provides power
to legacy PoE devices
• High availability with always-on PoE that supplies PoE
power even during scheduled reboots and rmware
upgrades
• Quick PoE supplies PoE power to powered devices as
soon as the switch is plugged into AC power so device can
initialize at same time as switch OS boots up.
• Support for Energy Ecient Ethernet IEEE 802.3az
reduces power consumption during periods of low
network trac.
• Support for top-of-rack (ToR) and out-of-band
management (OOBM) data center deployments with
CX 6300M Power-to-port bundle that delivers required
power-to-port (back to front) airow.
• Auto-MDIX provides automatic adjustments for
straight-through or crossover cables on all 10/100/1000,
Smart Rate and 10GBASE-T ports
• Unsupported Transceiver Mode (UTM) allows to insert
and enable all unsupported 1G and 10G transceivers and
cables. Note that there is no warranty nor support for the
transceiver/cable when this feature is used
• IPv6 capabilities include:
- IPv6 host enables switches to be managed in an IPv6
network
- Dual stack (IPv4 and IPv6) transitions from IPv4 to IPv6,
supporting connectivity for both protocols
- MLD snooping forwards IPv6 multicast trac to the
appropriate interface
- IPv6 ACL/QoS supports ACL and QoS for IPv6 network
trac
- IPv6 routing supports Static and OSPFv3 protocols
- Security provides RA guard, DHCPv6 protection, dynamic
IPv6 lockdown, and ND snooping
• Jumbo frames allow for high-performance backups and
disaster-recovery systems; provides a maximum frame
size of 9198 bytes
• Packet storm protection against broadcast and multicast
storms with user-dened thresholds
• Smart link enables simple, fast converging link redundancy
and load balancing with dual uplinks avoiding Spanning
Tree complexities
CX 6300M bundle for data centers
The CX 6300M 48 port power-to-port switch bundle serves
as a top of rack (ToR) switch for 1GbE ser vers and also as
a 1GbE out-of-band management (OOBM) switch for data
centers server racks. Features include:
• Power-to-port bundle (JL762A) includes 48 port 1GbE
switch with 2 x Fan Trays (JL761A) and 1 x power supply
(JL760A)
• Back (power-side) to front (1GbE port side) airow
• 1GbE/10GbE/25GbE/50GbE1 SFP uplinks
High availability and resiliency
To ensure a high degree of up-time we oer high availability
and multicast features needed for a full Layer 3 deployment
at access and aggregation such as PBR, BFD, MSDP, BSR, and
IP SLA without the need for software licenses. This includes:
• Hot Swappable Power Supplies available in the 6300 “M”
models
- Provides N+1 and N+N redundancy for high reliability in
the event of power line or supply failures
- Optional secondary power supplies to increase the total
available PoE power
- Fixed power supplies in 6300 “F” models
• Bidirectional Forward Detection (BFD) enables sub-second
failure detection for rapid routing protocol re-balancing,
supporting both IPV4 and IPv6 networks
• Virtual Router Redundancy Protocol (VRRP) allows groups
of two routers to dynamically create highly available
routed environments in IPV4 and IPV6 networks
• Uni-directional Link Detection (UDLD) to monitor link
connectivity and shut down ports at both ends if uni-
directional trac is detected, preventing loops in STP-
based networks
• IEEE 802.3ad LACP supports up to 256 LAGs, each with
up to 8 links per LAG; and provides support for static or
dynamic groups and a user-selectable hashing algorithm
• IEEE 802.1s Multiple Spanning Tree provides high link
availability in VLAN environments where multiple spanning
trees are required; and legacy support for IEEE 802.1d
and IEEE 802.1w
• IEEE 802.3ad link-aggregation-control protocol (LACP) and
port trunking support static and dynamic trunks where
each trunk supports up to eight links (ports) per static
trunk
• Support for Microsoft Network Load Balancer (NLB) for
server applications
4
Page 5
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• Ethernet Ring Protection Switching (ERPS) supports rapid
protection and recovery in a ring topology
Quality of Service (QoS) features
To support congestion actions and trac prioritization, the
Aruba CX 6300 Series includes the following:
• Strict priority (SP) queuing and Decit Weighted Round
Robin (DWRR)
• Trac prioritization (IEEE 802.1p) for real-time
classication into 8 priority levels that are mapped to 8
queues
• Layer 4 prioritization based on TCP/UDP port numbers
• Class of Service (CoS) sets the IEEE 802.1p priority tag
based on IP address, IP Type of Service (ToS), Layer 3
protocol, TCP/UDP port number, source port, and DiServ
• Rate limiting sets per-port ingress enforced maximums
and per-port, per-queue minimums
• Transmission rates of egressing frames can be limited on
a per-queue basis using Egress Queue Shaping (EQS)
• Large buers for graceful congestion management
Simplied conguration and management
In addition to the Aruba CX Mobile App, Aruba NetEdit and
Aruba Network Analytics Engine, the 6300 series oers the
following:
• Built-in programmable and easy to use REST API interface
• Simple day zero provisioning
• Scalable ASIC-based wire speed network monitoring and
accounting with no impact on network performance;
network operators can gather a variety of network
statistics and information for capacity planning and real-
time network monitoring purposes
• Management interface control enables or disables each of
the following depending on security preferences, console
port, or reset button
• Industry-standard CLI with a hierarchical structure for
reduced training time and expense. Delivers increased
productivity in multivendor environments
• Management security restricts access to critical
conguration commands, provides multiple privilege
levels with password protection and local and remote
syslog capabilities allow logging of all access
• SNMP v2c/v3 provides SNMP read and trap support of
industry standard Management Information Base (MIB),
and private extensions
• Remote monitoring (RMON) with standard SNMP to
monitor essential network functions. Supports events,
alarms, history, and statistics groups as well as a private
alarm extension group; RMON, and sFlow provide
advanced monitoring and reporting capabilities for
statistics, history, alarms and events
• TFTP and SFTP support oers dierent mechanisms
for conguration updates; trivial FTP (TFTP) allows
bidirectional transfers over a TCP/ IP network; Secure
File Transfer Protocol (SFTP) runs over an SSH tunnel to
provide additional security
• Debug and sampler utility supports ping and traceroute
for IPv4 and IPv6
• Network Time Protocol (NTP) synchronizes timekeeping
among distributed time servers and clients; keeps
timekeeping consistent among all clock-dependent
devices within the network so the devices can provide
diverse applications based on the consistent time
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from
adjacent devices on a network, facilitating easy mapping
by network management applications
• Dual ash images provides independent primary and
secondary operating system les for backup while
upgrading
• Assignment of descriptive names to ports for easy
identication
• Multiple conguration les can be stored to a ash image
• Ingress and egress port monitoring enable more ecient
network problem solving
• Unidirectional link detection (UDLD) monitors the link
between two switches and blocks the ports on both ends
of the link if the link goes down at any point between the
two devices
• IP SLA for Voice monitors quality of voice trac using the
UDP Jitter and UDP Jitter for VoIP tests
Layer 2 Switching
The following layer 2 services are suppor ted:
• VLAN support and tagging for IEEE 802.1Q (4094 VLAN
IDs)
• Jumbo packet support improves the performance of large
data transfers; supports frame size of up to 9198 bytes
• IEEE 802.1v protocol VLANs isolate select non-IPv4
protocols automatically into their own VLANs
• Rapid Per-VLAN Spanning Tree (RPVST+) allows each
VLAN to build a separate spanning tree to improve link
bandwidth usage; is compatible with PVST+
• MVRP allows automatic learning and dynamic assignment
of VLANs
5
Page 6
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• VXLAN encapsulation (tunnelling) protocol for overlay
network that enables a more scalable virtual network
deployment
• Bridge Protocol Data Unit (BPDU) tunnelling Transmits STP
BPDUs transparently, allowing correct tree calculations
across service providers, WANs, or MANs
• Port mirroring duplicates port trac (ingress and egress)
to a monitoring port; supports 4 mirroring groups
• STP supports standard IEEE 802.1D STP, IEEE 802.1w
Rapid Spanning Tree Protocol (RSTP) for faster
convergence, and IEEE 802.1s Multiple Spanning Tree
Protocol (MSTP)
• Internet Group Management Protocol (IGMP) Controls
and manages the ooding of multicast packets in a
Layer2 network
• IPv4 Multicast in VXLAN/EVPN Overlay support allows PIM-
SM/IGMP snooping in the VXLAN Overlay
• IPv6 VXLAN/EVPN Overlay support, allows IPv6 trac over
the VXLAN overlay
• VXLAN ARP/ND suppression allows minimization of ARP
and ND trac ooding within individual VXLAN segments,
thus optimizing the VXLAN network
Layer 3 Services
The following layer 3 services are suppor ted:
• Bidirectional Forwarding Detection (BFD) enables
link connectivity monitoring and reduces network
convergence time for static route, OSPFv2 and VRRP
• User Datagram Protocol (UDP) helper function allows
UDP broadcasts to be directed across router interfaces
to specic IP unicast or subnet broadcast addresses and
prevents server spoong for UDP services such as DHCP
• Loopback interface address denes an address in Open
Shortest Path First (OSPF), improving diagnostic capability
• Route maps provide more control during route
redistribution; allow ltering and altering of route metrics
• Address Resolution Protocol (ARP) determines the MAC
address of another IP host in the same subnet; supports
static ARPs; gratuitous ARP allows detection of duplicate
IP addresses; proxy ARP allows normal ARP operation
between subnets or when subnets are separated by a
Layer 2 network
• Dynamic Host Conguration Protocol (DHCP) simplies
the management of large IP networks and supports client;
DHCP Relay enables DHCP operation across subnets
• DHCP server centralizes and reduces the cost of IPv4
address management
• Domain Name System (DNS) provides a distributed
database that translates domain names and IP addresses,
which simplies network design; supports client and
server
• mDNS (Multicast Domain Name System) Gateway enables
discovery of mDNS groups across L3 boundaries
• Generic Routing Encapsulation (GRE) enables tunneling
trac from site to site over a Layer 3 path
• Supports internal loopback testing for maintenance
purposes and increased availability; loopback
detection protects against incorrect cabling or network
congurations and can be enabled on a per-port or per-
VLAN basis for added exibility
Layer 3 Routing
The following layer 3 routing services are supported:
• Border Gateway Protocol (BGP) provides IPv4 and IPv6
routing, which is scalable, robust, and exible
• Border Gateway Protocol 4 (BGP-4) delivers an
implementation of the Exterior Gateway Protocol (EGP)
utilizing path vectors; uses TCP for enhanced reliability
for the route discovery process; reduces bandwidth
consumption by advertising only incremental updates;
supports extensive policies for increased exibility; scales
to very large networks with graceful restart capability
• Equal-Cost Multipath (ECMP) enables multiple equal-cost
links in a routing environment to increase link redundancy
and scale bandwidth
• Multi-protocol BGP (MP-BGP) enables sharing of IPv6
routes using BGP and connections to BGP peers using
IPv6
• Routing Information Protocol version 2 (RIPv2) provides an
easy to congure routing protocol for small networks as
while RIPng provides support for small IPv6 networks
• Open shortest path rst (OSPF) delivers faster
convergence; uses link-state routing Interior Gateway
Protocol (IGP), which supports ECMP, NSSA, and MD5
authentication for increased security and graceful restart
for faster failure recovery
• OSPF provides OSPFv2 for IPv4 routing and OSPFv3 for
IPv6 routing
• Static IP routing provides manually congured routing;
includes ECMP capability
• Policy-based routing uses a classier to select trac that
can be forwarded based on policy set by the network
administrator
6
Page 7
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• Static IPv4 and IPv6 routing provides simple manually
congured IPv4 and IPv6 routes
• IP performance optimization provides a set of tools to
improve the performance of IPv4 networks; includes
directed broadcasts, customization of TCP parameters,
support of ICMP error packets, and extensive display
capabilities
• Dual IP stack maintains separate stacks for IPv4 and IPv6
to ease the transition from an IPv4-only network to an
IPv6-only network design
Security
The Aruba CX 6300 Switch Series come with an integrated
trusted platform module (TPM) for platform integrity. This
ensures the boot process started from a trusted combination
of Aruba AOS-CX switches. Other security features include:
• TAA Compliance uses FIPS 140-2 validated cryptography
for protection of sensitive information
• Access control list (ACL) support for both IPv4 and IPv6;
allows for ltering trac to prevent unauthorized users
from accessing the network, or for controlling network
trac to save resources; rules can either deny or permit
trac to be forwarded; rules can be based on a Layer 2
header or a Layer 3 protocol header
• ACLs also provide ltering based on the IP eld, source/
destination IP address/subnet, and source/ destination
TCP/UDP port number on a per-VLAN or per-port basis
• Enrollment over Secure Transport (EST) enables secure
certicate enrollment, allowing for easier enterprise
management of PKI
• Remote Authentication Dial-In User Service (RADIUS)
• Terminal Access Controller Access-Control System
(TACACS+) delivers an authentication tool using TCP with
encryption of the full authentication request, providing
additional security
• Management access security for both on- and o-
box authentication for administrative access. RADIUS
or TACACS+ can be used to provide encrypted user
authentication. Additionally, TACACS+ can also provide
admin authorization services
• Control Plane Policing sets rate limit on control protocols
to protect CPU overload from DOS attacks
• Supports multiple user authentication methods. Uses an
IEEE 802.1X supplicant on the client in conjunction with a
RADIUS server to authenticate in accordance with industry
standards
• Web based authentication using Captive Portal on
ClearPass is supported for use cases such as Guest
Access and for devices that don’t support 802.1x or
MACAuth.
• Supports MAC-based client authentication
• Concurrent IEEE 802.1X, Web, and MAC authentication
schemes per switch port accepts up to 32 sessions of IEEE
802.1X, Web, and MAC authentications
• DHCP protection blocks DHCP packets from unauthorized
DHCP servers, preventing denial-of-service attacks
• Secure management access delivers secure encryption of
all access methods (CLI, GUI, or MIB) through SSHv2, SSL,
and/or SNMPv3
• Switch CPU protection provides automatic protection
against malicious network trac trying to shut down
theswitch
• ICMP throttling defeats ICMP denial-of-service attacks
byenabling any switch port to automatically throttle
ICMPtrac
• Identity-driven ACL enables implementation of a highly
granular and exible access security policy and VLAN
assignment specic to each authenticated network user
• STP BPDU port protection blocks Bridge Protocol Data
Units (BPDUs) on ports that do not require BPDUs,
preventing forged BPDU attacks
• Dynamic IP lockdown works with DHCP protection to block
trac from unauthorized hosts, preventing IP source
address spoong
• Dynamic ARP protection blocks ARP broadcasts from
unauthorized hosts, preventing eavesdropping or theft of
network data
• STP root guard protects the root bridge from malicious
attacks or conguration mistakes
• Port security allows access only to specied MAC
addresses, which can be learned or specied by the
administrator
• MAC address lockout prevents particular congured MAC
addresses from connecting to the network
• Source-port ltering allows only specied ports to
communicate with each other
• Secure shell encrypts all transmitted data for secure
remote CLI access over IP networks
• Secure Sockets Layer (SSL) encrypts all HTTP trac,
allowing secure access to the browser-based
management GUI in the switch
• Secure FTP allows secure le transfer to and from the
switch; protects against unwanted le downloads or
unauthorized copying of a switch conguration le
7
Page 8
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• Critical Authentication Role ensures that important
infrastructure devices such as IP phones are allowed
network access even in the absence of a RADIUS server
• MAC Pinning allows non-chatty legacy devices to stay
authenticated by pinning client MAC addresses to the port
until the clients logo or get disconnected
• Security banner displays a customized security policy
when users log in to the switch
• RadSec enables RADIUS authentication and accounting
data to be passed safely and reliably across insecure
networks
Multicast
• IGMP Snooping allows multiple VLANs to receive the
same IPv4 multicast trac, lessening network bandwidth
demand by reducing multiple streams to each VLAN
• Multicast Listener Discovery (MLD) enables discovery of
IPv6 multicast listeners; support MLD v1 and v2
• Protocol Independent Multicast (PIM) denes modes
of IPv4 and IPv6 multicasting to allow one-to-many and
many-to-many transmission of information; supports PIM
Sparse Mode (SM) and Dense Mode (DM) for both IPv4
and IPv6
• Internet Group Management Protocol (IGMP) utilizes
Any-Source Multicast (ASM) to manage IPv4 multicast
networks; supports IGMPv1, v2, and v3
• Multicast Service Discovery Protocol (MSDP) eciently
routes multicast trac through core networks
• MSDP for Anycast RP is an intra-domain feature that
provides redundancy and load-sharing capabilities
extension of LLDP that stores values for parameters such
as QoS and VLAN to automatically congure network
devices such as IP phones
• PoE allocations supports multiple methods (allocation by
usage or class, with LLDP and LLDP-MED) to allocate PoE
power for more ecient power management and energy
savings.
• Auto VLAN conguration for voice RADIUS VLAN
uses a standard RADIUS attribute and LLDP-MED to
automatically congure a VLAN for IP phones
• CDPv2 uses CDPv2 to congure legacy IP phones
Additional information
• Green initiative support for RoHS (EN 50581:2012) and
WEEE regulations
Warranty, services and support
• Limited Lifetime Warranty, see
https://www.arubanetworks.com/support-services/
product-warranties/ for warranty and support
information included with your product purchase
• For Software Releases and Documentation, refer to
https://asp.arubanetworks.com/downloads
• For support and services information, visit https://www.
arubanetworks.com/support-services/arubacare/
Convergence
• IP multicast routing includes PIM Sparse and Dense
modes to route IP multicast trac
• IP multicast snooping (data-driven IGMP) prevents
ooding of IP multicast trac
• Protocol Independent Multicast for IPv6 supports one-to-
many and many-to-many media casting use cases such as
IPTV over IPv6 networks
• LLDP-MED (Media Endpoint Discovery) denes a standard
8
Page 9
SPECIFICATIONS
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M 24-port
SFP+ and 4-port SFP56
Switch (JL658A)
Description 24x 1G/10G SFP+ ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
Power supplies 2 eld-replaceable, hot-
swappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supports JL085A PSU
Fans Switch has two fan tray
slots and comes with two
fan trays installed.
• Min 2 fan trays
required.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
Physical characteristics
Dimensions (H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Conguration Weight 5.8 Kg (12.78 lbs) 6.71 kg (14.8 lbs) 6.06 (13.36 lbs) 5.72 kg (12.61 lbs)
Additional Specications
CPU Quad Core ARM Cortex™
A72 @ 1.8GHz
Memory and Flash 8 GB DDR4
32 GB eMMC
Packet Buer 8 MB Packet Buer
Memory
Aruba 6300M 48port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL659A)
48x ports SmartRate
100M/1G/2.5G/5G
BaseT Class 6 PoE ports
supporting up to 60W
per port
4x 1/10/25/50G1 SFP
ports
Supports PoE Standards
IEEE 802.3af, 802.3at and
802.3bt (up to 60W)
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
2 eld-replaceable, hotswappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supported PSUs
JL086A
JL087A
JL670A
Max PoE Power: 2880W
Switch has two fan tray
slots and comes with two
fan trays installed.
• Min 2 fan trays
required.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
(H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300M 24port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL660A)
24x ports Smart Rate
100M/1G/2.5G/5G
BaseT Class 6 PoE ports
supporting up to 60W
per port
4x 1/10/25/50G1 SFP
ports
Supports PoE Standards
IEEE 802.3af, 802.3at and
802.3bt (up to 60W)
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
2 eld-replaceable, hotswappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supported PSUs
JL086A
JL087A
JL670A
Max PoE Power: 1440W
Switch has two fan tray
slots and comes with one
fan tray installed.
• Min 1 fan tray required.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
(H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300M 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL661A)
48x ports 10/100/1000
BaseT PoE+ ports
supporting up to 30W
per port
4x 1/10/25/50G1 SFP
ports
Supports PoE Standards
IEEE 802.3af, 802.3at
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
2 eld-replaceable, hotswappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supported PSUs
JL086A
JL087A
JL670A
Max PoE Power: 1440W
Switch has two fan tray
slots and comes with one
fan tray installed.
• Min 1 fan tray required.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
(H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
9
Page 10
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M 24-port
SFP+ and 4-port SFP56
Switch (JL658A)
Performance
System Switching Capacity 880 Gbps 880 Gbps 880 Gbps 880 Gbps
System Throughput
Capacity
Model Switching Capacity 880 Gbps 880 Gbps 640 Gbps 496 Gbps
Model Throughput
Capacity
Average Latency (LIFO-64bytes packets)
Stack Size 10 members 10 members 10 members 10 members
Max. Stacking Distance Up to 10 kms with long
Stacking Bandwidth 200 Gbps 200 Gbps 200 Gbps 200 Gbps
Switched Virtual Interfaces
(dual stack)
IPv4 Host Table (ARP) 49,152 49,152 49,152 49,152
IPv6 Host Table (ND) 49,152 49,152 49,152 49,152
IPv4 Unicast Routes 61,000 61,000 61,000 61,000
IPv6 Unicast Routes 61,000 61,000 61,000 61,000
IPv4 Multicast Routes 8,192 8,192 8,192 8,192
IPv6 Multicast Routes 8,192 8,192 8,192 8,192
MAC Table Capacity 32,768 32,768 32,768 32,768
IGMP Groups 8,192 8,192 8,192 8,192
MLD Groups 8,192 8,192 8,192 8,192
IPv4/IPv6/MAC ACL Entries
(ingress)
IPv4/IPv6/MAC ACL Entries
(egress)
VRF 256 256 256 256
Environment
Operating Temperature 32°F to 113°F (0°C to
Operating Relative
Humidity
660 Mpps 660 Mpps 660 Mpps 660 Mpps
654 Mpps 654 Mpps 476 Mpps 369 Mpps
1Gbps: 1.99μSec
10Gbps: 1.49μSec
25Gbps: 2.85μSec
50Gbps: 2.82μSec
range transceivers
1,024 1,024 1,024 1,024
20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480
8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft.
Can support excursion
to 131°F (55°C) for
short periods1 of time.
Operating temperature is
reduced to 32°F (0°C) to
104°F (40°C) up to 5000ft
when 10G SFP+ LR or ER
Transceivers are installed.
15% to 95% @ 104°F
(40°C) non-condensing
Aruba 6300M 48port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL659A)
1Gbps: 4.24μSec
10Gbps: 1.50μSec
25Gbps: 2.91μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C for
every 1,000 ft from 5,000
ft to 10,000 ft
15% to 95% @ 104°F
(40°C) non-condensing
Aruba 6300M 24port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL660A)
1Gbps: 4.24μSec
10Gbps: 1.50μSec
25Gbps: 2.91μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft.
Cansupport excursion
to 131°F (55°C) for short
periods1 of time. Requires
two fan trays to support
excursion.
15% to 95% @ 104°F
(40°C) non-condensing
Aruba 6300M 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL661A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft.
Cansupport excursion
to 131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
10
Page 11
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M 24-port
SFP+ and 4-port SFP56
Switch (JL658A)
Aruba 6300M 48port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL659A)
Aruba 6300M 24port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL660A)
Aruba 6300M 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL661A)
Environment (continued)
Non-Operating -40°F to 158°F (-40°C to
70°C) up to 15,000 ft
Non-Operating Storage
relative humidity
15% to 90% @ 149°F
(65°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
Max Operating Altitude 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max
Max non-operating Altitude 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max
Acoustic Sound Power,
L
= 4.9 Bel
WAd
Sound Pressure,
L
(Bystander) = 31.0 dB
pAm
Sound Power,
L
= 4.8 Bel
WAd
Sound Pressure,
L
(Bystander) = 30.6 dB
pAm
Sound Power,
L
= 5.2 Bel
WAd
Sound Pressure,
L
(Bystander) = 34.2 dB
pAm
Sound Power,
L
= 4.7 Bel
WAd
Sound Pressure,
L
(Bystander) = 29.8 dB
pAm
Primary Airow Front and side to back Front and side to back Front and side to back Front and side to back
Electrical Characteristics
Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
AC Voltage JL085A PSU: 100V-240V JL670A PSU:
110V-120V/208V-240V
JL086A PSU: 100V-240V
JL087A PSU: 110V-240V
Current (for voltages
listed above)
JL085A PSU: 3A/1.2A JL670A PSU: 11A/8A
JL086A PSU: 8A/3.5A
JL087A PSU: 12A/5A
Power Consumption
(230VAC)
Hibernation
(0 rpm fan): 9W
Idle: 51W
100% Trac Rate: 85W
With JL086A PSU:
Hibernation (0 rpm fan):
24W
Idle: 133W
100% Trac Rate: 199W
With JL087A PSU:
Hibernation (0 rpm fan):
22W
Idle: 138W
100% Trac Rate: 193W
With JL670A PSU:
Hibernation (0 rpm fan):
21W
Idle: 140W
100% Trac Rate: 201W
JL670A PSU:
110V-120V/208V-240V
JL086A PSU: 100V-240V
JL087A PSU: 110V-240V
JL670A PSU: 11A/8A
JL086A PSU: 8A/3.5A
JL087A PSU: 12A/5A
With JL086A PSU:
Hibernation (0 rpm fan):
24W
Idle: 93W
100% Trac Rate: 137W
With JL087A PSU:
Hibernation (0 rpm fan):
22W
Idle: 91W
100% Trac Rate: 131W
With JL670A PSU:
Hibernation (0 rpm fan):
21W
Idle: 98W
100% Trac Rate: 139W
JL670A PSU:
110V-120V/208V-240V
JL086A PSU: 100V-240V
JL087A PSU: 110V-240V
JL670A PSU: 11A/8A
JL086A PSU: 8A/3.5A
JL087A PSU: 12A/5A
With JL086A PSU:
Hibernation (0 rpm fan):
18W
Idle: 70W
100% Trac Rate: 90W
With JL087A PSU:
Hibernation (0 rpm fan):
16W
Idle: 71W
100% Trac Rate: 88W
With JL670A PSU:
Hibernation (0 rpm fan):
16W
Idle: 73W
100% Trac Rate: 96W
Safety
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
11
Page 12
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M 24-port
SFP+ and 4-port SFP56
Switch (JL658A)
Emissions
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
Lasers
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
Immunity
Generic CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 24 / CISPR 35
EN EN 55024:2010 /
EN 55035:2017
ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2
Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3
EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4
Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5
Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic
eld
Voltage dips and
interruptions
Harmonics IEC 61000-3-2,
Flicker IEC 61000-3-3,
Mounting and Enclosure
IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8
IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11
EN 61000-3-2
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 48port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL659A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 24port HPE Smart Rate
1/2.5/5GbE Class 6
PoE and 4 -port SFP56
Switch (JL660A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL661A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
12
Page 13
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M
24-port 1GbE Class 4
PoE and 4 -port SFP56
Switch (JL662A)
Description 24x ports 10/100/1000
BaseT PoE+ ports
supporting up to 30W
per port
4x 1/10/25/50G1 SFP
ports
Supports PoE Standards
IEEE 802.3af, 802.3at
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to
beused with CX Mobile
App
Power supplies 2 eld-replaceable, hot-
swappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supported PSUs
JL086A
JL087A
JL670A
Max PoE Power: 720W
Fans Switch has two fan tray
slots and comes with one
fan tray installed.
• Min 1 fan tray required.
Optional second
fan tray ordered
separately.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
Physical characteristics
Dimensions (H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Conguration Weight 5.55 kg (12.23 lbs) 5.51 kg (12.14 lbs) 5.43 kg (11.97 lbs) 1PSU: 5.7 kg (12.5 lbs)
Additional Specications
CPU Quad Core ARM Cortex™
A72 @ 1.8GHz
Memory and Flash 8 GB DDR4
32 GB eMMC
Packet Buer 8 MB Packet Buer
Memory
Aruba 6300M 48-port
1GbE and 4-port SFP56
Switch (JL663A)
48x ports 10/100/1000
BaseT ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
2 eld-replaceable, hotswappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supports JL085A PSU
Switch has two fan tray
slots and comes with one
fan tray installed.
• Min 1 fan tray required.
Optional second
fan tray ordered
separately.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
(H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300M 24-port
1GbE and 4-port SFP56
Switch (JL664A)
24x ports 10/100/1000
BaseT ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to be
used with CX Mobile App
2 eld-replaceable, hotswappable power supply
slots
1 minimum power
supply required (ordered
separately)
Supports JL085A PSU
Switch has two fan tray
slots and comes with one
fan tray installed.
• Min 1 fan tray required.
Optional second
fan tray ordered
separately.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
(H) 4.4 cm x
(W) 44.2 cm x
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300M 48-port
1GbE and 4-port SFP56
Power-to-Port 2 Fan
Trays 1 PSU Bundle
(JL762A)
48x ports 10/100/1000
BaseT ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM
1x USB Type A Host port
1x Bluetooth dongle to be
used with AOS-CX Mobile
App
2 Field-replacable, hotswappable power-supply
slots and comes with 1
Pwr2Prt power-supply
pre-installed
Additonal Pwr2Prt powersupply can be ordered
separately
Supports JL760A Pwr2Prt
power-supply only
Switch has two fan tray
slots and comes with two
fan trays installed.
• Min 2 fan trays
required.
• Fan trays are eld
replaceable and hotswappable.
• Each fan tray contains
two fans.
• Supports JL761A
Pwr2Prt Fan Tray only.
(H) 4.4 cm
(W) 44.2 cm
(D) 38.5 cm
(1.73” x 17.4” x 15.2”)
2PSU: 6.27kg (13.8 lbs)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GBytes DDR4
32 GBytes eMMC
8 MB Shared Packet
Buer Memory
13
Page 14
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M
24-port 1GbE Class 4
PoE and 4 -port SFP56
Switch (JL662A)
Performance
System Switching Capacity 880 Gbps 880 Gbps 880 Gbps 880 Gbps
System Throughput
Capacity
Model Switching Capacity 448 Gbps 496 Gbps 448 Gbps 496 Gbps
Model Throughput
Capacity
Average Latency (LIFO-64bytes packets)
Stack Size 10 members 10 members 10 members 10 members
Max. Stacking Distance Up to 10 kms with long
Stacking Bandwidth 200 Gbps 200 Gbps 200 Gbps 200 Gbps
Switched Virtual Interfaces
(dual stack)
IPv4 Host Table (ARP) 49,152 49,152 49,152 49,152
IPv6 Host Table (ND) 49,152 49,152 49,152 49,152
IPv4 Unicast Routes 61,000 61,000 61,000 61,000
IPv6 Unicast Routes 61,000 61,000 61,000 61,000
IPv4 Multicast Routes 8,192 8,192 8,192 8,192
IPv6 Multicast Routes 8,192 8,192 8,192 8,192
MAC Table Capacity 32,768 32,768 32,768 32,768
IGMP Groups 8,192 8,192 8,192 8,192
MLD Groups 8,192 8,192 8,192 8,192
IPv4/IPv6/MAC ACL Entries
(ingress)
IPv4/IPv6/MAC ACL Entries
(egress)
VRF 256 256 256 256
Environment
Operating Temperature 32°F to 113°F (0°C to
Operating Relative
Humidity
Non-Operating -40°F to 158°F (-40°C to
Non-Operating Storage
relative humidity
660 Mpps 660 Mpps 660 Mpps 660 Mpps
334 Mpps 369 Mpps 334 Mpps 369 Mpps
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
range transceivers
1,024 1,024 1,024 1,024
20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480
8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft
Cansupport excursion
to 131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
Aruba 6300M 48-port
1GbE and 4-port SFP56
Switch (JL663A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft
Cansupport excursion
to 131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
Aruba 6300M 24-port
1GbE and 4-port SFP56
Switch (JL664A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft
Cansupport excursion
to 131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
Aruba 6300M 48-port
1GbE and 4-port SFP56
Power-to-Port 2 Fan
Trays 1 PSU Bundle
(JL762A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
32°F to 113°F (0°C to
45°C) upto 5000 ft derate
-1°C for every 1000 ft
from 5000 ft to 10000 ft
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15000 ft
15% to 90% @ 149°F
(65°C) non-condensing
14
Page 15
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M
24-port 1GbE Class 4
PoE and 4 -port SFP56
Switch (JL662A)
Aruba 6300M 48-port
1GbE and 4-port SFP56
Switch (JL663A)
Aruba 6300M 24-port
1GbE and 4-port SFP56
Switch (JL664A)
Aruba 6300M 48-port
1GbE and 4-port SFP56
Power-to-Port 2 Fan
Trays 1 PSU Bundle
(JL762A)
Environment (continued)
Max Operating Altitude 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10000 feet (3.04 km) Max
Max non-operating Altitude 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15000 feet (4.6 km) Max
Acoustic Sound Power,
L
= 4.7 Bel
WAd
Sound Pressure,
L
(Bystander) = 29.4 dB
pAm
Sound Power,
L
= 4.6 Bel
WAd
Sound Pressure,
L
(Bystander) = 28.7 dB
pAm
Sound Power,
L
= 4.6 Bel
WAd
Sound Pressure,
L
(Bystander) = 28.6 dB
pAm
Sound Power,
L
= 5.0 Bel
WAd
Sound Pressure,
L
(Bystander) = 32.5 dB
pAm
with 1 x JL760A PSU
Primary Airow Front and side to back Front and side to back Front and side to back Back to Front and Side
Electrical Characteristics
Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
AC Voltage JL670A PSU:
JL085A PSU: 100V-240V JL085A PSU: 100V-240V JL760A PSU: 100V-240V
110V-120V/208V-240V
JL086A PSU: 100V-240V
JL087A PSU: 110V-240V
Current (for voltages listed
above)
JL670A PSU: 11A/8A
JL086A PSU: 8A/3.5A
JL085A PSU: 3A/1.2A JL085A PSU: 3A/1.2A JL760A PSU: 3A-1.2A
JL087A PSU: 12A/5A
80plus.org certicaiton TBA for JL760A PS.
Power Consumption
(230VAC)
With JL086A PSU:
Hibernation
(0 rpm fan): 20W
Idle: 60W
Hibernation
(0 rpm fan): 9W
Idle: 56W
100% Trac Rate: 75W
Hibernation
(0 rpm fan): 9W
Idle: 49W
100% Trac Rate: 64W
Hibernation
(0rpm fan): 9W
Idle: 56W
100% Trac Rate: 75W
100% Trac Rate: 76W
With JL087A PSU:
Hibernation (0 rpm fan):
17W
Idle: 59W
100% Trac Rate: 74W
With JL670A PSU:
Hibernation (0 rpm fan):
16W
Idle: 62W
100% Trac Rate: 81W
Safety
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 60950-
1:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
EN 62368-1:2014
+A11:2017
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
IEC 62368-1:2014 2nd Ed.
Taiwan:
CNS-14336-1
15
Page 16
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300M
24-port 1GbE Class 4
PoE and 4 -port SFP56
Switch (JL662A)
Emissions
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
Lasers
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
Immunity
Generic CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 35
EN EN 55024:2010 /
EN 55035:2017
ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2
Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3
EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4
Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5
Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic
eld
Voltage dips and
interruptions
Harmonics IEC 61000-3-2,
Flicker IEC 61000-3-3,
Mounting and Enclosure
IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8
IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11
EN 61000-3-2
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 48-port
1GbE and 4-port SFP56
Switch (JL663A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIA-
standard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 24-port
1GbE and 4-port SFP56
Switch (JL664A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300M 48-port
1GbE and 4-port SFP56
Power-to-Port 2 Fan
Trays 1 PSU Bundle
(JL762A)
Europe:
EN 55032:2015 +AC:2016,
Class A
EN 55035:2017
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC 47 CFR part 15B,
Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 32 Ed 2.0: 2015 +
COR1:2016, Class A
CISPR 35:2016
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1 (Applicable
for accessories - Opitcal
Transceivers only)
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
16
Page 17
SPECIFICATIONS
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300F 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL665A)
Description 48x ports
10/100/1000BaseT PoE+
Ports supporting up to
30W per port
4x 1/10/25/50G1 SFP
ports
Supports PoE Standards
IEEE 802.3af, 802.3at
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to
beused with CX Mobile
App
Power supplies Internal (xed) power
supply (950W)
Max PoE Power: 720W
Fans Fixed fans Fixed fans Fixed fans Fixed fans
Physical characteristics
Dimensions (H) 4.39 cm x
(W) 44.2 cm x
(D) 32.7 cm
(1.73” x 17.4” x 12.9”)
Conguration Weight 5.10 kg (11.24 lbs) 4.95 kg (10.91 lbs) 4.46 kg (9.83 lbs) 4.36 kg (9.61 lbs)
Additional Specications
CPU Quad Core ARM Cortex™
A72 @ 1.8GHz
Memory and Flash 8 GB DDR4
32 GB eMMC
Packet Buer 8 MB Packet Buer
Memory
Aruba 6300F 24-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL666A)
24x ports
10/100/1000BaseT Ports
supporting up to 30W
per port
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to
beused with CX Mobile
App
Internal (xed) power
supply (950W)
Max PoE Power: 370W
(H) 4.39 cm x
(W) 44.2 cm x
(D) 32.7 cm
(1.73” x 17.4” x 12.9”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300F
48-port 1GbE and
4-port SFP56 Switch
(JL667A)
48x ports
10/100/1000BaseT Ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to
beused with CX Mobile
App
Internal (xed) power
supply (200W)
(H) 4.39 cm x
(W) 44.2 cm x
(D) 32.7 cm
(1.73” x 17.4” x 12.9”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
Aruba 6300F
24-port 1GbE and
4-port SFP56 Switch
(JL668A)
24x ports
10/100/1000BaseT Ports
4x 1/10/25/50G1 SFP
ports
1x USB-C Console Port
1x OOBM port
1x USB Type A Host port
1x Bluetooth dongle to
beused with CX Mobile
App
Internal (xed) power
supply (200W)
(H) 4.39 cm x
(W) 44.2 cm x
(D) 32.7 cm
(1.73” x 17.4” x 12.9”)
Quad Core ARM Cortex™
A72 @ 1.8GHz
8 GB DDR4
32 GB eMMC
8 MB Packet Buer
Memory
17
Page 18
SPECIFICATIONS
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300F 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL665A)
Performance
System Switching Capacity 880 Gbps 880 Gbps 880 Gbps 880 Gbps
System Throughput
Capacity
Model Switching Capacity 496 Gbps 448 Gbps 496 Gbps 448 Gbps
Model Throughput
Capacity
Average Latency (LIFO-64bytes packets)
Stack Size 10 members 10 members 10 members 10 members
Max. Stacking Distance Up to 10 kms with long
Stacking Bandwidth 200 Gbps 200 Gbps 200 Gbps 200 Gbps
Switched Virtual Interfaces
(dual stack)
IPv4 Host Table (ARP) 49,152 49,152 49,152 49,152
IPv6 Host Table (ND) 49,152 49,152 49,152 49,152
IPv4 Unicast Routes 61,000 61,000 61,000 61,000
IPv6 Unicast Routes 61,000 61,000 61,000 61,000
IPv4 Multicast Routes 8,192 8,192 8,192 8,192
IPv6 Multicast Routes 8,192 8,192 8,192 8,192
MAC Table Capacity 32,768 32,768 32,768 32,768
IGMP Groups 8,192 8,192 8,192 8,192
MLD Groups 8,192 8,192 8,192 8,192
IPv4/IPv6/MAC ACL Entries
(ingress)
IPv4/IPv6/MAC ACL Entries
(egress)
VRF 256 256 256 256
660 Mpps 660 Mpps 660 Mpps 660 Mpps
369 Mpps 334 Mpps 369 Mpps 334 Mpps
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
range transceivers
1,024 1,024 1,024 1,024
20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480 20,480/5,120/20,480
8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192 8,192/2,048/8,192
Aruba 6300F 24-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL666A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
Aruba 6300F
48-port 1GbE and
4-port SFP56 Switch
(JL667A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
Aruba 6300F
24-port 1GbE and
4-port SFP56 Switch
(JL668A)
1Gbps: 2.28μSec
10Gbps: 1.46μSec
25Gbps: 1.90μSec
50Gbps: 3.49μSec
Up to 10 kms with long
range transceivers
18
Page 19
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300F 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL665A)
Aruba 6300F 24-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL666A)
Aruba 6300F
48-port 1GbE and
4-port SFP56 Switch
(JL667A)
Aruba 6300F
24-port 1GbE and
4-port SFP56 Switch
(JL668A)
Environment
Operating Temperature 32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft
Cansupport excursion
to 131°F (55°C) for short
periods1 of time.
Operating Relative
Humidity
15% to 95% @ 104°F
(40°C) non-condensing
Non-Operating -40°F to 158°F (-40°C to
70°C) up to 15,000 ft
Non-Operating Storage
relative humidity
15% to 90% @ 149°F
(65°C) non-condensing
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft. Can
support excursion to
131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft. Can
support excursion to
131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
32°F to 113°F (0°C to
45°C) up to 5,000 ft.
Derate -1 degree C
for every 1,000 ft from
5,000 ft to 10,000 ft. Can
support excursion to
131°F (55°C) for short
periods1 of time.
15% to 95% @ 104°F
(40°C) non-condensing
-40°F to 158°F (-40°C to
70°C) up to 15,000 ft
15% to 90% @ 149°F
(65°C) non-condensing
Max Operating Altitude 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max 10,000 feet (3.04 km) Max
Max non-operating Altitude 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max 15,000 feet (4.6 km) Max
Acoustic Sound Power,
L
= 5.2 Bel
WAd
Sound Pressure,
L
(Bystander) = 34.9 dB
pAm
Sound Power,
L
= 5.0 Bel
WAd
Sound Pressure,
L
(Bystander) = 32.3 dB
pAm
Sound Power,
L
= 4.9 Bel
WAd
Sound Pressure,
L
(Bystander) = 31.5 dB
pAm
Sound Power,
L
= 4.9 Bel
WAd
Sound Pressure,
L
(Bystander) = 31.6 dB
pAm
Primary Airow Front and side to back Front and side to back Front and side to back Front and side to back
Electrical Characteristics
Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
AC Voltage Fixed PSU:
100V-120V/200V-240V
Current (for voltages listed
Fixed PSU: 11A/6A Fixed PSU: 11A/6A Fixed PSU: 2.5A/1.4A Fixed PSU: 2.5A/1.4A
Fixed PSU:
100V-120V/200V-240V
Fixed PSU:
100V-120V/200V-240V
Fixed PSU:
100V-120V/200V-240V
above)
80plus.org certicaiton
Power Consumption
(230VAC)
Hibernation
(0 rpm fan): 12W
Idle: 63W
100% Trac Rate: 86W
Hibernation
(0 rpm fan): 12W
Idle: 52W
100% Trac Rate: 67W
Hibernation
(0 rpm fan): 6W
Idle: 52W
100% Trac Rate: 74W
Hibernation
(0 rpm fan): 6W
Idle: 49W
100% Trac Rate: 63W
Safety
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 60950-
1:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
Europe: EN 60950-1:2006
+A11:2009 +A1:2010
+A12:2011 + A2:2013
US: UL 60950-1 2nd Ed.
Canada: CAN/CSA-C22.2
No. 60950-1-07
Worldwide: IEC 609501:2005 w/all known
National Deviations
19
Page 20
SPECIFICATIONS (CONTINUED)
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
Aruba 6300F 48-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL665A)
Emissions
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
Lasers
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1
(Applicable for
accessories - Optical
Transceivers only)
Immunity
Generic CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 24 / CISPR 35 CISPR 24 / CISPR 35
EN EN 55024:2010 /
EN 55035:2017
ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2
Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3
EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4
Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5
Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic
eld
Voltage dips and
interruptions
Harmonics IEC 61000-3-2,
Flicker IEC 61000-3-3,
Mounting and Enclosure
IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8
IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11
EN 61000-3-2
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300F 24-port
1GbE Class 4 PoE and
4-port SFP56 Switch
(JL666A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1 (Applicable
for accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIA-
standard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300F
48-port 1GbE and
4-port SFP56 Switch
(JL667A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1 (Applicable
for accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
Aruba 6300F
24-port 1GbE and
4-port SFP56 Switch
(JL668A)
Europe:
EN 55022:2010, Class A
EN 55032:2012, Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
US:
FCC part 15 Class A
Canada:
ICES-003 Class A
Worldwide:
VCCI Class A
CISPR 22 Class A
CISPR 32 Class A
CISPR 24:2010
EN 60825-1:2007 / IEC
60825-1:2007 Class 1
Class 1 Laser Products /
Laser Klasse 1 (Applicable
for accessories - Optical
Transceivers only)
EN 55024:2010 /
EN 55035:2017
IEC 61000-3-2,
EN 61000-3-2
IEC 61000-3-3,
EN 61000-3-3
Mounts in an EIAstandard 19 in. telco rack
or equipment cabinet.
Horizontal surface
mounting only. 2-post
rack kit included.
20
Page 21
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
STANDARDS AND PROTOCOLS
• ANSI/TIA-1057 LLDP Media Endpoint Discovery
(LLDP-MED)
• CPU DoS Protection
• Bootstrap Router (BSR) Mechanism for PIM, PIM WG
• draft-ietf-savi-mix
• IEEE 802.1AB-2005
• IEEE 802.1ak-2007
• IEEE 802.1AX-2008 Link Aggregation
• IEEE 802.1D MAC Bridges
• IEEE 802.1p Priority
• IEEE 802.1Q VLANs
• IEEE 802.1s Multiple Spanning Trees
• IEEE 802.1t-2001
• IEEE 802.1v VLAN classication by Protocol and Port
• IEEE 802.1w Rapid Reconguration of Spanning Tree
• IEEE 802.3ad Link Aggregation Control Protocol (LACP)
• IEEE 802.3ae 10-Gigabit Ethernet
• IEEE 802.3af Power over Ethernet
• IEEE 802.3at Power over Ethernet
• IEEE 802.3bt Power over Ethernet
• IEEE 802.3az Energy Ecient Ethernet (EEE)
• IEEE 802.3x Flow Control
• IEEE 802.3z 1000BASE-X
• RFC 1122 Requirements for Internet Hosts -
Communications Layers
• RFC 1215 Convention for dening traps for use with the
SNMP
• RFC 1256 ICMP Router Discovery Messages
• RFC 1350 TFTP Protocol (revision 2)
• RFC 1393 Traceroute Using an IP Option
• RFC 1403 BGP OSPF Interaction
• RFC 1519 CIDR
• RFC 1542 BOOTP Extensions
• RFC 1583 OSPF Version 2
• RFC 1591 Domain Name System Structure and Delegation
• RFC 1657 Denitions of Managed Objects for BGP-4 using
SMIv2
• RFC 1772 Application of the Border Gateway Protocol in
the Internet
• RFC 1812 Requirements for IP Version 4 Router
• RFC 1918 Address Allocation for Private Internet
• RFC 1997 BGP Communities Attribute
• RFC 1998 An Application of the BGP Community Attribute
in Multi-home Routing
• RFC 2131 DHCP
• RFC 2132 DHCP Options and BOOTP Vendor Extensions
• RFC 2236 IGMP
• RFC 2328 OSPF Version 2
• RFC 2375 IPv6 Multicast Address Assignments
• RFC 2385 Protection of BGP Sessions via the TCP MD5
Signature Option
• RFC 2401 Security Architecture for the Internet Protocol
• RFC 2402 IP Authentication Header
• RFC 2439 BGP Route Flap Damping
• RFC 2460 Internet Protocol, Version 6 (IPv6) Specication
• RFC 2464 Transmission of IPv6 over Ethernet Networks
• RFC 2545 Use of BGP-4 Multiprotocol Extensions for IPv6
Inter-Domain Routing
• RFC 2576 (Coexistence between SNMP V1, V2, V3)
• RFC 2579 (SMIv2 Text Conventions)
• RFC 2580 (SMIv2 Conformance)
• RFC 2710 Multicast Listener Discovery (MLD) for IPv6
• RFC 2711 IPv6 Router Alert Option
• RFC 2787 Denitions of Managed Objects for the Virtual
Router Redundancy Protocol
• RFC 2918 Route Refresh Capability for BGP-4
• RFC 2925 Denitions of Managed Objects for Remote
Ping, Traceroute, and Lookup Operations (Ping only)
• RFC 2934 Protocol Independent Multicast MIB for IPv4
• RFC 3019 MLDv1 MIB
• RFC 3046 DHCP Relay Agent Information Option
• RFC 3056 Connection of IPv6 Domains via IPv4 Clouds
• RFC 3065 Autonomous System Confederation for BGP
• RFC 3068 An Anycast prex for 6to4 Relay Route
• RFC 3137 OSPF Stub Router Advertisment sFlow
• RFC 3376 IGMPv3
• RFC 3416 (SNMP Protocol Operations v2)
• RFC 3417 (SNMP Transport Mappings)
• RFC 3418 Management Information Base (MIB) for the
Simple Network Management Protocol (SNMP)
• RFC 3484 Default Address Selection for IPv6
• RFC 3509 Alternative Implementations of OSPF Area
Border Routers
• RFC 3575 IANA Considerations for RADIUS
• RFC 3623 Graceful OSPF Restart
• RFC 3768 VRRP
• RFC 3810 Multicast Listener Discovery Version 2 (MLDv2)
for IPv6
• RFC 3973 PIM Dense Mode
• RFC 4022 MIB for TCP
• RFC 4113 MIB for UDP
• RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and
Routers
21
Page 22
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• RFC 4251 The Secure Shell (SSH) Protocol
• RFC 4252 SSHv6 Authentication
• RFC 4253 SSHv6 Transport Layer
• RFC 4254 SSHv6 Connection
• RFC 4271 A Border Gateway Protocol 4 (BGP-4)
• RFC 4273 Denitions of Managed Objects for BGP-4
• RFC 4291 IP Version 6 Addressing Architecture
• RFC 4292 IP Forwarding Table MIB
• RFC 4293 Management Information Base for the Internet
Protocol (IP)
• RFC 4360 BGP Extended Communities Attribute
• RFC 4419 Key Exchange for SSH
• RFC 4443 ICMPv6
• RFC 4456 BGP Route Reection: An Alternative to Full
Mesh Internal BGP (IBGP)
• RFC 4486 Subcodes for BGP Cease Notication Message
• RFC 4541 IGMP & MLD Snooping Switch
• RFC 4552 Authentication/Condentiality for OSPFv3
• RFC 4601 PIM Sparse Mode
• RFC 4675 RADIUS VLAN & Priority
• RFC 4724 Graceful Restart Mechanism for BGP
• RFC 4760 Multiprotocol Extensions for BGP-4
• RFC 4861 IPv6 Neighbor Discovery
• RFC 4862 IPv6 Stateless Address Auto-conguration
• RFC 4940 IANA Considerations for OSPF
• RFC 5065 Autonomous System Confederation for BGP
• RFC 5095 Deprecation of Type 0 Routing Headers in IPv6
• RFC 5187 OSPFv3 Graceful Restart
• RFC 5340 OSPFv3 for IPv6
• RFC 5424 Syslog Protocol
• RFC 5492 Capabilities Advertisement with BGP-4
• RFC 5519 Multicast Group Membership Discovery MIB
(MLDv2 only)
• RFC 5701 IPv6 Address Specic BGP Extended Community
Attribute
• RFC 5722 Handling of Overlapping IPv6 Fragments
• RFC 5798 VRRP (exclude Accept Mode and sub-sec timer)
• RFC 5880 Bidirectional Forwarding Detection
• RFC 5905 Network Time Protocol Version 4: Protocol and
Algorithms Specication
• RFC 6620 FCFS SAVI
• RFC 6987 OSPF Stub Router Advertisement
• RFC 7047 The Open vSwitch Database Management
Protocol
• RFC 7313 Enhanced Route Refresh Capability for BGP-4
• RFC 768 User Datagram Protocol
• RFC 783 TFTP Protocol (revision 2)
• RFC 791 IP
• RFC 792 ICMP
• RFC 793 TCP
• RFC 813 Window and Acknowledgement Strategy in TCP
• RFC 815 IP datagram reassembly algorithms
• RFC 8201 Path MTU Discovery for IP version 6
• RFC 826 ARP
• RFC 879 TCP maximum segment size and related topics
• RFC 896 Congestion control in IP/TCP internetworks
• RFC 917 Internet subnets
• RFC 919 Broadcasting Internet Datagrams
• RFC 922 Broadcasting Internet Datagrams in the Presence
of Subnets (IP_BROAD)
• RFC 925 Multi-LAN address resolution
• RFC 951 BOOTP
• RFC 1027 Proxy ARP
• SNMPv1/v2c/v3
• RFC 4861 IPv6 Neighbor Discovery
• RFC 4862 IPv6 Stateless Address Auto-conguration
• ITU-T Rec G.8032/Y.1344 Mar. 2010
• RFC 1757 Remote Network Monitoring Management
Information Base
• 2.5G/5GBASE-T (IEEE 802.3bz-2016), 2.5G/5G NBASE-T
• 10GBASE-T (IEEE 802.3an-2006)
• 25-Gigabit Ethernet (IEEE 802.3by-2016, 802.3cc-2017)
• 50-Gigabit Ethernet (IEEE 802.3cd-2018)
• RFC 3101 OSPF Not-so-stubby-area option
• RFC 4750 OSPFv2 MIB partial support no SetMIB
ARUBA CX 6300 SWITCHES AND ACCESSORIES
Switch Models
• Aruba 6300M 24-port SFP+ and 4-port SFP56 Switch
(JL658A)
• Aruba 6300M 48-port HPE Smart Rate 1/2.5/5GbE Class 6
PoE and 4-port SFP56 Switch (JL659A)
• Aruba 6300M 24-port HPE Smart Rate 1/2.5/5GbE Class 6
PoE and 4-port SFP56 Switch (JL660A)
• Aruba 6300M 48-port 1GbE Class 4 PoE and 4-port SFP56
Switch (JL661A)
• Aruba 6300M 24-port 1GbE Class 4 PoE and 4-port SFP56
Switch (JL662A)
• Aruba 6300M 48-port 1GbE and 4-port SFP56 Switch
(JL663A)
• Aruba 6300M 24-port 1GbE and 4-port SFP56 Switch
(JL664A)
• Aruba 6300F 48-port 1GbE Class 4 PoE and 4-port SFP56
Switch (JL665A)
22
Page 23
DATA SHEET
ARUBA CX 6300 SWITCH SERIES
• Aruba 6300F 24-port 1GbE Class 4 PoE and 4-port SFP56
Switch (JL666A)
• Aruba 6300F 48-port 1GbE and 4-port SFP56 Switch
(JL667A)
• Aruba 6300F 24-port 1GbE and 4-port SFP56 Switch
(JL668A)
• Aruba 6300M 48-port 1GbE and 4-port SFP56 Power-to-
Port 2 Fan Trays 1 PSU Bundle (JL762A)
Power Supplies
• Aruba X371 12VDC 250W 100-240VAC Power Supply
(JL085A)
• Aruba X372 54VDC 680W 100-240VAC Power Supply
(JL086A)
• Aruba X372 54VDC 1050W 110-240VAC Power Supply
(JL087A)
• Aruba X372 54VDC 1600W 110-240VAC Power Supply
(JL670A)
• Aruba X371 12VDC 250W 100-240VAC Power-to-Port
Power Supply (JL760A)
Fan Tra y
• Aruba 6300M Fan Tray (JL669A)
• Aruba 6300M Power-to-Port Fan Tray (JL761A)
• Aruba 50G SFP56 to SFP56 0.65m DAC Cable (R0M46A)
• Aruba 50G SFP56 to SFP56 3m DAC Cable (R0M47A)
Transceivers
• Aruba 100M SFP LC FX 2km MMF XCVR (J9054D)
2
• Aruba 1G SFP LC SX 500m MMF Transceiver (J4858D)
• Aruba 1G SFP LC LX 10km SMF Transceiver (J4859D)
• Aruba 1G SFP LC LH 70km SMF Transceiver (J4860D)
• Aruba 1G SFP RJ45 T 100m Cat5e Transceiver (J8177D)
• Aruba 10G SFP+ LC SR 300m MMF Transceiver (J9150D)
• Aruba 10G SFP+ LC LR 10km SMF Transceiver (J9151E)
• Aruba 10G SFP+ LC ER 40km SMF Transceiver (J9153D)
• Aruba 10GBASE-T SFP+ RJ-45 30m Cat6A Transceiver
(JL563A)
• Aruba 25G SFP28 LC SR 100m MMF Transceiver (JL484A)
• Aruba 25G SFP28 LC eSR 400m MMF Transceiver (JL485A)
• Aruba 25G SFP28 LC LR 10km SMF Transceiver (JL486A)
Software
• Aruba CX Mobile App https://www.arubanetworks.com/
products/networking/switches/cx-mobileapp/
• Aruba NetEdit Single Node: 1 year (JL639AAE)
• Aruba NetEdit Single Node: 3 years (JL640AAE)
1
1
Mounting Kit
• HPE X410 1U Universal 4-post Rack Mount Kit (J9583A)
• Aruba X414 1U Universal 4-post Rack Mounting Kit
(J9583B)
Cables
• Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
(J9281D)
• Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
(J9283D)
• Aruba 25G SFP28 to SFP28 0.65m Direct Attach Copper
Cable (JL487A)
• Aruba 25G SFP28 to SFP28 3m Direct Attach Copper
Cable (JL488A)
• Aruba 25G SFP28 to SFP28 5m Direct Attach Copper
Cable (JL489A)
1
50G capability is for use with 50G DACs for both interconnect and VSX stacking. 50G transceiver capability enabled by future software release.
© Copyright 2021 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without
notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
DS_Aruba6300SwitchSeries_RVK_040821 a00085162enw
Contact Us Share
23
Loading...
