Aruba 510 Series Campus Access Points
Installation Guide
The Aruba 510 Series Campus Access Points (AP-514 and AP-515) are high-performance, multi-radio wireless devices that can be deployed in either controller-based (ArubaOS) or controllerless (Aruba Instant) network environments. These access points deliver high performance concurrent 2.4 GHz and 5 GHz 802.11ax Wi-Fi functionality with MIMO radios (2x2 in 2.4 GHz, 4x4 in 5 GHz), while also supporting legacy 802.11a/b/g/n/ac wireless services. Wired Ethernet ports located on the back of this access points are used to connect the device to the wired networking infrastructure and to provide (802.3at class 4) PoE power to the device. Wired speeds up to 2.5Gbps are supported. In addition to both Wi-Fi radios, these APs also incorporate a Bluetooth Low Energy (BLE) and Zigbee radio, supporting a variety of use-cases and services, such as locationing and IoT. A variety of mounting scenarios are supported by a range of mount kits (sold separately). Make sure to purchase the correct mount kit for the intended deployment of the AP.

Package Contents

The following materials are included with this product:
Aruba 510 Series Campus Access Point (with a pre-installed mount bracket)Startup guide
The AP mount bracket attaches to a variety of mount kits (sold separately).
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including the original packing materials. Use these materials to repack and return the unit to the supplier if needed.

Hardware Overview

The following sections outline the hardware components of the 510 Series access points.
Figure 1 AP-515 Front View
510-IG-01 | September 2018 1
Figure 2 AP-514 Front View
A0
A1
A2
A3

External Antenna Connectors

The AP-514 access points are equipped with four external antenna connectors located on the front corners of the access point (see
Figure 2).

LEDs

The LED displays located on the front panel of the access point indicate the following functions:

System Status

The System Status LED indicates the operating condition of the access point, See Table 1.
Table 1 System Status LED
Color/State Meaning
Off Device Powered off
Green- solid Device ready, fully functional, no network restrictions
Green- blinking
Green- flashing
Amber- solid Device ready, restricted power mode (limited PoE power available, or IPM
Amber- flashing Device ready, restricted power mode (limited PoE power available, or IPM
1
2
Device booting, not ready
Device ready, fully functional, either uplink negotiated in sub-optimal speed (<1Gbps)
restrictions applied), no network restrictions
restrictions applied), upling negotiated in sub-optimal speed
Red System error condition
1. Blinking: one second on, one second off, 2 seconds cycle.
2. Flashing: mostly on, fraction of a second off, 2 seconds cycle.
The Radio Status LED indicates the operating mode of the access point’s radios. See Table 2.
2 Aruba 510 Series Campus Access Points | Installation Guide
Table 2 Radio Status LEDs
!
E1 E0
Console
DC Jack
Reset USB Interface
Color/State Meaning
Off Device powered off, or both radios disabled
Green- solid Both radios enabled in access mode
Green- blinking One radio enabled in access mode, other disabled
Amber- solid Both radios enabled in monitor mode
Amber- blinking One radio enabled in monitor mode, other disabled
Green/Amber- alternating
3
Green: one radio in access mode Amber: one radio in monitor mode

LED Display Settings

The LEDs have three operating modes that can be selected in the system management software:
Default mode: Refer to Table 1and Table 2Off mode: LEDs are offBlink mode: LEDs blink green (synchronized)
Force the LEDs into off mode and back to software defined mode by pressing the reset button for a short duration.
Pressing the reset button for longer than 10 seconds may cause the AP to reset and return to factory default state.
Figure 3 AP-515 Rear View
Aruba 510 Series Campus Access Points | Installation Guide 3
Kensington Lock Slot
Step2: push
Step1: Insert screwdriver into this slot and press down
4 Aruba 510 Series Campus Access Points | Installation Guide
Figure 4 Removing Cable Guide

Cable Guide

The cable guide on the rear of the access point is used to organize cables. To remove the cable guide, perform the following steps:
1. Insert the flat head of a screwdriver into the slot on the cable guide. Press the screwdriver down to disengage the buckle on underside of the tab, as shown in Figure 4.
2. Push the cable guide towards the chassis as shown in Figure 4, the cable guide will slide out.

Bluetooth Low Energy and Zigbee Radio

510 Series access points are equipped with an integrated BLE and Zigbee radio that provide the following capabilities:
location beacon applicationswireless console access
IOT gateway applications
1: N/C
2: RXD
3: TXD
4: GND
5: GND

Console Port

The console port is a Micro-B connector located on the back of this device. A proprietary serial adapter cable (AP­CBL-SERU) is needed to use this interface. It is sold separately to connect the AP to a serial terminal or a laptop for direct local management (a standard USB cable cannot be used for this interface). For pin-out details, refer to
Figure 5.
Figure 5 Micro-B Port Pin-out

Ethernet Ports

The Aruba 510 Series access points are equipped with two Ethernet ports (E0 and E1), shown in Figure 3.
E0 port: 100/1000/2500BaseT auto-sensing MDI/MDX wired RJ45 network connectivity portE1 port: 100/1000BaseT auto-sensing MDI/MDX wired RJ45 network connectivity port
Both ports are compliant with 802.3ab 1000BaseT Gigabit Ethernet standard, while E0 also supports both NBase-T and 802.3bz standards for 2.5bps Ethernet. The E0 port supports 802.3af, 802.3at and 802.3bt to accept power from a POE source, such as a PoE midspan injector, or a network switch.

Kensington Lock Slot

The 510 Series is equipped with a Kensington lock slot for additional physical security.

USB 2.0 Interface

The top of this access point is equipped with a USB-A port that is compatible with cellular modems. When active, this port can supply up to 5W/1A to a connected device.

Reset Button

The reset button located on the bottom of the device can be used to reset the access point to factory default settings or turn off/on the LED display.
There are two ways to reset the access point to factory default settings:

Reset the AP during normal operation

press and hold down the reset button using a small, narrow object such as a paper clip for several seconds for more than 10 seconds during normal operation.

Reset the AP while powering up

1. Press and hold down the reset button using a small, narrow object such as a paper clip while the access point is not powered on (either via DC power or PoE).
2. Connect the power supply (DC or PoE) to the access point while the reset button is being held down.
3. Release the reset button on the access point after 15 seconds.
To turn off/on the LED display, press and release the reset button using a small, narrow object, such as a paperclip for less than 10 seconds during normal operation of the access point.

Power

Both Ethernet ports support PoE-in (AP is a PoE-PD device), allowing the device to draw power from compliant PoE power sources. If PoE is not available, a proprietary AP-AC-12V30B power adapter (sold separately) can be used to power the access point. When both PoE and DC power sources are available, the DC power source takes precedence. In that case, the access point simultaneously draws a minimal current from the PoE source. In the
Aruba 510 Series Campus Access Points | Installation Guide 5
event that the DC source fails, the access point switches to the PoE sources.
!
The Intelligent Power Monitoring (IPM) feature may also be used to manage the power consumption preferences for this device. When enabled, the user may enable/disable power restrictions for the access point using Aruba’s AP management software.
Table 3 lists operational restrictions when the access point is powered by different power options.
Table 3 Power Options and Operational Restrictions
Power Source IPM Restrictions
DC power n/a No restrictions, all capabilities available
PoE 802.3bt n/a No restrictions, all capabilities available
PoE 802.3at n/a No restrictions, all capabilities available
PoE 802.3af enabled All capabilities available (features may be disabled with
PoE 802.3af disabled USB disabled
1. This restriction may be overridden using Aruba’s AP management software.
IPM configuration)
1
operate in 2x2 mode
, one Ethernet port disabled, both radios

Before You Begin

Refer to the sections below before beginning the installation process.
FCC Statement: Improper termination of access points installed in the United States configured to non-US model controllers will be in violation of the FCC grant of equipment authorization. Any such willful or intentional violation may result in a requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80).

Pre-Installation Checklist

Before installing your Aruba 510 Series access point, be sure that you have the following (not included with the AP):
A mount kit compatible with the AP and mount surfaceCat5E or better UTP cable with network accessOne or more external antennas (when using the AP-514)(Optional) a compatible 12V AC-to-DC power adapter with power cord (Optional) a compatible PoE midspan injector with power cord(Optional) a compatible snap-on front cover (for easy aesthetic customization)(Optional) an AP-CBL-SERU console cable
Also make sure that (at least) one of the following network services is supported:
Aruba Discovery Protocol (ADP)DNS server with an “A” recordDHCP Server with vendor-specific options
Aruba Networks, Inc., in compliance with governmental requirements, has designed the 510 Series access points so that only authorized network administrators can change the settings. For more information about access poit configuration, refer to the AP Software Quick Start Guide.

Identifying Specific Installation Locations

Use the access point placement map generated by Aruba RF Plan software application to determine the proper installation location(s). Each location should be as close as possible to the center of the intended coverage area and should be free from obstructions or obvious sources of interference. These RF absorbers/reflectors/ interference sources will impact RF propagation and should be accounted for during the planning phase and
6 Aruba 510 Series Campus Access Points | Installation Guide
adjusted for in RF plan.
!
!
!
!
Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in improper operation. If such use is necessary, this equipment and the other equipment should be observed to verify that they are operating normally.

Identifying Known RF Absorbers/Reflectors/Interference Sources

Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation phase is critical. Make sure that these sources are taken into consideration when you attach an access point to its fixed location. RF absorbers include:
Cement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing
for potential RF propagation. New concrete has high levels of water concentration in the concrete, blocking RF signals.
Natural Items—Fish tanks, water fountains, ponds, and treesBrick
RF reflectors include:
Metal Objects—Metal pans between floors, rebar, fire doors, air conditioning/heating ducts, mesh windows,
blinds, chain link fences (depending on aperture size), refrigerators, racks, shelves, and filing cabinets.
Do not place an access point between two air conditioning/heating ducts. Make sure that access points are
placed below ducts to avoid RF disturbances.
RF interference sources include:
Microwave ovens and other 2.4 or 5 GHz objects (such as cordless phones)Cordless headset such as those used in call centers or lunch rooms
Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the access point. Otherwise, degradation of the performance of this equipment could result.
RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits. This equipment should be installed and operated with a minimum distance of 13.78 inches (35cm) between the radiator and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Déclaration sur les limites d'exposition aux radiofréquences : cet équipement est conforme aux limites d'exposition aux rayonnements radioélectriques spécifiées par la FCC. Il doit être installé et utilisé à une distance minimale de 35 cm par rapport à votre corps pour les fréquences de 2,4 et 5 GHz. Cet émetteur-récepteur ne doit pas être utilisé ou situé à proximité d'autres antennes ou émetteurs-récepteurs.

Access Point Installation

the Aruba 510 Series access points are designed for ceiling or wall mounted deployments. Several optional mount kits are available to attach the Aruba 510 Series access point to a variety of surfaces. These mount kits are available as accessories and must be ordered separately. Refer to the online ordering guide at http://
www.arubanetworks.com/assets/og/OG_AP-510Series.pdf
All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP). The installer is responsible for ensuring that grounding is available and meets applicable national and electrical codes. Failure to properly install this product may result in physical injury and/or damage to property.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures corporelles et / ou des dommages matériels.
Aruba 510 Series Campus Access Points | Installation Guide 7
!
The installer is responsible for securing the access point onto the ceiling tile rail in accordance with the steps
!
!
!
below. Failure to properly install this product may result in physical injury and/or damage to property.
Use of accessories, transducers and cables other than those specified or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper operation.

Software

For instructions on choosing operating modes and initial software configuration, refer to the AP Software Quick Start Guide.
Aruba access points are classified as radio transmission devices, and are subject to government regulations of the host country. The network administrator(s) is/are responsible for ensuring that configuration and operation of this equipment is in compliance with their country’s regulations. For a complete list of approved channels in your country, refer to the Aruba Downloadable Regulatory Table at support.arubanetworks.com.

Verifying Post-Installation Connectivity

The integrated LED on the access point can be used to verify that the access point access point is receiving power and initializing successfully (see Table 1 on verifying post-installation network connectivity.
-Table 2). Refer to the AP Software Quick Start Guide for further details

Electrical and Environmental Specifications

For additional specifications on this product, please refer to the product data sheet at www.arubanetworks.com

Electrical

Ethernet:
E0 port: 100/1000/2500BaseT auto-sensing MDI/MDX wired RJ45 network connectivity portE1 port: 100/1000BaseT auto-sensing MDI/MDX wired RJ45 network connectivity port
Power:
12V DC power interface, support powering through AC-to-DC power adapter (AP-AC-12V30B)Power over Ethernet (PoE): 802.3af, 802.3at or 802.3bt compliant source
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed, with an output rated 12V DC, minimum 0.75A, marked “LPS” and “Class 2,” and suitable for plugging into a standard power receptacle in the US and Canada.

Environmental

Operating:
Temperature: 0°C to +50°C (+32°F to +122°F)
Humidity: 5% to 93% non-condensing
Storage and transport:
Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5% to 93% non-condensing
The Aruba 510 Series access points are for indoor use only. The access point, AC adapter, and all connected
cables are not designed for outdoor use.
8 Aruba 510 Series Campus Access Points | Installation Guide
!
This device is intended for stationary use in partly temperature controlled weather-protected environments.
!
!
!
!

Regulatory Model Name

The following regulatory model numbers (RMN) apply to the 510 Series:
AP-514: APIN0514AP-515: APIN0515

Safety and Regulatory Compliance

FCC
To view the FCC ID for controller-managed access points:
1. Log into the controller WebUI
2. Navigate to Maintenance > Controller > About
To view the FCC ID for Instant access points:
1. Log into the virtual controller WebUI
2. Navigate to Maintenance > About
RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equipment should be installed and operated with a minimum distance of 13.78 inches (35cm) between the radiator and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Déclaration de la concernant l’exposition aux rayonnements à fréquence radioélectrique (FR): Cet appareil est conforme aux limites d’exposition aux rayonnements FR établies par la FCC. Il doit être installé et utilisé à une distance minimale de 35 cm (13,78 pouces) entre le radiateur et votre corps, qu’il opère sur la bande 2,4 GHz ou 5 GHz. Cet émetteur ne doit pas être installé ou utilisé à proximité immédiate d’une autre antenne ni d’un autre transmetteur.
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la conformité est susceptible d'annuler son droit d'utilisation.

Federal Communication Commission

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Aruba 510 Series Campus Access Points | Installation Guide 9
Increase the separation between the equipment and receiver.Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.Consult the dealer or an experienced radio or TV technician for help.

Industry Canada

This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment Regulations. In accordance with Industry Canada regulations, this radio transmitter and receiver may only be used with an antenna, the maximum type and gain of which must be approved by Industry Canada. To reduce potential radio interference, the type of antenna and its gain shall be chosen so that the equivalent isotropic radiated power (EIRP) does not exceed the values necessary for effective communication. This device complies with Industry Canada's license-exempt RSS regulations. Operation of this device is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation. When operated in the 5.15 to 5.25 GHz frequency range, this device is restricted to indoor use to reduce the potential for harmful interference with co-channel Mobile Satellite Systems.

Déclaration d’Industrie Canada

Conformément aux réglementations d’Industrie Canada, cet émetteur-récepteur radio doit être utilisé uniquement avec une antenne dont le type et le gain maximal doivent être approuvés par Industrie Canada. Pour réduire les interférences radio potentielles, le type d’antenne et son gain doivent être choisis de façon à ce que la puissance isotrope rayonnée équivalente (PIRE) ne dépasse pas les valeurs nécessaires à une communication efficace. Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce périphérique est soumise aux deux conditions suivantes : (1) ce périphérique ne doit pas provoquer d’interférences, et (2) ce périphérique doit accepter toute interférence, y compris les interférences susceptibles de provoquer un dysfonctionnement.
En cas d'utilisation dans la plage de fréquences de 5,15 à 5,25 GHz, cet appareil doit uniquement être utilisé en intérieur afin de réduire les risques d'interférence avec les systèmes satellites mobiles partageant le même canal.

Canadian Caution

This radio transmitter model APIN0514/APIN0515 has been approved by Industry Canada to operate with the antenna typeslisted in the table in the online ordering guide (link provided below) with the maximum permissible gain indicated. Antenna types not included in this list, having a gaingreater than the maximum gain indicated for that type, are strictly prohibited for usewith this device.
http://www.arubanetworks.com/assets/og/OG_AP-510Series.pdf
Le présent transmetteur radio modèle APIN0514/APIN0515 a été approuvé par Industrie Canada pour fonctionner avec les types d'antennesindiqués dans le tableau du guide de commande en ligne (lien fourni ci­dessous) avec le gain permissible maximum indiqué. Il est strictement défendu d'utiliser avec cet appareil les types d'antennes non inclus dans cette liste, ayant un gain supérieur au gain maximumindiqué pour ce type.
http://www.arubanetworks.com/assets/og/OG_AP-510Series.pdf

European Union Regulatory Conformance

The Declaration of Conformity made under Radio Equipment Directive 2014/53/EU is available for viewing at: www.hpe.com/eu/certificates. Select the document that corresponds to your device’s model number as it is indicated on the product label
This radio transmitter model has been approved to operate with the antenna types listed in the online ordering guide (link provided below) with the maximum permissible gain indicated. Antenna types not included in this list, having a greater gain than the maximum gain indicated for the type, are strictly prohibited for use with this device. Compliance is only assured if the Aruba approved accessories as listed in the ordering guide are used.
http://www.arubanetworks.com/assets/og/OG_AP-510Series.pdf

Wireless Channel Restrictions

5150-5350MHz band is limited to indoor only in the following countries; Austria (AT), Belgium (BE), Bulgaria (BG), Croatia (HR), Cyprus (CY), Czech Republic (CZ), Denmark (DK), Estonia (EE), Finland (FI), France (FR), Germany (DE), Greece (GR), Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI), Lithuania (LT), Luxembourg (LU), Malta (MT), Netherlands (NL), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovakia
10 Aruba 510 Series Campus Access Points | Installation Guide
(SK), Slovenia (SL), Spain (ES), Sweden (SE), Switzerland (CH), Turkey (TR), United Kingdom (UK).
!
!
!
!
Frequency Range MHz Max EIRP
2402-2480 9 dbm
2412-2472 20 dbm
5150-5250 23 dbm
5250-5350 23 dbm
5470-5725 30 dbm
5725-5850 N/A for EU
Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User Guide/ Instant User Guide for details on restrictions.

Medical

1. Equipment not suitable for use in the presence of flammable mixtures.
2. Connect to only IEC 60950-1 or IEC 60601-1 certified products and power sources. The end user is
responsible for the resulting medical system complies with the requirements of IEC 60601-1.
3. Wipe with a dry cloth, no additional maintenance required.
4. No serviceable parts, the unit must be sent back to the manufacturer for repair.
5. No modifications are allowed without Aruba approval.
This device is intended for indoor use, in hallways, breakrooms, office areas of professional medical facilities. This device should not be installed in rooms housing patients.
This device has no IEC/EN60601-1-2 essential performance.
Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in improper operation. If such use is necessary, this equipment and the other equipment should be observed to verify that they are operating normally.
Compliance is based on the use of Aruba approved accessories. Refer to the ordering guide for this access point at http://www.arubanetworks.com/assets/og/OG_AP-510Series.pdf.
Use of accessories, transducers and cables other than those specified or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper operation.
Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the access point. Otherwise, degradation of the performance of this equipment could result.

Brazil

Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados.
Aruba 510 Series Campus Access Points | Installation Guide 11

Japan

México

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debeaceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.

Morocco

Нормативные требования Евразийского Экономического Союза

HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г. Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499 403
4677
'HPE Belarus': ИООО «Хьюлетт-Паккард Бел», Республика Беларусь, 220030, г. Минск, ул. Интернациональная, 36-1, Тел е ф он/факс: +375 17 392 28 20
'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г.
Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Те лефон/факс: + 7 727 355 35 50

Kazakhstan

ЖШС "Хьюлетт Паккард Энтерпрайз" Ресей Федерациясы, 125171, Мәскеу, Ленинград тас жолы, 16A блок 3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677
«HEWLETT-PACKARD Bel» ЖШС, Беларусь Республикасы, 220030, Минск қ., Интернациональная көшесі, 36/ 1, Телефон/факс: +375 17 392 28 20
ЖШС «Хьюлетт-Паккард (К)», Қазақстан Республикасы, 050040, Алматы к., Бостандык ауданы, Әл-Фараби даңғ ылы, 77/7, Телефон/факс: +7 (727) 355 35 50

Taiwan

第十二條   經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功 能。 第十四條   低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時方得繼續使 用。   前項合法通信,指依電信法規定作業之無線電通信。   低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電 機設備之干擾

Proper Disposal of Aruba Equipment

Dispose of Aruba products per local regulation. For the most current information about Global Environmental Compliance and Aruba products, see our website at www.arubanetworks.com.
12 Aruba 510 Series Campus Access Points | Installation Guide

Waste of Electrical and Electronic Equipment

Aruba products at end of life are subject to separate collection and treatment in the EU Member States, Norway, and Switzerland and therefore are marked with the symbol shown at the left (crossed-out wheelie bin). The treatment applied at end of life of these products in these countries shall comply with the applicable national laws of countries implementing Directive 2002/96/EC on Waste of Electrical and Electronic Equipment (WEEE).

European Union RoHS

Aruba products also comply with the EU Restriction of Hazardous Substances Directive 2011/65/EC (RoHS). EU RoHS restricts the use of specific hazardous materials in the manufacture of electrical and electronic equipment. Specifically, restricted materials
under the RoHS Directive are Lead (including Solder used in printed circuit assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some Aruba products are subject to the exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit assemblies). Products and packaging will be marked with the “RoHS” label shown at the left indicating conformance to this Directive.

China RoHS

Aruba products also comply with China environmental declaration requirements and are labeled with the “EFUP 25” label shown below.
Aruba 510 Series Campus Access Points | Installation Guide 13

Taiwan RoHS

單元
限用物質及其化學符號
台灣限用物質含有情況標示
(Pb) (Hg)
六價
(Cd)
(
&U

)
(PBB)
(PBDE)
傳輸線和線材
〇〇 〇 〇 〇
外殼
〇〇〇 〇
記憶體
〇〇 〇 〇 〇
其他機械組裝設備
〇〇 〇
〇〇〇 〇
印刷電路零組件 (PCAs)
(斷路器 選配)
〇〇〇 〇
(冷卻及加熱系統 選配)
〇〇 〇 〇 〇
(風扇 選配)
〇〇 〇 〇 〇
()
存取裝置(HDD) 選配
〇〇〇 〇
〇〇〇 〇
讀寫元件(CD/DVD/ 機)(選配)
() −
變壓器/電源供應器 選配
〇〇 〇
備考1.〝〇係指該項限用物質之百分比含量未超出百分比含量基準。 備考2.〝−係指該項限用物質為排除項目。
選配單元使用於特定產品型號,詳細規格請參照產品說明書。

India RoHS

This product complies with RoHS requirements as prescribed by E-Waste (Management & Handling) Rules, governed by the Ministry of Environment & Forests, Government of India.
Turkey RoHS
Ukraine RoHS
14 Aruba 510 Series Campus Access Points | Installation Guide

Contacting Support

Table 4 Contact Information
Main Site www.arubanetworks.com
Support Site https://support.arubanetworks.com
Airheads Social Forums and Knowledge Base
North American Telephone 1-800-943-4526 (Toll Free)
International Telephones http://www.arubanetworks.com/support-services/contact-support/
Software Licensing Site https://hpe.com/networking/support
End of Support information http://www.arubanetworks.com/support-services/end-of-life-
Security Incident Response Team (SIRT) Site: http://www.arubanetworks.com/support-services/security-
community.arubanetworks.com
1-408-754-1200
products/end-of-life-policy/
bulletins/
Email: sirt@arubanetworks.com

Copyright

© Copyright 2018 Hewlett Packard Enterprise Development LP

Open Source Code

This product includes code licensed under the GNU General Public License, the GNU Lesser General Public License, and/or certain other open source licenses. A complete machine-readable copy of the source code corresponding to such code is available upon request. This offer is valid to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product version by Hewlett Packard Enterprise Company. To obtain such source code, send a check or money order in the amount of US $10.00 to:
Hewlett Packard Enterprise Company Attn: General Counsel 3000 Hanover Street Palo Alto, CA 94304 USA

Warranty

This hardware product is protected by an Aruba warranty. For more details visit www.hpe.com/us/en/
support.html
Aruba 510 Series Campus Access Points | Installation Guide 15
Loading...
