Aruba 370 Series Outdoor Access Points
Installation Guide
The Aruba 370 Series outdoor wireless access points (AP-374, AP-375 and AP-377) support IEEE 802.11ac Wave 2
standard, delivering high performance with the MU-MIMO (Multi-User Multiple-Input, Multiple-Output)
technology, while also supporting 802.11a/b/g/n wireless services.
The 370 Series outdoor wireless access points provide the following capabilities:
IEEE802.11a/b/g/n/ac operation as a wireless access point
IEEE802.11a/b/g/n/ac operation as a wireless air monitor
IEEE802.11a/b/g/n/ac spectrum monitor
Compatibility with IEEE 802.3at PoE
Guide Overview
“Hardware Overview” on page2 provides a detailed hardware overview of the 370 Series access points.
“Before You Begin” on page6 provides key questions to ask and items to consider when deploying an
outdoor wireless network.
“Installing the Access Point” on page8 describes the multi-step process for a successful installation and
deployment of the 370 Series access points.
“Safety and Regulatory Compliance” on page14 provides an overview of safety and regulatory compliance
information.
Package Contents
370 Series access point
Ethernet cable gland x1
USB console cable x1
Copper lug x1
M4x6 screw x1
Startup guide
Simplified Declaration of Conformity
The weatherproof caps for Ethernet, Console, and power interfaces are connected to the access point, not
loose in the package.
Mounting kits for use with the 370 Series access points are sold separately. Contact your Aruba sales
representative for details.
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton,
including the original packing materials. Use these materials to repack and return the unit to the supplier if
needed.
Rev 02 | January 2018 1
Hardware Overview
System LED
System LED
Figure 1 AP-374 Front View (with Aesthetic Cover)
The antenna connectors of AP-374 are covered by an aesthetic cover. The aesthetic cover can be removed
when necessary.
Figure 2 AP-375 Front View
Figure 3 AP-377 Front View
2 Aruba 370 Series Outdoor Access Points |Installation Guide
LED
AC Power Interface
E1/SFP
E0/POE
Grounding Point
USB Console Port and Reset button
The 370 Series access point is equipped with one LED that indicates the system status of the access point.
Table 1 370 Series LED Meanings during Boot Up
LED Color/State Meaning
System LED Off No power to AP
Red Initial power-up
Green - Flashing AP booting
Green - Steady AP ready and 1000Mbps Ethernet link established. The LED turns
off after 1200 seconds
Green - Yellow, 6 seconds
period
AP ready and 10/100Mbps Ethernet link established. The LED
turns off after 1200 seconds
Table 2 370 Series LED Meanings during Operation
LED Color/State Meaning
System LED Solid Red General fault
One blink off every 3
seconds
Tw o q ui c k b l in k o f f 0 .5
seconds apart cycled every
3 seconds
Radio 0 fault (5 GHz)
Radio 1 fault (2.4GHz)
Figure 4 AP-374 Rear View
Aruba 370 Series Outdoor Access Points |Installation Guide 3
Figure 5 AP-375 Rear View
AC Power Interface
E1/SFP
E0/POE
Grounding Point
USB Console Port and Reset button
AC Power Interface
E1/SFP
E0/POE
Grounding Point
USB Console Port, Reset button & LED
Figure 6 AP-377 Rear View
E0/POE
The 370 Series access point is equipped with one 10/100/1000 Base-T auto-sensing MDI/MDX Ethernet port. This
port supports wired-network connectivity, in addition to Power over Ethernet (PoE) from IEEE 802.3at compliant
power sources.
This access point accepts 56V DC (802.3at) nominal as a standard powered device (PD) from a Power Sourcing
Equipment (PSE) such as a PoE midspan injector, or network infrastructure that supports PoE.
This port has an RJ-45 female connector with the pin-outs shown in Figure 7.
E1/SFP Port
The 370 Series access point is equipped with one 1000 Base-X small form-factor pluggable (SFP) port for fiberoptic network connections. The applicable SFP modules includes:
Aruba SFP-LX-EXT SFP module (part number: Q8N52A)
Aruba SFP-SX-EXT SFP module (part number Q8N53A)
4 Aruba 370 Series Outdoor Access Points |Installation Guide
The applicable SFP cable gland is Aruba CKIT-OD-SFP SFP cable gland (part number: Q8N54A). The SFP module
1000Base-T Gigabit
Ethernet Port
RJ-45 Female
Pin-Out
Signal Name
1
2
3
4
5
6
7
8
BI_DC+
BI_DC-
BI_DD+
BI_DD-
BI_DA+
BI_DABI_DB+
BI_DB-
Function
Bi-directional pair +C, POE Positive
Bi-directional pair -C, POE Positive
Bi-directional pair +D, POE Negative
Bi-directional pair -D, POE Negative
Bi-directional pair +A, POE Negative
Bi-directional pair -A, POE Negative
Bi-directional pair +B, POE Positive
Bi-directional pair -B, POE Positive
and cable gland are sold separately. Contact your Aruba sales representative for details.
Figure 7 Gigabit Ethernet Port Pin-Out
Grounding Point
Always remember to protect the access point by installing grounding lines. The ground connection must be
complete before connecting power to the access point enclosure.
USB Console Port
The USB Micro-B console port allows you to connect the access point to a laptop or serial console for direct
management. Use the included USB console cable to connect the access point. You can download the necessary
driver for USB-UART adapter from support.arubanetworks.com under the Tools & Resources tab.
You need a proper Allen wrench (8mm) to open the cover of the USB Console port.
Use the following setting to access the terminal:
Table 3 Console Settings
Baud Rate Data Bits Parity Stop Bits Flow Control
9600 8 None 1 None
Reset Button
The reset button can be used to return the access point to factory default settings. To reset the access point:
1. Power off the AP.
2. Press and hold the reset button using a small, narrow object, such as a paperclip.
3. Power-on the AP without releasing the reset button. The system LED will flash within 5 seconds.
4. Release the reset button.
The system LED will flash again within 15 seconds indicating that the reset is completed. The AP will now
continue to boot with the factory default settings.
AC Power Interface
The 370 Series access point is capable of AC power in the range of 100 - 240 VAC. The power cord or power
connector kit is sold separately.
External Antenna Connectors
The AP-374 access point is equipped with six external antenna connectors. The connectors are labeled 2G0, 2G1,
5G0, 5G1, 5G2, and 5G3.
Aruba 370 Series Outdoor Access Points |Installation Guide 5
!
CAUTION
External antennas for this device must be installed by an Aruba Certified Mobility Professional (ACMP) or other
5G1 2G0 5G3
5G2 2G1 5G0
!
CAUTION
!
CAUTION
Aruba-certified technician, using manufacturer-approved antennas only.
The Equivalent Isotropically Radiated Power (EIRP) levels for all external antenna devices must not exceed the
regulatory limit set by the host country/domain.
Installers are required to record the antenna gain for this device in the system management software.
Les antennes externes pour cet appareil doivent être installées par un professionnel de la mobilité certifié Aruba
(ACMP) ou un autre technicien certifié Aruba, en utilisant uniquement des antennes approuvées par le fabricant.
Les niveaux équivalents de puissance à rayonnement isotrope (EIRP) pour tous les périphériques d'antenne
externe ne doivent pas dépasser la limite réglementaire définie par le pays hôte / domaine.
Les installateurs doivent enregistrer le gain d'antenne pour cet appareil dans le logiciel de gestion du système.
Figure 8 AP-374 Bottom View (without Aesthetic Cover)
Before You Begin
FCC Statement: Improper termination of access points installed in the United States configured to non-US
model controllers will be in violation of the FCC grant of equipment authorization. Any such willful or
intentional violation may result in a requirement by the FCC for immediate termination of operation and may
be subject to forfeiture (47 CFR 1.80).
EU Statement:
Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS/Instant
User Guide for details on restrictions.
Produit réseau local radio basse puissance operant dans la bande fréquence 2.4 GHz et 5 GHz. Merci de vous
referrer au ArubaOS/Instant User Guide pour les details des restrictions.
Low Power FunkLAN Produkt, das im 2.4 GHz und im 5 GHz Band arbeitet. Weitere Informationen bezlüglich
6 Aruba 370 Series Outdoor Access Points |Installation Guide
Einschränkungen finden Sie im ArubaOS/Instant User Guide.
Apparati Radio LAN a bassa Potenza, operanti a 2.4 GHz e 5 GHz. Fare riferimento alla ArubaOS/Instant User
Guide per avere informazioni detagliate sulle restrizioni.
