Datasheet
HP DreamColor Z31x Studio Display
Designed for the world’s elite
color professionals, the
award-winning HP
DreamColor Technology
brings the industry’s boldest
visions to life. Captivate with
Cinema 4K resolution, an
expansive color gamut for
remarkably vivid colors,
integrated colorimeter and
custom-tailored management
tools.
And the award goes to…
●
The display that walked the red carpet. The HP DreamColor Technology won the 2015 Scientific
and Engineering Award from the Academy of Motion Picture Arts and Sciences.1Experience
theater-quality color from HP’s most precise display yet.
More time creating. Less time calibrating.
●
Maintain accurate color with a pop-up sensor that calibrates on demand or on a regular
schedule. No longer wonder if your color is correct-it just is.
Designed by pros. For pros.
●
HP worked with leading visual effects and animation studios to create customized solutions for
the optimal design process. Speed projects to completion with True 2K, onscreen markers and
keyboard-based input switching between your devices.
Datasheet | HP DreamColor Z31x Studio Display
HP DreamColor Z31x Studio Display Specifications Table
Product Number
Display Size (diagonal)
Viewing Angle
Brightness
Contrast Ratio
Response Ratio
Aspect Ratio
Native Resolution
Resolutions Supported
Display Features
Input Signal
Ports and Connectors
Input Power
Power Consumption
Dimensions with Stand
(W x D x H)
Dimensions without
Stand (W x D x H)
Weight
Ergonomic Features
Environmental
What´s in the box
See important legal notifications on the last page
Z4Y82A4
79 cm (31.1")
178° horizontal; 178° vertical
250 cd/m²
1500:1 static
20 ms on/off
17:9
4096 x 2160 @ 60 Hz
4096 x 2160; 3840 x 2160; 2048 x 2160; 2560 x 1440; 2048 x 1080; 1920 x 1080; 1366 x 768; 1280 x 1024; 1280 x 720; 1024 x 768; 800 x 600; 720 x
400; 640 x 480
Anti-glare; BrightView Panel; In plane switching; Language selection; LED Backlights; On-screen controls; Plug and Play; User programmable; Anti-static
2 DisplayPort™ 1.2; 2 HDMI 2.0
1 USB 3.0 Type-B (upstream); 1 USB Type-C™ (DisplayPort™ 1.2, power delivery up to 60 W); 4 USB 3.0 (downstream, two side and two rear)
Input voltage: 100 to 240 VAC
260 W (maximum), 120 W (typical), 0.5 W (standby)
29.05 x 9.76 x 22.28 in
73.8 x 24.8 x 56.6 cm
29.05 x 3.25 x 16.3 in
73.80 x 8.26 x 41.41 cm
Without stand
33 lb
15 kg
With stand
Tilt: -5 to +30°; Swivel: ±45°; Height: 117 mm
Arsenic-free display glass; Mercury-free display backlights
AC power cable; CD with User Guide, warranty, drivers; DisplayPort™ 1.2 cable; HDMI cable; Monitor; USB cable (Type A male to Type B male); USB Type-C™
cable; USB Type-C™ to A cable
1,3
1
1
1
Datasheet | HP DreamColor Z31x Studio Display
Accessories and services (not included)
HP Business PC Security Lock
Kit
HP DisplayPort Cable Kit
HP 4 year Next business day
Exchange Large Monitor
Service
Protect your HP Business PC from tampering or theft in public locations by locking-down peripherals such as keyboards,
mice, monitors or USB security devices and preventing the removal of the PC chassis cover.
Product number: PV606AA
Connects a DisplayPort connector on an HP Business Desktop computer to a DisplayPort connector on a monitor.
Product number: VN567AA
When you can’t afford to wait for your device to be exchanged, let HP Hardware Next Business Day Advance Exchange get
you back up and running as quickly as possible. You’ll get remote technical assistance to help you resolve problems. Then,
if needed, we’ll ship you a replacement unit within the next business day1 – along with a prepaid waybill to ship back your
defective unit.
Product number: U0J12E
Datasheet | HP DreamColor Z31x Studio Display
Messaging Footnotes
1
The 2015 Scientific and Engineering Award from the Academy of Motion Picture Arts and Sciences went to John Frederick, Bob Myers, Karle Rasche and TomLianza for the development of the HP DreamColor LP2480zx
Professional Display. This cost-effective display offered a stable, wide color gamut, allowing facility-wide adoption in feature animation and visual effects studios.
Technical Specifications Footnotes
1
All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
3
HP applied uniformity compensation to each Z31x display, which brings the typical uniform peak luminance down to 250 cd/m² from a 350 cd/m² native peak brightness. Display supports luminance calibration up to 250
cd/m², reserving any luminance headroom for panel aging compensation.
