Hewlett Packard X9S70EA Product Data Sheet
QuickSpecs
HP t310 Quad-Display Zero Client
Overview
c04957266 — DA – 15563 Worldwide — Version 1 — May 9, 2016
Page 1
HP t310 Quad-Display Zero Client
FRONT
1.
(1) PCOIP indicator LED
2.
(1) Power button
3.
(2) USB 2.0
4.
(1) Headphone Jack
5.
(1) Microphone Jack
QuickSpecs
HP t310 Quad-Display Zero Client
Overview
c04957266 — DA – 15563 Worldwide — Version 1 — May 9, 2016
Page 2
BACK FRONT
1.
(2) USB 2.0
2.
(1) RJ-45/SFP port
3.
(4) DisplayPort 1.2
4.
Cable lock slot
5.
(1) Speaker/Headphone Jack
6.
(1) 12V Power Connector
QuickSpecs
HP t310 Quad-Display Zero Client
Overview
c04957266 — DA – 15563 Worldwide — Version 1 — May 9, 2016
Page 3
Models:
HP t310 Quad-Display Zero Client
RJ-45 NIC version
W5W64UA
Fiber NIC version
W5W68UA
Hardware features:
TERA2140 PCoIP Zero Client processor
512 MB DDR3 1333 MT/s RAM (with transfer rates up to 1333 MT/s)
32 MB SPI Flash memory to store firmware
10/100/1000 Gigabit Ethernet (RJ-45) or 100Mbps Fiber NIC (optional and must be configured at purchase) or 1Gbps Fiber
NIC (optional and must be configured at purchase)
Supports up to 4 displays, using 4 DisplayPort connections at resolutions up to 1920x1200 at displays at resolutions up
to 2560x1600.
4 USB 2.0 ports (2 front, 2 rear): 1 for keyboard, 1 for mouse, 2 for other USB devices
Contains over 10% post-consumer recycled plastics (by weight)
HP PCoIP Zero Client System Features:
Uses the TERA2140 PCoIP Zero Client Processor to provide dedicated hardware decode of the PCoIP desktop
Delivers a high performance end-user experience using the PCoIP protocol
Fully interoperable with all PCoIP endpoints including PCoIP virtual desktops, PCoIP remote workstation hosts and APEX
2800 server offload cards
Full power management with Wake-on-LAN support
AES-128 bit or AES-256 bit encryption
No application operating system and no persistent user data is stored on the zero client device
Simple and quick to deploy and manage using the PCoIP Management Console (available from techsupport.teradici.com)
Warranty:
HP Total Care Warranty and Services: three-year limited hardware warranty in most regions and may vary by country. HP Care
Pack Services are optional extended service contracts that go beyond your standard limited warranties. For more details visit:
http://www.hp.com/go/cpc.
QuickSpecs
HP t310 Quad-Display Zero Client
Technical Specifications
c04957266 — DA – 15563 Worldwide — Version 1 — May 9, 2016
Page 4
OPERATING SYSTEM
No Operating System
PROCESSOR
TERA2140 PCoIP Zero Client processor
MEMORY
Flash memory (boot drive)
32 MB SPI
System memory
512 MB DDR3 1333 MT/s RAM (Transfer rates up to 1333 MT/s)
DISPLAY
Supports up to 4 displays with resolutions up to 1920 x 1200, or dual displays with resolutions up to 2560 x 1600.
INPUT/OUTPUT (peripheral support)
Keyboard
HP USB Keyboard
Mouse
HP USB Mouse
AUDIO
Output
1/8-inch mini-jack
16, 20, 24, or 32-bit stereo
8-96 kHz sample rate
Input
1/8-inch microphone mini-jack
16, 20, 24, or 32-bit stereo -bit stereo,
96 kHz sample rate
QuickSpecs
HP t310 Quad-Display Zero Client
Technical Specifications
c04957266 — DA – 15563 Worldwide — Version 1 — May 9, 2016
Page 5
HARDWARE SECURITY
HP Cable Lock Slot
NETWORKING & COMMUNICATIONS
Hardware networking
10/100/1000 Gigabit Ethernet (RJ-45) or 100Mbps Fiber NIC* or 1Gbps Fiber NIC*
Wake on LAN (WOL) using magic packet
Wake on USB
TCP/IP with DNS and DHCP
UDP *Optional and must be configured at purchase
I/O PORTS & CONNECTORS
Front:
(2) USB 2.0
(1) Microphone
(1) Headphone
Rear:
(2) USB 2.0
(1) NIC (RJ-45 or Fiber)
(4) DisplayPort 1.2
(1) Speaker/headphone jack
(1) 12V Power Connector
NOTE: 1 each of 4 USB 2.0 ports used for keyboard and mouse.
PLATFORM
Host Support
VMware® Horizon View™, PCoIP remote workstations
VMware Horizon® DaaS®, through PCoIP
Amazon WorkSpaces, through PCoIP
Protocols
PCoIP
Management
PCoIP Management Console (available from techsupport.teradici.com)
LANGUAGES
English, French, German, Italian, Spanish, Portuguese, Greek, Traditional Chinese, Simplified Chinese, Japanese, and
Korean
