QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 1
Front/ Left
1.
Webcam LED
4.
Touchpad
2.
Webcam
5.
Power button
3.
Speakers (2)
HP Spectre Pro13 G1 Notebook PC
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 2
Rear
1.
USB Type-C
TM
port
3.
Headphone / microphone combo jack
2.
USB Type-C™ with Thunderbolt™ Gen 3 technology (2)
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 3
AT A GLANCE
Window 10 versions
Choice of the 6th generation Intel® Core™ i7 or i5 Processor
Intel® HD Graphics 520
13.3" diagonal FHD WLED BrightView (1920 x 1080) Ultra Slim-flat UWVA Display
Choice of 255 GB or 512 GB Solid State Drive
8 GB of memory
Weight starting at 2.56 lbs (1.16 kg)
TPM 2.0 and Windows 10 Pro security features such as Microsoft Passport, device encryption, bitlocker
Full-size island style backlit keyboard
Touchpad with gestures support
HP TrueVision HD webcam
Audio by Bang & Olufsen with 4 integrated stereo speakers
Battery life up to TBD hours and minutes
With Intel® Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo to keep you connected
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 4
Preinstalled
Windows 10 Pro 641
Windows 10 Home 64
1
Windows 10 Home Single Language 641
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://http://www.microsoft.com.
Intel® Core™ i7-6500U with Intel® HD Graphics 520
(2.5 GHz, up to 3.1 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)1
Intel® Core™ i5-6200U with Intel® HD Graphics 520
(2.3 GHz, up to 2.8 GHz with Intel® Turbo Boost Technology, 3 MB cache, 2 cores)1
1. Multicore is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload
and your hardware and software configurations. Intel’s numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization
mode.
Integrated with processor
Integrated
Intel® HD Graphics 5201
1. HD content required to view HD images.
Internal
13.3" diagonal FHD WLED BrightView (1920 x 1080) Ultra Slim-flat UWVA1
Display Capabilities
Up to 4096 x 2304 @ 60Hz
1. HD content required to view HD images.
Primary Storage Bay
PRODUCT NAMES
HP Spectre Pro13 G1 Notebook PC
OPERATING SYSTEM
PROCESSORS
CHIPSET
GRAPHICS
DISPLAY
STORAGE AND DRIVES
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 5
Support M.2 SATA-3/PCIe Solid State Drives
Solid State Drives1
256 GB SATA-3/PCle Solid State Drive
512 GB SATA-3/PCle Solid State Drive
1. For storage drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for
system recovery software.
Memory soldered down
No SODIMM slots
Dual channel support
Non customer accessible / upgradeable
LPDDR3-1866 (Transfer rates up to 1866 MT/s)
Configuration
8192 MB Total System Memory (256 MB x 32 x 4, 2pcs)
Maximum
8 GB
Wireless LAN (WLAN)
1
Intel® Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo
Support for Miracast
Compatible with Miracast-certified devices2
Support for Intel® WiDi3
1. Wireless access point and Internet service is required and is not included. Availability of public wireless access points
limited.
2. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media
players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide
show. For more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast
3. Integrated Intel Wi-Di software requires separately purchased projector, tv or computer monitor with an integrated or
external Wi-Di receiver. External Wi-Di receivers connect to the projector, tv or computer monitor via a standard VGA,
HDMI cable, also sold separately.
Audio
Audio by Bang & Olufsen
(4) Integrated stereo speakers
Integrated dual-microphone array
HP noise cancellation
HP Audio Boost
Camera
MEMORY
NETWORKING/COMMUNICATIONS
AUDIO/MULTIMEDIA
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 6
HP TrueVision HD1
Full HD camera
Fixed (no tilt) + activity LED
USB 2.0
BSI sensor
f2.4
1. HD content required to view HD images.
Webcam
HP Webcam1
720p by 30 frames per second
1. Wireless access point and Internet service is required and is not included. Availability of public wireless access points
limited.
Keyboard
Full-size
Island style backlit
Touchpad
Image sensor Clickpad with glass surface
Multi-touch gestures enabled
Supports modern trackpad gestures
Taps enabled as default
Preinstalled Software with Windows Operating System
Buy Office
Microsoft Bitlocker
Absolute Data Protect1
Foxit PhantomPDF Express for HP
CyberLink Power DVD
Power Media Player 12
Intel® WiDi Software2
Adobe® Shockwave Player
CyberLink YouCam
HP Wireless Hotspot4
HP ePrint5
Security and Manageability
TPM 2.0
Windows 10 Security Features
HP Touchpoint Manager3
1. Absolute subscription required, see http://www.absolute.com/landing/2012/computrace-hp for complete details.
Absolute Data Protect agent is shipped turned off, and must be activated by customers. Service may be limited, check with
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
SOFTWARE AND SECURITY
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 7
Absolute for availability outside the U.S. The optional subscription service of Absolute Recovery Guarantee is a limited
warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement.
2. Integrated Intel Wi-Di software requires separately purchased projector, tv or computer monitor with an integrated or
external Wi-Di receiver. External Wi-Di receivers connect to the projector, tv or computer monitor via a standard VGA, HDMI
cable, also sold separately.
3. HP Touchpoint Manager requires purchase of a subscription and supports Android™, iOS and Windows 7 or higher
operating systems and PCs, notebooks, tablets and smartphones from various manufacturers. Not available in all countries
see www.hp.com/touchpoint for availability information.
4. The Wireless Hotspot application requires an active Internet connection and separately purchased data plan. While HP
Wireless Hotspot is active, on-device applications will continue to work and will use the same data plan as the wireless
hotspot. Wireless Hotspot data usage may incur additional charges. Check with your for plan details. Requires Windows.
5. ePrint requires an Internet connection to HP web-enabled printer. HP ePrint account registration
required. For a list of eligible printers, supported documents and image types, and for complete details, see
www.hp.com/go/businessmobileprinting.
Power Supply
HP 45 W Smart USB Type-C™ AC adapter
Primary Battery
HP 4-cell Polymer battery (38 Whr)
Battery Life and System Standby Time
TBD
Weight
Starting at 2.55 lbs (1.16 kg)
1
(4-cell battery, SSD, 4G LPDDR4, Intel WLAN, SSD, Webcam)
Dimensions (w x d x h)
12.79 x 9.03 x .43 in (Thinnest edge)
32.5 x 22.94 x 1.09 cm
1. Weight varies by configuration and components.
Ports
USB Type-CTM ports- One (Data transfer, power delivery, Display port 1.2 out and HDMI 1.4 out through dongle)
USB Type-C™ with Thunderbolt™ Gen 3 technology – Two (Docking, charging and USB 3.1)
Headphone/microphone – One
NOTE: All ports support data transfer, power delivery, Display Port 1.2 out up to 4096x2304 (60Hz) and HDMI 1.4 out through
dongle and USB Boost
Expansion slot
M.2 slot for Solid State Drive - One
POWER
WEIGHTS & DIMENSIONS
PORTS/SLOTS
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 8
HP Services offers 1-year limited warranty and 90 days software support depending on country. Batteries have a default one
year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform.
On-site service and extended coverage is also available. HP Care Pack Services
1,2
are optional extended service contracts that
go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack
Services Lookup Tool at: http://www.hp.com/go/cpc
1. Sold separately or as an optional feature.
2. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on
date of hardware purchase. Restrictions and limitations apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
SERVICE AND SUPPORT
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 9
China
Networking/communications
TBD
ENVIRONMENTAL
TBD
COUNTRY OF ORIGIN
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 10
Type
Description
Part Number
Cases
HP Executive 15.6 Black Top Load
P6N18AA
HP Executive 15.6 Brown Top Load
P6N19AA
HP Executive 15.6 Black Slim Top Load
P6N20AA
HP Exec 15.6 Black Messenger
P6N21AA
HP Exec 15.6 Brown Backpack
P6N22AA
Docking
HP USB-C Travel Dock
T0K29AA#ABA
HP Display and Notebook Stand II
E8G00AA#xxx
Input/Output
HP Slim Bluetooth Mouse
F3J92AA
HP Conferencing Keyboard
K8P74AA#xxx
HP Wired Headset
K7V17AA
USB-C to USB 3.0
N2Z63AA#ABA
USB-C to RJ45
V7W66AA#ABA
USB-C to 4.5mm
N2Z65AA#ABA
HP USB-C to VGA Adapter
N9K76AA#ABA
HP USB-C to HDMI Adapter
N9K77AA#ABA
HP USB-C to DisplayPort Adapter
N9K78AA#ABA
Power
HP 45W USB-C power adapter
V5Y26AA
Displays
HP Elite E232 Display
M1N98AA
HP Elite E242 Display
M1P02AA
HP Elite E272q QHD Display
M1P04AA
Options and Accessories (Sold separately and availability may vary by country.)
QuickSpecs
HP Spectre Pro13 G1 Notebook PC
Not all configuration components are available in all regions/countries.
c04934922– DA 15517 – World Wide – Version 2 – July 13, 2016
Page 11
Date of change:
Version History:
Description of change:
July 13, 2016
Version 1 to 2
Removed
HP Elite 65W Thunderbolt 3 Dock P5Q54AA#xxx
HP Elite USB-C Docking Station T3V74AA#xxx
Summary of changes
Copyright © 2016 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not
be liable for technical or editorial errors or omissions contained herein. Bluetooth is a trademark owned by its proprietor and used
by HP Inc. under license. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the
U.S. and other countries. Adobe is a trademark of Adobe Systems Incorporated. ENERGY STAR is a registered trademark owned by
the U.S. Environmental Protection Agency. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. All Rights
Reserved.
