QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Overview
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 1
HP L7014t 14-in Retail Touch Monitor
1.
Power button
2.
OSD Controls – OK button
3.
OSD Controls – Plus “+” button
4.
OSD Controls – Minus “-“ button
5.
Menu button
Note: Stand and cables are sold separately; not included. At least one cable kit is required in order to power the
monitor. Configuration options are shown on pages 8-10 of this document.
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Overview
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 2
Models
HP L7014t 14-in Retail Touch Monitor
T6N32AA
Introduction
Complete your retail solution with the HP L7014t Touch Monitor, an eye-catching, edge-to-edge widescreen display that gives
customers and associates easily readable transaction data. Interactive touch allows customers to enter loyalty information and
associates to work with touch-enabled apps.
Key Benefits
Wide aspect for a wide range of apps - 14-inch diagonal, 16:9 aspect ratio, high-resolution display
Easy interactivity with Integrated projective capacitive touch technology that supports 10-point and Beep-on-touch
Durability for high-traffic areas with a VESA mount
1
that enables use as a customer-facing display or as a standalone
display on a stand or wall.
Compatibility
The HP L7014t 14-in Retail Touch Monitor is recommended to work with HP RP9, HP RP5, HP RP5800 systems, HP Desktop Mini,
and HP Desktops.
NOTE: Not all HP Retail system models are available in all regions.
Service and Support
Your HP Peripheral Limited Warranty is a three (3) year advanced exchange parts replacement warranty.
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Technical Specifications
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 3
General
Display Size (diagonal)
14 inch
Display Type
TN w/LED backlight
Native Resolution
1366x768@60Hz
Aspect Ratio
16:9
Brightness
200 nits (with glass)
Static Contrast Ratio Typical
350:1 static
Dynamic Contrast Ratio
(DCR)
N/A
Pixel Pitch
0.2265(H) mm x 0.2265(V) mm
Pixels Per Inch (PPI)
112
Backlight Lamp Life
15,000 hrs (Min.)
Anti-Glare Panel
Yes
BrightView Panel
No
Response Time
16 ms on/off (typ.)
Color Gamut
45%
Color Support
14.4M colors
Horizontal Viewing Angle
(typical CR>10)
90 degrees
Vertical Viewing Angle
(typical CR>10)
60 degrees
3D Vertical Viewing Angle
N/A
Panel Active Area
309.4mm x 173.95mm
Preset Graphic
Modes/Supported
Resolutions
1366x768@ 60 Hz
1280 x 1024@ 60Hz
1280 X 800 @ 60 Hz
1280 X 720 @ 60 Hz
1024 X 768 @ 60 Hz
800 X 600 @ 60 Hz
720 X 400 @ 70 Hz
640 X 480 @ 60 Hz "
Maximum Resolution
1366x768@60Hz
Recommended Resolution
1366x768@60Hz
Vertical Scan Range
50 to 76 Hz
Horizontal Scan Range
24 to 80 kHz
Default Color Temperature
6500K
Maximum Pixel Clock Speed
110 MHz
Exterior Color of Monitor
Bezel and Stand
HP logo(front): PMS Cool Gray 10c
Rear cover: Asteroid
Front cover: HP Black
Plug & Play
Yes
Tilt
-5 to +135 degrees
Swivel
N/A
Pivot
N/A
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Technical Specifications
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 4
Security Lock Ready
N/A
Height Adjustment
N/A
Height Adjustment Range
(Min-Max)
N/A
Detachable Base
Yes
Webcam
N/A
Speakers Output Power
N/A
Warranty
3 years
VESA Mounting
Yes
Touch Specifications
Touch Panel Type
Projected Capacitive Touch, > 10 points
Positional Accuracy
±1.0 mm for all areas of touchable active area
Resolution Accuracy
4096 x 4096
Optical Light Transmission
(per ASTM D1003)
Normal Glass: ≧85%
Electrostatic Projection (pr
EN6100-4-2, 1955)
Air +/- 8kv, contact +/-4k
On Screen Display (OSD)
On Screen Display User
Controls
Brightness, Contrast, Input Control, Color, Image Control, Power
Control, Menu Control, Management, Language, Information,
Factory Reset, Exit
User Programmable Modes
Yes, 8
Monitor Control Buttons or
Switches
Brightness, Color Control, Information, Menu
Audio Controls
N/A
Languages
10 (German, Simplified Chinese, Traditional Chinese, Japanese,
English, Spanish, French, Italian, Netherlands, Brazilian
Portuguese)
Input Connectors
(1) DisplayPort 1.2,
HDCP Support
Power
Power Supply
External Power Supply
Power Source
100-240VAC 50/60Hz
Power Consumption Maximum
9.5W
Energy Saving/Standby
Mode
<0.5W
Power Consumption Typical
7.17W
Power Cable Length
1.83m
Operational Mode at 100
VAC
23.5KWh
Operational Mode at 115
VAC
23.5KWh
Operational Mode at 230
VAC
23.5KWh
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Technical Specifications
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 5
Operating Conditions
Operating Temperature
41° to 95° F (5 to 35° C) at 20% to 80% humidity (non-condensing
at ambient)
Non-operating Temperature
-4° to 140° F (-20° to 60° C) at 5% to 95% humidity (noncondensing at ambient)
Operating Humidity
20% - 80% (non-condensing)
Non-operating Humidity
5% - 95%
Operating Altitude
0 to 5000m (16,400 feet)
Non-operating Altitude
0 to 12,192m (40,000 feet)
Dimensions
Unpacked without stand
339.8mm x 41.5mm x 218.0mm
13.4 in x 1.7 in x 8.6 in
Packed
410mm x 140mm x 286mm (inner)
442mm x 426mm x 316mm (outer)
16.14 in x 5.51 in x 11.26 in (inner)
17.40 in x16.77 in x12.44 in (outer)"
Display Head Dimensions
(Unpacked without stand)
339.8mm x 41.5mm x 218.0mm
13.4 in x 1.7 in x 8.6 in
Weight (unpacked with
stand)
1.70kg
3.76lbs
Weight (packed)
2.81kg
6.19lb
Weight (head only)
Software
HP Display Assistant
What’s in the box?
HP Retail Display, Setup poster, and Documentation CD. Cable kit must be ordered separately. A
minimum of one cable kit is required to connect the monitor to a host PC. See the configuration
options and options and accessories sections of this document for available options.
Country of Origin
China
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Environmental
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 6
Environmental
Mercury-free display
backlighting
Yes, Mercury-free backlights
Arsenic-Free Display Glass
Yes
Low Halogen
Yes
NOTE: External power supplies, power cords, cables and peripherals are not Low Halogen. Service
parts obtained after purchase may not be Low Halogen.
Agency Approvals and
Certifications
CB, CE, FCC marking, ErP, CSA/C-UL/C-ETL Mark, cTUVus/UL/CSA-NTRL/ETL-NRTL Mark, ICES,
Japan VCCI, CCC, CECP, China CEL, Taiwan BSMI, Bauart; KCC; e-standby; PSB, ISC mark, C-tick, ETC,
Vietnam MEPS, Australian-New Zealand MEPS/EPA7.0
Microsoft WHQL Certification
Win-10, Win-8, Win-7
ENERGY STAR® Qualified
Yes, ES7
EPEAT® Registered
Gold
NOTE: EPEAT® registered where applicable. EPEAT registration varies by country. See
http://www.epeat.net/ for registration status by country.
China Energy Label
Grade1 (GB21520-2008)
TCO Certified Edge
N/A
TCO Certified
N/A
SmartWay Transport
Partnership
Yes (NA SKU)
Contains Recycled Plastics in
Back Cover
Yes
Contains Recycled Plastics in
Base/Stand
Yes
Contains Recycled Plastics in
Other Parts
Yes
Recyclable Plastics
N/A
Recyclable Packaging
N/A
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Configurations
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 7
Configuration Options
1) HP 14-in Retail Touch Monitor mounted to an HP Retail System as CFD.
HP Arm Mounting Bracket
700mm DisplayPort Cable
700mm USB/Power “Y” Cable
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Configurations
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 8
2) HP 14-in Retail Touch Monitor connected to an HP RP5 Retail System with a 12 V powered USB port.
HP Compact Stand
(T6N33AA)
300cm DisplayPort Cable
300cm USB/ Power “Y" Cable
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Configuration
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 9
3) HP 14-in Retail Touch Monitor connected to an HP Retail System without a 12 V powered USB port.
HP Compact Stand
(T6N33AA)
HP 45 W Power Adapter
300cm DisplayPort Cable
300 cm USB B-A cable
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Options and Accessories
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 10
Options and Accessories
Category
Description
Part Number
Stands
HP Monitor Stand for L7010t, L7014, L7014t
T6N33AA
Cables
HP 700mm Cable Kit for CFD on RP9
V7563AA
HP 300cm DP and USB Power Cable for L7014
V4P95AA
HP 300cm DP Cable for L7014
V4P97AA
Adapters
HP 45w Smart AC Adapter
H6Y88AA
QuickSpecs
HP L7014t 14-in Retail Touch Monitor
Summary of Changes
c04964757 — DA - 15547 Worldwide — Version 1 — February 24, 2016
Page 11
Date of change:
Version History:
Description of change:
From v1 to v2
