Datasheet
HP RP9 G1 Retail System, Model 9015
An exceptionally elegant all-in-one for retail and hospitality
Deliver a stylish and engaging experience to your customers with the modern, versatile HP RP9 Retail System, an All-in-One (AiO) that combines powerhouse performance with reliable engineering.
Make a big impression in a small footprint
Create a welcoming point of contact for your customers with a contemporary design that has edge-to-edge, 39,62 cm (15.6”) diagonal, 10-point multi-touch glass and optional integrated peripherals.
Powerhouse performer
Deploy the system—available with 6th generation Intel® processors, M.2 storage, a bay for a 6,35 cm (2.5”) SSD or HDD, efficient DDR4 memory, and wired or wireless network connectivity—anywhere you need a reliable, high­performance All-in-One.
Versatility for every demand
Customize each system for your specific usability requirements—in a kiosk, on a counter or a pole—with mounting and hardware options. Choose your processor, operating system, peripherals , and more.
Designed and tested to work as hard as you do
Make a confident IT choice with a reliability-tested system that has built-in security and manageability, a stable 5­year lifecycle for consistent, staggered installations, and is backed by a 3-year limited warranty and optional HP Care Pack.
Additional features
Show and share data on a cleanable, durable, sealed touchscreen that’s stylish and functional with a 1366 x 768 resolution and choice of screen sizes, plus pivot for portrait or landscape mode. Use Pre-Boot Touch for easy access to BIOS functions.
Pick the familiar operating system that’s best suited to your environment—preinstalled Windows 7, Windows 8.1, Windows 10 Pro, Windows Embedded 8.1 Industry Pro Retail, Windows POSReady 7 or Windows 10 IoT Enterprise.
Complete your All-in-One with a range of hardware options , including the stand, associate display, and customer­facing displays, and integrated HP peripherals such as a barcode scanner, MSR, fingerprint reader, and more.
Add devices and displays when you’re ready with a range of connections, and select wired or wireless networking. Secure your system with HP SureStart, TPM, Intel® AMT, and optional client management software. Reduce power consumption and help lower your total cost of ownership with an intelligent, energy-efficient design
that is ENERGY STAR® certified and EPEAT® Gold registered.
1
1
3 1
4
1
Data sheet | HP RP9 G1 Retail System, Model 9015
HP RP9 G1 Retail System, Model 9015 Specifications Table
Available Operating Systems
Windows 10 Pro 64 Windows 10 IoT Enterprise 2016 LTSB 64 Windows 7 Professional 32 (available through downgrade rights from Windows 10 Pro) Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) Windows Embedded 8.1 Industry Pro Retail 64 Windows Embedded POSReady 7 64 Windows Embedded POSReady 7 32 FreeDOS 2.0
Processor family Intel® Core™ i7 processor; Intel® Core™ i5 processor; Intel® Core™ i3 processor; Intel® Pentium® processor; Intel® Celeron® processor
Available Processors
Intel® Celeron® G3900 with Intel® HD Graphics 510 (2.8 GHz, 2 MB cache, 2 cores); Intel® Core™ i3-6100 with Intel® HD Graphics 530 (3.7 GHz, 3 MB cache, 2 cores); Intel® Core™ i3-6100T with Intel® HD Graphics 530 (3.2 GHz, 3 MB cache, 2 cores); Intel® Core™ i5-6500 with Intel® HD Graphics 530 (3.2 GHz base frequency, up to 3.6 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores); Intel® Core™ i7-6700 with Intel® HD Graphics 530 (3.4 GHz base frequency, up to 4 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores); Intel® Pentium® G4400 with Intel® HD Graphics 510 (3.3 GHz, 3 MB cache, 2 cores); Intel® Core™ i7-7700 with Intel® HD Graphics 630 (3.6 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores); Intel® Core™ i3-7100E with Intel® HD Graphics 630 (3.9 GHz, 3 MB cache, 2 cores); Intel® Core™ i7-7600 with Intel® HD Graphics 630 (3.5 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores); Intel® Celeron® G3930Ewith Intel® HD Graphics 610 (2.9 GHz, 2 MB cache, 2 cores)
Chipset Intel® Q170
Form factor All-in-one
Maximum memory
32 GB DDR4-2400 SDRAM Transfer rates up to 2400 MT/s.
Memory slots 2 SODIMM
Internal storage
up to 500 GB SATA (7200 rpm) up to 500 GB SATA SED (7200 rpm) up to 1 TB SATA SSHD 64 GB up to 256 GB SATA SSD up to 128 GB SATA SED SSD 128 GB up to 256 GB HP Turbo Drive SSD (M.2 PCIe) 128 GB up to 256 GB HP Turbo Drive G2 SSD (M.2 PCIe) 128GB up to 256GB SATA M.2
Display 39,62 cm (15.6") diagonal wide aspect (16:9), HD, anti-glare, anti-fingerprint, projected capacitive 10-point touchscreen (1366 x 768)
Available Graphics
Integrated: Intel® HD Graphics (Intel® Core™ processors use Intel® HD Graphics 530 or 630. Intel® Pentium® and Celeron® processors use Intel® HD Graphics 510 or 610.)
Audio
Conexant CX5001 Audio codec. Integrated high-performance 2x2.2W internal speakers, stereo headphone jack re-taskable for line-out, microphone jack-in, re-taskable for line-in.
Expansion slots 1 M.2 2230; 1 M.2 2280 (M.2 2230 slot for WLAN. M.2 2280 slot for SSD)
Ports and Connectors
Display Head (bottom): 1 audio-in; 1 audio-out; 1 DisplayPort™ 1.2; 1 RJ-45; 2 RS-232; 2 USB 2.0; 2 USB 3.0; 3 Powered 12 Volt USB; 1 Powered 24 Volt USB; 1 cash drawer Display Head (top, left, right): 3 USB for peripheral integration
Communications
LAN: Intel® I219-LM Ethernet Connection ; WLAN: Intel® Dual Band Wireless-AC 7265 802.11ac (2x2) PCIe®; Intel® Dual Band Wireless-AC 8260 802.11ac M.2 and Bluetooth® Combo ;
Drive Bays One 6,35 cm (2.5’’); Two M.2
Environmental
Operating temperature: 10 to 40°C; Operating humidity: 20 to 85% RH;
Available Software HP Client Security Manager; HP ePrint Driver; HP Recovery Manager; HP Support Assistant; Microsoft Security Essentials
Security management
Power-on password (via BIOS); Setup password (via BIOS); Fingerprint reader; Security lock slot; Trusted Platform Module TPM 1.2; Hood sensor; Kensington Lock; Serial enable/disable (via BIOS); Automatic drive lock; Secure erase (via BIOS); HP Client Security Manager; HP Multi-Factor Authenticate; HP MIK (SCCM Integration); HP Image Assistant; HP vPRO Support; Device Guard Enablement; Self Encrypting Drives
Management features Intel® vPro™ Technology capable (select models)
Power 230 W, up to 89% efficient, active PFC
Dimensions
15.6 x 8.8 x 11.5 in 39.56 x 22.23 x 39.56 cm (15" display models); 46.22 x 24.9 x 35.11 cm (18" display models) (With compact stand (15" display models). With ergonomic stand (18" display models).)
Weight 9.7 lbs 4.4 kg (15" display models); 5.6 kg (18" display models) (Starting weight without stand. Exact weight depends on configuration.)
Energy efficiency compliance ENERGY STAR® certified configurations available and EPEAT® registered configurations available
Sustainable impact specifications Low halogen
Warranty
3-year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
1
1
2,16 2,16
15,16 15,16 15,16
4
4,16
5
6
6
6
6
6
6
6
6
8
9
7
10,11
12,17,18,19
13
14
