Hewlett-Packard SW-450 User Manual

SW450
Digital Camera
User Manual
I
Table of Contents
Preface 1
About this Manual .................................................................................1
Important Notes and Information ..........................................................2
Package Contents 5
Getting Started 6
Inserting an SD/SDHC Memory Card ......................................................7
Understanding the LCD Screen 14
Recording Photos, Video and Voices 21
Recording Videos ................................................................................22
Setting the Focus Mode .......................................................................25
II
Setting the Scene Mode .......................................................................30
Using the Setup Menu 62
Setting Sounds ...................................................................................62
Setting Date & Time ............................................................................63
Making Connections 66
Connecting the Camera to a Printer 68
Appendix 70
Troubleshooting 71
Getting Help 72
1

Preface

About this Manual

This manual is designed to assist you in using your new digital camera. All information presented is as accurate as possible but is subject to change without notice.
For the latest reversion, please visit www.hp.com/support.
Copyright
This manual contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer. © Copyright 2010
Federal Communications Commission (FCC) Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the distance between the equipment and the receiver.•
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.•
Consult the dealer or an experienced radio/TV technician for help.•
Warning: A shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to radio and television reception. Use only shielded cable to connect I/O devices to this equipment. Any changes or modifications not expressly approved by the manufacturer may void your warranty and service agreement.
Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
This device may not cause harmful interference.•
This device must accept any interference received, including interference that may cause undesired operation.•
Trademark Recognition
Windows 2000/XP/Vista/Windows 7 are registered trademarks of Microsoft Corporation in the United States and/or other countries. Macintosh and Mac OS are registered trademarks of Apple Inc. In addition, all other companies or product names are trademarks or registered trademarks of their respective companies.

Safety and Handling Precautions Camera Information

Do not take apart or attempt to service the camera yourself.•
Do not expose the camera to moisture, or extreme temperatures.•
Allow the camera to warm up when moving from cold to warm temperatures.•
Do not touch the camera lens.•
Do not expose the lens to direct sunlight for extended periods.•
Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the product. Wipe the product • with a clean slightly damp soft cloth.

Battery Information

Only use the provided battery or type of battery and charger that came with your camera. Using other types of • battery or charger may damage the equipment and invalidate the warranty
Turn off the camera before installing or removing the battery.•
When the camera is used for an extended period of time, it is normal for the camera body to feel warm. •
Do not remove the battery while downloading pictures, videos, or audio content. This could result in a complete • loss of these items.
It is recommended to remove the battery if the camera will not be used for a long period of time.•
When inserting the battery in this camera, ensure that they are oriented correctly. Please see • Inserting the battery section of this manual for additional details. Inserting the battery incorrectly may cause damage to the camera and battery.
An single depleted or low battery power level may cause the lens to not extend or retract properly. •
Dispose of used battery according to their instructions.•

Important Notes and Information

Throughout this manual, look for the symbols below that highlight useful and important information.
This symbol will be used to indicate useful information when using the camera.
This symbol will be used to indicate important message that should be read before using the function.
2

Photography Terms and Definitions

Terms Definitions
A simple technique professional photographers use to ensure they properly
Auto Exposure Bracketing
(AEB)
Auto Focus (AF)
Album
expose their pictures, especially in challenging lighting situations. When AEB is selected, the camera automatically takes three or more shots with a different exposure for each frame.
Auto focus refers to a camera lens’ ability to adjust its configuration in order to focus properly on a subject regardless of whether it is near or far from the camera. Auto focus lenses generally provide vastly superior image quality than do their fixed focus cousins since they do not have to rely on their depth of field. Also known as: “AF”, “auto-focus”.
An end-user created object that is used to logically group data objects according to some user-defined criteria. An album may or may not be a physical folder in a file system.
Analog to Digital Converter
(A/D or ADC)
Aspect Ratio
Auto White Balance (AWB)
Charge Coupled Device (CCD)
Compression
Digital Print Order Format
(DPOF)
Digital Still Camera (DSC)
Dynamic Range
Exif/JPEG
A circuit that converts an analog signal, having a continuously varying amplitude, to a digitally quantized representation using binary output signals.
The aspect ratio of a camera is the ratio of the length of the length and width of the display or images.
With auto white balance, the camera attempts to determine the color temperature of the light and automatically adjust for that color temperature. Many people just leave the camera set to auto white balance all the time.
A type of silicon integrated circuit used to convert light into an electronic signal.
The process of encoding information using fewer bits cf. image compression, sound file compression.
A standardized ASCII file created in a digital camera and stored on removable media along with the image files that indicate how many copies of which images should be printed. It also allows index prints, cropping, and text overlays to be specified.
A camera incorporating an image sensor which outputs a digital signal representing a still picture, or records a digital signal representing a still picture on a removable medium, such as a memory card or magnetic disk.
Dynamic range in photography describes the ratio between the maximum and minimum measurable light intensities (white and black, respectively).
A compressed file format for digital cameras in which the images are compressed using the baseline JPEG standard, described in ISO 12234-2, and metadata and thumbnail images are stored using TIFF tags within an application segment at the beginning of the JPEG file.
A numerical value that is inversely proportional to the exposure provided to
Exposure Index
ISO Speed
JPEG
Protocol Defined mechanisms for exchanging data between devices.
an image sensor to obtain an image. Images obtained from a camera using a range of exposure index values will normally provide a range of image quality levels.
A numerical value calculated from the exposure provided at the focal plane of an electronic camera to produce specified camera output signal characteristics using the methods described in the referenced standard. The ISO speed should correlate with the highest exposure index value that provides peak image quality for normal scenes.
Joint Photographic Experts Group. An image compression method defined in ISO/IEC 10918-1.
3
4
Terms Definitions
A device-specific four byte unsigned integer (UINT32) that represents a
StorageID
unique storage area that may contain data objects. The most significant sixteen bits of a StorageID represents the PhysicalStorageID, while the least significant sixteen bits of a StorageID represents the LogicalStorageID.
USB
Universal serial bus, a digital interface for connecting up to 64 devices in a tiered-star topology. See http://www.usb.org.
The adjustment of electronic still picture color channel gains or image
White Balance
processing so that radiation with relative spectral power distribution equal to that of the scene illumination source is rendered as a visual neutral.
Source: ISO/WE 12231 Photography-- Electronic still-picture cameras -- Terminology
5

Package Contents

Please check the contents of your camera package. It should contain:
Digital camera Li-ion Battery x 1 pcs Battery charger
Wrist strap USB cable
Quick Start guide Warranty card
CDROM disc with User Manual and
Software installation
6

Getting Started

Attach the Camera Strap

To reduce the risk of dropping the camera, it is strongly recommended to attach and use the provided camera strap.
To reduce the risk of dropping the camera, it is strongly recommended to attach and use the provided camera strap.

Charging the Battery

The battery that comes along with your package is not fully charged. You need to charge the battery before using the camera.
Insert the battery into the battery charger as shown.1.
Connect the power cord to the battery charger.2.
Plug the power cord to the main outlet.3.
The battery charging time is 2 hours.

Inserting the Battery

Follow these instructions to insert the battery into the battery/memory card compartment. Please read "Battery Information" on page 2 before inserting/removing battery.
If the battery is already installed, make sure to power off 1. the camera before removing and inserting a recharged or new battery.
Open the battery/memory card compartment at the bottom 2. of the camera as illustrated.
7
Insert the battery into the compartment with correct 3. orientation as illustrated.
Close and secure the battery/memory card compartment.4.

Inserting an SD/SDHC Memory Card

It is highly recommended that the camera storage is expanded by inserting a SD or SDHC memory card. These memory cards are available at most consumer store and online locations.
Make sure to power off the camera before proceeding. Inserting the 1. memory card while powered on may damage the card and camera.
Open the Battery/memory card compartment at the bottom of the camera.2.
Insert the SD/SDHC card into the memory card slot with the metallic 3. connectors facing the front side of the camera as illustrated below.
Push the SD/SDHC card into the memory slot until it clicks into place. 4. If the card does not click into place, repeat the previous step to ensure proper orientation.
Close the Battery/memory card compartment. 5.
To remove the SD/SDHC card
Make sure to power off the camera before proceeding. Removing the 1. memory card while powered on may damage the card and camera.
Open the battery/memory card compartment.2.
Gently push the card until it clicks and pushes our of position.3.
Carefully pull out the card.4.
8

Camera Memory

Internal memory
This camera is equipped with 32MB of internal memory. However, storage of images, video and audio clips is limited to approximately 12MB. For optimal use, it is strongly recommend that this camera is used with SD or SDHC memory cards. If there is no SD or SDHC memory card inserted in the memory card slot, all images, videos and audio clips recorded are automatically stored in the internal memory.
External storage
This camera supports SD cards of up to 4GB, and SDHC cards with a maximum capacity of 32GB. It is strongly recommended that Class 4 or above memory cards are used with this camera. Consult the reseller or manufacturer of the memory card for class rating details.
If a SD/SDHC card is inserted in the memory slot, the camera automatically saves all images, videos and audio clips
to this storage card. The LCD memory card icon
Not all SD/SDHC memory cards may be compatible with this camera. When
purchasing a card, please verify the card’s specications.
indicates the camera is using SD card.
9

Camera Views

1
4
2
3
5
6
8
9
10
7
11
14
1213
Front View
Flash1.
Self-timer LED / AF Assist Lamp2.
Lens3.
Microphone4.
Back View
LCD display screen5.
LED indicator6.
Mode Selector Switch7.
Photo Mode Video Mode Playback Mode
Function / OK button / 8. 4-way navigation control
Menu button9.
Delete button10.
Top View
Shutter button11.
Power button12.
Stabilizer button13.
Zoom buttons14.
10
Bottom View
16 15
17
18
19
Left/Right View
Speaker15.
Tripod screw hole16.
USB17.
Battery/Memory compartment door18.
Strap ring19.
11

Camera Buttons

42
5
1
3
Button Description
Power Press the Power button to turn the power on/off.
Stabilizer
Shutter
Zoom
Menu
Function/ Delete
The stabilizer sets the optimal ISO value according to light levels to compensate for camera shake and help reduce motion blur. Press to set stabilizer on/off.
Press to capture an image or start/stop recording video or audio clips.
In photo and Movie mode, move the toggle to the W position to zoom out, or T to zoom in.
Press to enter or exit menu/submenu.
In Photo or Video Mode, press to enter function submenu. In Playback mode, press to delete an image, video or audio clip.

Navigation Control

The 4-way Navigation Control and the OK button is used to access and select the various menus, settings and options available from the On Screen Display (OSD). Configure a wide range of settings to ensure optimal results for images and videos. Further functions of these buttons are as follows:
No. Description
1 Face Tracking, Photo Rotation, and up direction
2 Macro/Focus mode selector and left direction
3 Display mode selection and down direction
4 Flash mode / right direction
5 OK Button
Button Description
Press to confirm a selection when using the OSD menus.1.
OK Button
Flash Mode/ Right
Press to start the playback of video and audio clips. 2. Note: Must have the mode selector switch set to Playback mode.
In Photo Mode, press to cycle through the flash mode options. 1.
Auto, Anti Red-eye, Slow Sync, Forced On and Forced Off)
(
See page 23 for additional details.
In Playback mode, press to view the next image, video or audio clip.2.
During playback of recorded video clips, press to fast forward.3.
In Menu and Settings mode, press to enter the submenu or to navigate through 4. the menu selections.
12
Button Description
In Photo Mode, press to cycle through Macro and other focus options. 1.
Macro, Pan focus and Infinity) See pages 24-25 for additional
(
Macro/Left
Up/Face Tracking/ Rotate
Display/ Down
details.
In Playback mode, press to view the previous image, video or audio clip.2.
During playback of recorded video clips, press to rewind.3.
In Menu, press to exit a submenu or to navigate through the menu selections.4.
In Photo Mode, press to turn the face tracking function on and off.1.
During playback of video or audio clips, press once to Pause, press again to 2. Resume.
In Playback of photos, press to rotate the image clockwise 90 degrees by each 3. press of the button. Please note that this feature is applicable for Photos only and video clips cannot be rotated.
In Menu, press to navigate through the menu and submenu selections.4.
In Photo Mode, press to change the LCD screen display information. Continue to 1. press to cycle through the display options. See page 12 for additional details.
In Playback Mode, press to change the display of photo, video, or audio 2. information. Continue to press to cycle through the display options. See page 12 for additional details.
During playback of recorded video or audio clips, press to stop the playback.3.
In Menu, press to navigate through the menu and submenu selections.4.

Turning the Power On and Off

Press the Power button to power on and off the camera.
If the mode selector switch is set to Photo or Video mode, the startup image displays briefly and the startup • sound plays if enabled. The camera lens extends and the camera is ready for use.
If the mode selector switch is set to Playback mode, the last recorded photo, video clip, or audio clip will be • displayed and the lens will not be extended.
To turn off the camera, press the Power button the selected Power Save (see page 62 for details) setting. The default setting is after 1 minute of inactivity.
. or the camera will automatically shut off when not used for
13

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings of your camera. First is the setup of language menu. Specify in which language menus and messages are to be displayed on the LCD monitor.
Setting the Language
Press directional buttons to move through the selection.1.
Select a language, and then press 2. OK button
.
Setting the Date & Time
Press left and right direction buttons to move through the selection.1.
Press the up and down buttons to change the value for the date and time.2.
Press 3. OK button
If necessary, press 4. Menu button
At this point, the camera settings are set to the default automatic mode and is ready to take photos and videos.
Holding down • or keys to change the values continuously.
If the camera is without battery power for more than 48 hours, the initial settings • may reset and require another setup.
when finished. This will save your date and time settings.
to close the menu.

Modes Selector Switch

This camera has a three mode selector switch. The different modes are:
Photo Mode
Slide the mode switch to [ • ] take photos and record audio clips by selecting Voice REC from scene modes (see pages 12 for additional details).
Video Mode
Slide the mode switch to [ • ] record videos (see page 29 for additional details).
Playback Mode
Slide the mode switch to [ • ] view and edit captured images or playback videos and audio clips. The recording of voice memo attached to images is also available in this mode.
14

Understanding the LCD Screen

The LCD monitor shows all important information regarding camera settings as well as the visual image of your image or video. The display on the LCD monitor is called the On Screen Display or OSD.

LCD Screen Layout

Photo Mode Screen Layout
No. Item Description
1 Record Mode
2 Flash Please see page 23 for additional flash option details.
3 Self-timer/Burst Indicates drive mode settings.
4 Zoom indicator
5 Shots remaining Indicates the remaining shots available.
6 Battery
7 Storage media
8 Date stamp
9 Auto Exposure Bracketing (AEB)
10 Image Stabilizer
11 Saturation
12 Contrast Displays contrast settings. Please see page 42 for additional details.
13 Histogram
14 ISO Displays ISO settings. Please see page 27 for additional details.
15 Display focus area settings Use to frame subject to capture.
Indicates the current capture/scene mode. Please see page 43 for additional details.
Displays zoom type and level. Please see page 22 for additional details.
Indicates approximate battery level. Please see page 2 for additional details.
Indicates current storage media in use. Options are Internal memory and SD/SDHC memory card.
Indicates date stamp is enabled. Please see page 43 for additional details.
Indicates AEB function is enabled. Please see page 3 for additional details.
Indicates if the image stabilizer function is enabled. Please see page 22 for additional details.
Displays saturation settings. Please see page 41 for additional details.
Display the darkest and brightest values, corresponding to black and white respectively.
15
No. Item Description
16 Shutter speed
17 Aperture value Displays aperture settings. Please see page 38 for additional details.
18 Shake warning
19 Macro
20 Exposure Displays exposure settings. Please see page 38 for additional details.
21 Face tracking Indicates face tracking is enabled.
22 White balance
23 Metering Displays metering settings. Please see page 41 for additional details.
24 Sharpness
25 Quality Displays quality settings. Please see page 26 for additional details.
26 Resolution
27 AF lamp
Displays shutter speed settings. Please see page 20 for additional details.
Indicates that the camera is moving too much that may result in image blur. Use of a tripod or steady hand may be required.
Indicates macro is enabled. Please see page 24 for additional details.
Displays white balance settings. Please see page 26 for additional details.
Displays sharpness settings. Please see page 41 for additional details.
Displays photo resolution settings. Please see page 25 for additional details.
Indicates AF lamp is enabled. Please see page 40 for additional details.
16
Video Mode Screen Layout
Standby layout Recording Layout
No. Item Description
1 Record Mode Indicates the current mode.
2 Zoom indicator Displays zoom.
3 Time remaining Indicates the remaining time of video available.
4 Battery Indicates battery level.
5 Storage media Indicates current storage media in use.
6 Display focus area settings Use to frame subject to record.
7 Macro Indicates macro is enabled.
8 White balance Displays white balance settings.
9 Metering Displays metering settings.
10 Resolution Displays movie resolution settings.
11 Key indicator Indicates the buttons to press on the camera to apply the functions.
12 Recorded time Displays recorded time.
13 Recording status Indicates recording status.
14 Pre-record
Indicates pre-record is enable.
The Pre-Record icon appears on the screen in red color as the same position as zoom indicator.
17
Playback Mode Screen Layout
The Playback mode display varies depending on the type of image being viewed.
Playback mode display of still images:
No. Item Description
1 Playback mode Indicates the camera is in playback mode.
2 Protect Indicates file is protected. Please see page 54 for additional details.
3 Voice clip Indicates the photo has a attached audio clip.
4 Button intro Indicates that pressing the OK button will begin playback.
5 File Number
6 Battery Indicates approximate battery level.
7 Storage media
8 Recording information Displays the capture details of the photo.
9
10 Resolution Displays the photo resolution setting at the time it was taken.
DPOF (Digital Print Order Format)
Indicates the file number over the total number of files in the internal memory or SD/SDHC memory card.
Indicates current storage memory. Options are internal camera memory or SD/SDHC memory card.
Indicates the file is marked for printing. Please see page 60 for additional details.
18
Playback mode of videos:
No. Item Description
1 Playback mode Indicates the camera is in playback mode.
2 Protect Indicates file is protected. Please see page 54 for additional details.
3 Video clip Indicates the file is a video clip.
4 Button intro Indicates buttons used during playback.
5 File Number
6 Battery Indicates approximate battery level.
7 Storage media
8 Recording date & time Displays the date and time of the video clip at the time is was recorded.
9 Video Resolution Indicates the resolution setting of the video clip at the time is was recorded.
10 Volume
11 Video length Display the total length of the video clip.
12 Played time Indicates the played time of the video clip.
13 Playing status Displays playing status. The options are: play, pause, rewind, or fast forward.
14 Capture photo
Indicates the current file number and total files stored in the internal memory or SD/SDHC memory card.
Indicates current storage memory. Options are internal camera memory or SD/ SDHC memory card.
Indicates the volume while playing. Use the Zoom buttons to increase or decrease playback volume.
To capture a still image from the video clip, pause at the desired moment and press the shutter button. The image is automatically saved to memory and the video can resume playback.
19
Playback mode of audio clips:
No. Item Description
1 Playback mode Indicates the camera is in playback mode.
2 Protect Indicates file is protected. Please see page 54 for additional details.
3 Button intro Indicates buttons used during playback.
4 File no./Total no.
5 Battery Indicates the approximate battery level.
6 Storage media
7 Recording information Displays recording information at the time the audio clip was recorded.
8 Volume
9 Audio length Display the total length of the audio clip.
10 Played time Indicates played time.
11 Playing status Displays playing status. Options are play and pause.
Indicates the current file number and total files stored in the internal memory or SD/SDHC memory card.
Indicates current storage memory. Options are internal camera memory or SD/SDHC memory card.
Indicates the volume while playing. Use the Zoom buttons to increase or decrease playback volume.
20

Changing the LCD Display

The type of information displayed on the LCD monitor can be changed using the button. Press the button repeatedly to change the LCD display from one type to another. In Photo/Movie Mode, the LCD display can be changed into any of the following:
Basic•
Full•
Minimal •
Guidelines•
No icons or information•
The OSD information may vary depending on the record mode type.•
Use the “Guide lines” to properly set image for capture. Typically, these guide lines • are used to help vertical and horizontal alignment of the photo.
In Playback mode, the LCD display can be changed into any of the following:
Basic•
Full•
No icons or information•
LCD display cannot be changed in the following situations:
While recording movie or audio clips•
During playing movie or audio clips•
Playing slideshow•
Loading...
+ 55 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
