HP ProDesk 600 G2 Small Form Factor PC

Commercial-class performance and expandability

The HP ProDesk 600 MT/SFF delivers value with a balance of performance and expandability for businesses with commercial-class productivity, reliability, security, and manageability needs.

Windows 10 Pro

●

6th Gen Intel® Core™ Processors

●

Perform at thespeed of work

Power through your day with speed and performance. Get the latest in processing technology with your choice of 6th Generation

●

Intel® Core™ processors2and Intel® HD 530 Graphics.

Heavy security, exceptionally managed

IT efficiency reigns supreme when it’s backed by a full portfolio of security solutions, including HP BIOSphere3and Device Guard

●

available on Windows 101Enterprise Edition.

Ready to go the distance

HP ProDesks are rigorously tested to help ensure reliability. During the HP Total Test Process, PCs experience 120,000 hours of

●

performance trials to help get you through your business day.

The right balance

The HP ProDesk 600 Desktop MT/SFF delivers powerful performance, security, and manageability at a value that enables you to

●

keep focused on your businesses.

Featuring

Help secure the future of your modern business. Modern PCs from HP make the most of Windows 10 Pro1to help protect you

●

from today’s security threats and maximize management and productivity features for business. Help manage the fleet with Intel® Standard Manageability and reduce the burden on IT resources with HP’s Common Core BIOS

●

that allows standard manageability across HP Desktops and HP Notebooks. Extend your business investments with a long life cycle and platform stability.

●

Make conferencing from your PC as simple as the touch of a button with the optional HP Conferencing Keyboard.

●

Give yourself room to grow with ease with multiple expansion slots, ports and connectors.

●

HP helps you preserve your time and optimize your resources with expert configuration and deployment services that bring you

●

fast, accurate, and globally standardized IT solutions. Reduce power consumption and costs with ENERGY STAR® certified and EPEAT® Gold6qualified configurations.

●

Help increase productivity by up to 35%7with support for up to three external Pro Displays.

●

Datasheet

HP ProDesk 600 G2 Small Form Factor PC Specifications Table

Form Factor

Available Operating System

Available Processors

Chipset

Maximum Memory

Memory slots

Internal Storage

Optical Storage

Available Graphics

Audio

Communications

Expansion Slots

Ports and Connectors

Internal Drive Bays

External Drive Bays

Available Software

Security Management

Management Features

Power

Dimensions

Weight

Environmental

Energy Efficiency Compliance

Warranty

Small Form Factor

Windows 10 Pro 64 Windows 10 Home 64 Windows 8.1 Pro 64 Windows 8.1 64 Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) Windows 7 Professional 32 (available through downgrade rights from Windows 10 Pro) Windows 7 Professional 64 Windows 7 Professional 32 FreeDOS 2.0

Intel® Core™ i7-6700 with Intel HD Graphics 530 (3.4 GHz, up to 4 GHz with Intel Turbo Boost, 8 MB cache, 4 cores); Intel® Core™ i5-6600 with Intel HD Graphics 530 (3.3 GHz, up to 3.9 GHz with Intel Turbo Boost, 6 MB cache, 4 cores); Intel® Core™ i5-6500 with Intel HD Graphics 530 (3.2 GHz, up to 3.6 GHz with Intel Turbo Boost, 6 MB cache, 4 cores); Intel® Core™ i3-6320 with Intel HD Graphics 530 (3.9 GHz, 4 MB cache, 2 cores); Intel® Core™ i3-6300 with Intel HD Graphics 530 (3.8 GHz, 4 MB cache, 2 cores); Intel® Core™ i3-6100 with Intel HD Graphics 530 (3.7 GHz, 3 MB cache, 2 cores); Intel® Pentium® G4500 with Intel HD Graphics 530 (3.5 GHz, 3 MB cache, 2 cores); Intel® Pentium® G4400 with Intel HD Graphics 510 (3.3 GHz, 3 MB cache, 2 cores)

Intel® Q150

Up to 64 GB DDR4-2133 SDRAM Standard memory note: Transfer rates up to 2133 MT/s

4 DIMM

120 GB up to 500 GB SATA SSD 120 GB up to 256 GB SATA SE SSD 500 GB up to 1 TB SATA SSHD 128 GB up to 512 GB Turbo Drive G2 (M.2 PCIe SSD) 500 GB up to 2 TB SATA (7200 rpm)4128 GB up to 256 GB SATA 3D SSD

Slim SATA BDXL Blu-ray writer; Slim SATA SuperMulti DVD writer; Slim SATA DVD-ROM

Integrated: Intel® HD Graphics Discrete: NVIDIA® GeForce® GT 730 (2 GB) (Integrated graphics will depend on processor)

DTS Sound+™ audio management technology, HD audio with Realtek ALC221 codec (all ports are stereo), microphone and headphone front ports (3.5 mm), line-out and line-in rear ports (3.5 mm), multi-streaming capable and internal speaker.

LAN: Intel® I219LM Gigabit Network Connection LOM; Intel® I210-T1 PCIe GbE (optional) WLAN: Broadcom BCM943228Z 802.11n Wireless PCIe with optional Bluetooth® (optional); Intel® 7265 802.11ac Wireless PCIe with optional Bluetooth® (optional); Intel® 7265 802.11n Wireless PCIe (optional)

1 PCIe x16; 3 PCIe x1

Front: 2 USB 3.0; 2 USB 2.0 (1 fast charging); 1 audio line in; 1 audio line out Back: 4 USB 3.0; 2 USB 2.0; 1 serial; 1 serial (optional); 1 parallel (optional); 2 PS/2 (keyboard and mouse); 1 VGA; 2 DisplayPort; 1 audio line in; 1 audio line out; 1 RJ-45

Two 8,9 cm (3.5"); One 6,35 cm (2.5’’)

One slim ODD; One SD 4 reader (optional)

HP business PCs are shipped with a variety of software titles including: HP Drive Encryption (FIPS 140-2), HP Client Security, HP Security Manager, Microsoft Security Essentials, CyberLink Power DVD BD, Native Miracast Support, HP ePrint Driver, HP Recovery Manager, Foxit PhantomPDF Express. Please refer to this product's quick spec document for a full list of preinstalled software.

HP BIOSphere; Trusted Platform Module (TPM) 1.2/2.0 (Common Criteria EAL4+ certified); SATAport disablement (via BIOS); DriveLock and Automatic DriveLock; Serial, parallel, USB enable/disable (via BIOS); Optional USB port disable at factory (user configurable via BIOS); Removable media write/boot control; Power-on password (via BIOS); Setup password (via BIOS); HP Solenoid Hood Lock/Sensor; Support for chassis padlocks and cable lock devices

Intel® Standard Manageability

200 W, up to 92% efficient, active PFC

338 x 380 x 100 mm

Starting at 7.6 kg (Weight varies by configuration)

Low halogen

ENERGY STAR® certified and EPEAT® registered configurations available

3-year limited warranty including 3 years of parts, labour,and next-business-day onsite service. Terms and conditions vary by country. Certain restrictions and exclusions apply.
