Hewlett Packard K7C09A4 Getting Started Guide
Datasheet
HP Z27n 68,6 cm (27") Narrow Bezel IPS Display
No borders, no problem.
Enable a virtually borderless
panorama of multiple displays
with the HP Z27n Narrow Bezel IPS
Display, which has an
edge-to-edge screen for maximum
quad HD impact, out-of-the-box
factory color calibration, and
flexible connectivity for all of your
devices.
1
Edge-to-edge experience.
Get Quad HD 2560 x 1440 resolution2visuals from a three-sided borderless design that reveals more of the 68,6
●
cm (27”) diagonal screen and enables uninterrupted views of multiple displays.
Color calibration at the ready.
Enjoy reliable color accuracy across all of your projects with a factory-calibrated 99% sRGB color gamut from the
●
very first time you turn on your display.
Create a total workspace.
Connect to your everyday devices with integrated HDMI, mDP, DP, MHL3, DVI, and a USB 3.0 hub with a
●
fast-charging port. The DisplayPort output allows you to daisy chain up to two displays1with just one PC or
workstation connection.
Use picture-in-picture or picture-by-picture to get views from your connected devices and boost your
●
multi-tasking productivity.
Work comfortably with adjustable tilt, height adjustment, and swivel settings. Use pivot rotation to customize
●
portrait or landscape views when using multiple displays. An integrated HP Quick Release Bracket supports wall
mounting.
Rest assured that your IT investment is supported by a three-year standard limited warranty. To extend your
●
protection beyond the standard limited warranty, select optional HP Care Pack Services.
Reduce power consumption and lower costs with an intelligent, energy-efficient, low-halogen6design that is
●
ENERGY STAR® certified, TCO qualified, and EPEAT® Gold registered7with mercury-free display backlights and
arsenic-free display glass.
4
1
5
Datasheet
HP Z27n 68,6 cm (27") Narrow Bezel IPS Display Specifications Table
Product Number K7C09A4; K7C09AT
Product Color Black
Display size (diagonal) 68,6 cm (27”)
Display Type IPS
Panel Active Area 596.74 x 335.66 mm;
Viewing Angle 178° horizontal; 178° vertical
Brightness 350 cd/m²
Contrast Ratio 1000:1 static; 5000000:1 dynamic
Response Ratio 14 ms gray to gray
Aspect Ratio 16:9
Native Resolution 2560 x 1440 @ 60 Hz
Resolutions Supported 2560 x 1440; 1920 x 1200; 1920 x 1080; 1680 x 1050; 1600 x 1200; 1600 x 900; 1440 x 900; 1366 x 768; 1280 x 1024; 1280 x 720; 1024 x 768; 800 x
Display Features Plug and Play; Anti-glare; User programmable;Language selection; On-screen controls; LED Backlights; In plane switching
User Controls Menu; Minus ("-"); Plus ("+"); Luminance; Color Control; Input; Information
Input signal 1 MHL 2.0 /HDMI 1.4; 1 DVI-D; 1 DisplayPort 1.2; 1 Mini-DisplayPort 1.2; 1 DisplayPort 1.2 out
Ports and Connectors 4 USB 3.0 (four downstream and one upstream); 1 audio output
Input power Input voltage: 100 to 240 VAC
Power consumption Energy Efficiency Class: B; Panel Active Area: 596.74 x 335.66 mm; On-mode power consumption: 37 W; Annual energy consumption: 55 kWh; Power
Dimensions with Stand (W x D
x H)
Dimensions without Stand (W
x D x H)
Weight 7.66 kg
Ergonomic features Tilt: -5 to +22°; Swivel: 45° ±2°; Pivot rotation: 90°
Certification and Compliance CB; TUV/GS; TUV/Ergo; TUV-S; UL; TCO Edge; CCC; CECP; CEL; SEPA; BSMI; CE; FCC(Canada); BSMI; KC; VCCI; C-Tick; Microsoft WHQL Certification (Windows
Environmental Arsenic-free display glass; Mercury-free display backlights; Low halogen
Energy Efficiency Compliance ENERGY STAR® certified
What's in the box Monitor; AC power cord; USB cable; DisplayPort cable;mini-DisplayPort to DisplayPort cable; CD (includes user guide, warranty, drivers); HP Display
Warranty 3-years limited warranty including 3 years of parts and labour. Certain restrictions and exclusions apply.
1
1
1
600; 640 x 480
HDCP support on all input
consumption (standby): 0,47 W; Power consumption (off-mode): 0,47 W; Power consumption Description: 83 W (maximum), 47 W (typical), 0.5 W
(standby); Screen resolution: 2560 x 1440 @ 60 Hz
61.43 x 21.82 x 53.37 cm
61.43 x 5.39 x 36.41 cm
(With stand)
8.1 and Windows 7); SmartWay Transport Partnership (NA)
