QuickSpecs

HP EliteBook 830 G6 Notebook PC

Overview

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 1

HP EliteBook 830 G6 Notebook PC

Left

HD and IR Camera (Optional)

Glass Clickpad

Ambient Light Sensor (Optional)

Smartcard Reader (Optional)

IR Camera LEDs (Optional)

10.

USB 3.1 Gen 1 Charging Port

Internal Microphones

11.

Vents

Camera Shutter

12.

Standard Security Lock Slot (Lock sold separately)

HD Camera LED

13.

Power Button

Pointstick

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Overview

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 2

Right

Power Connector

USB 3.1 Gen 1 Port

USB Type-C™ with Thunderbolt™

Audio Combo Jack

Docking Connector

SIM Card Slot1

Ethernet Port

Touch Fingerprint Sensor (Optional)

HDMI Port (Cable not included)

1. All units have a SIM card stray but units that do not support WWAN are shipped with a non-removable SIM slot plug

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Overview

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 3

At a Glance

• Eye-catching Ultraslim design, premium precision-crafted machined aluminum (CNC) chassis for clean, crisp, premium

look and feel

• 8th Generation Intel® Core™ i5, i7 Processors

• Preinstalled with Windows 10 versions or FreeDOS

• Designed to support all HP docking options including HP’s traditional Ultraslim mechanical dock and all-new Thunderbolt

dock2

• Featuring HP Collaboration Keyboard with Clickpad to manage most commonly used conferencing functions with a single

keystroke

• Innovative world-facing third mic improves inbound ambient noise cancellation while 360 degree mic pick-up allows

everyone to clearly hear and be heard

• Optional ultrabright displays with ambient light sensor

• Choice of displays:

- 33.8 cm (13.3") diagonal FHD IPS Anti-Glare LED-backlit non-touch, 250 nits, 45% NTSC

- 33.8 cm (13.3") diagonal FHD IPS Anti-Glare LED-backlit non-touch, 400 nits, 72% NTSC

- 33.8 cm (13.3") diagonal FHD IPS Anti-Glare LED-backlit non-touch, 1000 nits, 72% NTSC with HP Sure View (Available 3Q 2019)

- 33.8 cm (13.3") diagonal FHD IPS Anti-Glare On-Cell LED-backlit touch, 250 nits, 45% NTSC

- 33.8 cm (13.3") diagonal FHD IPS Anti-Glare On-Cell LED-backlit touch, 1000 nits, 72% NTSC with HP Sure View (Available 3Q 2019)

• Enterprise grade security with HP Sure Sense

, HP SureStart Gen5, HP Privacy Camera, HP Sure View Gen31, HP Sure Run

Gen2, HP Sure Recover Gen2 with Embedded Reimaging2, HP Sure Click, SmartCard Reader2 and Touch Fingerprint reader2

• Ultimate connectivity with optional CAT16 4G/LTE WWAN, and Thunderbolt™ Docking (dock sold separately)

• Supports fast charging (50% in 30 minutes) with no impact on battery recharge cycles

• Flexible wireless connectivity options

• Choice of solid state drives up to 2 TB and DDR4 memory up to 32 GB

• Passed 19 MIL-STD 810G tests

• UMA graphics: Up to 19 hours (Intel® 8th generation CPU and 3-cell 50 WHr battery)

1. HP Sure View Gen3 integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.

2. Sold separately or as an optional feature

3. Recharges your battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging t ime may vary +/-10% due to System tolerance.

4. MIL STD 810G testing is not intended to demonstrate fitness for U.S. Department of Defense contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack.

5. HP Sure Sense requires Windows 10. See product specifications for availability.

NOTE: See important legal disclosures for all listed specs in their respective features sections.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 4

PRODUCT NAME

HP EliteBook 830 G6 Notebook PC

OPERATING SYSTEMS

Preinstalled

Windows 10 Pro 64 – HP recommends Windows 10 Pro1 Windows 10 Pro 64 (National Academic License)2 Windows 10 Home 641 Windows 10 Home Single Language 641 Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)1 FreeDOS

1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.

2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.

PROCESSORS

Intel® Core™ i7-8665U with Intel® UHD Graphics 620 (1.9 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)

3,4,5,6

Intel® Core™ i7-8565U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)

3,4,5,6

Intel® Core™ i5-8365U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)

3,4,5,6

Intel® Core™ i5-8265U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)

3,4,5,6

Intel® Core™ i3-8145U with Intel® UHD Graphics 620 (2.1 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB L3 cache, 2 cores)

3,4,5,6

Processor Family

8th Generation Intel® Core™ i7 processor (i7-8665U and i7-8565U)

8th Generation Intel® Core™ i5 processor (i5-8365U and i5-8265U)6 8th Generation Intel® Core™ i3 processor (i3-8145U) 6

3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.

4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.

5. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See

http://www.intel.com/technology/turboboost for more information.

6. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on

http://www.support.hp.com.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 5

CHIPSET

Chipset is integrated with processor

GRAPHICS

Integrated

Intel® UHD Graphics 6207

Supports Support HD decode, DX12, HDMI 1.4b8

7. HD content required to view HD images.

8. HDMI cable sold separately.

DISPLAY

Non-Touch

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare WLED-backlit slim, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare WLED-backlit slim for HD camera, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare WLED-backlit slim for HD+IR camera, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare WLED-backlit slim for WWAN, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare WLED-backlit slim for HD camera and WWAN, 250 nits, 45% NTSC (1920 x

1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare LED-backlit slim for HD+IR camera and WWAN, 250 nits, 45% NTSC (1920 x

1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP + PSR anti-glare WLED-backlit ultraslim with Ambient Light Sensor for HD+IR camera, 400 nits, 72% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP + PSR anti-glare WLED-backlit ultraslim with Ambient Light Sensor for HD+IR camera and WWAN, 400 nits, 72% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP + PSR WLED-backlit ultraslim with HP Sure View Gen3 Integrated Privacy Screen, Ambient Light Sensor for HD+IR camera and WWAN, 1000 nits, 72% NTSC (1920 x 1080)

7,9,10,11

(Available 3Q 2019)

Touch

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare on-cell WLED-backlit slim touch screen for HD+IR camera, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP anti-glare on-cell WLED-backlit slim touch screen for HD+IR camera and WWAN, 250 nits, 45% NTSC (1920 x 1080)

7,9,10

33.8 cm (13.3") diagonal FHD IPS eDP + PSR anti-glare on-cell WLED-backlit ultraslim touch screen with HP Sure View Gen3 Integrated Privacy Screen, Ambient Light Sensor for HD+IR camera and WWAN, 1000 nits, 72% NTSC (1920 x 1080)

7,9,10,11

(Available 3Q 2019)

HDMI 1.4b

Supports resolution up to 4k @ 60Hz via DP and @ 30Hz via HDMI

Displays support

Supports 3 independent displays if used with optional HP UltraSlim Docking Station.2

7. HD content required to view HD images.

9. Sold separately or as an optional feature.

10. Resolutions are dependent upon monitor capability, and resolution and color depth settings.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 6

11. HP Sure View Gen3 integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.

Docking station

model

Total number

of supported

displays (incl.

the notebook)

display)

Max.

resolutions

supported

Dock Connectors

Technical limitations

HP UltraSlim Docking

Station (Quest)

Dual 2.5K @

60Hz

2xDP, 1xVGA

Dual 2.5k only with both displays intoDP

HP Thunderbolt Dock G2

Dual 4K @ 60Hz

2xDP, 1xVGA, 1xTB,

1xUSB-C alt-mode

Dual 4k (4096 x 2160) only with:

• 1 DP + TB port or

• USB-C alt mode + TB port

Dual 4K (3840 x 2160) with any of the DP, TB

or USB-C alt mode video ports

HP Elite USB-C Dock G4

Dual 2K @ 60Hz

Single 4K @

60Hz (3840 x

1440)

1xHDMI, 2xDP

HP USB-C Universal Dock

Dual 4K @ 60Hz

Single 5K @

60Hz

2xDP

HP USB-C Travel Dock

Single 2K @

60Hz

1xHDMI, 1xVGA

Single external display

Only HDMI or VGA at the time

STORAGE AND DRIVES

Primary Storage

128 GB SATA-3 SS TLC12 256 GB PCIe NVMe Value SS TLC12 256 GB PCIe Gen3x4 NVMe SS TLC12 256 GB SATA-3 SS TLC Opal 212 512 GB PCIe NVMe Value12 512 GB PCIe Gen3x4 NVMe SS TLC12 512 GB Intel® PCIe® NVMe™ QLC + 32 GB Intel® Optane™ (Memory Planned to be available Q3 2019)

512 GB PCIe Gen3x4 NVMe SS TLC Opal 212 512 GB SATA-3 SS TLC FIPS-140-212 1 TB PCIe Gen3x4 NVMe SS TLC12 2 TB PCIe Gen3x4 NVMe SS TLC12

12. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 7

MEMORY

Maximum Memory

32 GB DDR4-2400 SDRAM

Memory

32 GB DDR4-2400 SDRAM (2 X 16 GB)

16 GB DDR4-2400 SDRAM (1 X 16 GB)

16 GB DDR4-2400 SDRAM (2 X 8 GB)13 8 GB DDR4-2400 SDRAM (1 x 8 GB)13 8 GB DDR4-2400 SDRAM (2 x 4 GB)13 4 GB DDR4-2400 SDRAM (1 x 4 GB)13

Memory Slots

2 SODIMM Both slots are customer accessible / upgradeable DDR4 SODIMMS, system runs at 2400 Supports Dual Channel Memory

13. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 8

NETWORKING/COMMUNICATIONS

WLAN

Intel® Dual Band Wireless-AC 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, vPro™14 Intel® Dual Band Wireless-AC 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, non-vPro™14 Intel® Wi-Fi 6 AX200 802.11a/b/g/n/ac/ax (2x2) and Bluetooth® 5 Combo, vPro™15 Intel® Wi-Fi 6 AX200 802.11a/b/g/n/ac/ax (2x2) Bluetooth® 5 Combo, non-vPro™15

WWAN

Intel® XMM™ 7360 LTE-Advanced Cat 9

Intel® XMM™ 7560 LTE-Advanced Pro Cat 1617 Intel® XMM™ 7262 LTE-Advanced Cat 6

NFC

NPC300 Near Field Communication module

Miracast

Native Miracast Support

Ethernet

Intel® I219-LM 10/100/1000 GbE, vPro™19 Intel® I219-V 10/100/1000 GbE, non-vPro™

14. Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.

15. Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other

802.11ax devices.

16. WWAN module is an optional feature, requires factory configuration and requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

17. Gigabit class Category 16 4G LTE module is optional and must be configured at the factory. Module designed for up to 1 Gb ps download speeds as carriers deploy 5 carrier aggregation and 100Mhz channel bandwidth, requires activation and separately purchased service contract. Backwards compatible to HSPA 3G technologies. Check with service provider for coverage and availability in your area. Connection, upload and download speeds will vary due to network, location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

18. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.

19. The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 9

AUDIO/MULTIMEDIA

Audio

Audio by Bang & Olufsen 2 Integrated stereo speakers Integrated 3 Multi Array Microphone

Camera

720p HD camera

7,9

720p HD IR camera

7,9

Sensors

Ambient light sensor (Select models only)

7. HD content required to view HD images.

9. Sold separately or as an optional feature.

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

Keyboard

HP Premium Collaboration Keyboard, backlit and spill resistant with drain Backlit keyboard available as an option

Pointing Device

Clickpad with multi-touch gestures enabled, taps enabled as default Microsoft Precision Touchpad Default Gestures Support

Function Keys

F1 - Display Switching F2 - Blank or Privacy F3 - Brightness Down F4 - Brightness Up F5 - Audio Mute F6 - Volume Down F7 - Volume Up F8 - Mic Mute F9 - Blank or Backlit Toggle F10 - numlk F11 - Wireless F12 – Calendar Share/Present Call Answer Call End

Hidden Function Keys

Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock Fn+E - Insert Fn+W - Pause

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 10

SOFTWARE AND SECURITY

Preinstalled Software

BIOS

HP BIOSphere Gen520 HP Drive Lock & Automatic Drive Lock21 BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase22 Absolute Persistence Module23 Pre-boot Authentication

Software

HP Native Miracast Support24 HP Connection Optimizer HP Image Assistant HP Hotkey Support HP JumpStart HP Support Assistant25 HP Noise Cancellation Software Buy Office (sold separately)

Manageability Features

HP Driver Packs26 HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP Manageability Integration Kit Gen3

Ivanti Management Suite

Client Security Software

HP Client Security Manager Gen528 HP Fingerprint Sensor29 HP Power On Authentication Windows Defender30

Security Management

Pre-boot Authentication TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified) SATA 0,1 port disablement (via BIOS) Serial, USB enable/disable (via BIOS) Power-on password (via BIOS) Setup password (via BIOS) Support for chassis padlocks and cable lock devices HP Sure Click31 HP Sure Start Gen532 HP Sure Run Gen233 HP Sure Recover Gen2

HP Sure Sense

TPM

Model: Infineon SLB9670 Version: 7.85

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 11

Revision: TPM 2.0 FIPS 140-2 Compliant: Yes

Smartcard Reader

Model number: Alcor AU9560 FIPS 201 Compliant: Yes

IPv6 Certification:

Yes

MD5 Hash: Please follow the instructions below to access MD5 Hash. Log-on to http://hp.com/support, enter your product name, select software and drivers, select OS, select driver. After

selecting the driver, click on “Associated files” and then click on “Download”. When opening the file, under “Purpose” you should see the appropriate “SOFTPAQ MD5:” Field

Graphics (Intel Video Driver): TBD WWAN: TBD WLAN: TBD

Is the BIOS on this notebook ISO/IEC 19678:2015 (formerly NIST 800-147) compliant?:

Yes UEFI version: 2.6

20. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details. Features may vary depending on the platform and configurations.

21. HP Automatic Drive Lock is not supported on NVMe drives.

22. HP Secure Erase for the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™.

23. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:

http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is an optional service provided by

Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.

24. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.

25. HP Support Assistant requires Windows and Internet access.

26. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.

27. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.

28. HP Client Security Manager Gen5 requires Windows and is available on the select HP Pro and Elite PCs. See product specifications for details.

29. HP Fingerprint Sensor sold separately or as an optional feature.

30. Windows Defender Opt in and internet connection required for updates.

31. HP Sure Click is available on select HP platforms and supports Microsoft Internet Explorer, Google Chrome™, and Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe Acrobat are installed.

32. HP Sure Start Gen5 is available on select HP PCs with Intel processors. See product specifications for availability.

33. HP Sure Run Gen2: See product specifications for availability.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 12

34. HP Sure Recover Gen2: See product specifications for availability. Requires an open, wired network connection. Not available on platforms with multiple internal storage drives. You must back up important files, data, photos, videos, etc. before using HP Sure Recover to avoid loss of data. HP Sure Recover (Gen1) does not support platforms with Intel® Optane™.

35. HP Sure Sense requires Windows 10. See product specifications for availability.

POWER

Power Supply

HP Smart 45 W External AC power adapter36 HP Smart 45 W External AC power adapter, 2-prong (Japan only)36 HP Smart 65 W External AC power adapter36 HP Smart 65 W EM External AC power adapter36 45 W USB Type-C™ adapter36 65 W USB Type-C™ adapter36

Primary Battery

HP Long Life 3-cell, 50 Wh Li-ion37

Battery Life

UMA graphics: Up to 19 hours (Intel® 8th generation CPU and 3-cell 50 WHr battery)38

Power Cord

2-wire plug - 1m36 3-wire plug - 1m36 3-wire plug - 1.8m36 Duckhead power cord - 1.0m36 Duckhead power cord - 1.8m36

Battery Weight

193 +/- 10g

36. Availability may vary by country.

37. Battery is internal and not replaceable by customer. Serviceable by warranty.

38. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See http://www.bapco.com for additional details

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 13

WEIGHTS & DIMENSIONS

Product Weight

Starting at 2.94 lb (non-touch); Starting at 3.18 lb (touch)

Starting at 1.33 kg (non-touch); Starting at 1.44 kg (touch)

Product Dimensions (W x D x H) Non-Touch

12.22 x 9.03 x 0.7 in

31.04 x 22.93 x 1.77 cm

Touch

12.22 x 9.03 x 0.7 in

31.04 x 22.93 x 1.78 cm

39. Weight will vary by configuration.

PORTS/SLOTS

1 Thunderbolt™ (USB Type-C™ connector) 2 USB 3.1 Gen 1 (1 charging) 1 docking connector 1 HDMI 1.4

1 RJ-45 1 AC power 1 Headphone/microphone combo jack 1 SIM card slot40 1 Smartcard reader (Optional) Standard Security Lock Slot (Lock sold separately)

8. HDMI cable sold separately.

40. All units have a SIM card slot and icon but units that do not support WWAN are shipped with a non-removable SIM slot plug

SERVICE AND SUPPORT

HP Services offers 1-year limited warranties and 90 day software limited warranty options depending on country. Batteries have a default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. Refer to http://www.hp.com/support/batterywarranty/ for additional battery information. Onsite service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.

41. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit

http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated

to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 14

SYSTEM UNIT

Stand-Alone Power Requirements (AC Power)

Nominal Operating Voltage

19 V Average Operating Power

Win10

Integrated Graphics

6.78W

Max Operating Power

UMA < 45W

Temperature

Operating

32° to 95° F (0° to 35° C)

Non-operating

-4° to 140° F (-20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Shock

Operating

40 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude (unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Planned Industry Standard Certifications

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR® qualified

Select models

EPEAT®

Registered Silver in United States

ICES

Yes

Australia

Yes

NZ A-Tick Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

BSMI

Yes

CE Marking Compliance

Yes

BNCI or BELUS

Yes

CIT

Yes

GOST

Yes

Saudi Arabian Compliance (ICCP)

Yes

SABS

Yes

42. Configurations of the HP Elitebook 830 G6 that are ENERGY STAR® certified are identified as HP Elitebook 830 G6 ENERGY STAR on HP websites and on http://www.energystar.gov.

43. EPEAT® registered where applicable. EPEAT registration varies by country. See http://www.epeat.net for registration status

by country. Search keyword generator on HP’s 3rd party option store for solar generator accessories at

http://www.hp.com/go/options.

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 15

ENVIRONMENTAL & INDUSTRY

Environmental Data

Eco-Label Certifications & declarations

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

• IT ECO declaration

• US ENERGY STAR®

• US Federal Energy Management Program (FEMP)

• Based on US EPEAT® registration according to IEEE 1680.1-2018

EPEAT®. Status varies by country. Visit http://www.epeat.net for more information.

• TCO 8.0

• China Energy Conservation Program (CECP)

• China State Environmental Protection Administration (SEPA)

• Taiwan Green Mark

• Korea Eco-label

• Japan PC Green label*

System Configuration

The configuration used for the Energy Consumption and Declared Noise

Emissions data for the Notebook model is based on a “Typically Configured Notebook”.

Energy Consumption (in accordance with US ENERGY STAR® test method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short idle)

5.04 W

4.88 W

5.04 W

Normal Operation (Long idle)

3.70 W

3.37 W

3.40 W

Sleep

0.90 W

0.89 W

0.91 W

Off

0.37 W

0.36 W

0.38 W

Note: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.

Heat Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short idle)

17 BTU/hr

16 BTU/hr

17 BTU/hr

Normal Operation (Long idle)

12 BTU/hr

11 BTU/hr

Sleep

3 BTU/hr

Off

1 BTU/hr

*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Sound Power

WAd

, bels)

Sound Pressure

pAm

, decibels) Typically Configured – Idle

2.5

14.5

QuickSpecs

HP EliteBook 830 G6 Notebook PC

Technical Specifications

Not all configuration components are available in all regions/countries.

c06308181 — DA 16443 - Worldwide — Version 4 — June 7, 2019

Page 16

Fixed Disk – Random writes

2.7

17.6

Optical Drive – Sequential reads

3.4

27.7

Longevity and Upgrading

This product can be upgraded, possibly extending its useful life by several years. Upgradeable features and/or components contained in the product may include:

• 3 USB ports

• 1 PC card slot (type I/II)

• 1 ExpressCard/54 slot

• 1 IEEE 1394 Port

• 2 SODIMM memory slots

• Optional expansion base docking station

• 1 multi-bay II storage port

• Interchangeable HDD

Spare parts are available throughout the warranty period and or for up to “5”

years after the end of production.

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain: Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight

Battery description: BCR1620 (coin cell) Battery type: Lithium Battery description: 6-cell high capacity Lithium-Ion battery (optional 8 cell available)

Additional Information

• This product is in compliance with the Restrictions of Hazardous

Substances (RoHS) directive - 2011/65/EC.

• This HP product is designed to comply with the Waste Electrical and

Electronic Equipment (WEEE) Directive – 2002/96/EC.

• This product is in compliance with California Proposition 65 (State of

California; Safe Drinking Water and Toxic Enforcement Act of 1986).

• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at

the Gold level, see www.epeat.net

• Plastics parts weighing over 25 grams used in the product are marked

per ISO11469 and ISO1043.

• This product contains 6.14% post-consumer recycled plastic (by wt.)

according to IEEE 1680.1-2018 standard, criterion 4.2.1.1.

• This product is 96.0% recycle-able when properly disposed of at end of

life.

Packaging Materials

External:

PAPER/Corrugated

261 g

Internal:

PLASTIC/EPE (Expanded Polyethylene)

63 g

PLASTIC/Polyethylene low density

14 g PLASTIC/PP

3 g

The plastic packaging material contains at least 50% recycled content.

The corrugated paper packaging materials contains at least 75% recycled content.

RoHS Compliance

HP Inc. complies fully with materials regulations. We were among the first companies to extend the restrictions in the European Union (EU) Restriction of Hazardous Substances (RoHS) Directive to our products worldwide through the

+ 35 hidden pages
