Hewlett Packard 6TL48ET Quick Start Guide

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 1

HP Z4 G4 Workstation

Front view

1.

Front I/O module options

- Premium (optional): power button, 2 USB 3.1 G1 Type-A, 2

USB 3.1 G2 Type-C™, Headset/Mic, Media Card Reader
(optional) (Left-most Type-A port has charging capability)

- Standard (shown here): power button, 4 USB 3.1 G1 Type-

A (left-most Type-A port has charging capability),
Headset/Mic, Media Card Reader (optional)

2.

Front handle

3.

2 x 5.25” external drive bays

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 2

Internal view

4.

Intel® Xeon® Processors: W-2100 family

9.

2 x 5.25” external drive bays

5.

2 PCIe G3 x16, 2 PCIe G3 x4, 1 PCIe G3 x8

10.

2 x 2.5”/3.5” internal drive bays

6.

2 PCIe G3 x4 M.2 for SSDs

11.

Fan and front card guide option

7.

8 DIMM slots; DDR4-2666 ECC Registered RAM

12.

6 x 6Gb/s SATA ports

8.

PSU options:

- 465W 90% efficient with 0 graphics power adapters

- 750W 90% efficient with 2 graphics power adapters

- 1000W 90% efficient with up to 4 graphics power

dongles*

* Available the first half of 2018

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 3

Rear view

13.

Rear power button

17.

Rear I/O (top to bottom):

- audio in/out, Keyboard/Mouse PS/2

- 6 USB 3.1 G1 Type-A

- 2 x 1GbE ports

14.

Rear handle

15.

Padlock loop

16.

Kensington lock slot

18.

Side panel barrel keylock (optional)

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 4

Form Factor

Minitower

Operating Systems

Preinstalled:

 Windows 10 Pro 64 for Workstations
 HP Linux-ready (minimal OS ready for customer OS installation)
 Red Hat® Enterprise Linux Desktop Workstation (Paper license with 1 year support; no

preinstalled OS)

Supported:

 Windows 7 Professional 64-bit (downgrade media available by request from HP Support)*
 Red Hat Enterprise Linux Desktop 7.4
 SUSE Linux Enterprise Desktop 12 SP3
 Ubuntu 16.04 LTS

Notes: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

*Windows 10 is preinstalled. Windows 7 media is only available upon request from HP Customer
Support. You may only use one version of the Windows software at a time. Switching between versions
will require you to uninstall one version and install the other version.

Available Processors

Name

Cores

Clock

Speed

(GHz)

Cache

(MB)

Memory

Speed

(MT/s)

Hyper-

Threading

Featuring

Intel® vPro™

Technology

Intel® Turbo

Boost

Technology1

TDP

(W)

Intel® Xeon

®

W-2195 processor

18

2.3

24.75

2666

YES

YES

3.2, 4.3

140

Intel® Xeon®
W-2155 processor

10

3.3

13.75

2666

YES

YES

4.0, 4.5

140

Intel® Xeon®
W-2145 processor

8

3.7

11.00

2666

YES

YES

4.3, 4.5

140

Intel® Xeon®
W-2135 processor

6

3.7

8.25

2666

YES

YES

4.4, 4.5

140

Intel® Xeon®
W-2133 processor

6

3.6

8.25

2666

YES

YES

3.8, 3.9

140

Intel® Xeon®
W-2125 processor

4

4.0

8.25

2666

YES

YES

4.4, 4.5

120

Intel® Xeon®
W-2123 processor

4

3.6

8.25

2666

YES

YES

3.7, 3.9

120

Intel® Xeon®
W-2104 processor

4

3.2

8.25

2400

NO

YES

N/A

120

Intel® Xeon®
W-2102 processor

4

2.9

8.25

2400

NO

YES

N/A

120

1

The specifications shown in this column represent the following: (all core maximum turbo frequency,
one core maximum turbo frequency). Processors that do not have turbo functionality are denoted as
N/A.

Available Processors

Overview

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 5

Disclaimers

Multicore is designed to improve performance of certain software products. Not all customers or
software applications will necessarily benefit from use of this technology. Performance and clock
frequency will vary depending on application workload and your hardware and software
configurations. Intel’s numbering, branding and/or naming is not a measurement of higher
performance.

Color

Black

Convertibility

No

Expansion Slots (see
system board section for
more details)

Slot 0:

Mechanical-only, for use with devices that require only rear bulkhead mounting

Slot 1:

PCI Express Gen3 x16 - CPU

Slot 2:

PCI Express Gen3 x4 - PCH with open-ended connector*

Slot 3:

PCI Express Gen3 x16 - CPU

Slot 4:

PCI Express Gen3 x4 – PCH with open-ended connector*

Slot 5:

PCI Express Gen3 x8 – CPU with open-ended connector*

M.2 Slot 1:

M.2 PCIe Gen 3 x4 - CPU up to 80mm storage devices

M.2 Slot 2:

M.2 PCIe Gen 3 x4 - CPU up to 80mm storage devices

* Open-ended connector allows a greater bandwidth (e.g. x16) card to be installed physically into a
lower bandwidth connector/slot.

Note: Thunderbolt™ 3 PCIe card support available the first half of 2018

Expansion Bays (see
storage section for more
details)

2 internal 2.5"/3.5” bays (with acoustic dampening rail assemblies pre-installed)
2 external 5.25" bays

 3rd and 4th 3.5" HDD each occupy one external bay
 3rd and 4th 2.5" HDD/SSD occupy a single external bay within a 2:1 carrier

Front I/O

 Base: Power button, 1 Headset audio port, 4 USB 3.1 G1 Type A (1 charging)
 Premium (optional): Power button, 1 Headset audio port, 2 USB 3.1 G2 Type C™, 2 USB 3.1 G1

TypeA (1 charging)

 Optional: SD reader

Internal I/O

1 USB 3.1 G1 (aka USB 3.0) single-port header, 1 USB 2.0 single-port header and 1 USB 2.0 dual-port
header

Rear I/O

6 USB 3.1 G1 (aka USB 3.0) Type A ports, 2 1Gbe LAN ports (1x supporting Intel AMT), Audio: 1 Line out,
1 Line in (Line in can be retasked as microphone), 1 PS/2 mouse port, 1 PS/2 keyboard port, 1 Rear
power button
Optional: 1 serial port (cable up to rear bulkhead)

Interfaces Supported

SD card reader (optional)
6-channel SATA interface (6 @ 6.0 Gb/s)

QuickSpecs

HP Z4 G4 Workstation

Overview

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 6

6 channels are eSATA configurable for use with eSATA CTO/AMO Kit (No hot plug / hot swap
supported)
USB 2.0, USB 3.1 G1 (aka USB 3.0), USB 3.1 G2 (optional)

On-board RAID Support

SATA RAID 0 Striped Array Configuration
SATA RAID 1 Mirrored Array Configuration
SATA RAID 10 Striped/Mirrored Configuration

Chassis Dimensions (H x
W x D)

H: 15.2" (386mm)
W: 6.65" (169mm)
D: 17.5" (445mm)

Packaged Dimensions

H: 22.5" (572mm)
W: 12.4" (314mm)
D: 22.2" (563mm)

Rack Dimensions

4U

Weight

Exact weights depend upon configuration (System weight only).
Minimum: 10.2 kg (22.4 lbs.)
Standard: 11.3 kg (24.9 lbs.)
Maximum: 17.3 kg (38.2 lbs.)

Temperature

Operating: 5° to 35°C (40° to 95°F)
Non-operating: -40° to 60°C (-40° to 140°F)

Note: Above 1524 m (5,000 feet) altitude, maximum operating temperature is reduced by 1° C (1.8° F)
per 305 m (1,000 feet) elevation increase

Humidity

Operating: 10% to 85% relative humidity, non-condensing, 35° C maximum wet bulb
Non-operating: 10% to 90% relative humidity, non-condensing, 35° C maximum wet bulb

Maximum Altitude (non­pressurized)

Operating: 3,048m (10,000ft)
Non-operating: 9,144m (30,000ft)

Note: Above 1524 m (5,000 feet) altitude, maximum operating temperature is reduced by 1° C (1.8° F)
per 305 m (1,000 feet) elevation increase

Power Supply

ENTRY

465 watts wide-ranging, active Power Factor Correction, 90% Efficient, with no 6-pin graphics power
cables

The Z4 G4 465W power supply efficiency report can be found at this link:

https://plugloadsolutions.com/psu_reports/HP%20INC_DPS-465AB­3%20A_465W_ECOS%204939_Report.pdf

HIGH-END
750 watts wide-ranging, active Power Factor Correction, 90% Efficient, with 2x 6-pin graphics power
cables

The Z4 G4 750W power supply efficiency report can be found at this link:

https://plugloadsolutions.com/psu_reports/HP%20INC_DPS-750AB­36%20A_750W_ECOS%204938_Report.pdf

NOTE: 1000 W internal power supply, up to 90% efficiency, active PFC available the first half of 2018

Workstation ISV
Certifications

See the latest list of certifications at

http://www8.hp.com/us/en/campaigns/workstations/industries-and-partners.html

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 7

Processors

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Intel® Xeon® W-2100 Series CPU

Intel® Xeon® W-2195 2.3 2666 18C CPU

Y

N

Intel® Xeon® W-2155 3.3 2666 10C CPU

Y

N

Intel® Xeon® W-2145 3.7 2666 8C CPU

Y

N

Intel® Xeon® W-2135 3.7 2666 6C CPU

Y

N

Intel® Xeon® W-2133 3.6 2666 6C CPU

Y

N

Intel® Xeon® W-2125 4.0 2666 4C CPU

Y

N

Intel® Xeon® W-2123 3.6 2666 4C CPU

Y

N

Intel® Xeon® W-2104 3.2 2400 4C CPU

Y

N

Intel® Xeon® W-2102 2.9 2400 4C CPU

Y

N

Multicore is designed to improve performance of certain software products. Not all customers or
software applications will necessarily benefit from use of this technology. Performance and clock
frequency will vary depending on application workload and your hardware and software

configurations. Intel’s numbering, branding and/or naming is not a measurement of higher

performance.

Monitors /
Displays

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

HP Z Display Z22n G2

Y

1JS05AA

HP Z Display Z23n G2

Y

1JS06AA

HP Z Display Z24i G2

Y

1JS08AA

HP Z Display Z24n G2

Y

1JS09AA

HP Z Display Z24nf G2

Y

1JS07AA

HP Z Display Z27n G2

Y

1JS10AA

HP Z Display Z27s (4K display)

Y

J3G07AA

Supported by all operating systems available from HP
Screen size measured diagonally

Storage / Hard Drives

SAS Hard Drives

SAS Hard Drives for HP Workstations

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

HP 300GB 15k SAS SFF

Y

Y

L5B74AA

NOTE: SAS controller add-in card required

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 8

SATA Hard Drives

Factory

Configured

Option Kit

Option
Kit Part
Number

Support

Notes

SATA (Serial ATA) Hard Drives for HP Workstations

500GB SATA 7200RPM 6Gb/s 3.5” HDD

Y

Y

LQ036AA

500GB SATA 7200RPM 6Gb/s OPAL2 SFF 3.5” HDD

Y

Y

D8N29AA

1TB SATA 7200RPM 3.5” HDD

Y

Y

LQ037AA

1TB SATA 7200RPM Ent 3.5” HDD

Y

Y

W0R10AA

2TB SATA 7200RPM HDD

Y

Y

QB576AA

4TB SATA 7200RPM Ent 3.5” HDD

Y

Y

K4T76AA

NOTES:

Up to (4) 3.5-inch 7200 rpm SATA drives: 500 GB, 1.0, 2.0, 4.0, 16TB max total

SATA Solid State Drives

Factory

Configured

Option Kit

Option
Kit Part
Number

Support

Notes

HP Solid State Drives (SSDs) for Workstations

HP 256GB SATA SSD

Y

Y

A3D26AA

HP 512GB SATA SSD

Y

Y

D8F30AA

HP 1TB SATA SSD

Y

Y

F3C96AA

HP 2TB SATA SSD

Y

Y

Y6P08AA

HP 256GB SATA SED OPAL2 SSD

Y

Y

G7U67AA

HP 512GB SATA SED OPAL2 SSD

Y

Y

N8T26AA

HP 240GB SATA Enterprise SSD

Y

Y

T3U07AA

HP 480GB SATA Enterprise SSD

Y

Y

T3U08AA

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 9

PCIe Solid State Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

PCIe SSDs for HP Workstations

HP Z Turbo Drive 256GB MLC Z4/Z6 G4 SSD Kit

Y

Y

1PD56AA

1

HP Z Turbo Drive 512GB MLC Z4/Z6 G4 SSD Kit

Y

Y

1PD57AA/AT

1

HP Z Turbo Drive 1TB MLC Z4/Z6 G4 SSD Kit

Y

Y

1PD58AA

1

HP Z Turbo Drive 256GB TLC Z4/Z6 G4 SSD Kit

Y

Y

1PD59AA/AT

1

HP Z Turbo Drive 512GB TLC Z4/Z6 G4 SSD Kit

Y

Y

1PD60AA

1

HP Z Turbo Drive 1TB TLC Z4/Z6 G4 SSD Kit

Y

Y

1PD61AA

1

HP Z Turbo Drive 256GB Z4/Z6 G4 SED Kit

Y Y TBD

1

HP Z Turbo Drive 512GB Z4/Z6 G4 SED Kit

Y Y TBD

1

HP Z Turbo Drive Quad Pro

HP Z Turbo Drive Quad Pro 2x256GB PCIe® SSD

Y

Y

N2M98AA

1, 2

HP Z Turbo Drive Quad Pro 2x512GB PCIe® SSD

Y

Y

N2M99AA

1, 2

HP Z Turbo Drive Quad Pro 2x1TB PCIe® SSD

Y

Y

T9H99AA

1, 2

HP Z Turbo Drive Quad Pro 256GB SSD module

N

Y

N2N00AA

1, 3

HP Z Turbo Drive Quad Pro 512GB SSD module

N

Y

N2N01AA

1, 3

HP Z Turbo Drive Quad Pro 1TB SSD module

N

Y

T9J00AA

1, 3

Note 1: All PCIe SSDs require the Z4 G4 Fan & Front Card Kit, available as CTO (1MY89AV) and AMO
(1XM33AA)

Note 2: Dual M.2 SSD modules plus carrier

Note 3: M.2 SSD module only, designed to be installed into Quad Pro carrier

Hard Drive Controllers

Factory

Configured

Option

Kit

Option Kit

Part Number

Support

Notes

SAS Controller

MicroSemi SmartHBA2100-4i4e SAS Controller

Y

Y

1FV90AA

Graphics

Factory

Configured

Option

Kit

Option Kit

Part Number

Support

Notes

Supported

# of cards

Graphics Cable Adapters

HP DisplayPort to HDMI Adapter

Y Y K2K92AA

1

HP DisplayPort to Dual Link DVI Adapter

Y

Y

NR078AA

1

HP DisplayPort to DVI-D Adapter

Y Y FH973AA

1

HP DisplayPort to DVI-D Adapter (2-pack)

Y N 1

HP DisplayPort to DVI-D Adapter (4-pack)

Y N 1

HP DisplayPort to DVI-D Adapter (6-pack)

Y N 1

NVIDIA SLI Graphics Connector

Y Y PP654A

1

NVIDIA SLI 2-slot Graphics Connector

Y Y 2YY84AA

1

Entry 3D

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 10

NVIDIA® Quadro® P400 1

st

GFX 2GB Graphics

Y

Y

1ME43AA/AT

4

2

NVIDIA® Quadro® P600 1

st

GFX 2GB Graphics

Y

Y

1ME42AA/AT

4

2

AMD FirePro™ W2100 2GB Graphics

Y

Y

J3G91AA/AT

3

2

Mid-range 3D

NVIDIA® Quadro® P1000 1

st

GFX 4GB Graphics

Y Y 1ME01AA/AT

3, 4 2

NVIDIA® Quadro® P2000 1

st

GFX 5GB Graphics

Y

Y

1ME41AA/AT

3, 4

2

AMD Radeon™ Pro WX 3100 4GB Graphics

Y Y 2TF08AA

3, 4 2

AMD Radeon™ Pro WX 4100 4GB Graphics

N Y Z0B15AA/AT

3, 4 2

High End 3D

NVIDIA® Quadro® P4000 1

st

GFX 8GB Graphics

Y Y 1ME40AA/AT

1, 2 2

NVIDIA® Quadro® P5000 1

st

GFX 16GB Graphics

Y Y Z0B13AA/AT

1, 2 1

NVIDIA® Quadro® P6000 1

st

GFX 24GB Graphics

Y Y Z0B12AA/AT

1, 2 1

AMD Radeon™ Pro WX 7100 1

st

GFX 8GB Graphics

Y

Y

Z0B14AA/AT

1, 2

2

NVIDIA® Quadro® Sync II

Y

Y

1WT20AA

NOTE 1: Single graphics configuration requires the HP Z4 G4 Fan and Front Card Guide Kit, which is available
both CTO (1MY89AV) and AMO (1XM33AA).

NOTE 2: Single graphics configuration requires the 750W chassis.
NOTE 3: Dual graphics configuration requires the HP Z4 G4 Fan and Front Card Guide Kit, which is available

both CTO (1MY89AV) and AMO (1XM33AA).

NOTE 4: Dual graphics configuration requires the 750W chassis.

Memory

CTO

Factory

Configured

Option Kit

Option Kit

Part

Number

Support

Notes

DDR4-2666 ECC Registered DIMMs

HP 8GB (1x8GB) DDR4-2666 ECC Reg RAM

Y

Y

1XD84AA/AT

1

HP 16GB (2x8GB) DDR4-2666 ECC Reg RAM

Y

1

HP 24GB (3x8GB) DDR4-2666 ECC Reg RAM

Y

1

32GB (4x8GB) DDR4-2666 ECC Reg RAM

Y

1

64GB (8x8GB) DDR4-2666 ECC Reg RAM

Y

1

16GB (1x16GB) DDR4-2666 ECC Reg RAM

Y

Y

1XD85AA/AT

1

32GB (2x16GB) DDR4-2666 ECC Reg RAM

Y

1

64GB (4x16GB) DDR4-2666 ECC Reg RAM

Y

1

128GB (8x16GB) DDR4-2666 ECC Reg RAM

Y

1

32GB (1x32GB) DDR4-2666 ECC Reg RAM

N

Y

1XD86AA/AT

1, 2

64GB (2x32GB) DDR4-2666 ECC Reg RAM

Y

1, 2

128GB (4x32GB) DDR4-2666 ECC Reg RAM

Y

1, 2

256GB (8x32GB) DDR4-2666 ECC Reg RAM

Y

1, 2

NOTES:

For details on the supported memory configurations on the HP Z4 G4 Workstation, please refer to the System
Technical Specifications - System Board section of this document.

Each processor supports up to 4 channels of DDR4 memory. To realize full performance at least 1 DIMM must
be inserted into each channel.

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 11

The CPUs determine the speed at which the memory is clocked. If an 2400MT/s capable CPU is used in the
system, the maximum speed the memory will run at is 2400MT/s, regardless of the specified speed of the
memory.

NOTE 1: ONLY registered DDR4 DIMMs are supported. DDR3 DIMMs ARE NOT SUPPORTED.

NOTE 2 Memory configurations using 32GB DIMMs require the HP Z4 Memory Cooling

Solution, which is

available both CTO (1MY90AV) and AMO (1XM34AA).

Multimedia and Audio Devices

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 12

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

Integrated Realtek HD ALC221 Audio

Y N

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP SlimTray Optical Drives

HP 9.5mm Slim Blu Ray Disc Writer

Y Y K3R65AA

1

HP 9.5mm Slim DVD ROM

Y Y K3R63AA

1

HP 9.5mm Slim DVD Writer*

Y Y K3R64AA

1

HP SD Card Reader

HP SD 4 Card Reader

Y Y Y0L99AA

NOTE 1: Installing an optical drive into Z4 G4 requires a 5.25” external bay adapter.

*Actual speeds may vary. No support for DVD-RAM (DVD Writer). Does not permit copying of
commercially available DVD movies or other copyright protected materials. Intended for creation and
storage of your original material and other lawful uses. Double Layer discs can store more data than
single layer discs. However, double-layer discs burned with this drive may not be compatible with
many existing single-layer DVD drives and players.

With Blu-ray, certain disc, digital connection, compatibility and/or performance issues may arise, and
do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order
for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may
require HDCP support. HD-DVD movies cannot be played on this workstation.

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support Notes

HP i350-T2 PCIe Dual Port Gigabit NIC

Y

Y

V4A91AA

Intel® i350-T4 PCIe 4-Port Gigabit NIC

N

Y

W8X25AA

Intel® Ethernet I210-T1 PCIe x1 Gb NIC

Y

Y

E0X95AA

Intel 8265 802.11 a/b/g/n/ac + BT PCIe WLAN

N

Y

1QL48AA

Intel® X550-T2 10GbE Dual Port NIC

Y

Y

1QL46AA

Intel® X710-DA2 10GbE SFP+ Dual Port NIC

Y

Y

1QL47AA

HP 10GbE SFP+ SR Transceiver

Y

Y

C3N53AA

Multimedia and Audio Devices

Optical and Removable Storage

Networking and Communications

Racking and Physical Security

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 13

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

HP Z4/Z6 Side Panel Barrel Keylock

Y

N

HP Solenoid Lock / Hood Sensor

Y N

HP Z4/Z6 Depth Adjustable Fixed Rail Rack Kit

N

Y

2HW42AA

HP Keyed Cable Lock 10mm

N

Y

T1A62AA

Factory

Configured

Option

Kit

Option Kit

Part

Number

Support

Notes

HP Wireless Business Slim Keyboard and Mouse

Y

Y

N3R88AA

Business Slim PS/2 Wired Keyboard

Y

Y

N3R86AA

USB Business Slim Wired Keyboard

Y

Y

N3R87AA

USB Premium Wired Keyboard

Y

Y

Z9N40AA

USB Wired SmartCard CCID Keyboard

Y

Y

E6D77AA

3Dconnexion CADMouse

Y

Y

M5C35AA

HP Optical USB Mouse

Y

Y

QY777AA

HP PS/2 Mouse

Y

Y

QY775AA

HP USB Hardened Mouse

Y

Y

P1N77AA

Factory

Configured

Option Kit

Option Kit

Part

Number

Support Notes

HP ENERGY STAR® certified Configuration

Y

HP Z Premium Front I/O 2xUSB-A 2xUSB-C

Y

Y

1XM32AA

HP Z4 G4 Memory Cooling Solution

Y

Y

1XM34AA

Note 1

HP Z4 G4 Fan and Front Card Guide Kit

Y

Y

1XM33AA

Note 2

HP Internal USB Port Kit

N

Y

EM165AA

Note 3

HP eSATA 2 port PCI Bulkhead Kit

Y

Y

GM110AA

HP Serial Port Adapter

Y

Y

PA716A

HP Workstation Mouse Pad

Y

HP ENERGY STAR® certified Configuration

Y

Note 1: The HP Z4 G4 Memory Cooling Solution is available to add to any configuration for improved
system cooling, but is required for memory configurations using 32GB DIMMs.

Note 2: Fan and Front Card Guide required with the following components:

- Specific graphics configurations (see Graphics section above)

- Any HP Z Turbo Drive configuration

- Any HP Z Turbo Quad Pro configuration

Note 3: The HP Internal USB Port kit has a single USB 2.0 type A connector.

Racking and Physical Security

Input Devices

Other Hardware

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 14

Software

Factory

Configured

Option Kit

Option Kit

Part

Number

Support Notes

Sobey Video Editing SW

Y

N China only

SW HP RGS for Z

Y

N

QuickSpecs

HP Z4 G4 Workstation

Supported Components

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 15

Operating Systems

Support Notes

Windows 10 Pro 64 for Workstations

Windows 7 Professional 64-bit

Note 3, 4

HP Linux® Installer Kit

Note 2

Red Hat® Enterprise Linux (RHEL) Workstation - Paper License (1yr)

Note 1

NOTE 1: This second OS must be ordered with the HP Linux Installer Kit as the first OS.

NOTE 2: includes drivers for 64-bit OS versions of RHEL 6 & 7, SUSE Linux Enterprise Desktop 11 and

Ubuntu 14.04.

NOTE 3: downgrade media available by request from HP Support.

NOTE 4: Windows 10 is preinstalled. Windows 7 media is only available upon request from HP

Customer Support. You may only use one version of the Windows software at a time. Switching
between versions will require you to uninstall one version and install the other version

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 16

System Board

System Board Form
Factor

Main System Board:

27.7 x 28.0 cm

10.9 x 11.0 inches

Processor Socket

Single LGA2066 R4

Chipset

Intel® C422 Chipset

Super I/O Controller

Nuvoton NPCD315HA0DX (SIO-15)

Memory Expansion
Slots

8 DDR4 memory slots

Memory Type
Supported

DDR4, RDIMM (Registered), ECC: 8GB, 16GB and 32GB
Memory Modes

Channel Interleaved

Memory Speed
Supported

2666MT/s, 2400MT/s, and 2133MT/s
Memory Protection

ECC available on data, parity on address and command

Maximum Memory

Supports up to 256GB

Memory Configuration
(Supported)

Only Registered DIMMs are supported.

Memory Load Order

Note on Maximum
Memory

Maximum memory capacities assume 64-bit operating systems such as Windows 10 Pro 64-bit, Windows
7 Professional 64-bit. Windows 7 Professional 32-bit supports up to 4GB. Linux 32-bit supports up to
8GB.

PCI Express Connectors

Slot 1 (top):

PCI Express Gen3 x16 from CPU
Full-height, Full-length (with extender)

Slot 2 (PCH):

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 17

PCI Express Gen3 x4 from PCH with open-ended connector** Full-height, Full-length (with extender)

Slot 3:

PCI Express Gen3 x16 from CPU
Full-height, Full-length (with extender)

Slot 4 (PCH):

PCI Express Gen3 x4 from PCH with open-ended connector**
Full-height, Full-length (with extender)

Slot 5:

PCI Express Gen3 x8 from CPU with open-ended connector**
Full-height, Full-length (with extender)
M.2 Slot 1:
PCI Express Gen3 x4 supplied by CPU
Socket Type 3, Key M, H4.2, sizes 2260-D5-M, 2280-D5-M, 22110-D5-M

M.2 Slot 2:

PCI Express Gen3 x4 supplied by CPU
Socket Type 3, Key M, H4.2, sizes 2260-D5-M, 2280-D5-M, 22110-D5-M

** Open-ended connector allows a greater bandwidth (e.g. x16) card to be installed physically into a
lower bandwidth connector/slot.

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 18

Supported Drive Interfaces

SATA

6 SATA @6Gb/s, supports RAID 0,1, 5, and 10
Factory integrated RAID is Microsoft Windows only

Serial Attached SCSI

Requires Optional PCIe card

Factory Configured RAID

• RAID 0 configuration - striped array

• RAID 1 configuration - mirrored array

• RAID 10 striped and mirrored array

*HW RAID functionality not supported by Linux. Use SW RAID
functionality provided in the Red Hat Operating system instead.

Integrated Graphics

No

Network Controller

Intel® I219LM GbE LAN

Supports the following management functionalities: Intel AMT11.1,
TXT, DASH 1.1, WOL, VLAN, Teaming and PXE 2.1

External SATA (eSATA)

Supported on all SATA ports configurable with optional eSATA*
cable kit
* hot plug / hot swap not supported with eSATA

IDE connector

No

Floppy connector

No

Serial

1 internal header
2nd Serial

No

Parallel

No

AUX IN (audio)

No

IEEE 1394 Connector(s)

Front

None

Rear

None

Internal

None

USB Connector(s)

Front

Front USB depends on which FIO module is selected:

- Standard: 4 USB 3.1 G1 Type A (1 charging)

- Premium: 2 USB 3.1 G2 Type C™, 2 USB 3.1 G1 Type A (1 charging)

Rear

6 USB 3.1 G1 Type A

Internal

1 USB 3.1 G1 single-port header
1 USB 2.0 single-port header
1x USB 2.0 dual-port header

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 19

HD Integrated Audio

Realtek ALC221

Flash ROM

Yes

CPU Fan Header

Yes

Rear Chassis Fan Header

Yes

Front PCI Fan Header

Yes

Front Control Panel/Speaker
Header

Yes

CMOS Battery Holder ­Lithium

Yes

Integrated Trusted Platform
Module

Trusted Platform Module (TPM) 2.0 (Infineon SLB 9670)
Common Criteria EAL4+ Certified
Convertible to FIPS 140-2 Certified mode through firmware v7.80
TPM Certified products list:

https://trustedcomputinggroup.org/membership/certification/tpm-certified-products/

Power Supply Headers

Yes

Power Switch, Power LED &
Hard Drive LED Header

Yes
Clear Password Jumper

Yes

Serial Port

1 internal header

Parallel Port

No

Keyboard/Mouse

USB or PS/2

Hood Lock Header

Yes

Hood Sensor Header

Yes

Memory Fan

1 Memory Fan Header

AUX IN (audio)

No

Power Supply

Power Supply

750W 90% Efficient, Custom PSU

(Wide-Ranging, Active PFC)

465W 90% Efficient, Custom PSU

(Wide-Ranging, Active PFC)

Operating Voltage Range

90–269 VAC

90–269 VAC

Rated Voltage Range

100-240 VAC

118 VAC

100-240 VAC

118 VAC

Rated Line Frequency

50–60 Hz

400 Hz

50–60 Hz

400 Hz

Operating Line Frequency
Range

47–66 Hz

393–407 Hz

47–66 Hz

393–407 Hz

Rated Input Current

100-240V @ 10A

118V @ 10A

100-240V @ 6A

118V @ 6A

Heat Dissipation

(Configuration and software
dependent)

Typical =

1850 btu/hr

Max = 3084 btu/hr

Typical =

1147 btu/hr

Max = 1912 btu/hr

Power Supply Fan

80x25 mm variable speed

80x25 mm variable speed

ENERGY STAR Qualified
(Configuration dependent)

Yes

Yes

80 PLUS® Compliant

90% Efficient

The Z4 G4 750W power supply efficiency report

can be found at this link:

https://plugloadsolutions.com/psu_reports/HP%

20INC_DPS-750AB-

36%20A_750W_ECOS%204938_Report.pdf

90% Efficient

The Z4 G4 465W power supply efficiency report

can be found at this link:

https://plugloadsolutions.com/psu_reports/HP%

20INC_DPS-465AB-

3%20A_465W_ECOS%204939_Report.pdf

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 20

FEMP Standby Power
Compliant @115V
<1W in S5 – Power Off)

Yes

Yes

EuP Compliant @ 230V
(<0.5 W in S5 – Power Off)

Yes

Yes

CECP Compliant @ 220V
(<4W in S3 – Suspend to RAM)

Yes; Configuration dependent

Yes; Configuration dependent

Power Consumption in sleep
mode
(as defined by ENERGY STAR)
– Suspend to RAM (S3)
(Instantly Available PC)

TBD TBD

Built-in Self Test LED

Yes

Yes

Surge Tolerant Full Ranging
Power Supply
(withstands power surges up
to 2000V)

Yes

Yes

NOTE: 1000 W internal power supply, up to 90% efficiency, active PFC available the first half of 2018

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 21

Example Z4 G4
Workstation
Configuration #1

ENERGY STAR
QUALIFIED

Processor

1x Intel Xeon W-2102 4C 2.9GHz

Memory

1x 8GB DDR4-2666 (Registered DIMM)

Graphics

1x NVIDIA Quadro P400

Disks / Optical

1x 500GB SATA 7200 ; 1x Slim DVD-ROM SATA

Power Supply

465W 90% custom PSU

Other

N/A

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

42.323

41.338

42.585

Windows Busy Typ(S0)

87.841

86.539

86.018

Windows Busy Max (S0)

90.231

92.323

90.786

Sleep (S3)

3.449

3.440

3.566

3.558

3.530

3.410

Off (S5)

1.041

1.014

1.242

1.231

1.310

1.180

Zero Power Mode (ErP)

0.187

0.43

0.174

Heat Dissipation
(Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Enabled

LAN Disabled

LAN Enabled

Windows Idle (S0)

144.406

141.045

145.301

Windows Busy Typ(S0)

299.713

295.271

293.493

Windows Busy Max (S0)

307.868

315.006

309.761

Sleep (S3)

11.767

11.737

12.167

12.140

12.044

11.634

Off (S5)

3.551

3.459

4.237

4.200

4.469

4.026

Zero Power Mode (ErP)

0.638

1.467

0.594

Example Z4 G4
Workstation
Configuration #2

ENERGY STAR
QUALIFIED

Processor

1x Intel Xeon W-2123 4C 3.6GHz

Memory

2x 8GB DDR4-2666 (Registered DIMM)

Graphics

1x NVIDIA QuadroP1000

Disks / Optical

1x 500GB SATA 7200 ; 1x Slim DVD-ROM SATA

Power Supply

750W 90% custom PSU

Other

N/A

Energy Consumption

(Watts)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

39.947

39.569

40.956

Windows Busy Typ(S0)

148.97

147.145

147.645

Windows Busy Max (S0)

149.543

150.789

147.845

Sleep (S3)

3.615

3.566

3.801

3.798

3.634

3.621

Off (S5)

1.079

1.016

1.440

1.238

1.320

1.170

Zero Power Mode (ErP)

0.204

0.430

0.191

Heat Dissipation

(Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Enabled

LAN Disabled

LAN Enabled

Windows Idle (S0)

136.299

135.009

139.741

System Configuration

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 22

Windows Busy Typ(S0)

508.286

502.058

503.764

Windows Busy Max (S0)

510.241

514.492

504.447

Sleep (S3)

12.338

12.167

12.969

12.959

12.399

12.355

Off (S5)

3.681

3.466

4.913

4.224

4.504

3.992

Zero Power Mode (ErP)

0.696

1.467

0.651

Example Z4 G4
Workstation
Configuration #3

Processor

1x Intel Xeon W-2133 6C 3.6GHz

Memory

4x 8GB DDR4-2666 (Registered DIMM)

Graphics

1x NVIDIA QuadroP2000

Disks/Optical

2x 1TB SATA7200 ; 1x Slim SuperMulti DVDRW SATA

Power Supply

750W 90% custom PSU

Other

N/A

Energy Consumption

(Watts)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

48.759

46.321

46.578

Windows Busy Typ(S0)

211.99

199.56

206.055

Windows Busy Max (S0)

209.60

208.66

198.82

Sleep (S3)

4.360

4.351

4.538

4.508

4.299

4.277

Off (S5)

1.039

1.017

1.42

1.219

1.015

0.997

Zero Power Mode (ErP)

0.203

0.399

0.191

Heat Dissipation

(Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Enabled

LAN Disabled

LAN Enabled

Windows Idle (S0)

166.366

258.047

158.924

Windows Busy Typ(S0)

723.309

680.898

703.059

Windows Busy Max (S0)

715.155

711.947

678.373

Sleep (S3)

14.876

14.845

15.483

15.381

14.668

14.593

Off (S5)

3.544

3.470

4.845

4.179

3.463

3.402

Zero Power Mode (ErP)

0.692

1.361

0.651

Example Z4 G4
Workstation
Configuration #4

Processor

1x Intel Xeon W-2155 10C 3.3GHz

Memory

8x 32GB DDR4-2666 (Registered DIMM)

Graphics

1x NVIDIA QuadroP6000

Disks / Optical

4x 2TB SATA 7200 ; 0x ODD

Power Supply

750W 90% custom PSU

Other

N/A

Energy Consumption

(Watts)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

65.959

69.321

68.635

Windows Busy Typ(S0)

450.015

389.69

443.795

Windows Busy Max (S0)

463.23

456.95

503.125

Sleep (S3)

6.336

6.102

6.971

6.189

6.266

6.264

Off (S5)

1.047

1.036

1.254

1.222

1.014

0.995

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 23

Zero Power Mode (ErP)

0.203

0.399

0.191

Heat Dissipation

(Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Enabled

LAN Disabled

LAN Enabled

Windows Idle (S0)

225.052

236.523

234.183

Windows Busy Typ(S0)

1535.451

1329.622

1514.229

Windows Busy Max (S0)

1580.541

1559.113

1716.663

Sleep (S3)

21.618

20.821

23.785

21.117

21.379

21.372

Off (S5)

3.572

3.534

4.278

4.169

3.459

3.394

Zero Power Mode (ErP)

0.692

1.361

0.652

NOTE: Power consumption measurements do not take advantage of the Intel Turbo Boost Technology. As a result, power consumption
measurements may be higher.

Declared Noise Emissions (Entry-level and High-end configurations)

System Configuration
(Entry level)

Processor Info

Intel® Xeon® W-2125 4.0 2666 4C CPU

Memory Info

32GB (4x8GB) DDR4-2666 ECC Reg RAM

Graphics Info

1-NVIDIA® Quadro® P400 2GB

Disks/Optical

1-500GB SATA 7200RPM 3.5” HDD / 1-HP 9.5mm Slim Blu Ray Disc Writer

Power Supply

465 W

Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)

Sound Power

(LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

3.2

13

Hard drive Operating
(random reads)

3.4

15

System Configuration
(High end)

Processor Info

Intel® Xeon® W-2155 3.3 2666 10C

Memory Info

128GB (8x16GB) DDR4-2666 ECC Reg RAM

Graphics Info

1-NVIDIA® Quadro® P6000 24GB

Disks/Optical

2-4TB SATA 7200RPM Ent 3.5” / 1-HP 9.5mm Slim Blu Ray Disc Writer

Power Supply

750 W

Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)

Sound Power

(LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

3.5

22

Hard drive Operating
(random reads)

3.7

23

NOTE: Higher noise levels may be experienced with non-HP approved graphic card(s). Some consumer graphics cards have side blowing
fans that may heat up thermal sensor(s) on the mother board causing fans to ramp.

DECLARED NOISE EMISSIONS

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 24

Environmental
Requirements

Temperature

Operating: 5° to 35° C (40° to 95° F)
Non-operating: -40° to 60° C (-40° to 140° F)

Humidity

Operating: 10% to 85% RH, non-condensing, 35° C maximum wet bulb
Non-operating: 10% to 90% RH, non-condensing, 35° C maximum wet bulb

Maximum Altitude

Operating: 3,048 m (10,000 feet)

Above 1524 m (5,000 feet) altitude, the maximum operating temperature is
reduced by 1° C (1.8° F) for every 305 m (1,000 feet) increase in elevation

Non-operating: 9,144 m (30,000 feet)

Shock (non-repetitive)

Operating: ½-sine: 40g, 2-3ms (~62 cm/sec)
Non-operating: ½-sine: 160 cm/s, 2-3ms (~105g)
square: 422 cm/s, 20g

Vibration
Operating random: 0.5g (rms), 5-300 Hz, up to 0.0025g²/Hz
Non-operating random: 2.0g (rms), 5-500 Hz, up to 0.0150 g²/Hz

Physical Security and Serviceability

Access Panel

Tool-less
Includes system board and memory information.

Hard Drives

Tool-less

Expansion Cards

Tool-less

Processor Socket

Tool-less

Blue User Touch Points

Yes, on primary serviceable components.

Color-coordinated Cables
and Connectors

Yes

Memory

Tool-less

System Board

Screw-In

Dual Color Power/Failure
LED

Yes

HDD Activity LED

Yes

Note: HDD Activity LED is not dual-color

Configuration Record SW

Yes

Over-Temp Warning on
Screen

Yes, at POST screen on reboot

Restore CD/DVD Set

Restores the computer to its original factory shipping image; can be obtained via HP Support.

Dual Function Front
Power Switch

Yes, causes a fail-safe power off when held for 4 seconds

Padlock Support

Yes (optional): Locks side cover and secures chassis from theft

7.0 mm (0.2756 in) diameter padlock loop at rear of system

Cable Lock Support

Yes, Kensington Cable Lock (optional): Locks side cover and secures chassis from theft
3 mm x 7 mm slot at rear of system

ENVIRONMENTAL DATA

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 25

Universal Chassis Clamp
Lock Support

Yes (optional): Locks side cover and locks cables to chassis. Secures chassis from theft and allows
multiple units to be chained together when used with optional cable
Threaded feature at rear of system

Solenoid Lock and Hood
Sensor

Yes (optional)
The Solenoid Hood Lock eliminates the need for a physical key by making the chassis lockable through
software and a password. You can also lock and unlock the chassis remotely over the network. The
Sensor Kit detects when the access panel has been removed

Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control

Yes, enables or disables serial, USB, audio, and network ports

Removable Media
Write/Boot Control

Yes, prevents ability to boot from removable media on supported devices (and can disable writes to
media)

Power-On Password

Yes, prevents an unauthorized person from booting up the workstation

Setup Password

Yes, prevents an unauthorized person from changing the workstation configuration

3.3V Aux Power LED on
System PCA

Yes

NIC LEDs (integrated)
(Green & Amber)

Yes

CPUs and Heatsinks

A T-15 Torx or flat blade screwdriver is needed to remove the CPU heatsink before the CPU can be
removed. CPU removal is tool-less

Power Supply Diagnostic
LED

Yes

Front Power Button

Yes, ACPI multi-function

Rear Power Button

Yes

Front Power LED

Yes, white (normal), red (fault)

Front Hard Drive Activity
LED

Yes, white

Front ODD Activity LED

Yes, on device

Internal Speaker

Yes

System/Emergency ROM
Flash Recovery

Recovers corrupted system BIOS.

Cooling Solutions

Air cooled forced convection heatsinks

Power Supply Fans

80 mm x 80 mm x 25 mm (non-serviceable)

CPU Heatsink Fan

92 mm x 92 mm x 25 mm, 5-wire, PWM

Chassis Fan

Front:
(Optional) 92 mm x 92mm x 25 mm, 4-wire, PWM

Rear:
120 mm x 120mm x 25 mm, 4-wire, PWM

Memory Heatsink Fan

Dual 60 mm x 60 mm x 25 mm, 6-wire, PWM, Blindmate (optional based on configuration)

HP PC Hardware
Diagnostics UEFI

HP PC Hardware Diagnostics (UEFI) enables hardware level testing outside the operating system on
many components. The diagnostics can be invoked by pressing ESC then F2 upon the PC reboot, and is
available as a download from HP Support.

Access Panel Key Lock

Yes, side panel barrel keylock (optional from the factory only)

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 26

ACPI-Ready Hardware

Advanced Configuration and Power Management Interface (ACPI).

 Allows the system to wake from a low-power mode.
 Controls system power consumption, making it possible to place individual cards and

peripherals in a low-power or powered-off state without affecting other elements of the
system

Trusted Platform Module
Chip

Infineon TPM 2.0 Certified

Integrated Chassis
Handles

Yes, Front handle and dedicated rear recess

Power Supply

Requires T15 Torx or flat blade screwdriver

PCIe Card Retention

Yes, rear (all), middle (all), front (full-length cards with extender, using HP Z4 G4 Fan and Front Card
Guide Kit)

Flash ROM

Yes

Diagnostic Power Switch
LED on board

Yes

Clear Password Jumper

Yes

Clear CMOS Button

Yes

CMOS Battery Holder

Yes

DIMM Connectors

Yes

BIOS 32-bit Services

Standard BIOS 32-bit Service Directory Proposal v0.4

PCI 3.0 Support

Full BIOS support for PCI Express through industry standard interfaces.

ATAPI

ATAPI Removable Media Device BIOS Specification Version 1.0.

BBS

BIOS Boot Specification v1.01.

WMI Support

WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is
fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM)
and WBEM specifications.

BIOS Boot Spec 1.01+

Provides more control over how and from what devices the workstation will boot.

BIOS Power On

Users can define a specific date and time for the system to power on.

ROM Based Computer
Setup Utility (F10)

Review and customize system configuration settings controlled by the BIOS.

System/Emergency ROM
Flash Recovery with
Video

Recovers system BIOS in corrupted Flash ROM.

Replicated Setup

Saves BIOS settings to USB flash device in human readable file (HpSetup.txt). BiosConfigUtility.exe
utility can then replicate these settings on machines being deployed without entering Computer
Configuration Utility (F10 Setup).

SMBIOS

System Management BIOS 2.8, for system management information.

Boot Control

Disables the ability to boot from removable media on supported devices.

Memory Change Alert

Alerts management console if memory is removed or changed.

Thermal Alert

Monitors the temperature state within the chassis. Three modes:

• NORMAL - normal temperature ranges.

• ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid

shutdown or provide for a smoother system shutdown.

• SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer
without warning before hardware component damage occurs.

Remote ROM Flash

Provides secure, fail-safe ROM image management from a central network console.

BIOS

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 27

ACPI (Advanced
Configuration and Power
Management Interface)

Allows the system to enter and resume from low power modes (sleep states).
Enables an operating system to control system power consumption based on the dynamic workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off state without
affecting other elements of the system.
Supports ACPI 5.0 for full compatibility with 64-bit operating systems.

Ownership Tag

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.

Remote Wakeup/Remote
Shutdown

System administrators can power on, restart, and power off a client computer from a remote location.

Instantly Available PC
(Suspend to RAM - ACPI
sleep state S3)

Allows for very low power consumption with quick resume time.

Remote System
Installation via F12 (PXE

2.1) (Remote Boot from
Server)

Allows a new or existing system to boot over the network and download software, including the
operating system.

ROM revision levels

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is
available through an industry standard interface (SMBIOS and WMI) so that management SW
applications can use and report this information.

System board revision
level

Allows management SW to read revision level of the system board.
Revision level is digitally encoded into the HW and cannot be modified.

Start-up Diagnostics
(Power-on Self-Test)

Assesses system health at boot time with selectable levels of testing.

Auto Setup when new
hardware installed

System automatically detects addition of new hardware.

Keyboard-less Operation

The system can be booted without a keyboard.

Localized ROM Setup

Common BIOS image supports System Configuration Utility (F10 Setup) menus in 14 languages with
local keyboard mappings.

Asset Tag

The user or MIS to set a unique tag string in non-volatile memory.

Per-slot Control

Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.

Adaptive Cooling

Control parameters are set according to detected hardware configuration for optimal acoustics.

Pre-boot Diagnostics

(Pre-video) critical errors are reported via beeps and blinks on the power LED.

Industry Standard
Specification Support

Industry Standard

Revision Supported by the BIOS

UEFI Specification
Revision

2.5

ACPI

Advanced Configuration and Power Management Interface, Version 5.0

ATA (IDE)

AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b

CD Boot

"El Torito" Bootable CD-ROM Format Specification Version 1.0

EDD

- Enhanced Disk Drive Specification Version 1.1

- BIOS Enhanced Disk Drive Specification Version 3.0

EHCI

Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0

PCI

PCI Local Bus Specification, Revision 2.3
PCI Power Management Specification, Revision 1.1
PCI Firmware Specification, Revision 3.0, Draft .7

PCI Express

PCI Express Base Specification, Revision 2.0
PCI Express Base Specification, Revision 3.0

PMM

POST Memory Manager Specification, Version 1.01

SATA

Serial ATA Specification, Revision 1.0a
Serial ATA 3 Gb/s: Serial ATA Specification, Revision 2.5
Serial ATA 6 Gb/s: Serial ATA Specification, Revision 3.0

SPD

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 28

TPM

Trusted Platform Module (TPM) 2.0 (Infineon SLB 9670)
Common Criteria EAL4+ Certified
Convertible to FIPS 140-2 Certified mode through firmware v7.80
TCG TPM Certified products list:

http://www.trustedcomputinggroup.org/certification/tpm-certified-products/

UHCI

Universal Host Controller Interface Design Guide, Revision 1.1

USB

Universal Serial Bus Revision 1.1 Specification
Universal Serial Bus Revision 2.0 Specification
Universal Serial Bus Revision 3.1 G1 Specification
Universal Serial Bus Revision 3.1 G2 Specification

SMBIOS

System Management BIOS Reference Specification, Version 2.8

External BIOS simulator found at: http://h20464.www2.hp.com/index.html

Eco-Label Certifications &
Declarations

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

 ENERGY STAR® (energy-saving features available on selected configurations-Windows only)
 US Federal Energy Management Program (FEMP)
 China Energy Conservation Program
 The ECO declaration (TED)

The Z4 G4 is registered EPEAT® Gold in the US and Canada. EPEAT® registration varies by country. See

http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party

option store for solar generator accessories at http://www.hp.com/go/options

Batteries

The battery in this product complies with EU Directive 2006/66/EC
Battery mass: 3g
Battery type: Lithium Metal

The battery in this product does not contain:

 Mercury greater than 5ppm by weight
 Cadmium greater than 10ppm by weight
 Lead greater than 40ppm by weight

Restricted Material Usage

This product meets the material restrictions specified in HP's General Specification for the Environment.

HP Inc. is committed to compliance with all applicable environmental laws and regulations, including
the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed
compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis

.

Low Halogen Statement

This product is low-halogen except for power cords, external cables and peripherals. Service parts
obtained after purchase may not be low-halogen.

End-of-Life Management
and Recycling

HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a responsible manner. This
product is greater than 90% recyclable by weight when properly disposed of at end of life.

Social and Environmental Responsibility

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 29

HP Inc. Corporate
Environmental
Information

For more information about HP's commitment to the environment:

Sustainability Report
Eco-label certifications ISO 14001 certificates

Additional Information

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

(WEEE) Directive – 2002/96/EC. Product Disassembly Instructions

 Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and

ISO1043.

Packaging

HP Workstation product packaging meets the HP's General Specification for the Environment

 Does not contain restricted substances listed in HP Standard 011-1 General Specification for

the Environment

 Does not contain ozone-depleting substances (ODS)
 Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of

100 ppm sum total for all heavy metals listed

 Maximizes the use of post-consumer recycled content materials in packaging materials
 All packaging material is recyclable
 All packaging material is designed for ease of disassembly
 Reduced size and weight of packages to improve transportation fuel efficiency
 Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards

formatting

Packaging Materials

Internal

Cushions and plastic bags made of low density polyethylene (LDPE).

External

Outer carton, accessories carton, and insert made of corrugated paper board.

Manageability

Industry Standard
Specifications

This product meets the following industry standard specifications for manageability functionality:

 DASH 1.1 (via Intel® LAN on motherboard)

Intel Active Management
Technology (AMT)

Intel® Active Management Technology (AMT) 11.10

An advanced set of remote management features and functionality providing IT administrators the
latest and most effective tools to remotely discover, heal, and protect networked client systems
regardless of the system's health or power state. AMT 11.10 includes the following advanced
management functions:

 Power Management (on, off, reset, graceful shutdown, sleep and hibernate)

o Support in Max Power Savings (Shutdown and Hibernate Modes)

 Hardware Inventory (includes BIOS and firmware revisions)
 Hardware Alerting
 Agent Presence
 System Defense Filters
 Serial Over LAN (SOL)


USB Redirect (Media Redirection)

 ME Wake-on-LAN (WOL)

, even with Maximum Power Savings Enabled

 DASH 1.1 compliance
 IPv6 Support
 Fast Call for Help - a client inside or outside the firewall may initiate a call for help via BIOS

screen, periodic connections, or alert triggered connection

 Remote Scheduled Maintenance - pre-schedule when the system connects to the IT or service

provider console for maintenance.

 Remote Alerts - automatically alert IT or service provider if issues arise

QuickSpecs

HP Z4 G4 Workstation

System Technical Specifications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 30

 Access Monitor - Provides oversight into Intel® AMT actions to support security requirements
 PC Alarm Clock
 Microsoft NAP Support
 Host Base set-up and configuration
 Management Engine (ME) firmware roll back
 Local Time Sync to UTC
 Remote Memory Dump Command – Creates memory dump for debug

Intel® vPro™ Technology

The HP Z4 G4 Workstation supports Intel® vPro™ technology when configured as outlined below:

 Intel® Xeon® processor W-2100 product family featuring Intel® vPro™ Technology
 Intel® C422 chipset


Intel® I219LM GbE LAN

Remote Manageability
Software Solutions

The HP Z4 G4 Workstation is supported on the following optional remote manageability software
consoles:

 LANDesk Management Suite (HP recommended solution)
 Microsoft System Center Configuration Manager

For questions or support for manageability needs, please visit http://www.hp.com/go/easydeploy

System Software
Manager

For questions or support for SSM, please visit: http://www.hp.com/go/ssm

Service, Support, and
Warranty

On-site Warranty and Service (Note 1): Three-years, limited warranty and service offering delivers on­site, next business-day (Note 2) service for parts and labor and includes free telephone support (Note 3)
8am - 5pm. Global coverage (Note 2) ensures that any product purchased in one country and
transferred to another, non-restricted country will remain fully covered under the original warranty and
service offering. 24/7 operation will not void the HP warranty.

NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized

HP third-party provider, and is not available in certain countries. Global service response times are
based on commercially reasonable best effort and may vary by country.
NOTE 3: Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party
hardware and software. Toll-free calling and 24x7 support service may not be available in some
countries.
HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from
date of hardware purchase. To choose the right level of service for your HP product, use the HP Care
Pack Services Lookup Tool at: http://www.hp.com/go/lookuptool. Additional HP Care Pack Services
information by product is available at: http://www.hp.com/hps/carepack. Service levels and response
times for HP Care Packs may vary depending on your geographic location.

Product Change
Notification

 Program to proactively communicate Product Change Notifications (PCNs) and Customer

Advisories by email to customers, based on a user-defined profile.

 PCNs provide advance notification of hardware and software changes to be implemented in the

factory providing time to plan for transition.

 Customer Advisories provide concise, effective problem resolution, greatly reducing the need

to call technical support.

QuickSpecs

HP Z4 G4 Workstation

Stable & Consistent Offerings

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 31

As part of its commitment to hardware, software, and solution innovation, HP is proud to introduce
this breakthrough platform configuration stability to HP Workstation customers. HP Stable &
Consistent Offerings are built on the foundation of a carefully chosen set of hardware designed and
tested to work with all HP Z Workstation platforms through their end of life. These components and
their corresponding HP Workstation platform compatibility are outlined in this section.

HP Stable & Consistent Offerings are available worldwide to all HP Workstation customers-no
special programs, no additional cost-no kidding. Simply select your hardware components when you
customize your HP Workstation and be assured that you'll be able to buy that same configuration
throughout the lifecycle of the product.

Processors

Product #

Offering

TBD

Intel® Xeon® W-2125 4.0 2666 4C CPU

TBD

Intel® Xeon® W-2123 3.6 2666 4C CPU

TBD

Intel® Xeon® W-2102 2.9 2400 4C CPU

Hard Drives
Product #

Offering

LQ037AA

1TB SATA 7200 RPM

Graphics
Product #

Offering

2TF08AA

AMD Radeon™ Pro WX 3100 4GB Graphics

Memory

Product #

Offering

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

TBD

Optical and Removable
Storage

Product #

Offering

TBD

TBD

TBD

TBD

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Processors

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 32

Intel® Xeon® W-2195 2.3 2666 18C CPU

Intel® Xeon® W-2155 3.3 2666 10C CPU

Intel® Xeon® W-2145 3.7 2666 8C CPU

Intel® Xeon® W-2135 3.7 2666 6C CPU

Intel® Xeon® W-2133 3.6 2666 6C CPU

Intel® Xeon® W-2125 4.0 2666 4C CPU

Intel® Xeon® W-2123 3.6 2666 4C CPU

Intel® Xeon® W-2104 3.2 2400 4C CPU

Intel® Xeon® W-2102 2.9 2400 4C CPU

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 33

HP SAS (Serial Attached
SCSI) Hard Drives for HP
Workstations

HP 300GB SAS 15K SFF
HDD

Capacity

300GB

Height

5.9 in; 15 cm

Width

Media Diameter

3.5 in; 8.9 cm

Interface

12Gb/s SAS

Synchronous Transfer
Rate (Maximum)

Up to 1200 MB/s (SAS single port)

Buffer

128MB

Seek Time (typical reads,
includes controller
overhead, including
settling)

Average

2.0ms

Rotational Speed

15K rpm

Operating Temperature

41° to 131° F (5° to 55° C)

STORAGE/HARD DRIVES

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 34

SATA (Serial ATA) Hard
Drives for HP
Workstations

500GB SATA 7200 rpm
6Gb/s 3.5" HDD

Capacity

500GB

Height

1 in; 2.54 cm

Width
Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Buffer

16MB

Seek Time (typical reads,

includes controller
overhead, including
settling)

Single Track

2 ms

Average

11 ms

Full Stroke

21 ms

Rotational Speed

7,200 rpm

Logical Blocks

976,773,168

Operating Temperature

41° to 131° F (5° to 55° C)

1TB SATA 7200 rpm
6Gb/s 3.5" HDD

Capacity

1TB

Height

1 in; 2.54 cm

Width
Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer
Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Cache

Adaptive

Seek Time (typical reads,
includes controller
overhead, including
settling)

Single Track

2 ms

Average

11 ms

Full Stroke

21 ms

Rotational Speed

7,200 rpm

Operating Temperature

41° to 131° F (5° to 55° C)

2.0TB SATA 7200 rpm
6Gb/s 3.5" HDD

Capacity

2.0TB

Height

1 in; 2.54 cm

Width

Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0 Gb/s), NCQ Enabled

Synchronous Transfer
Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Seek Time (typical reads,
includes controller
overhead, including
settling)

Single Track

1.0 ms

Average

11 ms

Full Stroke

18 ms

Rotational Speed

7,200 rpm

Logical Blocks

3,907,029,168

Operating Temperature

41° to 131° F (5° to 55° C)

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 35

1TB SATA 7200 rpm
6Gb/s 3.5" HDD
(Enterprise Class)

Capacity

1TB

Protocol

SATA

Form Factor

3.5"

Controller

AHCI

Reliability (MTBF)

2.0M hours

Rated Power On Hours

8760/yr

Annualized Failure Rate

(based on Rated POH)

<0.62%

Rated for 24/7/365
operation

YES
Physical Size (Height)

1 in; 2.54 cm

Physical Size (Width)

4 in; 10.17 cm

Media Diameter

3.5 in; 8.9 cm

Interface

Serial ATA (6Gb/s), NCQ enabled

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Buffer

128MB

Seek Time (typical reads,
includes controller
overhead, including
settling)

Single Track

0.32ms

Average

7.45ms

Full Stroke

14.2ms
Operating Temperature

41° to 140° F (5° to 60° C)

Performance
Sequential Read

up to 226MB/s

Sequential Write

up to 226MB/s

Enterprise Class Features

High Reliability

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 36

4TB SATA 7200 rpm
6Gb/s 3.5" HDD
(Enterprise Class)

Capacity

4TB

Height

0.275 in; 0.7 cm

Width

Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s), NCQ enabled

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s
Buffer

128MB

Seek Time (typical reads,
includes controller
overhead, including
settling)

Single Track

0.7ms

Average

8.5ms

Full Stroke

15.7ms
Rotational Speed

7,200 rpm

Operating Temperature

32° to 140° F (0° to 60° C)

500GB SATA 7.2K SED
SFF HDD

Capacity

500GB

Height

0.275 in; 0.7 cm

Width

Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s)

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s
Buffer

32MB

Seek Time (typical reads,
includes controller
overhead, including
settling)

Single Track

1ms

Average

4.2ms

Full Stroke

25ms (typical)
Rotational Speed

7,200 rpm

Operating Temperature

32° to 140° F (0° to 60° C)

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 37

SATA SSDs for HP
Workstations

HP 256GB SATA 6Gb/s
SSD

Capacity

256GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

192TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530MB/s (max)

Sequential Write

500MB/s (max)

Random Read

55K IOPS (max)

Random Write

83K IOPS (max)

HP 256GB SATA 6Gb/s
SED Opal 2 SSD

Capacity

256GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

192TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer
Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530MB/s

Sequential Write

500 MB/s

Random Read

55K IOPS

Random Write

83K IOPS

Self-Encrypting Drive
Support

OPAL 2

HP 512GB SATA 6Gb/s
SSD

Capacity

512GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

388TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 38

Physical Size (Width)

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer
Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530 MB/s

Sequential Write

500 MB/s

Random Read

95K IOPS

Random Write

83K IOPS

HP 512GB SATA SED SSD

Capacity

512GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

388TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530 MB/s

Sequential Write

500 MB/s

Random Read

95K IOPS

Random Write

83K IOPS

Self-Encrypting Drive
Support

OPAL 1 and 2

HP 1TB SATA 6Gb/s SSD

Capacity

1TB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

400TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer
Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530 MB/s

Sequential Write

500 MB/s

Random Read

95K IOPS

Random Write

83K IOPS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 39

HP 2TB SATA 6Gb/s SSD

Capacity

2TB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

400TBW (TB Written)

Reliability (MTTF)

1.5M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer
Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

530 MB/s

Sequential Write

500 MB/s

Random Read

95K IOPS

Random Write

83K IOPS

HP Enterprise Class
240GB SATA SSD

Capacity

240GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

2,200TBW (TB Written)

Reliability (MTTF)

2.0M hours

Physical Size (Height)

0.28 in; 0.7 cm

Physical Size (Width)

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

540 MB/s

Sequential Write

310 MB/s

Random Read

93K IOPS

Random Write

48K IOPS

Enterprise Class Features

High Endurance NAND
Power Loss Protection
End-to-End Data Protection

HP Enterprise Class
480GB SATA SSD

Capacity

480GB

Protocol

SATA

Form Factor

2.5"

Controller

AHCI

NAND Type

3D TLC

Endurance

4,400TBW (TB Written)

Reliability (MTTF)

2.0M hours

Physical Size (Height)

0.28 in; 0.7 cm

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 40

Physical Size (Width)

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer
Rate (Maximum)

Up to 600MB/s

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

540 MB/s

Sequential Write

460 MB/s

Random Read

93K IOPS

Random Write

74K IOPS

Enterprise Class Features

High Endurance NAND
Power Loss Protection
End-to-End Data Protection

PCIe SSDs for HP
Workstations

HP Z Turbo Drive G2
256GB SSD

Capacity

256GB

Protocol

PCIe

Form Factor

M.2

Controller

NVMe

NAND Type

MLC

Endurance

150TB

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1100 MB/s

Random Read

250K IOPS

Random Write

180K IOPS

HP Z Turbo Drive G2
512GB SSD

Capacity

512GB

Protocol

PCIe

Form Factor

M.2

Controller

NVMe

NAND Type

3D MLC

Endurance

300TB

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1600 MB/s

Random Read

260K IOPS

Random Write

260K IOPS

HP Z Turbo Drive G2 1TB
SSD

Capacity

1TB

Protocol

PCIe

Form Factor

M.2

Controller

NVMe

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 41

NAND Type

3D MLC

Endurance

600TB

Reliability (MTTF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

3000 MB/s

Sequential Write

1700 MB/s

Random Read

360K IOPS

Random Write

330K IOPS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 42

HP Z Turbo Drive Quad
Pro 2x256GB PCIe SSD

Capacity

512GB

Protocol

PCIe

Form Factor

PCIe Card, Full Height PCIe Slot

Controller

NVMe

NAND Type

MLC

Endurance

150TB

Reliability (MTBF)

1.5M hours

Interface

PCIe Gen3 x4 architecture

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1100 MB/s

Random Read

250K IOPS

Random Write

180K IOPS

HP Z Turbo Drive Quad
Pro 2x512GB PCIe SSD

Capacity

1TB

Protocol

PCIe

Form Factor

PCIe Card, Full Height PCIe Slot

Controller

NVMe

NAND Type

MLC

Endurance

292TB

Reliability (MTBF)

1.5M hours

Interface

PCIe Gen3 x4 architecture

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1600 MB/s

Random Read

250 K IOPS

Random Write

180K IOPS

HP Z Turbo Drive G2
256GB SED SSD

Capacity

256GB

Protocol

PCIe

Form Factor

Half-height, half-length

Controller

NVMe

NAND Type

MLC

Endurance

150TBW (TB Written)

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1100 MB/s

Random Read

250K IOPS

Random Write

180K IOPS

Self-Encrypting Drive
Support

OPAL 2

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 43

HP Z Turbo Drive G2
512GB SED SSD

Capacity

512GB

Protocol

PCIe

Form Factor

Half-height, half-length

Controller

NVMe

NAND Type

3D MLC

Endurance

300TBW (TB Written)

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

1600 MB/s

Random Read

260K IOPS

Random Write

150K IOPS

Self-Encrypting Drive
Support

OPAL 2

HP Z Turbo Drive Quad Pro
2x1TB PCIe SSD

Capacity

2TB

Protocol

PCIe

Form Factor

PCIe Card, Full Height PCIe Slot

Controller

NVMe

NAND Type

3D MLC

Endurance

600TB

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

3000 MB/s

Sequential Write

1700 MB/s

Random Read

360K IOPS

Random Write

330K IOPS

HP Z Turbo Drive G2
256GB TLC SSD

Capacity

256GB

Protocol

PCIe

Form Factor

M.2

Controller

NVMe

NAND Type

3D TLC

Endurance

75TBW (TB Written)

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

320 MB/s (1100 MB/s
max/Turbo)

Random Read

250K IOPS

Random Write

180K IOPS

HP Z Turbo Drive G2
512GB TLC SSD

Capacity

512GB

Protocol

PCIe

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drives

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 44

Form Factor

M.2

Controller

NVMe

NAND Type

3D TLC

Endurance

150TBW (TB Written)

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

2800 MB/s

Sequential Write

660 MB/s (1600 MB/s
max/Turbo)

Random Read

260K IOPS

Random Write

260K IOPS

HP Z Turbo Drive G2 1TB
TLC SSD

Capacity

1TB

Protocol

PCIe

Form Factor

M.2

Controller

NVMe

NAND Type

3D TLC

Endurance

300TBW (TB Written)

Reliability (MTBF)

1.5M hours

Interface

PCI Express 3.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

Performance

Sequential Read

3000 MB/s

Sequential Write

1150 MB/s (1700 MB/s
max/Turbo)

Random Read

360K IOPS

Random Write

330K IOPS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Hard Drive Controllers

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 45

MicroSemi 2100-4i4e 8­port SAS 12Gb/s RAID
Card

PCI Bus

8 lanes, PCI Express 3.0

RAID Levels

Offers Integrated RAID (0, 1, and 10)

PCI Data Burst Transfer
Rate

Half Duplex x8, PCIe, 8000 MB/s
SAS Bandwidth

Half Duplex

1200 MB/s per lane

PCI Card Type

3.3V Add-in Card

PCI Voltage

12 V ± 10%

PCI Power

9.8W typical, Airflow min 200 LFM

Bracket

Full height and low profile

Certification Level

PCI Express 3.0 compliant

SAS Processor

MicroSemi Series 8 SAS Controller

Internal Connectors

One x4 internal mini-SASHD (SFF-8643)

External Connectors

One x4 external mini-SASHD (SFF-8644)

Maximum Number of SCSI
Devices

256 Non-RAID SAS/SATA devices
LED Indicators

Connector for Drive Activity Light

HARD DRIVE CONTROLLERS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 46

NVIDIA® Quadro® P400 1st
GFX 2GB Graphics

Form Factor

Dimensions: 2.713” H x 5.7” L
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams

Graphics Controller

NVIDIA® Quadro® P400 Graphics Card
GP107-825 GPU
256 NVIDIA® CUDA® cores
Max Power: 30 Watts

Bus Type

PCI Express 3.0 x16

Memory

Size: 2 GB GDDR5, 2000 MHz
Memory Interface: 64-bit
Memory Bandwidth: 32 GB/s

Connectors

3mDP Outputs

Maximum Resolution

DisplayPort™ 1.4:

- up to 3x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)

Image Quality Features

10-bit internal display processing pipeline
10-bit scan-out support

Display Output

3 mDP Connectors

Shading Architecture

Full Microsoft DirectX® 12 Shader Model 5.1

Supported Graphics APIs

OpenGL® 4.5
DirectX® 12
Vulkan™ 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute, OpenCL™

Available Graphics
Drivers

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 7
Linux®

HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html

Notes

NVIDIA® Quadro® P600 1st
GFX 2GB Graphics

Form Factor

Dimensions: 2.713” H x 5.7” L
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams

Graphics Controller

NVIDIA® Quadro® P600 Graphics Card
GP107-850 GPU
384 NVIDIA® CUDA® cores
Max Power: 40 Watts

Bus Type

PCI Express 3.0 x16

GRAPHICS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 47

Memory

Size: 2 GB GDDR5, 2000 MHz
Memory Interface: 128-bit
Memory Bandwidth: 64 GB/s

Connectors

4mDP Outputs

Maximum Resolution

DisplayPort™ 1.4:

- up to 4x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)

Image Quality Features

10-bit internal display processing pipeline
10-bit scan-out support

Display Output

4 mDP Connectors

Shading Architecture

Full Microsoft DirectX® 12 Shader Model 5.1

Supported Graphics APIs

OpenGL® 4.5
DirectX® 12
Vulkan™ 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute , OpenCL

Available Graphics
Drivers

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 7
Linux®

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

AMD FirePro™ W2100

2GB Graphics

Form Factor

Low Profile, half length (full-height bracket included)

Graphics Controller

AMD FirePro™ W2100 professional graphics based on Oland GPU.
GPU: 320 Stream Processors organized into 5 Compute Units
GPU Frequency: 630Mhz
Power: 26W
Cooling: Active

Bus Type

PCI Express® x8, Generation 3.0

Memory

2GB DDR3 memory
Memory Bandwidth: up to 28.8 GB/s
Memory Width: 128 bit

Connectors

2x Display Port™ 1.2 connectors

Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are
available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort™ 1.2:

- up to 4096x2160 x 24 bpp @ 60Hz

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 48

Dual Link DVI(I) (requires adapter cable):

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I)(requires adapter cable):

- up to 1920 x 1200 x 32 bpp @ 60Hz

VGA (requires adapter cable):

- up to 1920 x 1200 x 32 bpp @ 60Hz

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component.
High bandwidth scaler for high quality up and downscaling.

Display Output

2 x DisplayPort™ 1.2a
Maximum number of displays: 2

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenCL™ 1.2, DirectX® 11.2/12, OpenGL® 4.4

OpenGL® 4.4 support with driver release 14.301.xxx
OpenCL™ 1.2 conformance expected with drive release 14.301.xxx

Available Graphics
Drivers

Windows10 (64-bit and 32-bit)
Windows 8.1 (64-bit and 32-bit)
Windows 7 (64-bit and 32-bit)
Linux®

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

Depending on the card model, native DisplayPort™ connectors and/or
certified DisplayPort™ active or passive adapters to convert your monitor’s
native input to your card’s DisplayPort™ or Mini-DisplayPort™ connector(s)
may be required. See www.amd.com/FirePro™ for details.

NVIDIA® Quadro® P1000
1st GFX 4GB Graphics

Form Factor

Dimensions:2.713” H x 5.7” L
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams

Graphics Controller

NVIDIA® Quadro® P1000 Graphics Card
GP107-860 GPU
640 NVIDIA® CUDA® cores
Max Power: 47 Watts

Bus Type

PCI Express 3.0 x16

Memory

Size: 4 GB GDDR5, 2500 MHz
Memory Interface: 128-bit memory interface
Memory Bandwidth: 80 GB/s memory bandwidth

Connectors

4mDP Outputs

Maximum Resolution

DisplayPort™ 1.4:

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 49

- up to 4x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)

Image Quality Features

10-bit internal display processing pipeline
10-bit scan-out support

Display Output

4 mDP Connectors

Shading Architecture

Full Microsoft DirectX® 12 Shader Model 5.1

Supported Graphics APIs

OpenGL® 4.5
DirectX® 12
Vulkan™ 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute, OpenCL™

Available Graphics
Drivers

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 7
Linux®

HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html

Notes

NVIDIA® Quadro® P2000
1st GFX 5GB Graphics

Form Factor

Dimensions: 4.4”Hx7.9”L

Single Slot
Cooling: Active
Weight: 260 grams

Graphics Controller

NVIDIA® Quadro® P2000 Graphics Card
Power: 75 Watts

Bus Type

PCI Express 3.0 x16

Memory

Size: 5GB GDDR5
Memory Bandwidth: 140 GB/s
Memory Width: 160-bit

Connectors

4x DisplayPort™ 1.4

Factory Configured Option: No adapter included with card
After Market Option: No video cable adapter included

Additional DVI to VGA, DisplayPort™ to VGA, DisplayPort™ to DVI, and
DisplayPort™ to Dual-Link DVI adapters available as accessories.

Maximum Resolution

DisplayPort™:

- up to 5120 x 2880 x 24 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST) DP 1.3
& 1.4 ready.

DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60 Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

HDMI 2.0 (requires DP to HDMI adapter):
5120 x 2880 x 24 bpp @ 60Hz

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 50

Image Quality Features

12-bit internal display pipeline (hardware support for 12-bit scanout on
supported panels, applications and connection)

Stereoscopic 3D display support including NVIDIA® 3D Vision™ technology,
NVIDIA® Mosaic and nView.

Display Output

Maximum number of displays

- 4 direct attached monitors

Maximum number of monitors across all available NVIDIA® Quadro® P2000
outputs is 4.

Shading Architecture

Shader Model 5.1

Supported Graphics APIs

OpenGL® 4.5
DirectX® 12

API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL™, Java, Python, and Fortran
software

Available Graphics
Drivers

Microsoft Windows 10
Microsoft Windows 7 Professional 64bit
Linux® - Full OpenGL® implementation, complete with NVIDIA® Quadro® and
ARB extensions

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

Radeon™ Pro WX 3100

4GB Graphics

Form Factor

Low-Profile Single Slot (6.6” Length )

Graphics Controller

Polaris12 GL
GPU: 512 Stream Processors organized into 8 Compute Units
Power: 50 Watts
Cooling: Active

Memory

4GB GDDR5 memory
Memory Bandwidth: 6 Gbps / 96 GB/s
Memory Width: 128 bit

Connectors

2x Mini DisplayPort™ 1.4 plus 1x DisplayPort™ 1.4 – HDR ready connectors
with HBR3 and MST support.

Factory Configured: No adapters included
After market option kit: One mDP-to-DP cable adapters included

Additional Mini DisplayPort™-to-DisplayPort™, DisplayPort™-to-VGA or
DisplayPort™-to-DVI adapters are available as Factory Configuration or
Option Kit accessories.

Maximum Resolution

5K support @ 60Hz

 1x single-cable 5K monitor, or 2x dual-cable 5K monitors

3x 4K support @ 60Hz

Image Quality Features

Advanced support for 8-bit and 10-bit per RGB color component. High
bandwidth scaler for high quality up and downscaling

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 51

Display Output

3 full physical DP1.3 HBR3 / DP1.4 HDR outputs
FreeSync support
GPU Architecture

Polaris

Supported Graphics APIs

DirectX®12
OpenGL® 4.5

OpenCL™ 2.0
Vulkan™ 1.0

Available Graphics
Drivers

Windows 10 64-bit
(Windows® 7 64-bit available from AMD)
Linux® 64-bit (selected Enterprise distributions)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. HDR content requires that the system be configured with a

fully HDR-ready content chain, including: graphics card,
monitor/TV, graphics driver and application. Video content
must be graded in HDR and viewed with an HDR-ready player.
Windowed mode content requires operating system support.

2. AMD PowerTune and AMD ZeroCore Power are technologies

offered by certain FirePro™ and Radeon™ Pro products, which

are designed to intelligently manage GPU power consumption
in response to certain GPU load conditions.

3. As of September 2016, certified for DisplayPort™ 1.4 HBR3

and ready for DisplayPort™ 1.4 HDR based on independent
verification by DisplayPort™ testing authority. HDR content

requires that the system be configured with a fully HDR­ready content chain, including: graphics card, monitor/TV,
graphics driver and application. Video content must be graded
in HDR and viewed with an HDR-ready player. Windowed
mode content requires operating system support.

Radeon™ Pro WX 4100

4GB Graphics

Form Factor

Low-Profile Single Slot (6.6” Length)

Graphics Controller

Polaris 11 Baffin GL XT
GPU: 1024 Stream Processors organized into 16 Compute Units
Power: 50 Watts
Cooling: Active

Memory

4GB GDDR5 memory
Memory Bandwidth: 6 Gbps / 96 GB/s
Memory Width: 128 bit

Connectors

4x Mini DisplayPort™ 1.4 – HDR ready connectors with HBR3 and MST
support.

Factory Configured: Four mDP-to-DP cable adapters included
After market option kit: Four mDP-to-DP cable adapters included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are
available as Factory Configuration or Option Kit accessories.

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 52

Maximum Resolution

5K support @ 60Hz

 1x single-cable 5K monitor, or 2x dual-cable 5K monitors

4x 4K support @ 60Hz

Image Quality Features

Advanced support for 8-bit and 10-bit per RGB color component. High
bandwidth scaler for high quality up and downscaling

Display Output

4 full physical DP1.3 HBR3 / DP1.4 HDR outputs
FreeSync support
GPU Architecture

GCN 4th Generation

Supported Graphics APIs

DirectX®12
OpenGL® 4.5

OpenCL™ 2.0
Vulkan™ 1.0

Available Graphics
Drivers

Windows 10 64-bit
Windows® 7 64-bit
Linux® 64-bit (selected Enterprise distributions)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

4. HDR content requires that the system be configured with a

fully HDR-ready content chain, including: graphics card,
monitor/TV, graphics driver and application. Video content
must be graded in HDR and viewed with an HDR-ready player.
Windowed mode content requires operating system support.

5. AMD PowerTune and AMD ZeroCore Power are technologies

offered by certain FirePro™ and Radeon™ Pro products, which

are designed to intelligently manage GPU power consumption
in response to certain GPU load conditions.

6. As of September 2016, certified for DisplayPort™ 1.4 HBR3

and ready for DisplayPort™ 1.4 HDR based on independent
verification by DisplayPort™ testing authority. HDR content

requires that the system be configured with a fully HDR­ready content chain, including: graphics card, monitor/TV,
graphics driver and application. Video content must be graded
in HDR and viewed with an HDR-ready player. Windows mode
content requires operating system support.

NVIDIA® Quadro® P4000
1st GFX 8GB Graphics

Form Factor

Dimensions: 4.4”H x 9.5”L
Single-slot, full-height
Weight: 475 grams (without extender)

Graphics Controller

NVIDIA® Quadro® P4000 Graphics Card
GPU: GP104 with 1792 CUDA cores
Power: 120 Watts

Bus Type

PCI Express 3.0 x16

Memory

Size: 8GB GDDR5
Memory Bandwidth: 243 GB/s
Memory Width: 256-bit

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 53

Connectors

4 x DisplayPort 1.4
3-pin mini-DIN connector via optional bracket
1 x 6-pin auxiliary power connector
4-pin header for stereo signal
SYNC connector for Quadro® Sync II
2 x SLI connectors

Factory Configured Option: No video cable adapter included
After Market Option: No video cable adapter included

Additional DisplayPort-to-VGA, DisplayPort-to-HDMI, or DisplayPort-to­DVI adapters are available as accessories

Maximum Resolution

Dual-link internal TMDS (DVI 1.0):

- up to 2560 x 1600 x 32 bpp @ 60 Hz

Single-link internal TMDS (DVI 1.0):

- up to 1920 x 1200 x 32 bpp @ 60 Hz

HDMI™ 2.0b (requires DP to HDMI adapter):

- up to 5120 x 2880 x 24 bpp @ 60Hz

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- up to 2560 x 1600 x 30 bpp @ 120 Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

Using two DP outputs, the P4000 can drive one dual DP input display with
5120 x 2880 x 30 bpp @ 60Hz resolution.

Image Quality Features

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color
component.
HDCP 2.2 support over DisplayPort, DVI, and HDMI connectors
NVIDIA 3D Vision™ and other 3D stereo technologies
NVIDIA Mosaic and nView

Display Output

Maximum number of displays

- 4 direct attached monitors

Maximum number of monitors across all available Quadro P4000 outputs
is 4.

Shading Architecture

Shader Model 5.1

Supported Graphics APIs

OpenGL 4.5
DirectX 12
Vulcan 1.0

API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics
Drivers

Microsoft Windows 10
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB
extensions

HP qualified drivers may be preloaded or available from the HP support
Web site:

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 54

http://welcome.hp.com/country/us/en/support.html

Notes

1. Quadro P4000 offered as Factory Configured Option does not

include a video cable adapter. Video cable adapters must be
ordered separately.

2. Quadro P4000 offered as an After Market Option does not include

video cables. Video cable adapters must be ordered separately.

NVIDIA® Quadro® P5000

1

st

GFX 16GB Graphics

Form Factor

Full-Height Dual Slot (4.4” Height x 10.5” Length)
Weight: 815 grams / 1.80 lbs

Graphics Controller

NVIDIA® Quadro® P5000 graphics
GPU: 2560 NVIDIA® CUDA® Parallel Processing Cores
Power: 180 Watts
Cooling: Active

Memory

16GB GDDR5X memory
Memory Bandwidth: Up to 288 GB/s
Memory Width: 256 bit
ECC Memory (disabled by default)

Connectors

DP (x4) with HDR support
DL-DVI(D)
3-pin mini-DIN connector
SLI connector
NVIDIA® Quadro® Sync connector (compatible with NVIDIA® Quadro® II
Sync)
One 8-pin auxiliary power connector

Factory configured option: No video cable adapter included with card.
After market option Kit: No video cable adaptor included with card.

DVI to VGA, DisplayPort™ to VGA, DisplayPort™ to DVI, and DisplayPort™ to
Dual-Link DVI adapters available as accessories.

Maximum Resolution

5K support @ 60Hz
1x single-cable 5K monitor, or 2x dual-cable 5K monitors

Image Quality Features

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color
component.

HDCP 2.2 support over DisplayPort™, DVI, and HDMI
connectors
NVIDIA® 3D Vision™ and other 3D stereo technologies
NVIDIA Mosaic and nView Desktop Management

Display Outputs1

4x DP1.4 HDR outputs (up to 3840x2160 UHD @ 120Hz refresh, or up to 8K
at 30Hz)
1x Dual-link DVI-D output (up to 2560 x 1600 @ 60 Hz and 1920x1200 @
120 Hz)

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 55

GPU Architecture

NVIDIA Pascal™

Supported Graphics APIs

DirectX®12 , OpenGL® 4.5, OpenCL™ 1.0, Vulkan™ 1.0
Developer API support includes: CUDA C, CUDA C++, DirectCompute 5.0,

OpenCL™, Java, Python, and Fortran

Available Graphics
Drivers

Windows 10 64-bit
Windows® 7 64-bit
Linux® 64-bit

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1- Supports up to a total of 4 displays

NVIDIA® Quadro®
P6000 1

st

GFX 24GB

Graphics

Form Factor

Full-Height Dual Slot (4.4” Height x 10.5” Length)
Weight: 967 grams / 2.14 lbs

Graphics Controller

NVIDIA® Quadro® P6000 graphics
GPU: 3840 NVIDIA® CUDA® Parallel Processing Cores
Power: 250 Watts
Cooling: Active

Memory

24GB GDDR5X memory
Memory Bandwidth: Up to 432 GB/s
Memory Width: 384 bit
ECC Memory (disabled by default)

Connectors

DP (x4) with HDR support
DL-DVI(I)
3-pin mini-DIN connector
SLI connector
Quadro Sync connector (compatible with Quadro II Sync)
One 8-pin auxiliary power connector

Factory configured option: No video cable adapter included with card.
After market option Kit: No video cable adaptor included with card.

DVI to VGA, DisplayPort™ to VGA, DisplayPort™ to DVI, and DisplayPort™
to Dual-Link DVI adapters available as accessories.

Maximum Resolution

5K support @ 60Hz
1x single-cable 5K monitor, or 2x dual-cable 5K monitors

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 56

Image Quality Features

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color
component.
HDCP 2.2 support over DisplayPort, DVI, and HDMI connectors
NVIDIA 3D Vision™ and other 3D stereo technologies
NVIDIA Mosaic and nView

Display Outputs1

4x DP1.4 HDR outputs (up to 3840x2160 UHD @ 120Hz refresh, or up to 8K
at 30Hz)
1x Dual-link DVI-D output (up to 2560 x 1600 @ 60 Hz and 1920x1200 @
120 Hz)

GPU Architecture

NVIDIA Pascal™

Supported Graphics APIs

DirectX®12, OpenGL® 4.5, OpenCL™ 1.0, Vulkan™ 1.0
Developer API support includes: CUDA C, CUDA C++, DirectCompute 5.0,

OpenCL™, Java, Python, and Fortran

Available Graphics
Drivers

Windows® 10 64-bit
Windows® 7 64-bit

Linux® 64-bit

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1- Supports up to a total of 4 displays

Radeon™ Pro WX 7100 1

st

GFX 8GB Graphics

Form Factor

Full-Height Single Slot (9.5” Length )

Graphics Controller

Radeon™ Pro WX 7100 graphics
GPU: 2304 Stream Processors organized into 36 Compute Units
Power: 130 Watts
Cooling: Active

Memory

8GB GDDR5 memory
Memory Bandwidth: 7 Gbps / 224 GB/s
Memory Width: 256 bit

Connectors

4x Display Port 1.4 – HDR ready connectors with HBR3 and MST support.

Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are
available as Factory Configuration or Option Kit accessories.

Maximum Resolution

5K support @ 60Hz

 1x single-cable 5K monitor, or 2x dual-cable 5K monitors

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color
component. High bandwidth scaler for high quality up and
downscaling

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 57

Display Output

4 full physical DP1.3 HBR3 / DP1.4 HDR outputs
FreeSync support
GPU Architecture

GCN 4th Generation

Supported Graphics APIs

DirectX®12
OpenGL® 4.5

OpenCL™ 2.0
Vulkan™ 1.0

Available Graphics
Drivers

Windows 10 64-bit
Windows® 7 64-bit
Linux® 64-bit

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

7. HDR content requires that the system be configured with a

fully HDR-ready content chain, including: graphics card,
monitor/TV, graphics driver and application. Video content
must be graded in HDR and viewed with an HDR-ready
player. Windowed mode content requires operating system
support.

8. Radeon VR Ready Creator Products are select Radeon Pro and

AMD FirePro™ GPUs that meet or exceed the Oculus Rift or

HTC Vive recommended specifications for video cards/GPUs.
Other hardware (including CPU) and system requirements
recommended by Oculus Rift or HTC Vive should also be met
in order to operate the applicable HMDs as intended. As VR
technology, HMDs and other VR hardware and software
evolve and/or become available, these criteria may change
without notice.

9. AMD PowerTune and AMD ZeroCore Power are technologies

offered by certain FirePro™ and Radeon™ Pro products, which

are designed to intelligently manage GPU power consumption
in response to certain GPU load conditions.

10. As of September 2016, certified for DisplayPort™ 1.4 HBR3

and ready for DisplayPort™ 1.4 HDR based on independent
verification by DisplayPort™ testing authority. HDR content

requires that the system be configured with a fully HDR-ready
content chain, including: graphics card, monitor/TV, graphics
driver and application. Video content must be graded in HDR
and viewed with an HDR-ready player. Windowed mode
content requires operating system support.

NVIDIA® Quadro® Sync II

Part number

1WT20AA

Dimensions (HxD)

6.0 inches × 4.2 inches

Devices Supported

NVIDIA® Quadro® P4000
NVIDIA® Quadro® P5000
NVIDIA® Quadro® P6000

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Graphics

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 58

Bus Type

Requires one free mechanical PCIe bus slot. 6-pin PCI or SATA power
connector

PCI Form Factor

Full Height, half length, single slot

Ports

2 RJ45 connectors for carrying frame lock signals over CAT5 cables.
BNC Connector for external house synchronization.

Internal Connectors

6 NVIDIA SLI® style edge fingers for connection to compatible GPUs

 Included with the board are 4 12-Inch Short Sync Cables to connect

to GPU's

 Included with the board are 2 24-Inch Long Sync Cables to connect

to GPU's

System Requirements

Requires one free mechanical PCIe bus slot. 6-pin PCI or SATA power
connector
Must be used with NVIDIA Quadro P4000, P5000 or P6000 graphics cards.
Requires Quadro driver version R375 or later.

Temperature ­Operating

0° to 55° C

Temperature - Storage

-40° to 60° C

Relative Humidity ­Operating

10% to 80%

Power Requirements

Board power dissipation: <15W

Operating Systems
Supported

Windows 10 64-bit
Windows 7 64-bit
Linux 64-bit

Kit Contents

Contains:

 Quadro Sync II Card
 4 x 12-Inch Short Sync Cables
 2 x 24-Inch Long Sync Cables (Two)
 Quick Start Guide

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications – Optical and Removable Storage

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 59

HP 9.5mm Slim DVD
Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

Full Stroke DVD

< 200 ms (seek)

Full Stroke CD

< 200 ms (seek)

Maximum Data Transfer
Rates

CD ROM Read

CD-ROM, CD-R Up to 24X
CD-RW Up to 24X

DVD ROM Read

DVD+RW Up to 8X
DVD-RW Up to 8X
DVD+R DL Up to 8X
DVD-R DL Up to 8X
DVD-ROM Up to 8X
DVD-ROM DL Up to 8X
DVD+R Up to 8X
DVD-R Up to 8X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -< 800 mA typical, <1600 mA
maximum

Operating Environmental
(all conditions non­condensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems
Supported

Windows 10, Windows 7 Professional 32-bit and 64-bit,
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista
Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP
Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11

* No driver is required for this device. Native support is provided by the
operating system.

Kit Contents

HP SATA DVD Writer drive, installation guide.

Description

9.5mm height, tray-load

OPTICAL AND REMOVABLE STORAGE

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications – Optical and Removable Storage

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 60

HP 9.5mm Slim DVD-ROM
Drive

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA / ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Disc Capacity

DVD-ROM

Single layer: Up to 4.7 GB
Double layer: Up to 8.5 GB

Access Times

DVD-ROM Single Layer

< 110 ms (typical)

CD-ROM Mode 1

< 110 ms (typical)

Full Stroke DVD

< 230 ms (typical)

Full Stroke CD

< 220 ms (typical)

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC – <800mA typical, < 1600 mA
maximum

Operating Environmental
(all conditions non­condensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems
Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit
and 64-bit,
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista
Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP
Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the
operating system.

Kit Contents

9.5mm Slim DVD-ROM Drive, 5.25" ODD Bay adapter/carrier, slim SATA
data/power cable, installation guide

HP 9.5mm Slim BDXL Blu­Ray Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

BD-ROM
BD-R
BD-RE
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications – Optical and Removable Storage

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 61

Blu-ray

25 GB (single-layer)
50 GB (dual-layer)
100/128 GB (BDXL)

Full Stroke DVD

< 230 ms (seek)

Full Stroke CD

< 220 ms (seek)

Blu-ray

< 230 ms (seek) (Full Stroke Blu-ray)

Startup Time

(Time to drive ready from tray
loading)
BD-ROM (SL/DL) 25S / 28S
BD-R (SL/DL) 25S / 28S
BD-RE (SL/DL) 25S / 28S
DVD-ROM (SL/DL) 18S / 18S
DVD-R (SL/DL) 25S / 25S
DVD-RW 25S
DVD+R (SL/DL) 25S / 25S
DVD+RW 25S
CD-ROM 15S

Maximum Data Transfer
Rates

CD ROM Read

CD-ROM, CD-R Up to 24X
CD-RW Up to 24X

DVD ROM Read

DVD+RW Up to 8X
DVD-RW Up to 8X
DVD+R DL Up to 8X
DVD-R DL Up to 8X
DVD-ROM Up to 8X
DVD-ROM DL Up to 8X
DVD+R Up to 8X
DVD-R Up to 8X

Blu-ray

BD-ROM Up to 6X
BD-ROM DL Up to 6X
BD-R Up to 6X
BD-R DL Up to 6X
BD-R Up to 6X
BD-RE SL/DL Up to 6X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -900 mA typical, 2000mA
maximum

Operating Environmental
(all conditions non­condensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems
Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit
and 64-bit,
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista
Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP
Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the
operating system.

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications – Optical and Removable Storage

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 62

Kit Contents

9.5mm Slim BDXL Blu-Ray Writer, 5.25" ODD Bay adapter/carrier, slim
SATA data/power cable, installation guide

As Blu-ray is a new format containing new technologies, certain disc,
digital connection, compatibility and/or performance issues may arise, and
do not constitute defects in the product. Flawless playback on all systems
is not guaranteed. In order for some Blu-ray titles to play, they may
require a DVI or HDMI digital connection and your display may require
HDCP support. HD-DVD movies cannot be played on this workstation.

HP SD Card Reader

Description

Supports hardware ECC (Error Correction Code) function
Supports hardware CRC (Cyclic Redundancy Check) function
Supports SD 4-bit parallel transfer mode

Interface Type

USB 3.0 High-speed interface

Dimensions (WxHxD)

1.15 x .9 x .15 in (29.00 x 23.6 x 3.15 mm) Fits conveniently in the Front IO
Bay

Supported Media Types

Secure Digital Card (SD)
Secure Digital High Capacity (SDHC)
SD Extended Capacity Memory Card (SDXC)
SD Ultra High Speed II(SD UHSII)

These additional media types are supported with a card adapter.
Memory Stick Micro (M2)
miniSD
miniSD High Capacity
Micro SD Memory Card (MicroSD)
Micro SD High Capacity Memory Card (MicroSDHC)

Test Parameters/Conditions - Power applied, unit operating on system
±5%

Operating Systems
Supported

Windows 10

No driver is required for this device. Native support is provided by the
operating system.
Kit Contents

Media card reader

Approvals

USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport
Specification Rev. 1.0,
Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.3, FCC, CE,
BSMI, C-Tick, VCCI, MIC, cUL, TUVT
Weight

0.35 lbs. (0.16 kg)

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Networking and Communications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 63

Integrated Intel I219LM
PCIe GbE Controller

Connector

RJ-45

Controller

Intel I219LM GbE platform LAN connect networking controller

Data Rates Supported

10/100/1000 Mbps

Boot ROM Support

PXE, UEFI

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Amber = 100Mbps
 Green = 1000Mbps

Management Capabilities

Intel ® Active Management Technology™ 11

Integrated Intel I210

Connector

RJ-45

Controller

Intel® I210

Data Rates Supported

10/100/1000 Mbps

Boot ROM Support

PXE, UEFI

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Amber = 100Mbps
 Green = 1000Mbps

Management Capabilities

Wake-On-LAN

Intel® I210-T1

Networking Interface

RJ-45

System Interface

PCI Express 2.1 x1

Networking Speeds
Supported

10Mbps, 100Mbps, 1Gbps

Cabling (up to 100m)

Cat3 (or higher) for 10Mbps
Cat5 (or higher) for 100Mbps
Cat5e (or higher) for 1Gbps

Power Consumption
(active-typical)

0.81W

Physical Dimensions

Length: 6.7cm (2.64 inches)
(Bracket) Width: 1.8cm (0.709 inches)
Full-height end bracket: 12.07cm (4.755 inches)
Low-profile end bracket: 8cm (3.15 inches)

NETWORKING AND COMMUNICATIONS

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Networking and Communications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 64

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Green = 100Mbps
 Amber = 1Gbps

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

Hardware Certifications

USA: FCC B,
EU: UL CE,
Japan: VCCI,
Taiwan: BSMI,
Australia/New Zealand: CTICK,
Korea: KCC,
Canada: ICES-003/NMB-003

Intel® I350-T2

Networking Interface

2 x RJ-45

System Interface

PCI Express 2.1 x4

Networking Speeds
Supported

10Mbps, 100Mbps, 1Gbps

Cabling (up to 100m)

Cat3 (or higher) for 10Mbps
Cat5 (or higher) for 100Mbps
Cat5e (or higher) for 1Gbps

Power Consumption
(active-typical)

4.4W

Physical Dimensions

Length: 13.54cm (5.33 inches)
Width: 6.89 (2.71 inches)
Full-height end bracket: 12.0cm (4.725 inches)
Low-profile end bracket: 7.92cm (3.117 inches)

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Green = 100Mbps
 Amber = 1Gbps

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

Hardware Certifications

USA: FCC B,
EU: UL CE,
Japan: VCCI,
Taiwan: BSMI,
Australia/New Zealand: CTICK,
Korea: KCC,
Canada: ICES-003/NMB-003

Intel® I350-T4
Networking Interface

4 x RJ-45

System Interface

PCI Express 2.1 x4

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Networking and Communications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 65

Networking Speeds
Supported

10Mbps, 100Mbps, 1Gbps

Cabling (up to 100m)

Cat3 (or higher) for 10Mbps
Cat5 (or higher) for 100Mbps
Cat5e (or higher) for 1Gbps

Power Consumption
(active-typical)

5W

Physical Dimensions

Length: 13.54cm (5.33 inches)
Width: 6.89 (2.71 inches)
Full-height end bracket: 12.0cm (4.725 inches)
Low-profile end bracket: 7.92cm (3.117 inches)

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Green = 100Mbps
 Amber = 1Gbps

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

Hardware Certifications

USA: FCC B,
EU: UL CE,
Japan: VCCI,
Taiwan: BSMI,
Australia/New Zealand: CTICK,
Korea: KCC,
Canada: ICES-003/NMB-003

Intel® X550-T2

Networking Interface

2 x RJ-45

System Interface

PCI Express 3 x4

Networking Speeds
Supported

100Mbps, 1Gbps, 2.5Gbps, 5Gbps, 10Gbps

Cabling (up to 100m)

Cat5 (or higher) for 100Mbps
Cat5e (or higher) for 1Gbps, 2.5Gbps, or 5Gbps
Cat6a (or higher) for 10Gbps

Power Consumption
(active-typical)

3.9W at 100Mbps

5.5W at 1Gbps

11.2W at 10Gbps

Physical Dimensions

5.2 in x 2.7 in (without bracket)

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = No link
 Amber = <10Gbps
 Green = 10Gbps

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Networking and Communications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 66

Hardware Certifications

USA: FCC B,
EU: UL CE,
Japan: VCCI,
Taiwan: BSMI,
Australia/New Zealand: CTICK,
Korea: KCC,
Canada: ICES-003/NMB-003

Intel® X710-DA2

Networking Interface

2 SFP+ Ports for LC SFP+ Transceivers

10GBASE-SR Converged
Network Adapter

System Interface

PCI Express 3.0 x8

Networking Speeds
Supported

1Gbps, 10Gbps

Cabling

LC fiber optic cabling with LC SFP+ Transceivers

Power Consumption
(active-typical)

4.3W

Physical Dimensions

6.578 in x 2.703 in

Connect Speed LED
Indicators

Link/Activity LED

 Off = No link
 Blinking = Activity

Speed LED

 Off = 10Mbps
 Green = 100Mbps
 Amber = 1Gbps

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

Hardware Certifications

USA: FCC B,
EU: UL CE,
Japan: VCCI,
Taiwan: BSMI,
Australia/New Zealand: CTICK,
Korea: KCC,
Canada: ICES-003/NMB-003

10GbE SFP+ SR
Transceiver

Connector Type

LC

Cable Type

62.5/125um or 50/125um (core/cladding), graded-index, low metal
content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC
793-2 Type A1b or A1a, respectively.

Cable Length

2-300m

Wavelength

850nm

Form Factor

SFP+

Physical Dimensions

0.47(h) x 0.54(w) x 2.19(d) inches
(1.19 x 1.38 x 5.57 cm)

Operating Temperature

0C to 45C (32F to 113F)

Operating Humidity

0% to 85%, noncondensing

QuickSpecs

HP Z4 G4 Workstation

Technical Specifications - Networking and Communications

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 67

Intel® 8265 WLAN

Networking Speeds

802.11ac MU-MIMO (up to 867 Mbps)
Bluetooth 4.2

IEEE WLAN Standard

IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w;

802.11r, 802.11k, 802.11v pending

Bluetooth

4.2

System Interface

PCI Express 2.1 x1

Antenna

2x2

QuickSpecs

HP Z4 G4 Workstation

Summary of Changes

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 68

Date of change:

Version History:

Description of change:

November 1, 2017

From v1 to v2

Added

HP DisplayPort to HDMI Adapter, NVIDIA SLI 2-slot Graphics Connector and
NVIDIA Quadro Sync II to Graphics section

Changed

Graphics, Storage / Hard Drives and Memory sections, changed Front and
internal view info on the Overview section, changed Operating Systems
section, changed System Board section, changed System Configuration,
DECLARED NOISE EMISSIONS and Physical Security and Serviceability
sections

November 29, 2017

From v2 to v3

Added

Processors, hard drives and graphics to offerings, added Intel Xeon W-2195
to Processors section

Changed

Wattage links on power supply section updated and Voltage links on
efficientcy section updated

SUMMARY OF CHANGES

QuickSpecs

HP Z4 G4 Workstation

c05527757 — DA - 15954 Worldwide — Version 3 —November 29, 2017

Page 69

© 2017 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties
for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein. Intel, Xeon, and Thunderbolt are trademarks of Intel Corporation in the U.S. and other countries.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. Red Hat is a registered trademark of Red Hat, Inc.
in the United States and other countries. Firewire is a trademark of Apple Inc. Linux® is the registered trademark of Linus Torvalds
in the U.S. and other countries. ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency. USB Type-C™
and USB-C™ are trademarks of USB Implementers Forum. AMD and Radeon are trademarks of Advanced Micro Devices, Inc.
Bluetooth is a trademark of its proprietor and used by HP Inc. under license. NVIDIA, Cuda, Pascal, and Quadro are trademarks
and/or registered trademarks of NVIDIA Corporation in the U.S> and other countries. DisplayPort™ and the DisplayPort™ logo are
trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries.
