Hewlett Packard 5ZU98AA Getting Started Guide

Datasheet
HP 24x Gaming Display
A faster way to see the action. Display your gaming skills. A fast, vibrant display with gaming essentials.
The HP 24x Display has all the essentials for faster action. Enjoy smooth, stutter-free visuals that respond as fast as you do - thanks to a 144Hz refresh rate and AMD® FreeSync™ technology. At 60.45 cm (23.8"), this Full HD screen with built-in speakers brings your entertainment up a notch.
The speed you needThe speed you need
Smooth, sharp visualsSmooth, sharp visuals
Experience the difference of fluid, stutter­free gameplay on this crystal clear FHD (1920 x 1080) display with AMD® FreeSync™ technology.
More comfortable immersionMore comfortable immersion
Micro-edge bezel design delivers a more immersive viewing experience and integrated speakers provides high-quality sound. Height, tilt, swivel, and pivot adjustments allow for optimal comfort while gaming.
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
FreeSync™ is only available when it is connected on DisplayPort or HDMI port. FreeSync is an AMD® technology enabled on FHD or QHD displays and is designed to eliminate stuttering and/or tearing in games and videos by locking a display’s refresh rate to the frame rate of the graphics card. Monitor, AMD® Radeon™ Graphics and/or AMD® A-Series APU compliant with DisplayPort™ Adaptive-Sync required. AMD® Catalyst™ 15.2 Beta (or newer) required. Adaptive refresh rates vary by display.
Full high-definition (FHD) content required to view FHD images.
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
1 2 3
1
3
2
1 2
3 4
Datasheet
HP 24x Gaming Display
FeaturingFeaturing
1ms response time with Overdrive1ms response time with Overdrive How fast your pixels can react to changing frames is critical for fast-paced gaming, and a 1ms response time ensures even the most action-packed moments are fluid, crisp, and free of motion blur.
Height adjustment standHeight adjustment stand Gas piston design allows 130mm of smooth, precise height adjustment so your display is always in the most comfortable position, no matter who is viewing it.
Micro-edge displayMicro-edge display With virtually no bezel encircling the display, an ultra-wide viewing experience provides for seamless multi-monitor set-ups.
Integrated speakersIntegrated speakers No need to buy external speakers for great audio. With integrated speakers this display is ready to go once you’re connected.
Included headphone jackIncluded headphone jack Conveniently located within reach, the headphone jack lets you easily plug in your headphones for a more lifelike experience.
TN panelTN panel Enjoy the latest action movie or high-octane video game with the low pixel latency and snappy response times of this TN panel.
144Hz refresh rate144Hz refresh rate Get smooth gaming, sharper objects, and cleaner details with a gaming display that refreshes frames 144 times a second – over twice the refresh rate of standard displays.
AMD FreeSync technologyAMD FreeSync™ technology See and feel the difference of fluid, responsive gameplay. By synchronizing the refresh rate with your GPU, AMD FreeSync™ makes display stutter, input lag, and screen tears ancient history.
Low blue lightLow blue light Using the Low blue light mode subtly shifts your display’s colors to a warmer spectrum, while making whites more natural and putting less strain on your eyes.
4
2
Datasheet
HP 24x Gaming Display
Display sizeDisplay size
60.45 cm (23.8")
Aspect ratioAspect ratio
16:9
Pixel pitchPixel pitch
0.274 mm
Response timeResponse time
1 ms (with overdrive)
BrightnessBrightness
250 cd/m²
Contrast ratioContrast ratio
1000:1 static; 12000000:1 dynamic
Viewing angleViewing angle
160° vertical; 170° horizontal
Recommended resolutionRecommended resolution
FHD (1920 x 1080 @ 60 Hz)
Resolution (maximum)Resolution (maximum)
FHD (1920 x 1080 @ 144 Hz)
Resolutions supportedResolutions supported
1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1440 x 900; 1600 x 900; 1680 x 1050; 1920 x 1080; 640 x 480; 720 x 400; 800 x 600
Display scan frequency (horizontal)Display scan frequency (horizontal)
Up to 167 kHz
Display scan frequency (vertical)Display scan frequency (vertical)
Up to 144 Hz
Display featuresDisplay features
Anti-glare; Language selection; LED backlights; On-screen controls; Plug and Play; AMD FreeSync™; Height adjustable; Low blue light mode; Dual speakers (2W per channel)
Display Input TypeDisplay Input Type
1 DisplayPort™ 1.2 in (with HDCP support); 1 HDMI 1.4 (with HDCP support)
Physical security featuresPhysical security features
Security lock-ready
Display moving angleDisplay moving angle
Tilt: –3.5 to +21.5°
Display User Control OptionsDisplay User Control Options
Audio control; Brightness; Color control; Image control; Information; Language; Management; Menu; Power
External I/O portsExternal I/O ports
1 audio
Product dimensionsProduct dimensions
53.08 x 21.8 x 37.99 cm Without stand.
54.08 x 21.8 x 48.99 cm With stand Packed: 65 x 20 x 39 cm
WeightWeight
6.1 kg
Operating temperature rangeOperating temperature range
5 to 35°C
Operating temperature rangeOperating temperature range
41 to 95°F
Operating humidity rangeOperating humidity range
20 to 80% RH
Certifications and compliancesCertifications and compliances
Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CEL; C-Tick; cTUVus; EAC; E-standby; EUP Lot-6; FCC; ICES; ISO 9241-307; KC; KCC; PSB; TUV Bauart; VCCI; Vietnam MEPS; WEEE; ISC; Low blue light; UkrSEPRO; South Africa MEPS; Ukraine Energy label
Power supplyPower supply
Input voltage 100 to 240 VAC
WarrantyWarranty
1 year parts and labour limited warranty.
What's in the boxWhat's in the box
AC power cord; HDMI cable; Warranty card; Monitor
VESA mountVESA mount
100 mm with included bracket
Product numberProduct number
5ZU98AA
Ordering infoOrdering info
5ZU98AA#ABB: 193424944088; 5ZU98AA#A2N: 193424944163; 5ZU98AA#ABU: 193424944095; 5ZU98AA#ABV: 193424944149; 5ZU98AA#ABY: 193424944118; 5ZU98AA#ACQ: 193424944132; 5ZU98AA#UUG: 193424944156; 5ZU98AA#UUZ: 193424944101
All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
Lock is sold separately.
© Copyright 2019 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. All other trademarks are the property of their respective owners.
August 2019
