QuickSpecs
HP EliteBook 755 G5
Overview
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 1
HP EliteBook 755 G5
Left
1.
Power connector
5.
HDMI port (Cable not included)
2.
USB Type-C™
6.
USB 3.1 Gen 1 port
3.
Docking connector
7.
Audio combo jack
4.
Ethernet port
8.
SIM card slot
QuickSpecs
HP EliteBook 755 G5
Overview
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 2
Right
1.
Internal microphones
7.
Indicator LEDs (Power, Wireless , and Storage usage light)
2.
Webcam
8.
Smartcard Reader (Select models)
3.
Internal microphones
9.
USB 3.1 Gen 1 charging port
4.
Speaker grill
10.
Vent
5.
Click button
11.
Security lock slot (Lock sold separately)
6.
Clickpad
12.
Power button
QuickSpecs
HP EliteBook 755 G5
Overview
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 3
AT A GLANCE
• Eye-catching ultraslim design, premium precision-crafted machined aluminum (CNC), seamless formed aluminum
chassis for clean, crisp, premium look and feel
• AMD Ryzen PRO processor
• Designed to support all HP docking options including HP’s traditional Ultraslim mechanical dock and the all-new
Thunderbolt™ dock
• Featuring HP Collaboration Keyboard with Clickpad to manage most commonly used conferencing functions with a single
keystroke
• Innovative world-facing third mic improves inbound ambient noise cancellation while 360 degree mic pick-up allows
everyone to clearly hear and be heard
• Optional ultrabright displays with ambient light sensor
• Enterprise grade security with HP SureStart, HP Privacy Camera, HP Sure View, HP Sure Run, HP Sure Recover, HP
WorkWise, SmartCard Reader and Fingerprint reader
• Choice of displays:
• - 33.7cm (13.3") diagonal FHD UWVA anti-glare LED-backlit, 220 cd/m², 45% sRGB
• - 33.7cm (13.3") diagonal FHD UWVA anti-glare LED-backlit, 400 cd/m², 72% sRGB
• Flexible wireless connectivity options
• Preinstalled with Windows 10 versions or FreeDOS 2.0
• Choice of solid state drives up to 512 GB and DDR4 memory up to 32 GB
• Supports fast charging (50% in 30 minutes) with no impact on battery recharge cycles
1
• Optional HD camera or Infra Red camera with multi-array microphone
• Battery life up to 10.5 hours
• Pending MIL-STD testing
2
1. Recharges your battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a
minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal.
Charging time may vary +/-10% due to System tolerance.
2. MIL STD 810G testing is not intended to demonstrate fitness for Department of Defense contracts requirements or for
military use. Test results are not a guarantee of future performance under these test conditions. Any accidental damage
requires an optional HP Accidental Damage Protection Care Pack.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 4
PRODUCT NAME
HP EliteBook 755 G5
OPERATING SYSTEM
Preinstalled
Windows 10 Pro 641
Windows 10 Pro 64 (National Academic only)
1,2
Windows 10 Home 641
Windows 10 Home Single Language 641
FreeDOS 2.0
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://www.windows.com/
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10
Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
PROCESSORS
AMD Ryzen™ 7 PRO 2700U APU with Radeon™ Vega Graphics
(2.2 GHz base frequency, up to 3.8 GHz burst frequency, 6 MB cache, 4 cores)
3,4,5
AMD Ryzen™ 5 PRO 2500U APU with Radeon™ Vega Graphics
(2 GHz base frequency, up to 3.6 GHz burst frequency, 6 MB cache, 4 cores)
3,4,5
AMD Ryzen™ 3 PRO 2300U APU with Radeon™ Vega Graphics
(2 GHz base frequency, up to 3.4 GHz burst frequency, 6 MB cache, 4 cores)
3,4,5
Processor Family
AMD® Ryzen™ APU processor
5
3. Multi-core is designed to improve performance of certain software products. Not all customers or software applications
will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application
workload and your hardware and software configurations. AMD’s numbering is not a measurement of clock speed.
4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
5. NOTE: In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system
on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7
drivers on http://www.support.hp.com.
CHIPSET
Chipset is integrated with processor
GRAPHICS
Integrated
AMD Radeon™ Vega Graphics
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 5
DISPLAY
Non-Touch
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB with HD camera (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB with HD IR webcam (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB for WWAN (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB with HD camera for WWAN (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 220 cd/m², 45% sRGB with HD IR webcam for WWAN (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 400 cd/m², 72% sRGB with Ambient Light Sensor and HD IR webcam
(1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS anti-glare LED-backlit, 400 cd/m², 72% sRGB with Ambient Light Sensor and HD IR webcam
for WWAN (1920 x 1080)
6,7,8
Touch
39.6 cm (15.6") diagonal FHD IPS LED-backlit touch screen with Corning® Gorilla® Glass 3, 220 cd/m², 45% sRGB with HD IR
webcam (1920 x 1080)
6,7,8
39.6 cm (15.6") diagonal FHD IPS LED-backlit touch screen with Corning® Gorilla® Glass 3, 220 cd/m², 45% sRGB with HD IR
webcam for WWAN (1920 x 1080)
6,7,8
HDMI 2.0
Supports resolution up to 4k @ 60Hz
9
Displays support
Docking station model
Total number of
supported
displays(incl. the
notebook
display)
Max.resolutions
supported
Dock Connectors
Technical limitations
HP UltraSlim Docking
Station
3
Dual 2.5K @ 60Hz
2xDP, 1xVGA
Dual 2.5k only with both
displays into
DP
HP Elite 120W
TB3 Dock
3
Dual 4K @ 60Hz
2xDP, 1xVGA, 1xTB,
1xUSB-C alt-mode
Dual 4k only with one display
in to DP
and + TB port or USB-C alt
mode + TB port
HP Elite USB-C Dock G4
3
Dual 2K @ 60Hz
Single 4K @ 60Hz
(3840 x 1440)
1xHDMI, 2xDP
HP USB-C Universal
Dock
3
Dual 4K @ 60Hz
Single 5K @ 60Hz
2xDP
HP USB-C Travel Dock
2
Single 2K @ 60Hz
1xHDMI, 1xVGA
Single external display
Only HDMI or VGA at the time
HP USB-C Mini Dock
2
Single 4K @ 30Hz
1xHDMI, 1xVGA
Single external display
Only HDMI or VGA at the time
6. HD content required to view HD images.
7. Sold separately or as an optional feature.
8. Resolutions are dependent upon monitor capability, and resolution and color depth settings.
9. HDMI cable sold separately.
STORAGE AND DRIVES
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 6
Primary M.2 Storage
128 GB SATA-3 SS TLC10
256GB PCIe NVMe SS10
256 GB PCIe Gen3x4 NVMe SS TLC10
256 GB SATA-3 SS TLC Opal 210
360 GB PCIe Gen3x4 NVMe SS TLC (Intel)10
512 GB PCIe Gen3x4 NVMe SS TLC10
512 GB PCIe Gen3x4 NVMe SS TLC Opal 210
512 GB SATA-3 SS TLC FIPS-140-210
10. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows
10) is reserved for system recovery software.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 7
MEMORY
Maximum Memory
32 GB DDR4-2400 SDRAM11
Memory
32 GB DDR4-2400 SDRAM (2 X 16 GB)11
16 GB DDR4-2400 SDRAM (1 X 16 GB)11
16 GB DDR4-2400 SDRAM (2 X 8 GB)11
8 GB DDR4-2400 SDRAM (1 x 8 GB)11
8 GB DDR4-2400 SDRAM (2 x 4 GB)11
4 GB DDR4-2133 SDRAM (1 x 4 GB)11
Memory Slots
2 SODIMM
Both slots are upgradeable
System runs at 2400
Supports Dual Channel Memory.
11. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 8
NETWORKING/COMMUNICATIONS
WLAN
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo, non-vPro™12
Realtek RTL8822BE 802.11ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo, non-vPro™12
WWAN
HP lt4132 LTE/HSPA+ 4G Mobile Broadband13
Intel® XMM™ 7360 LTE-Advanced13
NFC
NXP NPC300 Near Field Communication Module
Miracast
Support for Miracast14
Ethernet
Realtek PCIe GbE Family Controller 10/100/100015
12. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ
from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
13. WWAN module is optional and requires separately purchased service contract. Check with service provider for coverage
and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors.
4G LTE not available on all products, in all regions.
14. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming
15. The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet,
and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server
and network infrastructure is required.
AUDIO/MULTIMEDIA
Audio
Audio by Bang & Olufsen
Integrated 3 Multi Array Microphone
2 Integrated Stereo Speakers
Camera
HD camera
6,7
HD IR webcam
6,7
6. HD content required to view HD images.
7. Sold separately or as an optional feature.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 9
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
HP Premium Collaboration Keyboard with Numeric Keypad
Backlit keyboard available as an option
Dual point, spill resistant with drain
Pointing Device
Clickpad with multi-touch gestures enabled, taps enabled as default
Microsoft Precision Touchpad Default Gestures Support
Function Keys
F1 - Display Switching
F2 - Blank or Privacy
F3 - Brightness Down
F4 - Brightness Up
F5 - Audio Mute
F6 - Volume Down
F7 - Volume Up
F8 - Mic Mute
F9 - Blank or Backlit Toggle
F10 - numlk
F11 - Wireless
F12 - Calendar
Share/Present
Call Answer
Call End
Hidden Fuctions
Fn+R = Break
Fn+S = Sys Rq
Fn+C = Scroll Lock
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 10
SOFTWARE AND SECURITY
Preinstalled Software
BIOS
HP BIOSphere Gen417
HP DriveLock & Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase18
Absolute Persistence Module19
Pre-boot Authentication
HP Wireless Wakeup
Software
HP Native Miracast Support16
HP LAN-Wireless Protection
HP Velocity
HP ePrint + JetAdvantage20
HP Hotkey Support - CMIT
HP Recovery Manager
HP Jumpstart
HP Support Assistant21
HP Noise Cancellation Software
HP PhoneWise28
Buy Office
Manageability Features
HP Driver Packs22
HP System Software Manager (SSM)
HP BIOS Config Utility (BCU)
HP Client Catalog
HP Manageability Integration Kit Gen223
Ivanti Management Suite24
HP Collaboration Keyboard
Client Security Software
HP Client Security Suite Gen4 including:25
HP Security Manager26 (including Credential Manager, HP Password Manager, HP Spare Key)
Power On Authentication
HP Fingerprint Sensor30
HP Device Access Manager
HP Power On Authentication
Microsoft Defender
27
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 11
Security Management
HP BIOSphere Gen417
HP DriveLock & Automatic DriveLock
BIOS Update via Network
Secure Erase18
Pre-boot Authentication
TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)
SATA 0,1 port disablement (viaBIOS)
RAID configurations31
Serial, USB enable/disable (viaBIOS)
Power-on password (viaBIOS)
Setup password (viaBIOS)
Support for chassis padlocks and cable lock devices
Integrated hood sensor
HP Sure Click32
HP Sure Start Gen429
Security
TPM
Model:
Version:
Revision:
FIPS 140-2 Compliant:
Smartcard Reader
Model number:TBD
FIPS 201 Compliant: TBD
IPv6 Certification:
Yes / No
MD5 Hash: Please follow the instructions below to access MD5 Hash.
Log-on to http://hp.com/support, enter your product name, select software and drivers, select OS, select driver. After selecting
the driver, click on “Associated files” and then click on “Download”. When opening the file, under “Purpose” you should see
the appropriate “SOFTPAQ MD5:” Field
Graphics (Intel Video Driver): TBD
WWAN: TBD
WLAN: TBD
Is the BIOS on this notebook ISO/IEC 19678:2015 (formerly NIST 800-147) compliant?:
Yes / No
UEFI version:
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 12
16. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming
17. HP BIOSphere Gen4 features may vary depending on the PC platform and configurations. Requires Intel® or AMD 8th
generation processors.
18. Secure Erase for the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
Supported on Elite platforms with BIOS version F.03 or higher.
19. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription.
Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability
outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided
by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers
must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from
Absolute Software.
20. HP ePrint Drive requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of
eligible printers, supported documents and image types and other HP ePrint details, see
http://www.hp.com/go/eprintcenter). Print times and connection speeds may vary.
21. HP Support Assistant requires Windows and Internet access.
22. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.
23. HP Manageability Integration Kit can be downloaded from
http://www8.hp.com/us/en/ads/clientmanagement/overview.html
24. Ivanti Management Suite subscription required.
25. HP Client Security Suite Gen 4 requires Windows and Intel® or AMD 8th generation processors.
26. HP Password Manager requires Internet Explorer or Chrome or FireFox. Some websites and applications may not be
supported. User may need to enable or allow the add-on / extension in the internet browser.
27. Microsoft Defender Opt in and internet connection required for updates.
28. HP PhoneWise Client is only available on select platforms. For supported platforms and HP PhoneWise system
requirements see http://www.hp.com/go/HPPhoneWise.
29. HP Sure Start Gen4 is available on HP Elite products equipped with 8th generation Intel® or AMD processors.
30. HP Fingerprint Sensor sold separately or as an optional feature.
31. RAID configuration is optional and does require a second hard drive.
32. HP Sure Click is available on select HP platforms and supports Microsoft® Internet Explorer and Chromium™. Check
http://h20195.www2.hp.com/v2/GetDocument.aspx?docname=4AA7-0922ENW for all compatible platforms as they become
available.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 13
POWER
Power Supply
HP Smart 45 W External AC power adapter33
HP Smart 45 W External AC power adapter, 2-prong (Japan only)33
HP Smart 65 W External AC power adapter33
HP Smart 65 W EM External AC power adapter33
45 W USB Type-C™ adapter33
65 W USB Type-C™ adapter33
Primary Battery
HP Long Life 3-cell, 50 Wh Li-ion
34,35
Power Cord
2-wire plug - 1.0m (Japan only)33
3-wire plug - 1.0m33
3-wire plug - 1.8m33
Duckhead power cord - 1.0m33
Duckhead power cord - 1.8m33
Battery Life
Up to 10.5 hours35
33. Availability may vary by country.
34. Battery is internal and not replaceable by customer. Serviceable by warranty.
35. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded
applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See www.bapco.com for additional details.
WEIGHTS & DIMENSIONS
Weight
Starting at 4.09 lb (non-touch); Starting at 4.37 lb (touch)36
Starting at 4.09 lb (non-touch); Starting at 4.37 lb (touch)
36
Dimensions (w x d x h)
14.6 x 9.91 x 0.72 in
37.08 x 25.17 x 1.83 cm
36. Weight will vary by configuration.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 14
PORTS/SLOTS
Ports
1 USB Type-C™ (Alt Mode)
1 USB 3.1 Gen 1
1 USB Type-C™ (charging)
1 HDMI 2.037
1 RJ-45 / Ethernet
1 docking connector
1 headphone/microphone combo
1 AC power
37. HDMI cable sold separately.
ENVIRONMENTAL & INDUSTRY
Environmental
Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT Gold registered in the United States. See http://www.epeat.net
for registration status in your country. Search keyword generator on
HP’s 3rd party option store for solar energy accessory at
http://www.hp.com/go/options
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions
data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
8.59 W
8.05 W
8.59 W
Normal Operation
(Long idle)
6.49 W
6.1 W
5.06 W
Sleep
0.8 W
0.83 W
0.8 W
Off
0.43 W
0.44 W
0.43 W
Note: Energy efficiency data listed is for an ENERGY STAR® compliant product if
offered within the model family. HP computers marked with the ENERGY STAR®
Logo are compliant with the applicable U.S. Environmental Protection Agency
(EPA) ENERGY STAR® specifications for computers. If a model family does not offer
ENERGY STAR® compliant configurations, then energy efficiency data listed is for
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 15
a typically configured PC featuring a hard disk drive, a high efficiency power
supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
29
27
29
Normal Operation
(Long idle)
22
20
17
Sleep
2 2 3
Off
1 1 1
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured –
Idle
2.5
15
Fixed Disk – Random
writes
3.7
30
Longevity and Upgrading
"This product can be upgraded, possibly extending its useful life by several
years. Upgradeable features and/or components contained in the product may
include:
Spare parts are available throughout the warranty period and or for up to “5”
years after the end of production.
Batteries
"This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium"
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 16
Additional Information
• "• This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2011/65/EC.
• • This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
• • This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
• • This product is in compliance with the IEEE 1680 (EPEAT) standard at
the Gold level, see www.epeat.net
• • Plastics parts weighing over 25 grams used in the product are marked
per ISO11469 and ISO1043.
• • This product contains 0% post-consumer recycled plastic (by wt.)
• • This product is 94.4% recycle-able when properly disposed of at end of
life."
Packaging Materials
External:
PAPER/Corrugated
345 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
76 g PLASTIC/Polypropylene - PP
4 g PLASTIC/Polyethylene low density
15 g
The plastic packaging material contains at least 50% recycled content.
The corrugated paper packaging materials contains at least 75% recycled
content.
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 17
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product
packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in
packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated
materials.
• Reduce size and weight of packages to improve transportation fuel
efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in
many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities. This
information (product disassembly instructions) is posted on the Hewlett Packard
web site at: http://www.hp.com/go/recyclers. These instructions may be used
by recyclers and other WEEE treatment facilities as well as HP OEM customers
who integrate and re-sell HP equipment.
HP, Inc. Corporate
Environmental
Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hpinformation/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
SERVICE AND SUPPORT
HP Services offers 3-year and 1-year limited warranties and 90 day software limited warranty options depending on
country. Batteries have a default one year limited warranty except for Long Life batteries which will have same 1-year or 3year limited warranty as the platform. On-site service and extended coverage is also available. HP Care Pack Services are
optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for
your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc
38
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 18
38. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your
geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated to
Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and
such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with
your HP Product.
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 19
ENVIRONMENTAL & INDUSTRY
Environmental Data HP EliteBook 755 G5
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® Gold registered in the United States. See http://www.epeat.net for registration status in your
country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short
idle)
8.59 W
8.05 W
8.59 W
Normal Operation (Long
idle)
6.49 W
6.1 W
5.06 W
Sleep
0.8 W
0.83 W
0.8 W
Off
0.43 W
0.44 W
0.43 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable
U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model
family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for
a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft
Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short
idle)
29
27
29
Normal Operation (Long
idle)
22
20
17
Sleep
2 2 3
Off
1 1 1
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 20
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
2.5
15
Fixed Disk – Random
writes
3.7
30
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
• 3 USB ports
• 1 PC card slot (type I/II)
• 1 ExpressCard/54 slot
• 1 IEEE 1394 Port
• 2 SODIMM memory slots
• Optional expansion base docking station
• 1 multi-bay II storage port
• Interchangeable HDD
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard at the <gold> level, see
www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 6.9% post-consumer recycled plastic (by wt.)
• This product is 96.6% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
345 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
76 g
PLASTIC/Polypropylene - PP
4 g
PLASTIC/Polyethylene low density
15 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to
the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 21
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions
may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who
integrate and re-sell HP equipment.ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteBook 755 G5
Features
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 22
HP Inc. Corporate
Environmental
Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 23
SYSTEM UNIT
Stand-Alone Power
Requirements (AC Power)
Nominal Operating
Voltage
19V
Average Operating Power
Win 10
Integrated Graphics
15W
Max Operating Power
UMA < 45W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
Half sine wave shock: 40G, 2ms duration
Non-operating
Half sine wave shock: 240G, 2ms duration
Random Vibration
Operating
Nominal 1.043 grms
Non-operating
Nominal 3.5 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Yes
EPEAT®
Yes
Australia /
NZ A-Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
GOST
Yes
Saudi Arabian Compliance
(ICCP)
TRSE owned
UKRSERTCOMPUTER
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 24
DISPLAYS*
Panel LCD 14 inch FHD
(1920x1080) Anti-Glare WLED
UWVA 72% cg 700nits eDP
1.3+PSR ultraslim Privacy
Outline Dimensions (W x H)
315.41x 196.14 max.
Active Area
309.312 x 173.988
Weight
<225g max.
Diagonal Size
14.0"
Thickness
3.0mm max.
Interface
eDP 1.4
Surface Treatment
IPS Touch Enabled
Yes Contrast Ratio
Privacy mode 150:1 (typ.) – Privacy, 110:1(min.)- Privacy
Refresh Rate
120Hz
Brightness
Privacy mode 350nits
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB Backlight
LED Color Gamut Coverage
72%
Color Depth
6 bits + Hi FRC
Viewing Angle
Privacy mode CR>2: UWVA 50/50/85/85
Panel LCD 15.6 inch FHD
(1920x1080) Anti-Glare WLED
UWVA 45% cg 220nits eDP slim
NB
Outline Dimensions (W x H)
350.96 x 216.75 (max.)
Active Area
344.16 x 193.59 (typ.)
Weight
370g max.
Diagonal Size
15.6"
Thickness
3.2mm max.
Interface
eDP 1.2
Surface Treatment
IPS
Touch Enabled
Yes
Contrast Ratio
600:1 (typ) - AG
Refresh Rate
60Hz
Brightness
220 nits typical (Panel Only)
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB
Backlight
LED
Color Gamut Coverage
0.45
Color Depth
6 bits + Hi FRC
Viewing Angle
UWVA 85/85/85/85
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 25
Panel LCD 15.6 inch FHD
(1920x1080) Anti-Glare WLED
UWVA 72% cg 400nits eDP 1.3 +
PSR slim NB
Outline Dimensions (W x H)
350.96 x 216.75 (max.)
Active Area
344.16 x 193.59 (typ.)
Weight
370g max.
Diagonal Size
15.6"
Thickness
3.2mm max.
Interface
eDP 1.3 + PSR (2 lane)
Surface Treatment
IPS
Touch Enabled
No
Contrast Ratio
600:1 (typical)
Refresh Rate
60Hz
Brightness
400 nits typical (Panel Only)
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB
Backlight
LED
Color Gamut Coverage
0.72
Color Depth
6 bits + Hi FRC
Viewing Angle
UWVA 85/85/85/85
*NOTE: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance
may vary either higher or lower.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 26
STORAGE1
SSD 128 GB 2280 M2 SATA-3 TLC
Drive Weight
0.02 lb (10 g)
Capacity
128 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
Up To 520 MB/s
Maximum Sequential Write
Up To 450 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
DIPM; TRIM; DEVSLP
SSD 256 GB 2280 M2 PCIe-3x4 SS
NVMe TLC
Drive Weight
0.02 lb (10 g)
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up To 600 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
SSD 256 GB 2280 M2 SATA-3 Self
Encrypted OPAL2 TLC
Drive Weight
0.02 lb (10 g)
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
Up To 530 MB/s
Maximum Sequential Write
Up To 515 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
DIPM; TRIM; DEVSLP
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 27
256 GB 2280 PCIe NVMe Value
Solid State Drive
Drive Weight
0.02 lb (10 g)
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up To 600 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
TRIM; L1.2
SSD 360 GB 2280 PCIe-3x4 NVMe
TLC
Drive Weight
0.02 lb (10 g)
Capacity
360 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up To 600 MB/s
Logical Blocks
703,282,608
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
TRIM; L1.2
SSD 512 GB 2280 M2 PCIe-3x4 SS
NVMe TLC
Drive Weight
0.02 lb (10 g)
Capacity
512 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2600 MB/s
Maximum Sequential Write
Up To 1400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
TRIM; L1.2
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 28
SSD 512 GB 2280 M2 SATA-3 TLC
FIPS
Drive Weight
0.02 lb (10 g)
Capacity
512 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ACS-3, SATA 3.2
Maximum Sequential Read
Up To 530 MB/s
Maximum Sequential Write
Up To 400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
DIPM; TRIM; DEVSLP
SSD 512 GB 2280 PCIe-3x4 NVMe
Self Encrypted OPAL2 TLC
Drive Weight
0.02 lb (10 g)
Capacity
512 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2900 MB/s
Maximum Sequential Write
Up To 1400 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
TRIM; L1.2
1. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows
10) is reserved for system recovery software.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 29
NETWORKING/COMMUNICATIONS
Realtek
802.11a/b/g/n/ac (2x2)
WiFi and Bluetooth® 4.2
Combo1
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/n
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
• IEEE and Wi-Fi® compliant 64 / 128 bit WEP encryption for a/b/g mode
only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +14dBm minimum
• 802.11g : +12dBm minimum
• 802.11a : +12dBm minimum
• 802.11n HT20(2.4GHz) : +12dBm minimum
• 802.11n HT40(2.4GHz) : +12dBm minimum
• 802.11n HT20(5GHz) : +10dBm minimum
• 802.11n HT40(5GHz) : +10dBm minimum
• 802.11ac VHT80(5GHz) : +10dBm minimum
Power Consumption
• Transmit mode 2.0 W
• Receive mode 1.6 W
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 30
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express Half-MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF;
LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and
Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 31
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth Software
Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and Internet service is required. Availability of public wireless access point is limited. The
specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 32
HP lt4132 LTE/HSPA+ 4G
Mobile Broadband5
Technology/Operating
bands
LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3) MHz,
850 (Band 5), 2600 (Band 7), 900 (Band 8) MHz,
800 (Band 20), 700 (Band 28) MHz.
HSPA+: 2100 (Band 1), 1900 (Band 2), 850 (Band 5), 900 (Band 8) MHz
E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol
standards
3GPP Release 10 LTE Specification CAT.4, 20MHz BW
WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
E-GPRS: Class B, Multi-slot class 12, coding schemes CS1 - CS4
and MSC1 - MSC9
GPS
Standalone, A-GPS (MS-B and LTO)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 150 Mbps (Download), 50 Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
Maximum output power
LTE: 23 dBm
HSPA+: 23.5 dBm
E-GPRS 1900/1800: 26 dBm
E-GPRS 900/850: 27 dBm
GPRS 1900/1800: 29.5 dBm
GPRS 900/850: 32.5 dBm
Maximum power
consumption
LTE: 1,200 mA (peak); 900 mA (average)
HSPA+: 1,100 mA (peak); 800 mA (average)
E-GPRS: 2,600 mA (peak); 500 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions
(Length x Width x
Thickness)
42 x 30 x 2.3 mm
5. Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not
available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary
due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 33
HP lt4210 4G Module
6
Technology/Operating
bands
FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3),
1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 1400
(Band 11), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower),
850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1400 (Band 21),
850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30),
2100 (Band 66).
TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band 41).
HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4),
850 (Band 5), 900 (Band 8) MHz
Wireless protocol
standards
3GPP Release 11 LTE Specification CAT.9, DL 60MHz BW throughput up to
450Mbps; UL 20MHz throughput up to 50Mbps
WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
GPS
Standalone, A-GPS (MS-A, MS-B and XTRA)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098
MHz
Maximum data rates
LTE: 450 Mbps (Download), 50 Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm
HSPA+: 23.5 dBm
Maximum power
consumption
LTE: 1,200 mA (peak); 900 mA (average)
HSPA+: 1,100 mA (peak); 800 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
5.8 g
Dimensions
(Length x Width x
Thickness)
42 x 30 x 2.3 mm
6. Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not
available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary
due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countrie
Intel Windstorm Peak 2
8265 802.11a/b/g/n/ac
(2x2) WiFi and
Bluetooth® 4.2 Combo7
Non-vPro
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/n
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 34
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security9
• IEEE and Wi-Fi® compliant 64 / 128 bit WEP encryption for a/b/g mode
only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power8
• 802.11b : +14dBm minimum
• 802.11g : +12dBm minimum
• 802.11a : +12dBm minimum
• 802.11n HT20(2.4GHz) : +12dBm minimum
• 802.11n HT40(2.4GHz) : +12dBm minimum
• 802.11n HT20(5GHz) : +10dBm minimum
• 802.11n HT40(5GHz) : +10dBm minimum
• 802.11ac VHT80(5GHz) : +10dBm minimum
Power Consumption
• Transmit mode 2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity10
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 35
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express Half-MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF;
LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and
Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth Software
Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 36
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
7. Wireless access point and Internet service is required. Availability of public wireless access point is limited. The
specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices
8. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
9. Check latest software/driver release for updates on supported security features.
10. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 37
POWER
AC Adapter 65 Watt nPFC
USB type C
Dimensions
74x74x28.5mm
Weight
unit: 245g +/- 10g
Input
Input Efficiency
81.5% min at 115 Vac/ 230Vac @ 5V/3A
86.7% min at 115 Vac/ 230Vac @ 9V/3A
88% min at 115 Vac/ 230Vac @ 10V/5A
88% min at 115 Vac/ 230Vac @ 12V/5A
89% min at 115 Vac/ 230Vac @ 15V/4.33A
89% min at 115 Vac/ 230Vac @ 20V/3.25A
Input frequency range
47 ~ 63 Hz
Input AC current
1.7 A at 90 VAC and maximum load
Output
Output power
65W
DC output
5V/9V/10V/12V/15V/20V
Hold-up time
5ms at 115 Vac input
Output current limit
<8.0A
Connector
Duck head / duck head power cord, without Smart ID DC connector
Environmental Design
Operating temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
5% to 95%
Storage Humidity
5% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 100,000 hours at 25°C ambient condition.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 38
AC Adapter 45 Watt nPFC
USB type C™
Dimensions
62.0x62.0x28.5mm
Weight
unit: 220g +/- 10g
Input
Input Efficiency
Average Efficiency of 25%, 50%, 75%, 100%
load condition with 115Vac/230Vac Spec:5V :
81.5%9V : 86.7%10V : 87.5%12V : 87.8%15V :
87.8%20V : 87.8%
Input frequency range
47 ~ 63Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
5V/15W
9V/27W
10V/37.5W
12V/45W
15V/45W
20V/45W
DC output
5V / 9V / 10V /12V / 15V / 20V
Hold-up time
5ms at 115 Vac input
Output current limit
<5.0A
Connector
USB Type-C™
Environmental Design
Operating temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 39
HP 45W Smart AC adapter
Dimensions
3.74 x 1.57 x 1.04 in (9.5 x 4.0 x 2.65 cm)
Weight
0.386 lb (175g) max
Input
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 ~ 63Hz
Input AC current
1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8.0A
Connector
4.5mm Barrel Type, 3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart AC adapter
Dimensions
107.0x47.0x30.0mm
Weight
unit: 250g +/- 10g
Input
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5ms at 115 Vac input
Output current limit
<11.0A
Connector
4.5mm Barrel Type
Environmental Design
Operating temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP EliteBook 755 G5
Technical Specifications
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 40
HP 65W EM Smart AC
adapter
Dimensions
102x55x30mm
Weight
270g +/- 10g
Input
Input Efficiency
87% min at 115V/230V
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC and maximum load
Output
DC output
65W(19.5V/3.33A)
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
4.5mm Barrel Type, 3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
0° to 35° C
Non-operating (storage)
temperature
-20° to 85° C
Altitude
0 to 5,000 m
Humidity
0% to 95%
Storage Humidity
0% to 95%
Safety Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
Battery TT 3 Cell WHr 56
Long Life -PL
Dimensions (H x W x L)
L 281.7mm x W 79.65mm x H 7.15mm
Weight
193 +/- 10g
Cells/Type
3cell Lithium-Ion Polymer cell / P604883A1
Energy
Voltage
11.55V/
Amp-hour capacity
4.113Ah/ 4.330Ah
Watt-hour capacity
50 Wh
Temperature
Operating (Charging)
0˚ to 50˚ C
Operating (Discharging)
-10˚ to 60˚ C
Fuel Gauge LED
N/A
Warranty
3 years
Optional Travel Battery
Available
No
COUNTRY OF ORIGIN
China
QuickSpecs
HP EliteBook 755 G5
Options and Accessories (sold separately and availability may vary by country)
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 41
Type
Description
Part #
Cases
HP Slim Top Load
F3W16AA
HP Slim Backpack
F3W15AA
HP 15.6 Business Top Load
2SC66AA
Docking
HP UltraSlim Docking Station
D9Y32AA
HP USB-C Universal Dock
1MK33AA
HP USB-C Dock G4
3FF69AA
HP Thunderbolt Dock G2
2UK37AA
HP USB-C Mini Dock
1PM64AA
Input/Output
HP Slim Wireless Keyboard and Mouse
T6L04AA
HP Slim USB Keyboard and Mouse
T6T83AA
HP Wireless (Link-5) Keyboard
T6U20AA
HP Comfort Grip Wireless Mouse
H2L63AA
HP Ultra Mobile Wireless Mouse
H6F25AA
HP Wireless Premium Mouse
1JR31AA
HP USB Premium Mouse
1JR32AA
HP Elite Presenter Mouse
2CE30AA
HP USB Travel Mouse
G1K28AA
HP Stereo 3.5mm Headset
T1A66AA
HP Stereo USB Headset
T1A67AA
HP USB-C to USB-A Hub
Z6A00AA
HP USB-C to DP
N9K78AA
HP USB-C to VGA
N9K76AA
HP HDMI to DVI
F5A28AA
HP HDMI to VGA
H4F02AA
Power
HP 65W Slim AC Adapter
H6Y82AA
HP 90W Slim AC Adapter
H6Y83AA
HP 45W USB-C Power Adapter
1HE07AA
HP 65W USB-C Power Adapter
1HE08AA
HP USB-C Notebook Power Bank
2NA10AA
Memory
HP 4GB 2400MHz DDR4 Memory
Z4Y84AA
HP 8GB 2400MHz DDR4 Memory
Z4Y85AA
HP 16GB 2400MHz DDR4 Memory
Z4Y86AA
Storage
HP USB External DVDRW Drive
F2B56AA
HP 128GB TLC M.2 SATA-3 SSD
2JB95AA
HP 256GB M2 PCIe NVME SSD TLC (2280)
1FU87AA
HP 512GB M2 PCIe NVME SSD TLC 2280)
1FU88AA
QuickSpecs
HP EliteBook 755 G5
Options and Accessories (sold separately and availability may vary by country)
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 42
Security
HP Docking Station Cable Lock
AU656AA
HP Keyed Cable Lock
T0Y14AA
HP Keyed Cable Lock 10mm
T1A62AA
HP Dual Head Keyed Cable Lock
T1A64AA
UCC
HP USB Collaboration Keyboard
Z9N38AA
HP Wireless Collaboration Keyboard
Z9N39AA
HP UC Speaker Phone
K7V16AA
HP UC Wireless Mono Headset
W3K08AA
HP UC Wireless Duo Headset
W3K09AA
Displays
HP EliteDisplay E243 23.8-inch Monitor
1FH47AA
HP EliteDisplay E243i 23.8-inch Monitor
1FH49AA
HP EliteDisplay E273 27-inch Monitor
1FH50AA
HP EliteDisplay E273m 27-inch Monitor
1FH51AA
QuickSpecs
HP EliteBook 755 G5
Summary of Changes
c05934823 — DA16168 — Worldwide — Version 7 — May 17, 2018
Page 43
Date of change:
Version History:
Description of change:
February 28, 2018
V1 to V2
Update
256 GB 2280 PCIe NVMe Value Solid State Drive features specs added
Panel LCD 14 inch FHD (1920x1080) Anti-Glare WLED UWVA 72% cg 700nits
eDP 1.3+PSR ultraslim Privacy added to DISPLAYS section
April 27, 2018
V2 to V3
Update
Environmental
May 7, 2018
V3 to V4
Update
Display support matrix moved to Display Support section
May 8, 2018
V4 to V5
Added
Environmental tab
May 16, 2018
V5 to V6
Update
Battery life
May 17, 2018
V6 to V7
Update
Processors
Copyright © 2018 HP Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
AMD is a trademark of Advanced Micro Devices, Inc. Intel vPro is a trademark or registered trademark of Intel Corporation or its
subsidiaries in the U.S. and/or other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. ENERGY
STAR is a registered trademark of the U.S. Environmental Protection Agency. All other trademarks are the property of their
respective owners.
Loading...
