Hewlett Packard 1EP88EA Product Data Sheet

Datasheet

HP EliteBook 1040 G4 Notebook PC

With great power, comes great
productivity. Our most
powerful ultraslim 14-inch
diagonal business notebook
accelerates your day-to-day,
and makes even your hardest
tasks a breeze—with
powerful multitasking,
on-the-go collaboration, and
industry-leading security.

HP recommends Windows 10
Pro.

Supercharged performance

Powered to push your pace, the HP EliteBook 1040 is ready for your biggest challenges in and out of the office.
With up to 18-hours of battery life2and an optional quad-core Intel® Core™ processor (H-series)3under the
hood, there’s almost nothing you can’t handle.

Thin. Light. Your conference powerhouse.

Say hello to the ultrathin device packed with features and ready for your mobile world. Designed for
conferencing with powerful audio, intuitive call management, and a 180° hinge to share your ultra-bright
700-nit display4in a huddle room.

Our most secure and manageable PCs

Protection is simple and manageable thanks to a cutting-edge suite of security features that lets you browse
confidently, keeps visual hackers in the dark, and monitors and restores in memory BIOS automatically.

●

Power through your day with Windows 10 Pro1and the powerful, sleek, thin, and light HP EliteBook 1040.

●

Combine power and speed with 7th Gen quad-core Intel® Core™ processor (H-Series)3, optional PCIe Gen3
SSD5, DDR4 memory5.

●

Help protect your PC from infected websites, malware, ransomware, and viruses with HP Sure
Click6—hardware-enforced security for web browsers.

●

Instantly protect against visual hacking with the optional HP Sure View7integrated privacy screen. At the
touch of a button your screen appears unreadable to those around you while you see your content clearly.

●

Start with a genuine HP BIOS every time. HP Sure Start Gen38monitors in-memory BIOS, recovers the
platform without user or admin intervention, restores the BIOS to a custom state, and is enterprise ready for
centralized management.

●

Work and play with long battery life, and recharge up to 50% battery life in just 30 minutes9with an HP fast
charging battery.

●

HP PhoneWise allows you to answer and respond to your iOS or Android™ calls and texts through your PC10.

●

Stay productive with essential ports for optional docking6, and connect to networks with WiFi and optional
3G/4G LTE11.

●

Pick the right display for the way you work with FHD or UHD touch display5.

Datasheet | HP EliteBook 1040 G4 Notebook PC

HP EliteBook 1040 G4 Notebook PC Specifications Table

HP recommends Windows 10 Pro.

Available Operating System

Processor Family

Available Processors

Chipset

Maximum Memory

Internal Storage

Display

Available Graphics

Wireless Technologies

Communications

Ports and Connectors

Input Device

Camera

Available Software

Security Management

Management Features

Power

Dimensions

Windows 10 Pro 64 – HP recommends Windows 10 Pro.
Windows 10 Home 64
Windows 10 Home Single Language 64

1

1

1

FreeDOS 2.0

7th Generation Intel® Core™ i7 processor (i7-7820HQ model); 7th Generation Intel® Core™ i7 processor (i7-7600U model); 7th Generation Intel®
Core™ i7 processor (i7-7500U model); 7th Generation Intel® Core™ i5 processor (i5-7300U model); 7th Generation Intel® Core™ i5 processor
(i5-7200U model)

4

Intel® Core™ i7-7820HQ with Intel® HD Graphics 630 (2.9 GHz, up to 3.9 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)
Intel® Core™ i7-7600U with Intel® HD Graphics 620 (2.8 GHz, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
Intel® Core™ i7-7500U with Intel® HD Graphics 620 (2.7 GHz, up to 3.5 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
Intel® Core™ i5-7300U with Intel® HD Graphics 620 (2.6 GHz, up to 3.5 GHz with Intel® Turbo Boost Technology, 3 MB cache, 2 cores)
Intel® Core™ i5-7200U with Intel® HD Graphics 620 (2.5 GHz, up to 3.1 GHz with Intel® Turbo Boost Technology, 3 MB cache, 2 cores)

2,3,4

Chipset is integrated with processor

16 GB DDR4-2133 SDRAM

5

(Memory soldered down.Supports dual channel memory.)

128 GB up to 1 TB M.2 PCle Gen 3x4 NVMe TLC SSD
512 GB M.2 PCle Gen 3x4 NVMe TLC SSD
512 GB M.2 PCle Gen 3x4 NVMe MLC SSD
256 GB M.2 SATA SED SSD
128 GB M.2 SATA TLC SSD

6

6

6

6

6

14" diagonal 4K IPS eDP LED-backlit touch screen, 400 cd/m2, 100% sRGB, direct bonded with Corning® Gorilla® Glass 4, camera and WWAN
(3840 x 2160); 14" diagonal 4K IPS eDP anti-glare LED-backlit, 400 cd/m2, 100% sRGB with camera and WWAN (3840 x 2160); 14" diagonal FHD
IPS eDP LED backlit touch screen, 700 cd/m2, 100% sRGB with Corning® Gorilla® Glass 4, privacy screen, camera and WWAN (1920 x 1080); 14"
diagonal FHD IPS eDP anti-glare LED-backlit, 700 cd/m2, 100% sRGBwith privacy screen, camera and WWAN (1920 x 1080); 14" diagonal FHD
IPS eDP LED-backlit touch screen, 340 cd/m2, 100% sRGB, direct bonded with Corning® Gorilla® Glass 4, camera and WWAN (1920 x 1080); 14"
diagonal FHD IPS eDP LED-backlit touch screen, 340 cd/m2, 100% sRGB, direct bonded with Corning® Gorilla® Glass 4 and camera (1920 x 1080);
14" diagonal FHD IPS eDP anti-glare LED-backlit, 340 cd/m2, 100% sRGB with camera(1920x 1080); 14" diagonal FHD IPS eDP anti-glare
LED-backlit, 340 cd/m2, 100% sRGB with camera and WWAN (1920 x 1080)

Integrated: Intel® HD Graphics 630; Intel® HD Graphics 620

Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.0 Combo (vPro™); HP lt4120 LTE/EV-DO/HSPA+ with GPS M.2
Mobile Broadband; HP lt4132 LTE/HSPA+ with GPS M.2 Mobile Broadband

11

7,8

(Compatible with Miracast-certified devices (models with Windows 10))

HP Module with NXP NFC Controller NPC300 I2C NCI

2 USB 3.1 Gen 1 (1 charging); 2 USB 3.1 Type-C™; 1 HDMI 1.4; 1 headphone/microphone combo
(HDMI cable sold separately.)

Full size, backlit, HP Premium Collaboration Keyboard; Clickpad with image sensor, multi-touch gestures enabled, taps enabled as default

720p HD webcam; IR camera for face authentication with Windows Hello

Native Miracast Support; HP Connection Optimizer; HP LAN-WLAN Protection; HP Velocity; HP ePrint Driver + JetAdvantage; HP Hotkey Support;
HP Recovery Manager; HP JumpStart; HP Support Assistant; HP Noise Cancellation Software; Buy Office; Bing search for IE11

11,18

9,19,20

HP BIOSphere Gen3; HP DriveLock and Automatic DriveLock; HP Sure Start Gen3; TPM 2.0 Embedded Security Chip shipped with Windows 10
(Common Criteria EAL4+ Certified); Power-on Authentication (password); Absolute Persistence Module; HP Client Security Gen3; Microsoft

24,25,26,27

Defender

HP Driver Packs; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client Catalog; HP Management Integration Kit for
Microsoft System Center Configuration Manager; LANDESK Management

65 W USB Type-C™ AC adapter; 90 W USB Type-C™ AC adapter
HP Long Life 6-cell, 67 Wh Li-ion
Up to 18 hours

28

13,14

21,22,23

15

Battery life varies depending on configuration.

12.95 x 9.17 x 0.63 in

32.89 x 23.28 x 1.59 cm

2
