hertz-audio.com
HMR 50
DIGITAL MEDIA RECEIVER
SPECIFICATION
DISPLAY 3.5” COLOR IPS
PEAK POWER @ 4 Ω 4 x 50 W
FRONT PANEL IP RATING IP66
MULTI-ZONE
SUBWOOFER OUT (RCA) 1x L+R (LPF: ALL, 60, 80, 100 Hz)
AUX INPUT (RCA) 1x L+R
EQUALIZER CUSTOM 8 BANDS for each zone
EQ. PRESET 5
CAMERA IN Yes
BATTERY VOLTAGE GAUGE Yes
SOURCES
TUNER
USB Yes (2A)
IPOD/IPHONE Yes
DAB+ Ready -
SIRIUSXM READY Yes
NMEA 2000 READY -
BLUETOOTH
REMOTE CONTROL HMC D1 (up to 3) HMC U1 (up to 3)
SIZE & MOUNTING
Unit Size mm (in.)
Mounting Hole size mm (in.) W 122 (4.8) x H 52 (2.05)
Mounting Depth mm (in.) 99 (3.89)
Mounting Method Panel mount (4 screws)
3 ZONES
3x L+R (one per zone)
(HPF: ALL, 60, 80, 100 Hz on ZONE1 only)
AM/FM (RDS) (EU/US)
Weather band
5.0
Audio streaming with ID3 Tag Display
APTX (CD AUDIO QUALITY)
W 146 (5.748) x H 105 (4.134) x D 121
(4.763)
PURE MARINE DESIGN
HMR 50 features IP66 protection grade, ASTM-D4329 standards for UV resistance and
ASTM-B117 for salt fog operability, giving you unstopped pleasure season after season.
CONNECTIVITY
CAMERA
INPUT
SUBWOOFER
OUT
AM/FM
RADIO
AUX-IN
WEATHER
BAND
iPHONE
iPAD
KEY FEATURES
• The large 3.5” full color TFT IPS display remains visible
even during daytime navigation and the big buttons make it
easy operating while cruising.
• Voltage indicator to check-up battery status
• HMR 50 features 3 pairs of stereo outputs providing the
ability to create 3 independently controlled listening areas
(FLYBRIDGE, AFT DECK, CABIN) to obtain the perfect sound
everywhere.
• Multicolor backlight for a perfect match with cookpit lighting.
• The powerful 8 band digital equalizer will support you
finding the best sound.
HMC D1 OPTIONAL
REMOTE CONTROL
HMC D1 allows to
replicate every function
of the main unit in every
place of the boat you
desire, maximizing the
A 146 mm 5.75 in.
B 105 mm 4.13 in.
C 98 mm 3.86 in.
D 34 mm 1.34 in.
E 50 mm 1.97 in.
A
C
onboard comfort.
VOL
HMC U1 OPTIONAL
REMOTE CONTROL
B
SEL
E
Play your favorite song and
pump-up the volume while
swimming in open water.
Thanks to IPX7 certification
Elettromedia - 62018 Potenza Picena (MC) Italy - T +39 0733 870 870 - F +39 0733 870 880 - elettromedia.com
D
All Specifications Subject to Change Without Notice_22.A
