hertz-audio.com
HMR 15
DIGITAL MEDIA RECEIVER
SPECIFICATION
DISPLAY 2.8” DOT Matrix display
PEAK POWER @ 4 Ω 4 x 50 W
FRONT PANEL IP RATING IP66
LINE OUTS 2x L+R (Front and Rear)
SUBWOOFER OUT (RCA) 1x L+R (LPF: 80, 120,160 Hz)
AUX INPUT (RCA) 1x L+R
EQUALIZER BASS-TREBLE
EQ. PRESET 3
CAMERA IN -
BATTERY VOLTAGE GAUGE -
SOURCES
TUNER
USB Yes (1A)
IPOD/IPHONE -
DAB+ Ready -
SIRIUSXM READY -
NMEA 2000 READY -
BLUETOOTH
REMOTE CONTROL HMC U1 (up to 3)
SIZE & MOUNTING
Unit Size mm (in.)
Mounting Hole size mm (in.) Ø 89,5 (3.52)
Mounting Depth mm (in.) 72 (2.83)
Mounting Method Panel mount (4 screws); U-Bracket
HMR 15: AM/FM (EU/US) HMR 15 D: FM
(RDS*) (EU)
*where available
5.0
Audio streaming
W 126 (4.960) x H 114 (4.488)
x D 96.5 (3.799)
PURE MARINE DESIGN
HMR 15 features IP66 protection grade, ASTM-D4329 standards for UV resistance and
ASTM-B117 for salt fog operability, giving you unstopped pleasure season after season.
CONNECTIVITY
AUX-IN
AM/FM
RADIO
KEY FEATURES
• 3 EQ preset created by Hertz audio engineer
• Minimalist square-shaped design, perfectly in line with the latest trends in the most
prestigious navigation instruments.
• Generous display with the large marine-grade pushbutton panel
• Bluetooth® 5.0 to stream high quality audio from your favorite mobile device
HMC U1 OPTIONAL
REMOTE CONTROL
Play your favorite song and
pump-up the volume while
swimming in open water.
Thanks to IPX7 certification
A 126 mm 4.96 in.
B 114 mm 4.49 in.
C 70,8 mm 2.79 in.
D 25,7 mm 1 in.
E 89,5 mm 3.52 in.
A D
B E
C
Elettromedia - 62018 Potenza Picena (MC) Italy - T +39 0733 870 870 - F +39 0733 870 880 - elettromedia.com
All Specifications Subject to Change Without Notice_22.A
