1. YOUR HERCULES ePLUG 200 C/MULTI ADAPTER

PLC (Power Line Communication), also known as HomePlug, is a technology which uses your home's
existing electrical wiring to efficiently transfer digital data (audio, video, Internet, other types of files) within a secure personal network. HomePlug is an ideal alternative for those who wish to easily create a network, without the constraints of cables, and are unable to enjoy all of the potential of WiFi due to the configuration of their home (as a result of the presence of thick walls or other obstacles which impede wireless data transmission).
Hercules ePlug 200 C/Multi is an adapter employing HomePlug technology which can be connected to any electrical outlet in your home (from the ground floor to upstairs), thereby transforming your outlets into as many possible network connection points. Moreover, you can freely unplug Hercules ePlug 200 adapters and plug them into different outlets in your home, according to your needs (changing the location of a computer, or of your modem router...), without having to repeat the installation or re-create your network.
As a network is composed of at least two devices connected to one another, all you need to do is connect two Hercules ePlug 200 C/Multi adapters to two electrical outlets in your home (in the same room or in different rooms). For example, to access the Internet, you can connect your modem or your Internet “box” to a Hercules ePlug adapter plugged into the nearest electrical outlet, and connect your computer to another Hercules ePlug adapter plugged into another electrical outlet. Finally, your network is already preconfigured to provide you with maximum security.
All products in the Hercules ePlug 200 range are compatible with the HomePlug AV standard (including devices functioning at 200 Mbits/s), allowing you to enjoy high-definition video or stream multimedia files with ease. These adapters may be combined according to your needs or according to your devices (a TV decoder with a "Box", a modem with a computer or a game console, two computers, a computer and a printer...). You will find some possible configurations set out in the installation section of this manual.
Finally, with the goal of helping to protect the environment, Hercules offers energy-saving adapters, which conform to the European ERP (Energy Related Products) directive, guaranteeing electrical consumption of less than 1 watt when the device is in standby mode.
The HomePlug AV standard is not compatible with the Homeplug 1.0 standard corresponding to the Hercules ePlug 85 range (and other adapters conforming to this standard). Nevertheless, you are perfectly able to create a network composed of Hercules ePlug 85 adapters in your home coexisting alongside another network composed of Hercules ePlug 200 adapters.
Even though this type of device presents no danger in terms of your home's electrical wiring, you should take care to respect certain recommendations, set out below.
User Manual – 3/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
1.1. Recommendations
- Only connect the Hercules ePlug 200 C/Multi adapter to an electrical network which conforms to the security standards and specifications detailed on the device's electrical rating plate. If you are not sure about your electrical network, contact an electrician or your power supplier.
- Never open up the Hercules ePlug 200 C/Multi adapter, as doing so risks damaging its internal components.
- Do not attempt to insert any objects into the vents and openings of the Hercules ePlug 200 C/Multi adapter.
- Do not obstruct the vents and openings of the Hercules ePlug 200 C/Multi adapter.
- If you need to carry out any maintenance on your Hercules ePlug 200 C/Multi adapter, be sure to first unplug the adapter and entrust the job to a qualified professional in order to avoid the risk of electrocution.
- In order to avoid the risk of fire or electrical discharge, keep your adapter away from:
- rain or humidity, as well as all fluids (water, chemical products and any other liquids),
- sources of heat such as heaters, stoves and any other heat-producing devices (including amplifiers),
- direct sunlight.
- Only plug in the Hercules ePlug 200 C/Multi adapter in a sufficiently ventilated room.
- Only connect the Hercules ePlug 200 C/Multi adapter using the included Ethernet cable.
- Unplug the Hercules ePlug 200 adapter from its electrical outlet if you do not plan on using it again for an
extended period of time.
- Unplug the Hercules ePlug 200 C/Multi adapter from its electrical outlet before cleaning. Use a soft cloth for
cleaning and avoid using aerosol cleaners, water, solvent-based chemical products, benzene, alcohol or other cleaning products.
- Always keep children away from electrical outlets.
1.2. Specifications
Gigle GGL301 chipset Compatible with the IEE 802.3, IEE 802.3u, IEE 802.3x and Auto MDI/X specifications Compatible with the Homeplug AV standard Coexists with HomePlug 1.0 modules Encryption via the AES 128-bit security protocol 200 Mbits/s transfer rate Asynchronous transmission mode Modulation: OFDM, 1024/256/64 QAM, QPSK, BPSK 200m range over the electrical network Ethernet RJ45 port Average power consumption:
ePlug 200 C: 3.9W when in use, 1.8W when no data is circulating, 0.7W in standby mode,
enabled via the adapter's button (these values may vary depending on your home's electrical system)
ePlug 200 Multi: 4.2W when in use, 1.8W when no data is circulating, 0.45W in standby mode,
enabled via the adapter's button (these values may vary depending on your home's electrical
Internal power supply: 100~ 240V AC, 50/60Hz Connect button, allowing you to add a Hercules ePlug 200 adapter to an existing network LEDs on front face
4/63 – User Manual
system)
Hercules ePlug 200 C Hercules ePlug 200 Multi
1.3. Minimum system requirements
To connect a device to your Hercules ePlug 200 C/Multi adapter:
An Ethernet type network interface must be available on each device to be connected (computer, game
console, modem, router, TV decoder, etc.)
To access the Internet with the Hercules ePlug 200 C/Multi adapter:
Active Internet line Internet Explorer 6.0, Netscape Navigator 4.7 or Mozilla Firefox 1.0 or higher ADSL Ethernet modem, cable modem, Internet “Box” (Livebox
®
, Freebox®, Neufbox®…)
1.4. Box contents
Please verify that the following elements are present in the box:
Depending on the pack:
- Hercules ePlug 200 C/Multi Solo: 1 adapter
- Hercules ePlug 200 C/Multi Duo: 2 adapters
Quick Start Guide in English Ethernet cable (1 per adapter)
The "Hercules ePlug Station" network configuration and supervision software is available for download at http://www.hercules.com.
1.5. LEDs overview
Hercules ePlug 200 C
: HomePlug connection status LED:
- Green: very good connection (transfer rates greater than 60 Mbits/s)
- Orange: fairly good connection (transfer rates between 60 and 40 Mbits/s)
- Red: mediocre connection (transfer rates less than 40 Mbits/s)
: Power LED: flashes during traffic
Hercules ePlug 200 Multi
: Ethernet connection LED:
- lit up when the Ethernet cable is connected
- flashes during data transfer
User Manual – 5/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
1.6. Connectivity overview
Hercules ePlug 200 C
Power plug to plug the Hercules ePlug 200 C adapter into an
electrical outlet
Ethernet port allowing you to connect a device to the Hercules ePlug 200 C adapter (desktop computer, laptop or netbook computer, game console, TV decoder, modem/router, Internet “box”)
Pairing button with three functions, allowing you to:
- enable pairing, in order to connect other ePlug 200
adapters to the network (by way of a short press, from 2 to 4 seconds): the power LED flashes
- enable/disable "energy-saving" mode: a medium
Reset button, allowing you to restore factory default settings (by way of a short press from 3 to 5 seconds, using a pointed object): the adapter restarts
press from 5 to 9 seconds enables this mode (the LEDs switch off, with only the power LED flashing); a single press lets you exit this mode
- randomly generate a new network password (by
way of a long press, of more than 10 seconds): the adapter restarts
6/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
Hercules ePlug 200 Multi
Additional electrical outlet to plug in another electrical
device
Ethernet port allowing you to connect a device to the Hercules ePlug 200 Multi adapter (desktop computer, laptop or netbook computer, game console, TV decoder, modem/router, Internet “box”)
ON/OFF button, allowing you to turn the adapter on or off
Pairing button with three functions, allowing you to:
- enable pairing, in order to connect other ePlug 200
adapters to the network (by way of a short press, from 2 to 4 seconds): the power LED flashes
- randomly generate a new network password (by
way of a medium press, from 8 to 12 seconds): the adapter restarts when you release the button
- restore factory default settings (by way of a long
press, of more than 15 seconds): the adapter restarts
Power plug to plug the Hercules ePlug 200 Multi adapter into an electrical outlet
Hercules ePlug C/Multi adapters adapt their activity according to requirements on the network, thereby optimizing energy consumption.
User Manual – 7/63
Hercules ePlug 200 C Hercules ePlug 200 Multi

2. INSTALLING YOUR HERCULES ePLUG 200 C/MULTI

The Hercules ePlug 200 C/Multi adapter has been designed to be simple to use and install. If you have already purchased and installed HomePlug (or PLC) adapters, Hercules provides a Quick Start Guide which guides you through several steps to take to add your Hercules ePlug 200 adapters to your existing HomePlug network.
If you are new to the world of HomePlug technology, we invite you to follow the pieces of advice set out in chapters 2.1 and 2.2 in order to get started.
Otherwise, you can proceed directly to chapter 2.3. You haven't yet created a HomePlug network: initial
i
nstallation of Hercules ePlug 200 C/Multi Duo which sets out, step by step, the installation procedure for
your Hercules ePlug 200.
Finally, if you have already created a HomePlug network and wish to add a new adapter, please refer to chapter 2.4. You have already created a HomePlug network: adding a new adapter to your network
(Her
cules ePlug 200 C/Multi Solo or Duo).
2.1. How to position your Hercules ePlug 200 C/Multi
To help you connect your Hercules ePlug 200 C/Multi, start by selecting an electrical outlet near to the equipment you wish to connect and follow the pieces of advice set out below.
To optimize the transfer of data on your electrical network, be sure to follow these recommendations:
You should preferably plug the adapters and devices (computer, Internet "box"...) into
If you plug both an adapter and a device into the same powerstrip, the performance
separate wall outlets: one for the adapter and one for the device to be connected to the HomePlug network.
(bitrate) of your network may be affected.
8/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
2.2. HomePlug: the partner to WiFi in your home
If you have a modem router or an Internet "box", your various pieces of network equipment, whether connected by WiFi or HomePlug, can communicate with one another. All data is transferred to a central point, in this case your modem router or Internet "box", and may circulate either on the electrical network via your HomePlug adapters, or by way of radio waves via WiFi.
It is therefore perfectly possible for a computer or any other piece of network equipment connected via WiFi to communicate with another piece of equipment connected via the HomePlug network to the modem router.
In chapters 2.2.1 to 2.2.3, you will find different examples of purely HomePlug networks. However, there is nothing stopping you from adding WiFi devices as well: for example, an Internet "box" connected to the HomePlug network on the one hand, and a WiFi laptop computer connected to this same "box" via WiFi, on the other hand.

2.2.1. Connecting two computers in a HomePlug network

2.2.2. Connecting a computer to a modem, a modem router, an Internet "box" or a game console in a HomePlug network

User Manual – 9/63
Hercules ePlug 200 C Hercules ePlug 200 Multi

2.2.3. Connecting an Internet "box" to a Digital Terrestrial Television decoder in a HomePlug network

10/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
2.3. You haven't yet created a HomePlug network: initial installation of Hercules ePlug 200 C/Multi Duo
The HomePlug AV standard of Hercules ePlug 200 adapters is not compatible with the Homeplug 1.0 standard of Hercules ePlug 85 adapters and HomePlug 14 Mbits/s adapters, but these two standards can coexist side-by-side. In effect, if you have already
installed a HomePlug network in the HomePlug 1.0 standard (for example, with Hercules ePlug 85 adapters), you cannot add Hercules ePlug 200 adapters to that network. However, you are perfectly able to install a second network in your home composed of Hercules ePlug 200 adapters and HomePlug AV compatible devices.

To install a HomePlug network:

1. Connect the Ethernet cable to the Ethernet plug on your first adapter.
User Manual – 11/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
Hercules ePlug 200 C:
2. Plug the adapter into an electrical outlet located near the device to be connected to the network.
Hercules ePlug 200 Multi:
On the Hercules ePlug 200 Multi: if you wish, plug another device into the additional electrical outlet (powerstrip, modem, printer...).
3. Connect the other end of the Ethernet cable to the computer, modem, game console or any other network device (for example, a modem router).
12/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
4. Connect the Ethernet cable to the Ethernet plug on your second adapter.
5. Plug the adapter into an electrical outlet located near the device to be connected to the network.
In order to optimize data transfer on the PLC network, it is preferable not to plug your adapter directly into a powerstrip.
6. Connect the other end of the Ethernet cable to the computer, modem, game console or any other network device (for example, a computer).
When your adapters are connected, the
LED (connection status) lights up and indicates that the network is functioning properly. The signal quality is also indicated by a color code, explained in chapter 1.5. LEDs overview
User Manual – 13/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
Your computer can now access the Internet via your modem, as the two devices are connected to one another via the HomePlug network and have the same network password.
14/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
2.4. You have already created a HomePlug network: adding a new adapter to your network (Hercules ePlug 200 C/Multi Solo or Duo)
Let's take an example of a home in which you have already installed a HomePlug network composed of HomePlug adapters in the AV standard (Hercules ePlug 200 C/Multi, for example). You now wish to install one or more new Hercules ePlug 200 C/Multi adapters in order to expand your network and be able to connect new devices (printer, modem, router, game console...).
1. Ethernet connection and electrical connection of your new Hercules ePlug 200 adapter
1. Connect the Ethernet cable to the Ethernet plug on your new adapter.
User Manual – 15/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
Hercules ePlug 200 C:
Hercules ePlug 200 Multi:
2. Plug the new adapter into an electrical outlet located near the device to be connected to the network.
In order to optimize data transfer on the PLC network, it is preferable not to plug your adapter directly into a powerstrip.
On the Hercules ePlug 200 Multi: if you wish, plug another device into the additional electrical outlet (powerstrip, modem, printer...).
3. Connect the other end of the Ethernet cable to the computer, modem, game console or any other network device (here, a computer).
16/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
4. Press for 2 to 4 seconds on the Connect button on one of the adapters already connected to the network.
You now have 2 minutes to pair the new adapter.
5. Press for 2 to 4 seconds on the Connect button on the Hercules ePlug 200 C/Multi adapter.
The
LED lights up when a connection
to the network has been established.
6 Repeat this procedure to add another Hercules ePlug 200 C/Multi adapter.
User Manual – 17/63
Hercules ePlug 200 C Hercules ePlug 200 Multi
2. Connection to the network
The network password is applied to the Hercules ePlug 200 C/Multi adapter, which can now communicate with all the adapters of the existing network.
If the connection of your adapter to the network has failed, there are several possible causes.
Cause 1: You may not have carried out the connection procedure properly:
- Press for between 2 to 4 seconds on the Connect button (also referred to as the security button by some manufacturers) on the adapter which is already part of your existing network.
- Make the connection by pressing for between 2 to 4 seconds on the Connect button on your Hercules ePlug 200 C/Multi adapter. You have 2 minutes to carry this out.
Cause 2: Your adapter may not be properly plugged into an electrical outlet, or this outlet is not powered:
- Verify that the adapter's power LED
is lit up.
Cause 3: There may be a strong disturbance in your electrical network caused by other devices near to your adapter:
- Avoid plugging your adapter directly into a power strip.
- Unplug the devices plugged in near to the adapter.
- Try plugging the adapter into another outlet.
18/63 – User Manual
Hercules ePlug 200 C Hercules ePlug 200 Multi
2.5. How to change the network password
When you install a HomePlug network, a random password is automatically generated. You can easily generate a new random password by using the Connect button's restart function.
If you change the network password on an adapter, that adapter will no longer be part of the network.
- Press for more than 10 seconds (ePlug 200 C version) or between 8 and 12 seconds (ePlug 200 Multi version) on the Connect button on the adapter whose password you want to change.
- Wait until the adapter restarts.
- Connect the other adapters by pressing for between 2 to 4 seconds on the Connect button on the adapter which is already part of the network you wish to create, and then pressing the Connect button on the adapter you wish to integrate into that network.
- Repeat this procedure for all adapters you wish to integrate into the network.
User Manual – 19/63
Loading...
+ 44 hidden pages
