Specification Sheet
Part Number:
TAG24T1-100B
Thermal Transfer Labels, Self-Laminating, 2.0" x .5" x 1.43", 1 Across, VL, White, 1000/roll
Article Number
596-00008
Type
TAG24T1
Color
White (WH)
Features & Benefits
• Clear laminate provides excellent abrasion protection and chemical
resistance. • Flexible material bends around small gauge wires and tight
bends. • Labels are UL recognized and include a strong acrylic adhesive for
indoor and outdoor use. • Standard 3" core can be used with HellermannTyton
thermal transfer printers or most standard brands.
Quantity Per
roll
Product Description
HellermannTyton self-laminating thermal transfer printer labels are a made of a
flexible vinyl film with a white printable surface that easily confirms to wires.
These labels include a clear “tail” that laminates printed text when applied.
Labels are UL recognized for indoor and outdoor use and feature a strong
acrylic adhesive designed to bond to both large and small diameter wires.
Short Description
Thermal Transfer Labels, Self-Laminating, 2.0" x .5" x 1.43", 1 Across, VL,
White, 1000/roll
Global Part Name
TAG24T1-100B-WH
Width W (Imperial)
2.0
Width W (Metric)
50.8
Bundle Diameter Min (Imperial)
0.137
Bundle Diameter Min (Metric)
3.5
Bundle Diameter Max (Imperial)
0.29
Bundle Diameter Max (Metric)
7.37
Thickness T (Metric)
25
Width of Liner (Metric)
55.9
Width of Liner (imperial)
2.20
Material
Type 100B
Material Shortcut
100B
Adhesive
Acrylic
Halogen free
No
Adhesive Operating Temperature
-51°F to +200°F (-46°C to +93°C)
Operating Temperature (Metric)
-40°F to +194°F (-40°C to +90°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL-Recognized
UL Recognized (US)
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3919102055
Labels per Column
1
Labels per Row
1
Weight (Metric)
1.176
Weight (Imperial)
2.57
