Specification Sheet
Part Number:
TAG22T3-100B
Article Number
596-00007
Type
TAG22T3
Color
White (WH)
Features & Benefits
• HellermannTyton Self-Laminating Labels come on rolls on a standard 3" core
for easy loading into a printer or caddy. • Labels are conformable so that they
can bend around small gauge wires and tight bends without coming loose over
time. • Labels are UL recognized for indoor and outdoor use to expand
application options. • HellermannTyton thermal transfer labels work in any
thermal transfer printer so that the user always has options to get labels
printed without being locked into a single vendor.
Quantity Per
roll
Product Description
HellermannTyton thermal transfer self-laminating labels are a conformable vinyl
film with a white printable surface followed by a clear tail that laminates the
printed text when applied to a wire or cable. The labels are UL recognized for
indoor and outdoor use with an aggressive acrylic adhesive that allows the
label to bond to large and small diameter wires.
Short Description
Thermal Transfer Labels, Self-Laminating, 1.0" x .5" x 1.43", 3 Across, VL,
White, 5000/roll
Global Part Name
TAG22T3-100B-WH
Width W (Imperial)
1.0
Width W (Metric)
25.4
Bundle Diameter Min (Imperial)
.06
Bundle Diameter Min (Metric)
1.50
Bundle Diameter Max (Imperial)
0.29
Bundle Diameter Max (Metric)
7.37
Thickness T (Metric)
25
Width of Liner (Metric)
85.09
Width of Liner (imperial)
3.35
Material
Type 100B
Material Shortcut
100B
Adhesive
Acrylic
Halogen free
No
