Specification Sheet
Part Number:
T50MI0C2
1-Piece Cable Tie/Screw Mount, 12.4" Long, #10 Screw, 3.4" Max Bundle Dia, 50lb, PA66, Black, 100/pkg
Article Number
113-00038
Type
T50MI
Color
Black (BK)
Features & Benefits
•
Screw mount style creates low insertion and high extraction force. •
Choose
from several tensile strengths and lengths to accommodate a range of
applications.
Quantity Per
bag
Product Description
One-piece Screw Mount Cable Ties fasten with a screw or bolt to provide
secure routing of cable bundles. Multiple configurations are available to cover
a range of bundle sizes and tensile strengths.
Short Description
1-Piece Cable Tie/Screw Mount, 12.4" Long, #10 Screw, 3.4" Max Bundle Dia,
50lb, PA66, Black, 100/pkg
Global Part Name
T50MI-PA66-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
12.4
Length L (Metric)
315
Fixation Method
Fixing hole
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
3.35
Bundle Diameter Max (Metric)
85.0
Height H (Imperial)
0.23
