Specification Sheet
Part Number:
T50I7C2
Article Number
111-05240
Type
T50I
Color
Purple (PE)
Features & Benefits
•
Engineered and manufactured for maximum performance and quality. •
Made
from 100% high-quality plastic to ensure efficient recycling. •
Inside serration for
a strong grip onto bundles. •
Easy application either manually or with a
tensioning tool. •
Bent tail allows for simpler insertion.
Quantity Per
bag
Product Description
HellermannTyton standard cable ties feature inside serrations providing a
positive hold onto wire and cable bundles. The head design guarantees high
tensile strength, as well as a low insertion force. The bent tail design allows
quick and simple installations by hand. For high volume applications,
tensioning tools are availableto ensure consistent and safe installation.
Short Description
Cable Tie, 12" Long, UL Rated, 50lb Tensile Strength, PA66, Purple, 100/pkg
Global Part Name
T50I-PA66-VT
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225.0
Length L (Imperial)
12.0
Length L (Metric)
305.0
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
3.2
Bundle Diameter Max (Metric)
81.3
Thickness T (Metric)
1.2
