Specification Sheet
Part Number:
T40L9M4
Cable Tie, 14.6" Long, UL Rated, 40lb Tensile Strength, PA66, Natural, 1000/pkg
Article Number
111-04311
Type
T40L
Color
Natural (NA)
Features & Benefits
•
Engineered and manufactured for maximum performance and quality. •
Made
from 100% high-quality plastic to ensure efficient recycling. •
Inside serration for
a strong grip onto bundles. •
Easy application either manually or with a
tensioning tool. •
Bent tail allows for simpler insertion.
Quantity Per
bag
Product Description
T-Series Cable Ties feature inside serrations to provide a positive hold on wire
and cable bundles. The head design guarantees high tensile strength and a
low insertion force. The bent tail design allows quick and simple installations
by hand. For high-volume applications, tensioning tools are available to ensure
consistent and safe installation.
Short Description
Cable Tie, 14.6" Long, UL Rated, 40lb Tensile Strength, PA66, Natural,
1000/pkg
Global Part Name
T40L-PA66-NA
Minimum Tensile Strength (Imperial)
40.0
Minimum Tensile Strength (Metric)
180.0
Length L (Imperial)
14.6
Length L (Metric)
370.0
Identification Plate Position
none
Releasable Closure
No
Variant
Inside Serrated
Width W (Imperial)
0.16
Width W (Metric)
4.0
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
4.13
Bundle Diameter Max (Metric)
104.9
