Specification Sheet
Part Number:
SRCI0750C2
TSR Adhesive Cable Clamp, 1.25" Width, .77" Height, PVC, Ivory, 100/pkg
Article Number
151-00279
Type
SRCI0750
Color
Ivory (IV)
Features & Benefits
• Co-extruded hinge offers unlimited access to wire and cables and can be
open and closed repeatedly without signs of wear. • Rubber based adhesive
allows for a permanent bond to most surfaces.
Quantity Per
bag
Product Description
Manufactured from HellermannTyton's surface raceway, these adhesive cable
clamps are designed with a co-extruded hinge offering unlimited and easy
access to wire and cable. The clip can be open and closed repeatedly without
deformation or signs of wear. The rubber based adhesive allows for a
permanent bond to most surfaces. Available in three sizes.
Short Description
TSR Adhesive Cable Clamp, 1.25" Width, .77" Height, PVC, Ivory, 100/pkg
Global Part Name
SRCI0750-PVC-BGE
Length L (Imperial)
1.25
Length L (Metric)
31.75
Width W (Imperial)
1.36
Width W (Metric)
34.5
Bundle Diameter Max (Imperial)
0.75
Bundle Diameter Max (Metric)
19.0
Height H (Imperial)
.77
Height H (Metric)
19.60
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Adhesive
Rubber
Flammability
UL 94 V0 (excluding adhesive)
Operating Temperature (Metric)
+122°F (+50°C)
ROHS Complaint
Yes
