Routing, Protection and Insulation
Spiralwrap - Special Materials
Spiralwrap in Polytetrafluoroethylene-Teflon
HellermannTyton’s Spiralwrap protective sheathing provides cable
protection and flexible routing. Spiralwrap is wrapped around a group
of cables to shield and organize. Polytetrafluoroethylene-Teflon (PTFE)
offers the widest operating temperature range of any material. It's
chemically inert and nonflammable. Natural color is milky white.
Available by special order in black and colors.
Features and Benefits
• Sheathing allows flexible routing and lead-out of cables
• The inner edges are beveled preventing damage to cables
• Sheathing is reusable and resistant to most chemicals
• Spiralwrap is U.L. Recognized
Spiralwrap
MATERIAL
Flammability Non-Flammable
Operating Temperature -449°F to +500°F (-267°C to +260°C)
Min.
PART
NO. TYPE
1P9C* 1P 0.13 (3.18) 0.020 (0.51) 0.19 (4.75) 0.06 (1.6) 0.50 (12.7) Natural 100 ft
2P9C* 2P 0.25 (6.35) 0.030 (0.76) 0.38 (9.53) 0.18 (4.75) 2.00 (50.8) Natural 100 ft
2.5P9C* 2.5P 0.38 (9.53) 0.030 (0.76) 0.44 (11.13) 0.31 (7.92) 2.50 (63.5) Natural 100 ft
3P9C* 3P 0.50 (12.7) 0.030 (0.76) 0.50 (12.7) 0.38 (9.52) 3.00 (76.2) Natural 100 ft
4P9C* 4P 0.75 (19.05) 0.032 (0.81) 0.75 (19.05) 0.50 (12.7) 4.00 (102.0) Natural 100 ft
5P9C* 5P 1.00 (25.4) 0.040 (1.02) 1.00 (25.4) 0.75 (19.1) 5.00 (127.0) Natural 100 ft
Dimensions are approximate and subject to technical changes. Use Part No. for ordering and Type for specification purposes.
*This product meets UL standards. Please see appendix for specific file numbers.
Diameter
(D)
in. (mm)
Wall Thickness
(WT)
in. (mm)
Pitch
in. (mm)
Bundle
Diameter
in. (mm)
Polytetrafluoroethylene -Teflon (PTFE)
Max.
Bundle
Diameter
in. (mm) Color
Pkg.
Qty.
Please note! Not all products listed on this page may have this approval. Please check our website for latest approvals.
357
