Specification Sheet
Part Number:
SM1BK75MT
Self-Extinguishing Flexiform Grommet, Panel Thickness 0.039"-0.079", PVC, Black, 75m/roll
Article Number
800-00004
Type
SM1
Color
Black (BK)
Features & Benefits
• Fits in holes of all shapes and sizes without the aid of tools or adhesives,
making installation easy. • Easily cut to the right length with scissors, thus
reducing stock and eliminating waste. • Can be used on any type of material
including wood, steel, aluminum, plexiglass and glass, ensuring flexibility of
application.
Quantity Per
reel
Product Description
EdgeGuard is used to cover panel edging to protect cables, prevent chafing
and provide an attractive finish.The EdgeGuard is manufactured from a flexible
PVC compound ensuring ease of use.
Short Description
Self-Extinguishing Flexiform Grommet, Panel Thickness 0.039"-0.079", PVC,
Black, 75m/roll
Global Part Name
SM1-PVC-BK
Length L (Imperial)
246.1
Length L (Metric)
75
Width W (Imperial)
0.1969
Width W (Metric)
5.0
Height H (Imperial)
0.248
Height H (Metric)
6.3
Panel Thickness Min(Imperial)
0.039
Panel Thickness Max(Imperial)
0.079
Panel Thickness Min (Metric)
1.00
Panel Thickness Max (Metric)
2.00
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
UL 94 HB
