Specification Sheet
Part Number:
SEIR-3A-BK
IR Single Element SE Tray with 2 x 3A Insert, Black, 6/pkg
Article Number
857-40487
Type
TRAY-SE-IR-BK-2X3A-06
Color
Black (BK)
Features & Benefits
•
Positive fiber management maintains a minimum bend radius of 30 mm.
•
Trays are supplied in a package of six, with multiple colors available for color
coding of the installation. •
Optional splitter tray accommodates a single optical
splitter up to a maximum of 60 x 7 x 4 mm and up to 6 heat shrink splices
single stacked or 12 heat shrink splices double stacked.
Quantity Per
bag
Product Description
The Integrated Routing (IR) single element tray is manufactured from ABS and
finished to a high specification to eliminate the risk of snagging or macrobends.
All retaining tabs on the tray have radius edges and rounded corners where
fiber may pass. Tray has a splice capacity of up to 24 fibers (double stacked)
with heat shrink protectors up to 60 mm long. The IR single element tray is
suitable for use in the UFC-IR or FDN-IR closures.
Short Description
IR Single Element SE Tray with 2 x 3A Insert, Black, 6/pkg
Global Part Name
TRAY-SE-IR-BK-2X3A-06
Technical Description
The Integrated Routing (IR) single element tray is manufactured from ABS and
finished to a high specification to eliminate the risk of snagging or microbends.
All retaining tabs on the tray have radius edges and rounded corners where
fibre may pass. The overall dimensions of the tray are 148 x 125 x 7mm. The
IR single element tray accepts a wide range of splice protector inserts and the
maximum splice capacity of the tray is based on 24 double stacked heatshrink
(3A) splice protectors up to 60mm long. The IR single element tray can
accommodate 2 x 60 x 7 x 4mm optical splitters when using the optional
splitter/3A or ANT splice bridge. A single optical splitter up to a maximum of 60
x 7 x 4mm can be fitted into the tray in place of a splice bridge. The IR single
element tray is suitable for use in the UFC-IR, FDN-IR or FML-IR closures.
Width W (Imperial)
5.83
Width W (Metric)
148
Height H (Imperial)
4.92
Height H (Metric)
125
Depth D (imperial)
0.28
Depth D (metric)
7
Material
Acrylonitrile Butadiene Styrene (ABS)
Material Shortcut
ABS
