Page 1
Specification Sheet
Part Number:
RT250M0X2
Releasable Cable Tie, Release Tab, 22.3" Long, 250lb Tensile Strength, PA66, Black, 25/pkg
Article Number
131-75610
Type
RT250M
Color
Black (BK)
Features & Benefits
• Special extended-pawl design offers a release feature for quick and easy
access to wire bundles. • Head design provides high tensile strength with very
low insertion force even after repeated use. • Buckle feature on head allows
excess strap to be tucked away after installation.
Quantity Per
bag
Product Description
HellermannTyton heavy-duty releasable cable ties offer a release feature in the
head allowing for easy access to wire bundles when changes are necessary.
The head design guarantees high tensile strength even after repeated use, as
well as a low insertion force. For high volume applications, tensioning tools are
available to ensure consistent and safe installation.
Page 2
Short Description
Releasable Cable Tie, Release Tab, 22.3" Long, 250lb Tensile Strength, PA66,
Black, 25/pkg
Global Part Name
RT250M-PA66-BK
Minimum Tensile Strength (Imperial)
250.0
Minimum Tensile Strength (Metric)
1115.0
Length L (Imperial)
22.3
Length L (Metric)
565.3
Identification Plate Position
none
Releasable Closure
Yes
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.49
Width W (Metric)
12.5
Bundle Diameter Min (Imperial)
0.47
Bundle Diameter Min (Metric)
12.0
Bundle Diameter Max (Imperial)
5.9
Bundle Diameter Max (Metric)
150.0
Page 3
Thickness T (Imperial)
0.0837
Thickness T (Metric)
2.2
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
Bureau Veritas | IEC 60092 series UL | ANSI/UL 62275 UL | ANSI/UL 1565 UL
| ANSI/UL 746B
UL Recognized (US)
Yes
UL Recognized (US and Canada)
Yes
Package Quantity(Imperial)
25
Package Quantity (Metric)
25
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Page 4
Weight (Metric)
13
