Specification Sheet
Part Number:
RB8L4
RB Adhesive Cable Clamp, 0.32" Max. Bundle Dia, PA66, Natural, 200/pkg
Article Number
151-13608
Type
RB8
Color
Natural (NA)
Features & Benefits
•
Simple snap-in design allows for quick and easy installation or removal of
cables. •
Rubber based adhesive allows for a permanent bond to most
surfaces.
Quantity Per
bag
Product Description
The RB Adhesive cable clamps are designed with an easy snap-in feature
allowing simple installation or removal of cables, pipes or hoses. The rubber
based adhesive allows for a permanent bond to most surfaces.
Short Description
RB Adhesive Cable Clamp, 0.32" Max. Bundle Dia, PA66, Natural, 200/pkg
Global Part Name
RB8-PA66-NA
Length L (Imperial)
0.98
Length L (Metric)
25.0
Fixation Method
Pasting / Stick
Variant
Closed
Width W (Imperial)
1.0
Width W (Metric)
25.0
Bundle Diameter Max (Imperial)
0.31
Bundle Diameter Max (Metric)
8.0
Height H (Imperial)
0.45
Height H (Metric)
11.5
Nominal Diameter (Imperial)
5/16
Nominal Diameter (Metric)
8.0
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Adhesive
Synthetic rubber with base of polyethylene foam
Flammability
UL 94 V2 (excluding adhesive)
UV Resistant (Yes/No)
No
Adhesive Operating Temperature
-40°F to +140°F (-40°C to +60°C)
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
200
Package Quantity (Metric)
200
Customs Number
3926909988
Weight (Metric)
2.36
