Specification Sheet
Part Number:
PP110C648
Category 6 Universal 48 Port Patch Panel, 2U, Black, 1/box
Article Number
853-50003
Type
PP110C648
Color
Black (BK)
Features & Benefits
• Write-on labels provided for easy identification. • Clear plastic channel
protects PCB and allows easy viewing of wiring label. • Front face provides an
attractive, flush appearance.
Quantity Per
box
Product Description
The Universal 110 Category 6 range of patch panels offer exceptional
performance and are also available in 1U 24 port, 1U 48 port right angled and
12 port vertical versions. The 2U 48 Port Panel is constructed of 8 modular
units, each offering 6 RJ45 ports allowing for any of the 6 port modules to be
replaced in the case of port damage or failure. The Universal 110 2U 48 Port
Panel is supplied with or with Rack Snap mounting fixings and an optional rear
cable manager is also available. The Universal 110 Category 6 products are
designed to support any data or voice protocol that is capable of running over
a Category 6 cabling system.
Short Description
Category 6 Universal 48 Port Patch Panel, 2U, Black, 1/box
Global Part Name
PP110C648
Technical Description
Category 6 Universal 48 Port Patch Panel, 2U, Black
Port Count
48
Width W (Imperial)
19.0
Width W (Metric)
483.0
Height H (Imperial)
3.6
Height H (Metric)
88.0
Depth D (imperial)
1.14
Depth D (metric)
29.0
UL Listed (US and Canada)
Yes
UL Listed (US
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
