Specification Sheet
Part Number:
MDUS5-BX1QSP
S5 Splice & Patch Enclosure, 216 Fiber Splice, 96 LC adapters and pigtails, Wall Mounted, Gray
Article Number
857-01533
Type
MDU-S5-BXWXCP24M
Color
Gray RAL 7035 (7035)
Features & Benefits
•
High fiber splice capacity to accommodate large MDUs or be used as a
Building Entry Point (BEP). •
UV stable enclosure with IP54 (NEMA 3S) sealing
and IK08 impact rating for long-term outdoor performance. •
Supports cabled,
blown, pushed and pulled fiber deployments to accommodate any construction
style.
Quantity Per
EA
Product Description
The large S5 enclosure is for wall-mount distribution, configured with the
HellermannTyton IR Management System. The management system
accommodates 9x 900µm trays or 18x 250µm trays, for a maximum of 144x
900µm heat shrink splices or 216x 250µm heat shrink splices. The position of
the fiber management system allows easy access for the routing of fiber on to
the trays. The trays and fiber-optic routing modules are white, making it easy
to see the color of the fiber elements as they are routed through the positive
fiber management system. Fiber slot retaining blocks guide the fiber elements
on to the IR system; the foam pad on the retainer is partially cut through to
accommodate a range of fiber counts. Fiber management cassettes are fitted
with LC/APC simplex adapters and pigtails to provide customer connection
points. The LC/APC pigtails are routed on to the fiber management trays to be
spliced to the incoming fiber. A loop storage basket provides space for the
storage of fiber loops. Designed with eight dual input/output ports; four across
the bottom, two on the top and two on each side; each port will accommodate
a 20 or 25 mm cable gland.
Short Description
S5 Splice & Patch Enclosure, 216 Fiber Splice, 96 LC adapters and pigtails,
Wall Mounted, Gray
Global Part Name
MDU-S5-BXWXCP24M
Technical Description
The S5 enclosure is configured with the HellermannTyton250µm IR
Management System. The management system is mounted on an aluminium
backplane which accommodates 12 250µm SE-IR trays giving a maximum of
144 250µm 3A fibre splices. The position of the fibre management system
allows for easy access for the routing of fibre on to the trays. The trays and
fibre optic routing modules are white which makes it easy to see the colour of
the fibre elements as they are routed through the positive fibre management
system. Fibre slot retaining blocks guide the fibre elements on to the IR
system; the foam pad on the retainer is partially cut through to accommodate a
range of fibre counts. All IR system cover plates are coloured blue identifying
them as removable parts allowing access to the fibre, the fibre retaining block
and tray retaining clips are coloured red to aid in identification if they are
dropped. 2 LC Quad adaptor connection plates are fitted with 24 LC PC quad
adaptors to provide 96 customer connection points. A loop storage basket is
fitted for management of excess fibre and is located on left side of the fibre
management trays. The enclosure is 568 x 375 x 165mm (H x W x D) and
manufactured in light grey (RAL 7035), UV stable ABS (Acrylonitrile Butadiene
Styrene) and has an IP54, IK08 and V0 rating. Designed with 8 dual
input/output ports, 4 across the bottom, 2 on the top and 2 on each side, each
port will accommodate a 20 or 25mm cable gland. A 100 x 25mm inset
position on the front cover allows for a customer logo to be moulded in to the
enclosure.
Port Count
8
