Specification Sheet
Part Number:
MDU-S1-1LAP
S1 Enclosure, 10–15 mm, LC-APC Simplex, With Adapters And Pigtails Installed, Gray, 1/pkg
Article Number
857-01518
Type
MDU-S1-01LC08RA1
Color
Gray RAL 7035 (7035)
Features & Benefits
•
Entry port is sealed to maintain the IP55 (NEMA 4) rating for long-term
outdoor performance. •
Internal positive fiber management maintains a
minimum 30 mm bend radius throughout, ensuring reliable data throughput. •
A
cover prevents access to the network cables and splicing area.
Quantity Per
EA
Product Description
The S1 enclosure is designed for wall-mounted distribution, featuring separate
areas for inbound cable, fiber splice management and drop cable (customer
connection) management. The inbound cable management area has a
dedicated cable entry port, supporting both cable end and mid-span
applications with loop storage capacity for up to 1.5 m of excess fiber. The tray
features a crossover facility allowing for alternative routing direction and a fiber
storage capacity of 1.5 m of 250µm fiber and 1.0 m of 900µm fiber. Inside drop
cable management area can accommodate a PLC splitter (60 mm x 7 mm x 4
mm). Adapters are angled and spaced to allow for inspection prior to
connection. Eight anchor guides are provided for securing the drop cables
(maximum diameter 6.0 mm). • 2 Inbound/pass-thru and 8 Drop cables • 8x
SC or LC adapters and internal fiber pigtails for connection to incoming cable
and industry standard pre-terminated drop cables • 24 heat shrink fiber splice
capacity • Separation of inbound fiber from splicing and connectorized drop
cables
Short Description
S1 Enclosure, 10–15 mm, LC-APC Simplex, With Adapters And Pigtails
Installed, Gray, 1/pkg
Global Part Name
MDU-S1-01LC08RA1
Technical Description
A 241 x 154 x 72mm (H x W x D) enclosure manufactured from UV stable light
grey (RAL7035) polycarbonate and has an IP55, IK08 and V0 rating. The
enclosure has 3 separate management areas for inbound cable, fibre splice
management and drop cable (customer connection) management. The inbound
cable management area has a dedicated cable entry port which supports both
cable end and mid-span applications with loop storage capacity for up to 1.5m
of excess fibre and the entry port is sealed with a cable entry kit (cable
diameter 10mm - 15mm) to maintain the IP55 rating. The fibre splice
management area has capacity for a maximum of 12 x 3A splices and
maintains positive fibre management (30mm minimum bend radius) throughout
and is fitted with 8 LC APC pigtails. The tray has a crossover facility which
allows for alternative routing requirements and a fibre storage capacity of 1.5m
of 250µm fibre and 1.0m of 900µm fibre. The drop cable management area is
fitted with 8 LC APC Simplex adaptors for connection to industry standard
pre-terminated drop cables. A PLC splitter (60mm x 7mm x 4mm) can be fitted
on the inside of the management area. The drop cable management area
cover prevents access to the network cables and splicing area and the
adaptors are angled and spaced to allow for inspection prior to connection.
Eight anchor guides are provided for securing the drop cables (maximum
diameter 6.0mm) and an integral seal maintains the IP55 rating.
Port Count
8
Variant
Indoor/Outdoor FTTx Enclosures
