Specification Sheet
Part Number:
MCRFW-RDB
InfoStream Multi-Channel Raceway Raised Device Bracket Fitting, PVC, Office White, 10/pkg
Article Number
250-00025
Type
MCR-RDB
Color
Office White (OEWH)
Features & Benefits
• Raceway and fittings are manufactured from a UL94 V0 rated material to
insure compliance with codes • All fittings have been designed to maintain the
required 1" minimum bend radius to meet TIA/EIA-568-B and 569-A standard •
Raceway and fittings are UL Listed to 600 Volts to meet new UL5A and CSA
22.2 No. 62-93 standards • Patented hinged cover speeds installation time by
allowing installer to partially mount cover prior to laying cables
Quantity Per
bag
Product Description
HellermannTyton’s InfoStream non-metallic raceway system can accommodate
up to four separate channels of electrical, voice, data, video or fiber optic
cabling. The elliptical shape is aesthetically pleasing when compared to other
designs. The raceway’s unique and patented design make installations quicker
and easier.
Short Description
InfoStream Multi-Channel Raceway Raised Device Bracket Fitting, PVC, Office
White, 10/pkg
Global Part Name
MCR-RDB-PVC-WH
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
UL 94 V0
Halogen free
No
Operating Temperature (Metric)
+122°F (+50°C)
Reach Complaint(Article 33)
No
ROHS Complaint
Yes
UL Listed (US and Canada)
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
Customs Number
3925900000
