Specification Sheet
Part Number:
MCRFW-EE
InfoStream Multi-Channel Raceway External Elbow, PVC, Office White, 1/pkg
Article Number
250-00016
Type
MCR-EE
Color
Office White (OEWH)
Features & Benefits
• Raceway and fittings are manufactured from a UL 94V-0 rated material to
insure compliance with codes • All fittings have been designed to maintain the
required 1" minimum bend radius to meet TIA/EIA-568-B and 569-A standards
• Raceway and fittings are U.L. Listed to 600 Volts to meets new UL5A and
CSA 22.2 No. 62-93 standards • Patented hinged cover speeds installation
time by allowing installer to partially mount cover prior to laying cables
Quantity Per
bag
Product Description
HellermannTyton’s InfoStream non-metallic raceway system can accommodate
up to four separate channels of electrical, voice, data, video or fiber optic
cabling. The elliptical shape is aesthetically pleasing when compared to other
designs. The raceway’s unique and patented design make installations quicker
and easier.
Short Description
InfoStream Multi-Channel Raceway External Elbow, PVC, Office White, 1/pkg
Global Part Name
MCR-EE-PVC-WH
Material
Polyvinylchloride (PVC)
Material Shortcut
PVC
Flammability
UL 94 V0
Halogen free
No
Operating Temperature (Metric)
+122°F (+50°C)
Reach Complaint(Article 33)
No
ROHS Complaint
Yes
UL Listed (US and Canada)
Yes
UL Listed (US
Yes
Package Quantity(Imperial)
1
Package Quantity (Metric)
1
Customs Number
3925900000
