Specification Sheet
Part Number:
LTPHC40B-10M
Liquid-Tight Metallic Conduit, Flexible, 1.25" (40mm) Dia, Galvanized Steel w/TPE Cover, Black, 32.8 ft/Reel
Article Number
166-90711
Type
LTPHC40B-10M
Color
Black (BK)
Features & Benefits
• Flexible metallic conduit provides liquid-tight performance to IP66 + IP67 +
IP68 + IP69 when used with LTP or LTPUL fittings. • Helically wound (spiral)
galvanized steel core with an interlocking design delivers high degree of
compression strength and impact resistance. • Smooth thermoplastic TPE-V
rubber protects against corrosion remains flexible at low and high
temperatures. • UV-resistant (black), suitable for outdoor use. • Manufactured
to UL360 requirements. • Halogen free.
Quantity Per
reel
Product Description
A flexible, liquid-tight galvanized steel conduit with a smooth, halogen-free
thermoplastic elastomer coating. LTPHC series is ideal for machinery or
outdoor applications where extreme temperatures exist and liquid-tight
performance is a requirement. Use with HelaGuard LTP or LTPUL Metallic
Fittings for IP66 + IP67 + IP68 + IP69 ratings. May be used in hazardous
locations when accompanied with LTPUL or EXD metallic fittings.
Short Description
Liquid-Tight Metallic Conduit, Flexible, 1.25" (40mm) Dia, Galvanized Steel
w/TPE Cover, Black, 32.8 ft/Reel
Global Part Name
LTPHC40B-10M-GS/TPE-BK
Technical Description
Manufacturer Reference Number: LTPHC40B-10M
Length L (Imperial)
32.8
Length L (Metric)
10.0
Diameter D (imperial)
1.39
Diameter D (metric)
35.4
Outside Diameter OD(Imperial)
1.65
Outside Diameter OD(metric)
41.8
Nominal Diameter (Imperial)
1-1/4
Nominal Diameter (Metric)
40.0
Material
Galvanised Steel (GS) Thermoplastic Elastomer (TPE)
